Advanced-control timer (TIM1)
25.4.19

TIM1 capture/compare register 4 (TIM1_CCR4)

Address offset: 0x40
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 CCR4[15:0]: Capture/Compare value
If channel CC4 is configured as output: CCR4 is the value to be loaded in the actual
capture/compare 4 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2 register
(bit OC4PE). Else the preload value is copied in the active capture/compare 4 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC4 output.
If channel CC4 is configured as input: CCR4 is the counter value transferred by the last
input capture 4 event (IC4). The TIMx_CCR4 register is read-only and cannot be
programmed.
25.4.20

TIM1 break and dead-time register

(TIM1_BDTR)

Address offset: 0x44
Reset value: 0x0000 0000
31 30 29
Res. Res. BK2BID BKBID
rw
15 14 13
MOE AOE BKP BKE
rw rw rw
Note: As the bits BK2BID, BKBID, BK2DSRM, BKDSRM, BK2P, BK2E, BK2F[3:0], BKF[3:0],
AOE, BKP, BKE, OSSI, OSSR and DTG[7:0] can be write-locked depending on the LOCK
configuration, it can be necessary to configure all of them during the first write access to the
TIMx_BDTR register.
Bits 31:30 Reserved, must be kept at reset value.
Bit 29 BK2BID: Break2 bidirectional
Refer to BKBID description
