Digital-to-analog converter (DAC)
19.7.14
DAC sample and hold time register (DAC_SHHR)
Address offset: 0x48
Reset value: 0x0001 0001
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:10 Reserved, must be kept at reset value.
Bits 9:0 THOLD1[9:0]: DAC channel1 hold time (only valid in Sample and hold mode)
Hold time= (THOLD[9:0]) x LSI clock period
Note: This register can be modified only when EN1=0.
Note:
These bits can be written only when the DAC channel is disabled and in Normal operating
mode (when bit EN1=0 and bit CEN1=0 in the DAC_CR register). If EN1=1 or CEN1=1 the
write operation is ignored.
19.7.15
DAC sample and hold refresh time register (DAC_SHRR)
Address offset: 0x4C
Reset value: 0x0001 0001
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:8 Reserved, must be kept at reset value.
Bits 7:0 TREFRESH1[7:0]: DAC channel1 refresh time (only valid in Sample and hold mode)
Refresh time= (TREFRESH[7:0]) x LSI clock period
Note: This register can be modified only when EN1=0.
Note:
These bits can be written only when the DAC channel is disabled and in Normal operating
mode (when bit EN1=0 and bit CEN1=0 in the DAC_CR register). If EN1=1 or CEN1=1 the
write operation is ignored.
