RM0453
Bits 23:22 PUPD11[1:0]: Port Px11 pull configuration
Bits 21:20 PUPD10[1:0]: Port Px10 pull configuration
Bits 19:18 PUPD9[1:0]: Port Px9 pull configuration
Bits 17:16 PUPD8[1:0]: Port Px8 pull configuration
Bits 15:14 PUPD7[1:0]: Port Px7 pull configuration
Bits 13:12 PUPD6[1:0]: Port Px6 pull configuration
Bits 11:10 PUPD5[1:0]: Port Px5 pull configuration
Bits 9:8 PUPD4[1:0]: Port Px4 pull configuration
Bits 7:6 PUPD3[1:0]: Port Px3 pull configuration
Bits 5:4 PUPD2[1:0]: Port Px2 pull configuration
Bits 3:2 PUPD1[1:0]: Port Px1 pull configuration
Bits 1:0 PUPD0[1:0]: Port Px0 pull configuration
10.4.5

GPIOx input data register (GPIOx_IDR) (x = A to B)

Address offset: Block A: 0x0010
Address offset: Block B: 0x0410
Reset value: 0x0000 XXXX
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
ID15 ID14 ID13 ID12
r r r
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 ID[15:0]: Port Px[15:0] input data bit
These bits are written by software to configure the I/O pull-up or pull-down
00: No pull-up, pull-down
01: Pull-up
10: Pull-down
11: Reserved
27 26 25
Res. Res. Res.
11 10 9
ID11 ID10 ID9
r r r r
These bits are read-only. They contain the input value of the corresponding I/O port.
24 23 22
Res. Res. Res. Res.
8 7 6
ID8 ID7 ID6 ID5
r r r
RM0453 Rev 1
General-purpose I/Os (GPIO)
21 20 19 18
Res. Res. Res.
5 4 3 2
ID4 ID3 ID2
r r r r
17 16
Res. Res.
1 0
ID1 ID0
r r
405/1461
