• Register 0xc28 fields are defined as follows:
- 0xc28[31:2] is the timestamp field.
- 0xc28[1:0] is the timestamp flags field. Bit 0 is the tx time-sync packet timestamp valid bit, and bit 1 is the rx time-
sync packet timestamp valid bit.
• Register 0x0510 is the EtherType Matching Value register:
- Bits 23:16 store the Protocol ID value to be matched for the received time-sync packet.
- Bits 15:0 store the EtherType value to be matched for the received time-sync packet.
• Register 0x0514[3:0] specifies the offset of the 8-bit Protocol ID value in the received time-sync packet. Bits 3:0 define
the byte offset of the 8-bit Protocol ID value starting from the end of the EtherType field.
• Register 0x3C14[25:16] specifies the Send Coalesced BD Count for the ISO send ring.
• Register 0x468[26]=1 enables Rx Residential Ethernet support.
Table 9 shows an example of setting up an ISO stream.
pkt.bd Flags (14)
packet rate = every 125 microseconds
1.1 1 0
1.2 0 0
1.3 0 0
2.1 0 0
2.2 0 0
3.1 0 0
3.2 0 0
4.1 0 0
4.2 0 0
5.1 0 1
5.2 0 0
6.1 0 0
6.2 0 0
Document 5722-PG101-R

Table 9: Example of Setting up an ISO Stream

Flags (13) Flags (2) Launch time (15:0)
0 0xFE00
0 0x0000
1 0x0000
0 0xFE80
1 0x0000
0 0xFF00
1 0x0000
0 0xFF80
1 0x0000
0 0x0000
1 0x0000
0 0x0080
1 0x0000
Bro adco m Co rp or atio n
Descriptions
No other ongoing ISO streams
1st BD of the #1 ISO pkt
Flags_init bit is set
2nd BD of the 1st ISO pkt
Last BD of the 1st ISO pkt
1st BD of the #2 ISO pkt
Last BD of the #2 ISO pkt
1st BD of the #3 ISO pkt
Last BD of the #3 ISO pkt
1st BD of the #4 ISO pkt
last BD of the #4 ISO pkt
1st BD of the #5 ISO pkt
Launch time is wrapped
Last BD of the #5 ISO pkt
1st BD of the #6 ISO pkt
Last BD of the #6 ISO pkt
Transmit Data Path
