Table 157: Uncorrectable Error Mask Register (Offset 0X108) - Broadcom BCM5722 Programmer's Manual

BCM5722
U E
NCORRECTABLE
Bit Field
31:21 Reserved
20 Unsupported Request
Error Mask
19 ECRC Error Mask
18 Malformed TLP Mask
17 Receiver Overflow
Mask
16 Unexpected
Completion Mask
15 Completer Abort Mask Setting this bit will mask Completer Abort errors.
14 Completion Timeout
Mask
13 Flow Control Protocol
Error Mask
12 Poisoned TLP Mask
11:5 Reserved
4 Data Link Protocol
Error Mask
3:1 Reserved
0 Training Error Mask
Page 225 PCIe-Enhanced Capabilities
M R
RROR ASK EGISTER

Table 157: Uncorrectable Error Mask Register (Offset 0x108)

Description
–
Setting this bit will mask Unsupported Request errors.
Setting this bit will mask ECRC errors.
Setting this bit will mask Malformed TLP errors.
Setting this bit will mask Receiver Overflow errors.
Setting this bit will mask Unexpected Completion errors.
Setting this bit will mask Completion Timeout errors.
Setting this bit will mask Flow Control Protocol errors.
Setting this bit will mask Poisoned TLP errors.
–
Setting this bit will mask Data Link Protocol errors.
–
Setting this bit will mask Training errors.
Bro adco m C orp or atio n
(O 0 108)
FFSET X
Programmer's Guide
10/15/07
Init Access
0 RO
0 R/W
0 R/W
0 W2C
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 RO
0 R/W
0 RO
0 R/W
Document 5722-PG101-R
