Programmer's Guide
10/15/07
Bit
Field
3
TxMbuf & Misc_BD
BIST Fail
2
TxMbuf & Misc_BD
BIST Done
1
RxMbuf BIST Fail
0
RxMbuf BIST Done
Document
5722-PG101-R
Table 411: BIST Status Register (Offset 0x7404) (Cont.)
Description
Status indicating BIST test has failed.
Status indicating BIST has completed when set (TXMBUF).
Status indicating BIST test has failed.
Status indicating BIST has completed when set (RXMBUF).
Bro adco m Co rp or atio n
BCM5722
Init
Access
1
RO
0
RO
1
RO
0
RO
BIST Registers
Page 380
