Table 45: BCM5787/BCM5787M/BCM5754/BCM5754M Address Map (Cont.)
Region Size
High Priority 512B
Mailbox
Functional 31 KB
Registers
Mailboxes 1 MB
Unmapped 32 KB
RXCPU ROM 1.2 KB
Slave Access
* Indirect access via Memory Window Base Address and Memory Window Data register pair
** Indirect access via Register Window Base Address and Register Window Data register pair
Document 5722-PG101-R
NIC CPU View Host Flat View
– 0x00000200–0x00000
3FF
0xC0000400–0xC0 0x00000400–0x00007
007FFF FFF
0x00100000–0x001FF
FFF
0xC0030000–0xC0 0xC0030000–0xC003
037FFF 7FFF
0xC0038000–0xC0 0xC0038000–**
03B7FF
0xC003B7FF
