Table 223: Send Data Initiator Control Registers—BCM5722, BCM5755, BCM5755M, BCM5756M, BCM5757,
Offset
0x0c00–0x0c03
0x0c04–0x0c07
0x0c08–0x0c0b
0x0c0c–0x0c0f
0x0c10–0x0c13
0x0c14–0x0c7f
0x0c80–0x0c83
0x0c84–0x0cbf
0x0cc0–0x0cc3
0x0cc4–0x0cc7
0x0cc8–0x0ccb
0x0ccc–0x0ccf
0x0cd0–0x0cd3
0x0cd4–0x0cd7
0x0cd8–0x0cdb
0x0cdc–0x0cdf
Offset
0x0c00–0x0c03
0x0c04–0x0c07
0x0c08–0x0c0b
0x0c0c–0x0c0f
0x0c10–0x0c13
0x0c14–0x0c1f
0x0c20–0x0c23
0x0c24–0x0c27
0x0c28–0x0c2B
0x0c2C–0x0c2F
0x0c30–0x0c7F
0x0c80–0x0c83
0x0c84–0x0cdf
Document 5722-PG101-R
C
ONTROL
BCM5754, BCM5787 Only
Registers
Send Data Initiator Mode
Send Data Initiator Status
Send Data Initiator Statistics Control
Send Data Initiator Statistics Enable Mask
Send Data Initiator Statistics Increment Mask
Reserved
Local Statistics Counter—Class of Service 1
Reserved
Local Statistics Counter—DMA Read Queue Full
Local Statistics Counter—DMA High Priority Read Queue Full
Local Statistics Counter—SDC Queue Full
Local Statistics Counter—NIC Ring Set Send Producer Index
Local Statistics Counter—Status Updated
Local Statistics Counter—Interrupts
Local Statistics Counter—Avoided Interrupts
Local Statistics Counter—Send Threshold Hit
Table 224: Send Data Initiator Control Registers—BCM5906 Only
Registers
Send Data Initiator Mode
Send Data Initiator Status
Send Data Initiator Statistics Control
Send Data Initiator Statistics Enable Mask
Send Data Initiator Statistics Increment Mask
Reserved
ISO Packet Transmit Support
Local Network Time Clock
Logged Local Network Time for outbound time sync packet
Reserved
Reserved
Local Statistics Counter—Class of Service 1
Reserved
