INTR Indicator
When LED Status register bit 6 returns a 0, the device is in the interrupted mode. When this bit returns a 1, the device is not
in the interrupted mode.
LINKSPD Indicator
When LED Status register bits 4:3 return a 00, the device is in the 1000BASE-TX link mode. When these bits return a 01,
the device is in the 100BASE-TX link mode. When these bits return a 10, the device is in the 10BASE-T link mode. When
these bits return an 11, the device is not linked.
Transmit Indicator
When LED Status register bit 2 returns a 0, the device is in the transmitting mode. When this bit returns a 1, the device is
not in the transmitting mode.
Receive Indicator
When LED Status register bit 1 returns a 0, the device is in the receiving mode. When this bit returns a 1, the device is not
in the receiving mode.
Quality Indicator
When LED Status register bit 0 returns a 0, the device is in the quality good mode. When this bit returns a 1, the device is
not in the quality good mode.
