Programmer's Guide
10/15/07
G C
ENERAL ONTROL
Table 340: General Control Registers—BCM5722, BCM5755, BCM5755M, BCM5756M, BCM5757, BCM5754,
Field
0x6800–0x6803
0x6804–0x6807
0x6808–0x680b
0x680c–0x680f
0x6810–0x6813
0x6814–0x6817
0x6818–0x681b
0x681c–0x682f
0x6830–0x6837
0x6838–0x683b
0x683c–0x683f
0x6840–0x6843
0x6844–0x6847
0x6848–0x684b
0x684c–0x684f
0x6850–0x68ff
Field
0x6800–0x6803
0x6804–0x6807
0x6808–0x680b
0x680c–0x680f
0x6810–0x6813
0x6814–0x6817
0x6818–0x681b
0x681c–0x682f
0x6830–0x6837
0x6838–0x6843
0x6844–0x6847
0x6848–0x684b
0x684c–0x684f
0x6850–0x688f
0x6890–0x6893
Document 5722-PG101-R
R
EGISTERS
BCM5787 Only
Description
Mode Control Register
Misc Configuration Register
Misc Local Control Register
Timer Register
RX-RISC Event Register
RX-RISC Timer Reference Register
RX-RISC Semaphore Register
Reserved
Memory Power Up Register
Serial EEPROM Address Register
Serial EEPROM Data Register
Serial EEPROM Control Register
MDI Control Register
Serial EEPROM Delay Register
RX CPU Event Enable Register
Reserved
Table 341: General Control Registers—BCM5906 Only
Description
Mode Control Register
Misc Configuration Register
Misc Local Control Register
Timer Register
RX-RISC Event Register
Reserved
RX-RISC Semaphore Register
Reserved
Memory Power Up Register
Reserved
MDI Control Register
Reserved
RX CPU Event Enable Register
Reserved
Misc Control Register
Bro adco m Co rp or atio n
BCM5722
General Control Registers Page 332
