Table 218: Indirection Table Register 15 (Offset: 0X66C); Table 219: Hash Key Register 0 (Offset: 0X670) - Broadcom BCM5722 Programmer's Manual

Programmer's Guide
10/15/07
I T
NDIRECTION ABLE
This register is applicable to BCM5722, BCM5755, BCM5755M, BCM5756M, and BCM5757 devices only.
Bit Field
31:28 table_entry120
27:24 table_entry121
23:20 table_entry122
19:16 table_entry123
15:12 table_entry124
11:8 table_entry125
7:4 table_entry126
3:0 table_entry127
H K R
ASH EY EGISTER
This register is applicable to BCM5722, BCM5755, BCM5755M, BCM5756M, and BCM5757 devices only.
Bit Field
31:24 Hash_key[7:0]
23:16 Hash_key[15:8]
15:8 Hash_key[23:16]
7:0 Hash_key[31:24]
H K R
ASH EY EGISTER
This registers are applicable to BCM5722, BCM5755, BCM5755M, BCM5756M, and BCM5757 devices only.
Document 5722-PG101-R
R 15 (O
EGISTER FFSET

Table 218: Indirection Table Register 15 (Offset: 0x66C)

Description
The RSS_ring value for entry 120. Only the least significant 2 bits are
used. The upper 2 bits are for the future expansion purpose.
The RSS_ring value for entry 121. Only the least significant 2 bits are
used. The upper 2 bits are for the future expansion purpose.
The RSS_ring value for entry 122. Only the least significant 2 bits are
used. The upper 2 bits are for the future expansion purpose.
The RSS_ring value for entry 123. Only the least significant 2 bits are
used. The upper 2 bits are for the future expansion purpose.
The RSS_ring value for entry 124. Only the least significant 2 bits are
used. The upper 2 bits are for the future expansion purpose.
The RSS_ring value for entry 125. Only the least significant 2 bits are
used. The upper 2 bits are for the future expansion purpose.
The RSS_ring value for entry 126. Only the least significant 2 bits are
used. The upper 2 bits are for the future expansion purpose.
The RSS_ring value for entry 127. Only the least significant 2 bits are
used. The upper 2 bits are for the future expansion purpose.
0 (O : 0 670)
FFSET X

Table 219: Hash Key Register 0 (Offset: 0x670)

Description
The first byte of the hash_key. Bit31 is the first bit of the hash_key. It's
the big endian format.
The 2nd byte of the hash_key. The bits are in the big endian format
The 3rd byte of the hash_key. The bits are in the big endian format
The 4th byte of the hash_key. The bits are in the big endian format
1–8 (O : 0 674–0
FFSET X
Bro adco m Co rp or atio n
: 0 66C)
X
693)
X
Ethernet MAC Control Registers
BCM5722
Init Access
0 RW
0 RW
0 RW
0 RW
0 RW
0 RW
0 RW
0 RW
Init Access
0 RW
0 RW
0 RW
0 RW
Page 262
