Table 553: Interrupt Register (Address 26D, 1Ah) - Broadcom BCM5722 Programmer's Manual

Programmer's Guide
10/15/07
Interrupt Register
BIt Name
15 FDX LED Enable
14 INTR Enable
13 Cable Disconnect Mask
12 Reserved
11 FDX Mask
10 SPD Mask
9 LINK Mask
8 INTR Mask
7 Reserve
6 Cable Disconnect Link Change
5 Reserved
4 Global Interrupt Indicator
3 FDX Change
2 SPD Change
1 LINK Change
0 INTR Status
R/W = Read/Write, RO = Read only, SC = Self Clear, LL = Latched Low, LH = Latched High, LL and LH Clear
after read operation. Use default values of reserved bit(s) when writing to reserved bit(s).
DX LED Enable
Setting this bit enables FDX LED Mode. Bit 15 and 14 of this register are mutually exclusive. When FDX LED Mode is
enabled, TRANSMIT LED becomes FULL-DUPLEX LED and RECEIVE LED becomes ACTIVITY LED.
Interrupt Enable
Setting this bit enables Interrupt Mode. The state of this bit also affects which status signals are shifted out on the serial LED
data in serial LED mode.
Cable Disconnect Mask
When this bit is set to 1, the cable disconnect link change does not generate an interrupt.
FDX Mask
When this bit is set, changes in duplex mode does not generate an interrupt.
Document 5722-PG101-R

Table 553: Interrupt Register (Address 26d, 1Ah)

R/W
R/W
R/W
R/W
-
R/W
R/W
R/W
R/W
-
SC
LH
-
SC
LH
SC
LH
SC
LH
SC
LH
SC
LH
Bro adco m Co rp or atio n
Description
Ignore when read
Interrupt enable
Cable disconnect mask
-
Full-duplex interrupt mask
Speed interrupt mask
Link interrupt mask
Master interrupt mask
-
Cable disconnect Indication
-
1= Indicates an interrupt is present within the
PHY
Duplex change interrupt
Speed change interrupt
Link change interrupt
Interrupt status
Transceiver Registers (BCM5906/BCM5906M)
BCM5722
Default
0
0
0
00
1
1
1
1
000
0
0
0
0
0
0
0
Page 500
