Remote Fault
The PHY returns a 1 while its link partner is signaling a far-end fault condition. Otherwise, it returns a 0.
False Carrier Detected
The PHY returns a 1 in bit 5 of the extended status register if a false carrier has been detected since the last time this register
was read. Otherwise, it returns a 0.
Bad ESD Detected
The PHY returns a 1 in bit 4 if an end-of-stream delimiter error has been detected since the last time this register was read.
Otherwise, it returns a 0.
Receive Error Detected
The PHY returns a 1 in bit 3 if a packet was received with an invalid code since the last time this register was read. Otherwise,
it returns a 0.
Transmit Error Detected
The PHY returns a 1 in bit 2 if a packet was received with a transmit error code since the last time this register was read.
Otherwise, it returns a 0.
Lock Error Detected
The PHY returns a 1 in bit 1 if the descrambler has lost lock since the last time this register was read. Otherwise, it returns a 0.
MLT3 Code Error Detected
The PHY returns a 1 in bit 0 if an MLT3 coding error has been detected in the receive data stream since the last time this
register was read. Otherwise, it returns a 0.
100BASE-X Receive Error Counter
Bit Name
15:0 Receive Error Counter [15:0]
Receive Error Counter [15:0]
This counter increments each time the PHY receives a non-collision packet containing at least one receive error. The counter
automatically clears itself when read. When the counter reaches its maximum value, FFh, it stops counting receive errors
until cleared.
Page 495 Transceiver Registers (BCM5906/BCM5906M)

Table 548: 100BASE-X Receive Error Counter (Address 18d, 12h)

R/W Description
R/W Number of non-collision packets with receive errors
since last read
