Table 476: Phy Hardware Diagnostic 2 Register (Offset 0X7E3C) - Broadcom BCM5722 Programmer's Manual

BCM5722
PHY H D
ARDWARE IAGNOSTIC
Bit Field
31:0 LTSSM State Machine
State
Page 413 PCIe Registers
2 R
EGISTER

Table 476: PHY Hardware Diagnostic 2 Register (Offset 0x7E3C)

Description
LTSSM state machine states:
• 31:28 = Main State.
• 27:26 = Detect substate.
• 25:23 = Polling substate.
• 22:20 = Configuration substate.
• 19:18 = Recover substate.
• 17:16 = RX L0s substate.
• 15:14 = TX L0s substate.
• 13:12 = L1 substate.
• 11:10 = L2 substate.
• 9:8 = Disable substate.
• 7:6 = Loopback substate.
• 5:4 = Reset substate.
• 3:0 = Reserved.
Bro adco m C orp or atio n
(O 0 7E3C)
FFSET X
Programmer's Guide
10/15/07
Init Access
0 RO
Document 5722-PG101-R
