Programmer's Guide
10/15/07
L -P
OW RIORITY
These 64-bit registers are called low-priority mailbox registers (or low-priority mailboxes). When a value is written to the least
significant 32 bits of these registers, an event (known as a Mailbox Event) is generated to the RX RISC. Only lower 32 bits
of these 64-bit low-priority mailbox registers are implemented.
Table 328: Low-Priority Mailbox Registers—BCM5722, BCM5755, BCM5755M, BCM5756M, BCM5757, BCM5754,
Offset
0x5800–0x5807
0x5808–0x5867
0x5868–0x586F
0x5870–0x587F
0x5880–0x5487
0x5888–0x588F
0x5890–0x5897
0x5898–0x589F
0x58a0–0x58FF
0x5900–0x5907
0x5908–0x590F
0x5910–0x597F
0x5980–0x5987
0x5988–0x59FF
Offset
0x5800–0x5807
0x5808–0x5867
0x5868–0x586F
0x5870–0x587F
0x5880–0x5887
0x5888–0x58FF
0x5900–0x5907
0x5908–0x590F
0x5910–0x597F
0x5980–0x5987
0x5988–0x59FF
Document 5722-PG101-R
M
AILBOXES
Registers
Interrupt Mailbox 0
Reserved
Receive BD Standard Producer Ring Producer Index
Reserved
Receive BD Return Ring 1 Consumer Index
Receive BD Return Ring 2 Consumer Index
Receive BD Return Ring 3 Consumer Index
Receive BD Return Ring 4 Consumer Index
Reserved
Send BD Ring Host Producer Index
Reserved
Reserved
Send BD Ring NIC Producer Index
Reserved
Table 329: Low-Priority Mailbox Registers—BCM5906 Only
Registers
Interrupt Mailbox 0
Reserved
Receive BD Standard Producer Ring Producer Index
Reserved
Receive BD Return Ring 1 Consumer Index
Reserved
Data Send BD Ring Host Producer Index
ISO Send BD Ring Host Producer Index
Reserved
Send BD Ring NIC Producer Index
Reserved
Bro adco m Co rp or atio n
BCM5787 Only
BCM5722

Low-Priority Mailboxes

Page 324
