BCM5722
H K R
ASH EY EGISTER
This register is applicable to BCM5722, BCM5755, BCM5755M, BCM5756M, and BCM5757 devices only.
Bit Field
31:24 Hash_key[295:288]
23:16 Hash_key[303:296]
15:8 Hash_key[311:304]
7:0 Hash_key[319:312]
R MAC P
ECEIVE ROGRAMMABLE
This register is applicable to BCM5722, BCM5755, BCM5755M, BCM5756M, and BCM5757 devices only.

Table 221: Receive MAC Programmable IPv6 Extension Header Register (0x6A0)

Bit Field
31 Programmable Extension
Header Type #2 Enable
30 Programmable Extension
Header Type #1 Enable
29:16 Reserved
15:8 Programmable Extension
Header Type #2
7:0 Programmable Extension
Header Type #1
Page 263 Ethernet MAC Control Registers
9 (O : 0 694)
FFSET X

Table 220: Hash Key Register 9 (Offset: 0x694)

Description
The thirty-seventh byte of the hash_key. The bits are in the big
endian format
The thirty-eighth byte of the hash_key. The bits are in the big endian
format
The thirty-ninth byte of the hash_key. The bits are in the big endian
format
The fortieth byte of the hash_key. The bits are in the big endian
format
IP 6 E
V XTENSION
Description
This bit enables programmable extension header #2. If this bit
is clear, then the value programmed in bits [15:8] of this register
will be ignored. If this bit is set, then extension headers will be
checked for a type matching the value in bits [15:8]. This bit
should be set to 0 if IPv6 RX is disabled.
This bit enables programmable extension header #1. If this bit
is clear, then the value programmed in bits [7:0] of this register
will be ignored. If this bit is set, then extension headers will be
checked for a type matching the value in bits [7:0]. This bit
should be set to 0 if IPv6 RX is disabled.
Reserved bits
These bits contain the programmable extension header value
for programmable header #2.
These bits contain the programmable extension header value
for programmable header #1.
Bro adco m C orp or atio n
Programmer's Guide
H R (0
EADER EGISTER
10/15/07
Init Access
0 RW
0 RW
0 RW
0 RW
6A0)
X
Init Access
0 R/W
0 R/W
0 RO
0 R/W
0 R/W
Document 5722-PG101-R
