BCM5722
PCI
R
E
EGISTERS
Address
TLP Diagnostic Registers (these are Transaction Layer Protocol Hardware Debug Registers)—
BCM5722, BCM5755, BCM5755M, BCM5756M, BCM5757, BCM5754, BCM5754M, BCM5787, BCM5787M only
0x7C00
0x7C04
0x7C08
0x7C0C
0x7C10
0x7C14
0x7C18
0x7C1C
0x7C20
0x7C24
0x7C28
0x7C2C
0x7C30
0x7C34
0x7C38
0x7C3C
0x7C40
0x7C44
0x7C48
0x7C4C
0x7C50
0x7C54
0x7C58
0x7C5C
0x7C60
0x7C64
0x7C68
0x7C6C
0x7C70
0x7C74
0x7C78
0x7C7C
0x7C80
0x7C84–0x7CFF
Page 381
PCIe Registers

Table 412: PCIe Registers

Description
TLP Control register
TLP Workaround Register
Reserved
Reserved
Write DMA Request Upper Address Diagnostic register
Write DMA Request Lower Address Diagnostic register
Write DMA Length/Byte Enable and Request Diagnostic register
Read DMA Request Upper Address Diagnostic register
Read DMA Request Lower Address Diagnostic register
Read DMA Length and Request Diagnostic register
MSI DMA Request Upper Address Diagnostic register
MSI DMA Request Lower Address Diagnostic register
MSI DMA Length and Request Diagnostic register
Slave Request Length and Type Diagnostic register
Flow Control Inputs Diagnostic register
XMT State Machines and Gated Requests Diagnostic register
Address ACK Xfer Count and ARB Length Diagnostic register
DMA Completion Header Diagnostic register 0
DMA Completion Header Diagnostic register 1
DMA Completion Header Diagnostic register 2
DMA Completion Misc. Diagnostic register
DMA Completion Misc. Diagnostic register
DMA Completion Misc. Diagnostic register
Split Controller Requested Length and Address ACK Remaining Diagnostic register
Split Controller Misc 0 Register Diagnostic register
Split Controller Misc 1 Register Diagnostic register
TLP Register BusNo, DevNo, FuncNo Register
TLP Debug Register
Retry Buffer Free Register
Target Debug Register 1
Target Debug Register 2
Target Debug Register 3
Target Debug Register 4
Reserved
Bro adco m C orp or atio n
Programmer's Guide
10/15/07
Document 5722-PG101-R
