BCM5722
R B P
ETRY UFFER URGED

Table 452: Retry Buffer Purged Pointer Debug Register (Offset 0x7D34)

Bit Field
31:11 Reserved
10:0 Retry Buffer Purged
Pointer
R B R
ETRY UFFER EAD
Bit Field
31:0 Retry Buffer Data
E C T
RROR OUNT HRESHOLD
Bit Field
31:15 Reserved
14:12 Bad Sequence Number
Count Threshold
11:8 NAK Received Count
Threshold
7:4 DLLP Error Count
Threshold
3:0 TLP Error Count
Threshold
TLP E C
RROR OUNTER
Bit Field
31:24 Reserved
23:16 TLP Bad Sequence
Number Counter
15:0 TLP Error Counter
Page 401 PCIe Registers
P D
OINTER EBUG
Description
Write as 0, ignore when read.
Starting address of next TLP to be purged from retry
buffer RAM.
/W D P
RITE EBUG ORT

Table 453: Retry Buffer Read/Write Debug Port (Offset 0x7D38)

Description
Data written to this address is written into the retry buffer
RAM at the retry buffer write address. Reads to this
address will return the data stored at the retry buffer read
address in the retry buffer RAM.
R (O
EGISTER

Table 454: Error Count Threshold Register (Offset 0x7D3C)

Description
Write as 0, ignore when read.
Attention bits are set when error count reaches threshold.
Threshold = 2^n.
Attention bits are set when error count reaches threshold.
Threshold = 2^n.
Attention bits are set when error count reaches threshold.
Threshold = 2^n.
Attention bits are set when error count reaches threshold.
Threshold = 2^n.
R (O
EGISTER FFSET

Table 455: TLP Error Counter Register (Offset 0x7D40)

Description
Write as 0, ignore when read.
Counts number of TLPs with bad sequence number
received since last read. Counter freezes at max value
and will be cleared to one if event occurs simultaneously
to read.
Counts number of bad TLPs received (includes bad
LCRC, bad length or bad sequence number) since last
read. Counter freezes at max value and will be cleared to
one if event occurs simultaneously to read.
Bro adco m C orp or atio n
R (O
EGISTER FFSET
(O 0 7D38)
FFSET X
0 7D3C)
FFSET X
0 7D40)
X
Programmer's Guide
0 7D34)
X
Init
0
0
Init
–
Init
0
0x7
0xF
0xF
0xF
Init
0
0
0
Document 5722-PG101-R
10/15/07
Access
RO
R/W
Access
R/W
Access
RO
R/W
R/W
R/W
R/W
Access
RO
RO/CR
RO/CR
