Programmer's Guide
10/15/07
PHY T P
IMING ARAMETER

Table 474: PHY Timing Parameter Override Register (Offset 0x7E34)

Bit Field
31 ts1NumOverride
30 txIdleMinOverride
29 txIdle2IdleOverride
28 Reserved
27:16 N_TS1InPollingActive
15:8 txIdleMinTime
7:0 txIdleSettoIdleTime
PHY H D
ARDWARE
Bit Field
31:10 Reserved
9:4 Transmit State
Machine State
3:0 Receive State Machine
State
Document 5722-PG101-R
O R
VERRIDE EGISTER
Description
Set to override the TS1 number to be sen out in polling active state
with the value in bit (27:16) of this register from the specification
defined value.
Set to override the min time for a transmitter to stay with the value in
bit (15:8) of this register from the specification defined value.
Set to override the Max time for electrical idle transition with the value
in bit (7:0) of this register from the specification defined value.
–
TS1 number needed to be sent in Polling active state.
Minimum time (in symbol time) a transmitter must be in electrical idle. 0x5
Maximum time (in symbol time) to transition to a valid electrical idle
after sending an electrical idle ordered-set.
1 R
IAGNOSTIC EGISTER

Table 475: PHY Hardware Diagnostic 1 Register (Offset 0x7E38)

Description
–
Transmit state machine states:
• 9:8 = TX Data State
• 7:4 = TX Main State
Receive state machine states 3:0 = RX Main State
Bro adco m Co rp or atio n
(O 0 7E34)
FFSET X
(O 0 7E38)
FFSET X
BCM5722
Init Access
0 R/W
0 R/W
0 R/W
0 RO
0x400 R/W
R/W
0x2 R/W
Init Access
0 RO
0 RO
0 RO
PCIe Registers Page 412
