Table 492: Receive Error Counter (Phy_Addr = 0X1, Reg_Addr = 12H); Table 493: False Carrier Sense Counter (Phy_Addr = 0X1, Reg_Addr = 13H) - Broadcom BCM5722 Programmer's Manual

Programmer's Guide
10/15/07
R E C
ECEIVE RROR OUNTER
This counter increments each time the BCM5722 Ethernet controller receives a non-collision packet containing at least one
receive error (freezes at the maximum value FFFFh). The counter automatically clears when read.

Table 492: Receive Error Counter (PHY_Addr = 0x1, Reg_Addr = 12h)

Bit Field
15:0 Receive Error Counter Number of non-collision packets with receive errors since
F C S
ALSE ARRIER ENSE
S3MII Error Counter increments each time the BCM5722 Ethernet controller detects a S3MII overrun/underrun event. False
Carrier Sense Counter increments each time the BCM5722 Ethernet controller detects a false carrier on the receive input.
These counters freeze at the maximum value FFh. The counters automatically clear when read.

Table 493: False Carrier Sense Counter (PHY_Addr = 0x1, Reg_Addr = 13h)

Bit Field
15:8 Reserved
7:0 False Carrier Sense
Counter
Document 5722-PG101-R
(PHY_A = 0
DDR
Description
last read.
C (PHY_A
OUNTER DDR
Description
–
Number of false carrier sense events since last read.
Bro adco m Co rp or atio n
1, R _A = 12
X EG DDR
= 0 1, R _A
X EG DDR
BCM5722
)
H
Init Access
0000h R/W
= 13 )
H
Init Access
00h R/W
Transceiver Registers Page 432
