Table 185: Pcie 1.1 Advisory Non-Fatal Error Masking (Offset: 0X18C) - Broadcom BCM5722 Programmer's Manual

BCM5722
PCI 1.1 A
E DVISORY

Table 185: PCIe 1.1 Advisory Non-Fatal Error Masking (Offset: 0x18C)

Bit Field
31:6 Reserved
5 Retry Poison
4 Poison Advisory Non-Fatal
Enable
3 Unexpected Advisory Non-
Fatal Enable
2 Non-Posted Cfg Advisory Non-
Fatal Enable
1 NP Memory Read Advisory
Non-Fatal Enable
0 Completion Abort Memory
Read Advisory Non-Fatal
Enable
Page 237 PCIe-Enhanced Capabilities
N -F E
ON ATAL RROR
Description
–
Enable DMA Read Engine to retry poison
completion packet
• 1 = Enable
• 0 = Disable
Enable Poison Error to be classified as
Advisory Non-Fatal Correctable Error
• 1 = Enable
• 0 = Disable
Enable Unexpected Completion Error to be
classified as Advisory Non-Fatal Correctable
Error
• 1 = Enable
• 0 = Disable
Enable UR/CA error as a result of Non-Posted
Configuration Access to be classified as
Advisory Non-Fatal Correctable Error
• 1 = Enable
• 0 = Disable
Enable UR/CA error as a result of Non-Posted
Memory Read Access to be classified as
Advisory Non-Fatal Correctable Error
• 1 = Enable
• 0 = Disable
Enable CA error as a result of Memory Read
Access to be classified as Advisory Non-Fatal
Correctable Error
• 1 = Enable
• 0 = Disable
Bro adco m C orp or atio n
M (O : 0
ASKING FFSET
Programmer's Guide
18C)
X
Init Reset
0
0x1 PCI_Reset
0x1 PCI_Reset
0x1 PCI_Reset
0x1 PCI_Reset
0x1 PCI_Reset
0x1 PCI_Reset
Document 5722-PG101-R
10/15/07
Access
RO
FW-RW
Host-RO
FW-RW
Host-RO
FW-RW
Host-RO
FW-RW
Host-RO
FW-RW
Host-RO
FW-RW
Host-RO
