Nic Diagnostic Send Bd Consumer Index Register (Offset 0X3Cc0-0X3Cc3); Table 289: Nic Send Bd Consumer Index (Offset 0X3Cc0)-Bcm5722, Bcm5755, Bcm5755M, Bcm5756M, Bcm5757, Bcm5754, Bcm5787 Only; Table 290: Nic Send Bd Consumer Index (Offset 0X3Cc0)-Bcm5906 Only - Broadcom BCM5722 Programmer's Manual

Programmer's Guide
10/15/07
NIC D S
IAGNOSTIC END
This register keeps track of the NIC local copy of the send BD ring consumer index (not the host copy which is DMAed by
the Host Coalescing engine to the host). This is shared between the Send BD Initiator and the Host Coalescing state
machines.
Note: The programmer should not write to this register—it is for internal use only to aid with debugging and
diagnostics.
Table 289: NIC Send BD Consumer Index (Offset 0x3CC0)—BCM5722, BCM5755, BCM5755M, BCM5756M,
Bit Field
31:16 Reserved
15:0 NIC Send BD
Consumer Index
Table 290: NIC Send BD Consumer Index (Offset 0x3CC0)—BCM5906 Only
Bit Field
31:25 Reserved
24:16 NIC Send ISO BD
Consumer Index
15:9 Reserved
8:0 NIC Send data BD
Consumer Index
Document 5722-PG101-R
BD C I
ONSUMER NDEX
BCM5757, BCM5754, BCM5787 Only
Description
–
NIC Send BD Consumer Index
Description
–
NIC Send ISO BD Consumer Index
–
NIC Send data BD Consumer Index
Bro adco m Co rp or atio n
R (O
EGISTER FFSET
Host Coalescing Control Registers
BCM5722
0 3CC0–0 3CC3)
X X
Init Access
0 RO
R/W
Init Access
0 R/O
0 R/W
0 R/O
0 R/W
Page 300
