There are two basic formats for storing data in memory—little-endian and big-endian. The endianess of a system is
determined by how multibyte quantities are stored in memory. A big-endian architecture stores the most significant byte at
the lowest address offset while little-endian architecture stores the least significant byte at the lowest address offset.
For example, the 32-bit hex value 0x12345678 would be stored in memory as shown in the following table.
Address 00
Big Endian 12
Little Endian 78
Another way of viewing how this data would be stored is shown in the following tables.
Storage Byte 00
Data Contents 12
Storage Byte 03
Data Contents 12
Examples of big-endian platforms include SGI Irix, IBM RS6000, and SUN.
Examples of little-endian platforms include Intel x86 and DEC Alpha.
PCI assumes a little-endian memory model. PCI configuration registers are organized so that the least significant portion of
the data is assigned to the lower address.
