Table 183: Firmware Power Budgeting Register 7 (Offset 0X188); Table 184: Firmware Power Budgeting Register 8 (Offset 0X18A) - Broadcom BCM5722 Programmer's Manual

Programmer's Guide
10/15/07
F P
IRMWARE OWER
Bit Field
15:13 Power Rail
12:10 Type
9:8 PM State
7:0 Base Power
F P
IRMWARE OWER
Bit Field
15:13 Power Rail
12:10 Type
9:8 PM State
7:0 Base Power
Document 5722-PG101-R
B R
UDGETING EGISTER

Table 183: Firmware Power Budgeting Register 7 (Offset 0x188)

Description
Specifies the power rail of the operating condition
12V (000)
3.3V (001)
1.8V (010)
Thermal (111)
Specifies the type of the operating condition
PME Aux (000)
Auxiliary (001)
Idle (010)
Sustained (010)
Maximum (111)
Specifies the power management state of operating
condition—D0, D3
Specifies in Watts the base power value in a given
operating conditions
B R
UDGETING EGISTER

Table 184: Firmware Power Budgeting Register 8 (Offset 0x18A)

Description
Specifies the power rail of the operating condition
12V (000)
3.3V (001)
1.8V (010)
Thermal (111)
Specifies the type of the operating condition
PME Aux (000)
Auxiliary (001)
Idle (010)
Sustained (010)
Maximum (111)
Specifies the power management state of operating
condition—D0, D3
Specifies in Watts the base power value in a given
operating conditions
Bro adco m Co rp or atio n
7 (O 0 188)
FFSET X
8 (O 0 18A)
FFSET X
BCM5722
Init Access
0x0 RW from Internal CPU
Config RO
Memory RW
0x0 RW from Internal CPU
Config RO
Memory RW
0x0 RW from Internal CPU
Config RO
Memory RW
0x0 RW from Internal CPU
Config RO
Memory RW
Init Access
0x0 RW from Internal CPU
Config RO
Memory RW
0x0 RW from Internal CPU
Config RO
Memory RW
0x0 RW from Internal CPU
Config RO
Memory RW
0x0 RW from Internal CPU
Config RO
Memory RW
PCIe-Enhanced Capabilities Page 236
