Table 192: Ethernet Mac Event Enable Register (Offset 0X408); Table 193: Led Control Register (Offset 0X40C) - Broadcom BCM5722 Programmer's Manual

BCM5722
E MAC E
THERNET VENT
Bit Field
31:29 Reserved
28 Interesting Packet PME
Attention Enable
27 TX Statistics Overrun
26 RX Statistics Overrun
25 ODI Error
24 AP Error
23 MI Interrupt
22 MI Completion
21:13 Reserved
12 Link State Changed
11:0 Reserved
LED C R
ONTROL EGISTER
Bit Field
31 Override Blink Rate
30:19 Blink Period
18:16 Reserved
15 Wireless Combo Mode
Reserved (BCM5906 only)
14 Shared Traffic/Link LED Mode When this bit is set, the Link LED is solid green when there is a
Reserved (BCM5906 only)
13 MAC Mode (See Note 1
below)
Reserved (BCM5906 only)
Page 247 Ethernet MAC Control Registers
E R
NABLE EGISTER

Table 192: Ethernet MAC Event Enable Register (Offset 0x408)

Description
Always 0.
When this bit is set, an attention will be asserted on an interesting packet
match.
Enable attention when transmit statistics block has overrun.
Enable attention when receive statistics block has overrun.
Enable attention when an Output Data Interface block has an overrun or
underrun.
Enable attention when the Auto-polling interface has an error.
Enable attention when the Management Interface is signaling an
interrupt.
Enable attention when the Management Interface transaction has
completed.
–
Enable attention when the link has changed state.
–
(O 0 40C)
FFSET X

Table 193: LED Control Register (Offset 0x40C)

Description
If set, the blink rate for the Traffic LED is determined by the Blink
Period field (bit 30 to bit 9). This bit is reset to 1. If not set, the
blink rate assumes a Blink Period of 0x040, corresponding to
approximately 15.9 Hz.
Specifies the period of each blink cycle (on + off) for Traffic LED
in milliseconds. Must be a nonzero value.
For the BCM5906 only, this12-bit field is reset to 0x019, giving a
default blink period of approximately 15.9 Hz.
For all other devices, this is reset to 0x040, giving a default blink
period of approximately 15.9 Hz.
–
When this bit is set, the LED pins can be shared with a wireless
device which takes over when the link is lost.
–
link and blinks when there is traffic. (The LED_MODE field must
be set to 00 before enabling this bit.)
–
When this bit is set, the traffic LED blinks only when traffic is
addressed for the device. (The LED_MODE field must be set to
00 before enabling this bit.)
–
Bro adco m C orp or atio n
(O 0 408)
FFSET X
Programmer's Guide
10/15/07
Init Access
0 RO
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 RO
0 R/W
0 RO
Init Access
1 R/W
000000 R/W
011001
000001 R/W
000000
0 RO
0 R/W
0 RO
1 R/W
0 RO
0 R/W
0 RO
Document 5722-PG101-R
