Pattern Data Structure
The maximum number of entries in either 10/100 or 1000 mode is 128. The BCM5722 Ethernet controller cannot process a
pattern that requires more than 128 entries. The size of an entry will vary based on 10/100 or 1000 Mbps mode. Additionally,
all unused rows must be initialized with zeros. The WOL hardware cannot process an entry unless unused rows and rules
have been zeroed out (see

Figure 63: Unused Rows and Rules Must Be Initialized with Zeros

Frame patterns are stored as data structures in memory. A control word is always present in a 64 bit entry/row. The control
word describes proceeding data fields in the entry.
In 10/100 Mbps mode, one WOL entry requires three 64-bit wide rows (see
bits. Each 64-bit row contains a 16-bit control word, which identifies byte enables (see
contains 2-byte rules. The 2-byte rules are distributed across three streams: S, S+1, and S+2. The next row's 2-byte rules
will correspond to three more streams: S+3, S+4, and S+5. Both
comparison streams. The D0 notation indicates the first 2 bytes in the packet stream are compared.
