Table 468: Phy Attention Mask Register (Offset 0X7E1C); Table 469: Phy Receive Error Counter (Offset 0X7E20); Table 470: Phy Receive Framing Error Counter (Offset 0X7E24) - Broadcom BCM5722 Programmer's Manual

Programmer's Guide
10/15/07
PHY A M
TTENTION ASK
Bit Field
31:8 Reserved
7 Hot reset mask
6 Link down mask
5 Training error mask
4 Buffer overrun mask
3 Buffer underrun mask
2 Receive frame error
mask
1 Receive disparity error
mask
0 Receive code error
mask
PHY R E
ECEIVE RROR
Bit Field
31:16 Disparity error count
15:0 Code error count
PHY R F
ECEIVE RAMING
Bit Field
31:16 Reserved
15:0 Framing error count
Document 5722-PG101-R
R (O
EGISTER FFSET

Table 468: PHY Attention Mask Register (Offset 0x7E1C)

Description
–
Hot reset event mask bit.
Link down event mask bit.
LTSSM training error mask bit.
Receive elastic buffer overrun mask bit.
Receive elastic buffer underrun mask bit.
Receive frame error mask bit.
Receive 8b/10b running disparity error mask bit.
Receive 8b/10b code error mask bit.
C (O
OUNTER FFSET

Table 469: PHY Receive Error Counter (Offset 0x7E20)

Description
Receive 8b/10b running disparity error count.
Receive 8b/10b coding error count.
E C
RROR OUNTER

Table 470: PHY Receive Framing Error Counter (Offset 0x7E24)

Description
–
Receive framing error count.
Bro adco m Co rp or atio n
0 7E1C)
X
0 7E20)
X
(O 0 7E24)
FFSET X
BCM5722
Init Access
0 RO
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
Init Access
0 R/W
0 R/W
Init Access
0 RO
0 RO
PCIe Registers Page 408
