BCM5722
N -V
ON OLATILE
Address
0x7000
0x7004
0x7008
0x700c
0x7010
0x7014
0x7018
0x701c
0x7020
0x7024
0x7028
0x702c
0x7030
0x7034
0x7038
0x703c–0x73ff
Page 369 Non-Volatile Memory Interface Registers
M I
EMORY NTERFACE

Table 394: Non-Volatile Memory Interface Registers

Description
NVM Command Register
NVM Status Register
NVM Write Register
NVM Address Register
NVM Read Register
NVM Config 1 Register
NVM Config 2 Register
NVM Config 3 Register
Software Arbitration Register
NVM Access Register
NVM Write1 Register
NVM Arbitration Watchdog Timer Register
NVM Config4 Register
Reserved
NVM Auto Sense Status Register
Reserved
Bro adco m C orp or atio n
R
EGISTERS
Programmer's Guide
10/15/07
Document 5722-PG101-R
