Programmable LED I/O Control
Setting LED GPIO Control/Status register bits [3:0] set the LED pin to disable LED output. Clearing LED GPIO Control/Status
register bits [3:0] set the LED pin to enable LED output.
A SGMII/M
UTODETECT
11000 )
B

Table 526: Autodetect SGMII/Media Converter Register (Address 1Ch, Shadow Value 11000)

Bit Field
15 Write Enable
14:10 Shadow Register
Selector
9 SerDes Resolution
Fault
8:1 Reserved
0 SGMII/Media Converter
Autodetect Mode
Enable
Write Enable
During a write to this register, setting Autodetect SGMII/Media Converter register bit 15 allows writing to bits [9:0] of this
register. For reading the values of bits [9:0], perform an MDIO write with bit 15 cleared and preferred shadow values in bits
[14:10]. The next MDIO read of register address 1Ch contains the preferred Shadow register values in bits [9:0].
Shadow Register Selector
Register bits [14:10] of this register must be set to 11000 to enable read/write to the Autodetect SGMII/Media Converter
address 1Ch.
SerDes Resolution Fault
Bit 9 of the Auto-Detect SGMII/Media Converter register indicates there is a selected field mismatch on bit 0 of the base page
word. Otherwise, it reads a 0.
SGMII/Media Converter Autodetect Mode Enable
Setting Bit 0 of the Auto-Detect SGMII/Media Converter register enable the SGMII/media converter autodetect mode.
Otherwise, it is in the normal mode.
Page 467 Transceiver Registers
C (PHY_A
EDIA ONVERTER
Description
• 1 = Write bits [9:0].
• 0 = Read bits [9:0].
11000 = Autodetect SGMII/Media Converter register.
• 1 = Selected field mismatch.
• 0 = No mismatch or SGMII/media converter autodetect
mode is disabled.
Write as 00h, ignore when read.
• 1 = Enable SGMII/media converter autodetect mode.
• 0 = Normal operation.
Bro adco m C orp or atio n
Programmer's Guide
= 0 1, R _A
DDR X EG DDR
10/15/07
= 1C , S
H HADOW
Init Access
0 R/W
11000 R/W
0 RO
00h RO
INTF_SEL[3] R/W
AND RXCDLY
