RM0453
38.7.1
CTI registers
The register file base addresses are 0xE0043000 for CPU1 CTI and 0xF0001000 for CPU2
CTI (not an issue as the CTIs are accessed via different access ports). The registers are the
same for each CTI.
CTI control register (CTI_CONTROLR)
Address offset: 0x000
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:1 Reserved, must be kept at reset value.
Bit 0 GLBEN: global enable
0: Cross-triggering disabled
1: Cross-triggering enabled
CTI trigger acknowledge register (CTI_INTACKR)
Address offset: 0x010
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 INTACK[7:0]: trigger acknowledge
There is one bit of the register for each CTITRIGOUT output. When a 1 is written to a bit in
this register, the corresponding CTITRIGOUT output is acknowledged, causing it to be
cleared.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
27
26
25
Res.
Res.
Res.
11
10
9
Res.
Res.
Res.
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
24
23
22
Res.
Res.
Res.
Res.
8
7
6
Res.
rw
rw
RM0453 Rev 5
Debug support (DBG)
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
Res.
Res.
Res.
Res.
21
20
19
18
Res.
Res.
Res.
5
4
3
2
INTACK[7:0]
rw
rw
rw
rw
17
16
Res.
Res.
1
0
Res.
GLBEN
rw
17
16
Res.
Res.
1
0
rw
rw
1355/1450
1435
