ITM CoreSight peripheral identity register 1 (ITM_PIDR1)
Address offset: 0xFE4
Reset value: 0x0000 00B0
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 JEP106ID[3:0]: JEP106 identity code bits [3:0]
0xB: Arm
Bits 3:0 PARTNUM[11:8]: part number bits [11:8]
0x0: ITM part number
38.10.8
ITM CoreSight peripheral identity register 2 (ITM_PIDR2)
Address offset: 0xFE8
Reset value: 0x0000 003B
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 REVISION[3:0]: component revision number
0x3: r0p4
Bit 3 JEDEC: JEDEC assigned value
0x1: Designer ID specified by JEDEC
Bits 2:0 JEP106ID[6:4]: JEP106 identity code bits [6:4]
0x3: Arm
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
Res.
Res.
Res.
Res.
®
JEDEC code
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
Res.
Res.
Res.
Res.
®
JEDEC code
RM0453 Rev 5
23
22
21
20
Res.
Res.
Res.
Res.
7
6
5
4
JEP106ID[3:0]
r
r
r
r
23
22
21
20
Res.
Res.
Res.
Res.
7
6
5
4
REVISION[3:0]
r
r
r
r
Debug support (DBG)
19
18
17
Res.
Res.
Res.
Res.
3
2
1
PARTNUM[11:8]
r
r
r
19
18
17
Res.
Res.
Res.
Res.
3
2
1
JEDEC
JEP106ID[6:4]
r
r
r
1391/1450
16
0
r
16
0
r
1435
