Figure 359. Master Full-Duplex Communication With Crc - STMicroelectronics STM32WL5 Series Reference Manual

RM0453
NSS
SCK
BSY
MOSI
SPE
TXE
FTLVL
00
MISO
RXNE
DMA or software control at Rx events
FRLVL
DMA Tx TICF
Assumptions for master full-duplex communication with CRC example:
•
Data size = 16 bit
• CRC enabled
If DMA is used:
•
Number of Tx frames transacted by DMA is set to 2
•
Number of Rx frames transacted by DMA is set to 3
See also
and notes.
Serial peripheral interface / integrated interchip sound (SPI/I2S)

Figure 359. Master full-duplex communication with CRC
