Figure 381. Start Sequence In Master Mode - STMicroelectronics STM32WL5 Series Reference Manual

Serial peripheral interface / integrated interchip sound (SPI/I2S)
WS (O)
CK (O),
CKPOL = 0
CK (O),
CKPOL = 1
SD (O)
I2SE
WS (O)
CK (O),
CKPOL = 0
CK (O),
CKPOL = 1
SD (O)
I2SE
WS (O)
CK (O),
CKPOL = 0
CK (O),
CKPOL = 1
SD (O)
I2SE
WS (O)
CK (O),
CKPOL = 0
CK (O),
CKPOL = 1
SD (O)
I2SE
dum: not significant data
In slave mode, the way the frame synchronization is detected, depends on the value of
ASTRTEN bit.
If ASTRTEN = 0, when the audio interface is enabled (I2SE = 1), then the hardware waits for
the appropriate transition on the incoming WS signal, using the CK signal.
1290/1450

Figure 381. Start sequence in master mode

Master I2S Philips Standard
dum Left sample
Master I2S MSB or LSB justified
dum Left sample
Master PCM short frame
dum Sample1
Master PCM long frame
dum Sample1
RM0453 Rev 5
RM0453
Right sample
Right sample
Sample 2
Sample 2
MSv37520V2
