Enterasys Matrix DFE-Gold Series Configuration Manual page 502

Configuring RMON
Table 11-2 RMON Monitoring Group Functions and Commands (continued)
RMON
Group What It Does...
Host Records statistics associated
with each host discovered on
the network.
Host TopN Generates tables that
describe hosts that top a list
ordered by one of their
statistics. These rate based
statistics are samples of one
of their base statistics over an
interval specified by the
management station.
Matrix Records statistics for
conversations between two
IP addresses. As the device
detects a new conversation, it
creates a new matrix entry.
Filter Allows packets to be matched
by a filter equation. These
matched packets form a data
stream or "channel" that may
be captured or may generate
events.
Packet Allows packets to be
Capture captured upon a filter match.
11-14 Network Monitoring Configuration
What It Monitors...
Host address, packets and
bytes received and
transmitted, and broadcast,
multicast and error packets.
Statistics, top host(s), sample
stop and start period, rate
base and duration.
Source and destination
address pairs and packets,
bytes and errors for each
pair.
Packets matching the filter
configuration.
Packets matching the filter
configuration.
CLI Command(s)
show rmon host ("show rmon
page 11-27)
set rmon host properties ("set rmon host
properties" on page 11-28)
set rmon host status ("set rmon host
page 11-28)
clear rmon host ("clear rmon
page 11-29)
show rmon topN ("show rmon
page 11-29)
set rmon topN properties ("set rmon topN
properties" on page 11-31)
set rmon topN status ("set rmon topN
page 11-31)
clear rmon topN ("clear rmon
page 11-32)
show rmon matrix ("show rmon
page 11-32)
set rmon matrix properties
properties" on page 11-34)
set rmon matrix status ("set rmon matrix
on page 11-34)
clear rmon matrix ("clear rmon
page 11-35)
show rmon channel ("show rmon
page 11-35)
set rmon channel
("set rmon channel" on page 11-36)
clear rmon channel
("clear rmon channel" on page 11-37)
show rmon filter
("show rmon filter" on page 11-37)
set rmon filter
("set rmon filter" on page 11-38)
clear rmon filter
("clear rmon filter" on page 11-39)
show rmon capture
("show rmon capture" on page 11-40)
set rmon capture
("set rmon capture" on page 11-41)
clear rmon capture
("clear rmon capture" on page 11-42)
clear smon vlan
host" on
status" on
host" on
topN" on
status" on
topN" on
matrix" on
("set rmon matrix
status"
matrix" on
channel" on
