Configuring Policy Profiles
Parameters
profile‐index
name name
pvid‐status enable |
disable
pvid pvid
cos‐status enable |
disable
cos cos
egress‐vlans egress‐
vlans
forbidden‐vlans
forbidden‐vlans
untagged‐vlans
untagged‐vlans
append
clear
Defaults
If optional parameters are not specified, none will be applied.
Mode
Switch command, Read‐Write.
Example
This example shows how to create a policy profile 1 named "netadmin" with PVID override
enabled for PVID 10, and Class‐of‐Service override enabled for CoS 5. This profile can use VLAN
10 for untagged egress:
Matrix(rw)->set policy profile 1 name netadmin pvid-status enable pvid 10 cos-
status enable cos 5 untagged-vlans 10
8-4 Policy Classification Configuration
Specifies an index number for the policy profile. Valid values are 1 ‐
1023.
(Optional) Specifies a name for the policy profile. This is a string from 1
to 64 characters.
(Optional) Enables or disables PVID override for this policy profile. If
all the classification rules associated with this profile are missed, then
this parameter, if specified, determines default behavior.
(Optional) Specifies the PVID to assign to packets, if PVID override is
enabled and invoked as the default behavior.
(Optional) Enables or disables Class of Service override for this policy
profile. If all the classification rules associated with this profile are
missed, then this parameter, if specified, determines default behavior.
(Optional) Specifies a COS value to assign to packets, if CoS override is
enabled and invoked as the default behavior. Valid values are 0 to 255.
(Optional) Specifies that the port to which this policy profile is applied
should be added to the egress list of the VLANs defined by
vlans
. Packets will be formatted as tagged.
(Optional) Specifies that the port to which this policy profile is applied
should be added as forbidden to the egress list of the VLANs defined
forbidden-vlans
by . Packets from this port will not be allowed to
participate in the listed VLANs.
(Optional) Specifies that the port to which this policy profile is applied
should be added to the egress list of the VLANs defined by
vlans
. Packets will be formatted as untagged.
(Optional) Appends this policy profile setting to settings previously
specified for this policy profile by the egress‐vlans, forbidden‐vlans, or
untagged‐vlans parameters.
If append is not used, previous VLAN settings are replaced.
(Optional) Clears this policy profile setting from settings previously
specified for this policy profile by the egress‐vlans, forbidden‐vlans, or
untagged‐vlans parameters.
set policy profile
egress-
untagged-
