Functions of the System Management Console
4.3.1.4

Administering the system board's operating mode

In SX140 systems or higher it is possible to define, ascertain or modify the operating mode
of any system board located in a cabinet slot. A system board can be operated in the
following modes:
X for the extended system board (XSB) mode
P for the physical system board (PSB) mode
On SX130 systems there are only physical system boards.
In the Machine Administration Menu (see
Ê
System-Specific Administration:
1 <RETURN>
Select the required server.
Ê
Ê In the System-Specific Administration menu (see
item SB Mode Administration.
13 <RETURN>
Comment
U41272-J-Z385-3-76
On SX140 systems you must select the menu item System Board Maintenance
Administration and then SB Mode Administration in the System-Specific Administration
menu.
Functions of the System Console Software (SCS)
figure 21 on page
figure 22 on page
58) select the menu item
60) select the menu
75
