1 Preface

With the business servers in the SX series (abbreviated to: SX servers), Fujitsu Siemens
Computers is pursuing its strategy of opening up the BS2000/OSD operating system by
making available a modern hardware solution which is based on SPARC64
technology
™
and represents a future-safe investment for the customer.
The OSD Extended Configuration (OSD/XC) software package includes a ported variant of
the BS2000/OSD basic configuration which offers high performance when run on the
SX servers' SPARC64 architecture. Further software packages included in the OSD/XC
package extend the functionality available in the basic configuration. Existing BS2000/OSD
applications in the /390 world offer full object compatibility, i.e. they require no modifications,
when run on the SPARC64 architecture of the SX servers.
The SX server hardware is based on the PRIMEPOWER server hardware. The business
servers in the SX series can be divided into two classes: on the one hand the partitionable
models, with facilities for using several separate runtime environments for BS2000/OSD
and Solaris
applications, and on the other hand the entry-level models without partitioning
™
which offer a cost-effective way of entering the SX server series.
The hardware of the partitionable models is designed so that existing hardware compo-
nents (CPU, main memory, controllers, disks, etc.) can be distributed across multiple parti-
tions. This means that different, independent operating systems together with their available
applications can be run on separate partitions. These operating systems and applications
do not affect each other when they are running.
With their high availability and scalability, and the capacity for the parallel operation of
several independent application environments, the partitionable SX server models provide
an optimum basis for enterprise and business applications and for server and storage
consolidation. At the same time they also open up the SX series to the varied application
environment of the Solaris
operating system.
™
The SX100 series models are the entry-level models of the SX series. These non-partitio-
nable models are designed exclusively for use with BS2000/OSD. The SX series entry-level
models with their high availability and favourable total-cost-of-ownership (TCO) form an
optimum basis for the BS2000/OSD entry-level both for proven enterprise applications and
for new enterprise and E-business solutions.
1
U41272-J-Z385-3-76

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fujitsu Siemens Computers SX series

Summary of Contents for Fujitsu Siemens Computers SX series

  • Page 1: Preface

    The SX server hardware is based on the PRIMEPOWER server hardware. The business servers in the SX series can be divided into two classes: on the one hand the partitionable models, with facilities for using several separate runtime environments for BS2000/OSD...

  • Page 2: Figure 1: Example Of An Sx Server: Sx150 Business Server

    SX series models are a future-safe investment. Figure 1: Example of an SX server: SX150 Business Server On the business servers in the SX series suitable redundancy facilities result from the operation of several partitions. These facilities are explained in more detail in the manual “SX Series Business Servers...
  • Page 3 Administration and operation of the SX server Entry-level models in the SX series The entry-level models in the SX series are non-partitionable and designed for use exclu- sively with the BS2000/OSD operating system. BS2000/OSD running on entry-level models uses the functionality of the X2000 carrier system.

  • Page 4: Documentation For The Sx Series Business Servers

    Documentation for the SX Series Business Servers Preface 1.1 Documentation for the SX Series Business Servers Extensive documentation is available to help you in your work with SX servers. It can be ordered in printed form as a documentation package.

  • Page 5: Figure 2: Structure Of The Documentation For The Sx Series Business Servers

    Administration Guidelines Figure 2: Structure of the documentation for the SX Series Business Servers The core literature for the SX Series Business Servers in the BS2000 environment consists of: the manuals for the BS2000/OSD-BC V6.0 basic configuration the manuals for the shipped versions of OSD/XC software products...
  • Page 6 Documentation for the SX Series Business Servers Preface The following manuals in the core literature have been extended or replaced for OSD/XC: Manual Comment BS2000/OSD-BC Replaced by: Performance Handbook OSD/XC Performance Guidelines BS2000/OSD-BC Only valid in connection with Special Release System Exits The “OSD/XC Migration Guide”...

  • Page 7: Target Groups

    This manual is intended for privileged users (operators, system administrators) of the SX series business servers. It is assumed that readers possess a thorough understanding of the operating system and the hardware and have a basic knowledge of the graphical user interface PRIMEPOWER ServerView.
  • Page 8 The appendix provides information on the hardware properties of the business servers in the SX series and on the optional SKP-SR for BS2000 operation. This is followed by a list of abbreviations and figures, the related publications and an index.

  • Page 9: Notational Conventions

    Preface Notational conventions 1.4 Notational conventions The following fonts and symbols are used in this manual to indicate different types of infor- mation: Font/Symbol Indicates Example AaBbCc123 System outputs are written in this RC2000% typewriter font. AaBbCc123 Commands entered by the user are # ls -l <Return>...
  • Page 10 Notational conventions Preface U41272-J-Z385-3-76...

  • Page 11: Operating Concept Of The Sx Servers

    (SMC) as the central console for the hardware and for the BS2000 and – optionally – Solaris operating systems. The business servers of the SX series, with the exception of the entry-level models, are therefore also referred to in the following as “SX servers with SMC”.

  • Page 12: Figure 3: Example Of An Operating Concept For An Sx Server

    Operating concept for SX servers with SMC Operating concept of the SX servers 2.1 Operating concept for SX servers with SMC The figure below shows the operating concept of an SX server with SMC and a BS2000 and Solaris partition, taking the example of an SX130 configuration: SX1xx System cabinet Server...
  • Page 13 Operating concept of the SX servers Operating concept for SX servers with SMC System administration of X2000 functions (and optionally, Solaris functions) can be performed from any client via the PRIMEPOWER ServerView graphical user interface. To do this, you will need a Web browser which has Java support. The SMC server names and the names of all the partitions present on the SX server must be entered in the DNS.

  • Page 14: Figure 4: Operating Concept Of An Sx Server Without Smc

    SX server entry-level models (without SMC) Operating concept of the SX servers 2.2 Operating concept for SX server entry-level models (without SMC) SX100 Integrated console BS2000 OSD/XC Teleservicegate V24 Modem BS2000 ZASLAN SOLARIS / X2000 Customer LAN X-Server Browser SINIX-TE opt.

  • Page 15: Figure 5: Example Of An Operating Concept For An Entry-Level Model

    9750-Emu. Figure 5: Example of an operating concept for an entry-level model As an alternative to the integrated console on entry-level SX series servers, you can use a LAN console together with a V24/Ethernet converter, the remote console adapter (RCA).

  • Page 16: Remote Operation Via Lan-Pc

    Operating concept of the SX servers The LAN console is available for administering UNIX/Solaris midrange servers and SX server entry-level models from Fujitsu Siemens Computers Gmbh. The LAN console has the following features: It supports the installation, configuration, administration and diagnostics management of one or more connected SX server entry-level models, RM servers and PRIMEPOWER servers.

  • Page 17: Notes On Security

    The sections below provide some notes on access control. 2.4.1 Passwords The business servers in the SX series are shipped with standard passwords for access to the X2000 carrier system, Solaris (in the case of Solaris partitions) and the SMC.

  • Page 18: Ftp Access To Root

    Notes on security Operating concept of the SX servers However, should it become necessary to work under the root login then it is advisable to set up user-specific logins under which login can be performed. Only then should the user acquire root permissions by means of the su command.

  • Page 19: Security When Accessing Bs2000 Operation Functions

    Operating concept of the SX servers Notes on security Separate server administration and partition administration Each partition on the SX server can have its own partition administrator. The partition administrator possesses the rights necessary to switch the partition on and off and access the partition's hardware console.

  • Page 20: Secure Access With Secure Shell (Open Ssh)

    Secure Shell is independent of the type or speed of the network connection. In the business servers in the SX series Secure Shell is used for the connection between the administration PC and the system management console (or the server directly in the case of the entry-level models) and also the partitions.
  • Page 21 Operating concept of the SX servers Notes on security If the SSH is to be used on the BS2000 partition (i.e. the product OpenSSH is installed), the rlogin, rsh, rcp, ftp and telnet services offered on the LAN are deactivated automatically and they are replaced by the equivalent SSH interfaces ssh, scp and sftp.

  • Page 22: Remote Service (Teleservice)

    Remote service (Teleservice) Operating concept of the SX servers Components of the SSH The SSH suite comprises the client program ssh which replaces rlogin, rsh and telnet, Secure Copy scp which replaces rcp, and the Secure File Transfer Programm sftp which replaces ftp.

  • Page 23: Overview Of Operating Sequences On Server Switch-On / Switch-Off

    Operating concept of the SX servers Operating sequences on server switch-on / switch-off An ISDN telephone connection is also required in the vicinity of the system. If no ISDN connection can be provided then an analog modem must be ordered separately.

  • Page 24: Figure 6: Operating Sequences When Switching The Sx Server On/Off

    Operating sequences on server switch-on / switch-off Operating concept of the SX servers 2.6.1 SX server with SMC 2.6.1.1 Switch-on of the SX server and automatic start-up of the operating systems Power on the server (described in the SX1xx Operating Manual [2]) ready Start up the System Management Console (SMC) (described in the SX1xx Operating Manual [2])

  • Page 25: Automatic Termination Of Operating Systems And Server Switch-Off

    Operating concept of the SX servers Operating sequences on server switch-on / switch-off 2.6.1.2 Automatic termination of operating systems and server switch-off An SX server with SMC is switched off in the same way it is switched on, i.e. via the SCS Machine Administration Menu on the SMC.

  • Page 26: Figure 7: Operating Sequences When Switching Sx Server Without Smc On/Off

    Operating sequences on server switch-on / switch-off Operating concept of the SX servers 2.6.2 SX server entry-level models 2.6.2.1 Switch-on of entry-level model and automatic start-up of BS2000/OSD Power on the system unit Power on of (see SX100 operating instructions [2]) system unit This starts up the system unit.

  • Page 27: Functions Of The Solaris-Cde Interface

    3 Functions of the Solaris-CDE interface The business servers in the SX series are operated from the console of the server with the Solaris user interface. This user interface is called Common Desktop Environment – abbre- viated to CDE. Here, the interface provides not only functions for operating Solaris (or the X2000 carrier system) but is also used for operating BS2000 instances.

  • Page 28: Figure 8: Cde Login Screen (User Name)

    CDE interface Functions of the Solaris-CDE interface 3.1 CDE interface Login screen When the system console has been switched on, the following login screen appears (this example is for the SMC): Figure 8: CDE login screen (user name) Enter your user name in the text box (e.g. sxadmin; see the following section). Then click Ê...

  • Page 29: Figure 10: Cde Window After The First Login On A Smc

    Functions of the Solaris-CDE interface CDE interface If this is the first time you have logged in, the following windows appear on the system console (this example is for the SMC): Application Manager CDE control panel SCS button File manager with home directory Figure 10: CDE window after the first login on a SMC The next time you log in, the interface will appear in the form it was when you terminated the CDE.

  • Page 30: Figure 11: Application Manager Of The System Console Software (Scs)

    CDE interface Functions of the Solaris-CDE interface The Application Manager of the System Console Software (SCS) from which the functions can be activated looks like this: Figure 11: Application Manager of the System Console Software (SCS) A double-click calls up the functions. U41272-J-Z385-3-76...

  • Page 31: System Administration Of Bs2000 And Solaris (Optional)

    Functions of the Solaris-CDE interface System administration of BS2000 and Solaris (optional) 3.2 System administration of BS2000 and Solaris (optional) In the case of SX servers (not entry-level models) you must access the partitions in order to be able to administer the operating systems in the individual partitions. This is provided on the one hand by the consoles of the partitions supplied on the system management console (SMC) of RC2000, and on the other by the network access of the SMC via the administration LAN of the server.

  • Page 32: Figure 12: "Create Action" Window

    Preconfiguring terminals Functions of the Solaris-CDE interface 3.3 Preconfiguring terminals The preconfiguration for accessing the individual functions is based on the creation of an “action” in the CDE interface of the Solaris system on the SMC or on the X2000 carrier system.

  • Page 33: Figure 13: Window For Selecting An Icon

    Functions of the Solaris-CDE interface Preconfiguring terminals Three entries are important when creating an action: – The name of the action (subtitle of the icon) – The icon – The command which is triggered when the icon is activated (with a double-click) These three entries must be entered in that order in the fields of the window Create Action.

  • Page 34: Figure 14: Example For A Command In The "Create Action" Window

    Preconfiguring terminals Functions of the Solaris-CDE interface Confirm your selection with OK. After returning to the main window, enter the actual command. Do this in the line Command when Action is Opened (Double-clicked). Example Figure 14: Example for a command in the “Create Action” window In the example for a BS2000 console, the command consists of calling up the terminal emulation dtterm with parameters for the character set, the window title, the color settings for the console and a command which is executed in the generated window.

  • Page 35: Parameters For Configuring An Action For A Dtterm Terminal Emulation

    Functions of the Solaris-CDE interface Preconfiguring terminals Integrate the action into the CDE control panel First create a new button in the CDE control panel to do this. Right-click on the position at which the button is to be added. Select Add Icon from the context menu which is displayed.

  • Page 36: Solaris Shell (Not On Entry-Level Models)

    Preconfiguring terminals Functions of the Solaris-CDE interface Select a background color with -bg <Name_of_background_color>, e.g. -bg grey65. This is particularly important with the BS2000 console if the terminal type bs2console is not set, since the called BS2000 KVP program outputs the messages in yellow. All colors that can be selected are listed in the file /usr/openwin/lib/X11/rgb.txt.

  • Page 37: Bs2000 Console

    Functions of the Solaris-CDE interface Preconfiguring terminals 3.3.3 BS2000 console The ID cons0 mentioned in this section represents a predefined KVP ID. Here the relevant KVP ID must be entered, according to the desired IPL console mnemonics (for this see page 164).

  • Page 38: Bs2000 Dialog

    Preconfiguring terminals Functions of the Solaris-CDE interface 3.3.4 BS2000 dialog SX servers without entry-level models To create BS2000 dialog access to a partition, the following command must be entered when creating the action if the Secure Shell is not used: dtterm -e rlogin <server name of the BS2000 partition>...

  • Page 39: Primepower Serverview (Bs2000 System)

    “Displaying the configuration” on page 81) a further CDE action must therefore be created for the entry-level models in the SX series. The machine administration menu requires root rights, which is why the ID madmin is created with corresponding assignment of rights.

  • Page 40: Figure 15: Example Of A Desktop

    Calling terminal instances Functions of the Solaris-CDE interface 3.4 Calling terminal instances The desktop generated in the previous section can have the following appearance: Figure 15: Example of a desktop The generated actions (e.g. BS2000 console) are called either by clicking on the button in the CDE control panel or by activating the submenu of this button (click on the small arrow at the top edge of the icon) and the clicking on the relevant entry.
  • Page 41 Functions of the Solaris-CDE interface Calling terminal instances If windows are opened during the current CDE session and the session is terminated with EXIT, these windows will automatically be restarted when you next log in to the CDE interface. U41272-J-Z385-3-76...
  • Page 42 Calling terminal instances Functions of the Solaris-CDE interface U41272-J-Z385-3-76...

  • Page 43: Functions Of The System Management Console

    4 Functions of the System Management Console A PRIMEPOWER250 (up to and including SX140 a PRIMESTATION) is used on SX servers (with the exception of entry-level models) as the System Management Console (SMC): The SMC checks the hardware configuration and the operating status of the SX server. The SMC partitions the resources and thus enables the processor and memory capacities of the SX server to be shared.

  • Page 44: User Groups And Logins

    User groups and logins Functions of the System Management Console 4.1 User groups and logins The System Console Software supports a graded system of rights to manage the hardware functions of the SX server. The following sections describe how to set up logins for the various administrator roles (server administrator, partition administrator, BS2000 or Solaris administrator, and also administrator of PRIMEPOWER ServerView) with PRIMEPOWER ServerView and the System Console Software (SCS).

  • Page 45: Table 1: Functionality Of The Administrator User Group In The Scs

    Functions of the System Management Console User groups and logins The functionality of the user groups cladmin and clmon and the partition administration groups p0grp, p1grp, etc. described in the sections below is determined by SCS and described in the following table. The user groups mentioned are set in the factory. User group cladmin clmon...

  • Page 46: Server Administrator

    User groups and logins Functions of the System Management Console 4.1.1 Server administrator The administrator of the server manages the entire server and the system console. The administrator has root access to the system console. This root authorization allows the administrator to use all available functions of the SCS.

  • Page 47: Figure 16: Primepower Serverview Window: "Create User" (Cladmin)

    Functions of the System Management Console User groups and logins d) Create a new user (e.g. user name sxadmin1) as a member of the user group cladmin: Figure 16: PRIMEPOWER ServerView window: “Create user” (cladmin) Make the following entries here: –...
  • Page 48 User groups and logins Functions of the System Management Console – No entries are required in the “Supplementary groups” section for someone who is exclusively an SX server administrator. If PRIMEPOWER ServerView is also to be operated in write mode under this user ID, wsauser must be selected as the secondary user group.

  • Page 49: Partition Administrators

    Functions of the System Management Console User groups and logins 4.1.2 Partition administrators Partition administrators also use the interface of the System Console Software to manage the hardware of the partition. They have access to the hardware console of the partition assigned to them and are authorized to switch the partition on/off.

  • Page 50: Figure 17: Primepower Serverview Window: "Create User" (Clmon)

    User groups and logins Functions of the System Management Console d) Create a new user (e.g. user name soladmin2) as a member of the user group clmon: Figure 17: PRIMEPOWER ServerView window: “Create user” (clmon) No entries are required in the “Supplementary groups” section for someone who is exclusively an SX server administrator.

  • Page 51: Figure 18: Primepower Serverview Window: "Create Group

    Functions of the System Management Console User groups and logins 2. If necessary, configure a further partition-specific user group with PRIMEPOWER ServerView, e.g. part1grp. User groups suitable for this have already been configured by default with the name p0grp, p1grp, etc. and are used for the partition administrators bs2admin and soladmin.

  • Page 52: Bs2000 Or Solaris Administrators

    User groups and logins Functions of the System Management Console 4.1.3 BS2000 or Solaris administrators To manage the operating systems of individual partitions, it may be useful to configure user IDs which do not have extended rights relating to the management of the hardware of the server (like server administrators or partition administrators).

  • Page 53: Administration Of Primepower Serverview

    Functions of the System Management Console User groups and logins 2. Set up the SCS user interface (Terminal in the Application Manager) for the user ID using the following command (which must be executed with root authorization): /opt/FJSVscsl/bin/scslowneradd -h <server name_of_partition>:clmon <user name>...

  • Page 54: Figure 19: Primepower Serverview Window:"Create User" (Administrator Of Primepower Serverview)

    User groups and logins Functions of the System Management Console d) Create the new user (e.g. user name pwsvadm) Figure 19: PRIMEPOWER ServerView window:”Create user” (administrator of PRIMEPOWER ServerView) As the user is not to be allocated special SCS privileges, the user must be assigned as a member of the primary user group other.
  • Page 55 Functions of the System Management Console User groups and logins 2. After this it may be necessary to adjust the access rights to the applications of PRIMEPOWER ServerView and the nodes of the administration domain. In the following cases such a user ID is automatically assigned the full access rights to all available applications of PRIMEPOWER ServerView and to all nodes of the administration domain: Use of PRIMEPOWER ServerView Suite Version <...

  • Page 56: Figure 20: System Console Menu

    System console software (SCS) Functions of the System Management Console 4.2 System console software (SCS) The system console menu used to activate the functions looks like this: Figure 20: System console menu Click the system console icon in the toolbar to open the menu. U41272-J-Z385-3-76...
  • Page 57 Functions of the System Management Console System console software (SCS) The table below describes the functions of the tools provided on the system console: Function Description System Console Menu with the functions provided by the system console. Is automati- cally started after logging in. RC2000 Shows a host browser via which the console windows of the server can be opened.

  • Page 58: Functions Of The System Console Software (Scs)

    Functions of the System Console Software (SCS) Functions of the System Management Console 4.3 Functions of the System Console Software (SCS) This section describes the SCS functions Machine Administration Menu, RC2000 and Monitoring Messages. 4.3.1 Machine Administration Menu The System Console Machine Administration Menu enables the management and servicing of the system hardware.

  • Page 59: Functions For Switching The Server On/Off

    Functions of the System Management Console Functions of the System Console Software (SCS) 4.3.1.1 Functions for switching the server on/off This section describes how the power supply of the server is handled via the system console. The following procedure describes how to access the System/Partition Power Administration Menu: 1.

  • Page 60: Figure 22: Machine Administration Menu: "System-Specific Administration

    Functions of the System Console Software (SCS) Functions of the System Management Console 2. Select the required server. Example 1 <RETURN> The System-Specific Administration menu is opened for the selected server (in this example machine0 of the SX150 server): Server Figure 22: Machine Administration Menu: “System-Specific Administration”...

  • Page 61: Figure 23: Machine Administration Menu: "System/Partition Power Administration

    Functions of the System Management Console Functions of the System Console Software (SCS) 3. Select System/Partition Power Administration: 8 <Return> This opens the menu System/Partition Power Administration for the selected server (machine0): Figure 23: Machine Administration Menu: “System/Partition Power Administration” The System/Partition Power Administration menu contains the following functions: Switches the server on 1.
  • Page 62 Functions of the System Console Software (SCS) Functions of the System Management Console Switching the entire server on The function System Power-On Instruction switches the server on if it is switched off. Switching on the server via this menu item has the same effect as powering on the server via the control panel on the front side of the SX server (see the SX1xx Operating Manual [2]).
  • Page 63 Functions of the System Management Console Functions of the System Console Software (SCS) Switching the entire server off The function System Power-Off Instruction switches the server off if it is switched on. 1. Select the function System Power-Off Instruction from the menu System/Partition Power Administration: 2 <RETURN>...
  • Page 64 Functions of the System Console Software (SCS) Functions of the System Management Console Switching partitions on The function Partition Power-On Instruction switches on one or more partitions. Switching on a partition starts the operating system in the partition. 1. Select the function Partition Power-On Instruction from the menu System/Partition Power Administration: 3 <RETURN>...
  • Page 65 Functions of the System Management Console Functions of the System Console Software (SCS) Switching partitions off The function Partition Power-Off Instruction powers off one or more partitions. 1. Select the function Partition Power-Off Instruction from the menu System/Partition Power Administration: 4 <RETURN>...

  • Page 66: Switching The Server On/Off On A Scheduled Basis

    Functions of the System Console Software (SCS) Functions of the System Management Console 4.3.1.2 Switching the server on/off on a scheduled basis The automatic power control system (APCS: ) switches the server on or off automatically, on the basis of a series of on/off schedule entries. These entries form the system schedule. Switching on/off thus affects all partitions of the server.

  • Page 67: Figure 24: Machine Administration Menu: "Apcs Setup Menu

    Functions of the System Management Console Functions of the System Console Software (SCS) Select Auto Power Control System (APCS) Administration from System-Specific Ê Administration (see figure 22 on page 60): 11 <RETURN> This opens the APCS Setup Menu: Figure 24: Machine Administration Menu: “APCS Setup Menu” The following actions can be performed using this menu: –...
  • Page 68 Functions of the System Console Software (SCS) Functions of the System Management Console Examples a) Setting the power on time: Set Power On Time (Add) Please set the automatic power on time. Press the "RETURN" key if you do not wish to power on the system automatically.
  • Page 69 Functions of the System Management Console Functions of the System Console Software (SCS) c) Setting the schedule: Schedule Setup (Add) Please set the day or days to put into operation. .Specific Day Example) Feb. 1st, 2000 : 20000201 .Specific days in this month Example) From 1st through 10th : 01-10 .To repeat this for several months Example) From 1st through 10th in Feb.
  • Page 70 Functions of the System Console Software (SCS) Functions of the System Management Console 3. You can enter holidays with the function Add Holiday: 4 <RETURN> Example Add Holiday Please set the day when schedule entry or entries are to be ignored. Example) Feb.

  • Page 71: Switching Partitions On/Off On A Time-Driven Basis

    Functions of the System Management Console Functions of the System Console Software (SCS) 6. Select the function Start System Schedule to start the system schedule: 1 <RETURN> 7. Transfer the schedule to every partition: If the server is switched on while changes are being made to the schedule, these changes need to be passed to the console of every partition via the schedule update command: # /opt/FJSVapcs/sbin/apcsflush...

  • Page 72: Figure 25: Primepower Serverview- Window: "Create Task

    Functions of the System Console Software (SCS) Functions of the System Management Console In this application the tasks are preferably executed on the SMC since the System Console Software (SCS) is only directly available there. Example Activating a partition every Monday at 8.00 a.m.. Figure 25: PRIMEPOWER ServerView- window: “Create task”...

  • Page 73: Figure 26: Control Panel Of An Sx140 Or Sx150 Server

    Functions of the System Management Console Functions of the System Console Software (SCS) After the power supply has been switched on the system unit is started up. After the POST (Power On Self Test) the Solaris operating system and, in the BS2000 partitions, the X2000 carrier system is started automatically if the mode selector in the SX server’s control panel is set to LOCK (see figure “Control panel of an SX140 or SX150...
  • Page 74 Functions of the System Console Software (SCS) Functions of the System Management Console Switching a partition off A partition is switched off using the following SCS command: /opt/FJSVcsl/bin/node_control -down <machine_name> -pid=<partition ID> Example /opt/FJSVcsl/bin/node_control -down fernando0 -pid=1 In this case any Solaris system which is still running is closed down in an orderly manner and the power supply to this partition is interrupted.

  • Page 75: Administering The System Board's Operating Mode

    Functions of the System Management Console Functions of the System Console Software (SCS) 4.3.1.4 Administering the system board’s operating mode In SX140 systems or higher it is possible to define, ascertain or modify the operating mode of any system board located in a cabinet slot. A system board can be operated in the following modes: X for the extended system board (XSB) mode P for the physical system board (PSB) mode...

  • Page 76: Figure 28: Sb Mode Administration Menu

    Functions of the System Console Software (SCS) Functions of the System Management Console The SB Mode Administration menu is opened: Figure 28: SB Mode Administration Menu The current operating mode of each system board in a slot s in cabinet c (presented in the format cs in the Slot column, in other words, for example, 01 for slot 1 and cabinet 0) is displayed in the Mode column of this menu: The system board is operated in XSB mode.
  • Page 77 Functions of the System Management Console Functions of the System Console Software (SCS) This menu also enables a system board to be configured or modified. To modify a board you must first select the function m. You can then use the function x in XSB mode and the function p in PSB mode to modify it (see also the Select line in figure 28 on page 76).

  • Page 78: Figure 29: Partition And System Board Administration Menu, Taking An Sx150

    Functions of the System Console Software (SCS) Functions of the System Management Console 4.3.1.5 Configuring and modifying partitions Partitions can be configured for the operating systems and applications which run on them using the physical and/or (from SX140 systems on) the extended system board mode. In this case a partition can, however, only incorporate on type of system board mode.

  • Page 79: Figure 30: System Board Addition To Partition Menu, Taking An Sx150 Server As

    Functions of the System Management Console Functions of the System Console Software (SCS) Adding a system board to a partition Ê To add a system board to a partition select the menu item System Board Addition to Partition in the Partition and System Board Administration menu: 2 <RETURN>...

  • Page 80: Figure 31: System Board Removal From Partition Menu, Taking An Sx150 Server

    Functions of the System Console Software (SCS) Functions of the System Management Console Removing a system board from a partition Ê To remove a system board from a partition select the menu item System Board Removal from Partition in the menu Partition and System Board Administration: 3 <RETURN>...

  • Page 81: Configuring/Changing The Partitioning

    Functions of the System Management Console Functions of the System Console Software (SCS) 4.3.1.6 Configuring/changing the partitioning At least one partition of the SX server is reserved for running BS2000/OSD. These parti- tions are designated below as BS2000/OSD partitions. In addition to the BS2000/OSD partitions, an SX server can include Solaris partitions. Configuring a Solaris partition and adding or removing system boards of a partition is carried out in the same way as for the PRIMEPOWER servers.

  • Page 82: Figure 32: Machine Administration Menu: "Hardware Configuration Displays

    Functions of the System Console Software (SCS) Functions of the System Management Console Now you can call up information on the hardware and partition configuration: Server hardware configuration After selecting Hardware Configuration Displays, the following menu is opened. This example is for an SX130 server: Figure 32: Machine Administration Menu: “Hardware Configuration Displays”...
  • Page 83 Functions of the System Management Console Functions of the System Console Software (SCS) Example for SX130: displaying system information (Display System Information) Enter “1”; the server-specific information will be displayed: PRIMEPOWER800 Serial No:23092; System Clock:225 MHz; Operation Panel Switch:Lock; Altitude:0 m; Partition#00 1 System Board;...

  • Page 84: Figure 33: Machine Administration Menu: "System Notification Administration

    Functions of the System Console Software (SCS) Functions of the System Management Console 4.3.1.8 Error notifications The system console SMC detects hardware errors on the server and generates messages when an error occurs. This involves the following functions: – Displaying detected errors in the message window of the console (monitoring messages) –...
  • Page 85 Functions of the System Management Console Functions of the System Console Software (SCS) You can make the following settings under System Notification Administration: Output error messages in a message window on the system console Notify the system administrator by e-mail Determine whether the system administrator is to be informed by e-mail about errors which occur.

  • Page 86: Figure 34: Rc2000 Main Window

    Functions of the System Console Software (SCS) Functions of the System Management Console 4.3.2 Consoles of the partitions with RC2000 This section describes how the RC2000 system (RC = Remote Console) is handled. Activating RC2000 This function is called up by selecting RC2000 from the system console menu (see figure 20 on page 56) or by double-clicking the RC2000 icon in the Application Manager (see...
  • Page 87 Functions of the System Management Console Functions of the System Console Software (SCS) Activating the console window of partitions Proceed as follows to open the console window: Activating from the menu 1. Select a partition from the host browser (RC2000). 2.

  • Page 88: Figure 35: Sequence Of Post, Obp And Solaris Startup After Switching On Or A Reset

    Example of screen outputs until the OBP prompt appears POST Sequence 03 POST Sequence 1a POST Sequence Complete Fujitsu Siemens PRIMEPOWER800 2-slot 4x SPARC64 IV 675MHz OpenBoot 3.14.7-1, 4096 MB memory installed Ethernet address 0:0:e:25:5:22, Host ID: 80f30522. {0} ok...
  • Page 89 Functions of the System Management Console Functions of the System Console Software (SCS) OBP commands OBP help function {0} ok help A help text on the individual commands is output: {0} ok help boot boot <device-name> printenv setenv <name> <value> devalias devalias <name>...
  • Page 90 Functions of the System Console Software (SCS) Functions of the System Management Console Diagnostics routines probe-scsi Probes SCSI devices on the first SCSI controller Probes SCSI devices on all SCSI controllers probe-scsi-all Show commands Show POST result show-post-results Show all installed devices (including hardware path) show-devs show-disks Show path of disks...

  • Page 91: Figure 36: Boot Process Sequence

    Functions of the System Management Console Functions of the System Console Software (SCS) 4.3.2.2 Starting Solaris Enter the following command in OBP mode: {0} ok boot disk disk here is the alias of the boot disk. The full command with the physical device name of the boot disk would be, for instance: {0} ok boot /pci@8c,2000/scsi@1/disk@1,0:a Sequence of the boot operation:...

  • Page 92: Figure 37: Monitoring Messages: Example For Sx System Error Messages

    Functions of the System Console Software (SCS) Functions of the System Management Console 4.3.3 Monitoring messages If the system console detects a server error, an error message is displayed in the window Monitoring Messages. Double-click the icon in the Application Manager to call up the window Monitoring Messages (see figure 11 on page 30) or select it from the system console menu (see...

  • Page 93: Time Synchronization Between Smc And The Partitions

    This affects: The System Management Console All partitions (BS2000 and, optionally, Solaris) The optional SKP-SR This also applies to the SX series entry-level models (see section “Time cluster with external time servers” on page 131).
  • Page 94 Time synchronization between SMC and partitions Functions of the System Management Console The configuration of the SMC as an NTP server and of the partitions as NTP clients as supplied is described below. If an external timer (with an official time reference, i.e. stratum 1) is used, the configuration of the SMC must be changed, so that it operates in addition to its task as an NTP server for the partitions as an NTP client of this external timer.

  • Page 95: Figure 38: Ntp Diagnostic Command Ntpq (Example)

    Functions of the System Management Console Time synchronization between SMC and partitions If the time of the System Management Console is more than 1000 seonds ahead of or behind the time of a partition the time cannot be automatically synchronized via NTP (start of the NTP daemon of the partitions or of the NTP client is suppressed).

  • Page 96: Figure 39: Ntp Diagnostic Command Ntptrace (Example)

    Time synchronization between SMC and partitions Functions of the System Management Console Meaning of the values in the entry: – Name or address of the peer – Reference ID (0.0.0.0 if the reference ID is unknown) – Stratum value of the peer –...

  • Page 97: Backing Up/Restoring The Smc

    Functions of the System Management Console Backing up/restoring the SMC 4.5 Backing up/restoring the SMC If you create data backups at regular intervals, you can restore your data easily in the event of a system crash. The following sections describe the procedures for creating backups and explain which data types must be backed up.

  • Page 98: Scs Configuration Data

    Backing up/restoring the SMC Functions of the System Management Console 4.5.1 SCS configuration data This section describes how to back up and restore the SCS configuration data. 4.5.1.1 Backing up the configuration data of the System Console Software (SCS) A backup of the configuration data of the System Console Software is of benefit if you wish to replace an incorrect configuration setting with the old configuration.

  • Page 99: Figure 21: Machine Administration Menu

    Functions of the System Management Console Backing up/restoring the SMC 5. Insert the data cartridge containing the backed up configuration data in the DAT drive. Check beforehand that the data cartridge is write-protected, i.e. that the write protection tab is set at “writeable”. 6.

  • Page 100: System Drive

    Backing up/restoring the SMC Functions of the System Management Console 4.5.2 System drive 4.5.2.1 Backing up the system drive of the SMC This section describes how to back up offline. When the system drive is backed up, all data saved on the hard disks which are installed in the SMC is transferred onto DAT data cartridges.
  • Page 101 Functions of the System Management Console Backing up/restoring the SMC 6. When a prompt appears, enter the command format. The system disks available for selection are offered. Example #format Searching for disks...done AVAILABLE DISK SELECTIONS: 0. c0t0d0 <sfdsk type1.0; ST320420A cyl 39533 alt 2 hd 16 sec 63>...

  • Page 102: Restoring The System Drive Of The Smc

    Backing up/restoring the SMC Functions of the System Management Console 4.5.2.2 Restoring the system drive of the SMC To restore the system drive, you will need: – The DDS4 data cartridges (150 m) with the backed up data of the system drive –...
  • Page 103 Functions of the System Management Console Backing up/restoring the SMC 7. When a prompt appears, start the restore process by entering the following command: SMC# dd if=/dev/rmt/0 of=/dev/rdsk/c0t0d0s2 bs=1024k When you enter this command, ensure that the value of the bs option (buffer size) is identical to the value used when the backup was created.

  • Page 104: Configuration Data Of The Cde Interface

    Backing up/restoring the SMC Functions of the System Management Console 4.5.3 Configuration data of the CDE interface All settings of the CDE interface for a login are located in the home directory of the user in the subdirectory .dt. This also includes the preconfigured terminals described in the section “Preconfiguring terminals”...
  • Page 105 Functions of the System Management Console Backing up/restoring the SMC To include further configuration data with the command scslbackup, proceed as follows: – A new directory must be created in the directory /etc/opt/FJSVscsl/backup (any name, e.g. CDEbackup). – A file with the name printlist must be created in this directory, containing all file names to be saved.
  • Page 106 Backing up/restoring the SMC Functions of the System Management Console Backing up and restoring manually If the data is written to a separate DAT tape from the SCS management data, this can be done using the procedure above and the following additional commands: # tar cf /tmp/cde.tar -I /etc/opt/FJSVscsl/backup/CDEbackup/printlist # tar cf /dev/rmt/0 /tmp/cde.tar # rm /tmp/cde.tar...

  • Page 107: Backing Up/Restoring Systems In The Partitions

    Functions of the System Management Console Backing up/restoring systems in the partitions 4.6 Backing up/restoring systems in the partitions This section describes the procedures for backing up and restoring data for the disk on which the operating system of a partition is located (referred to hereafter as the “system disk”).

  • Page 108: Data Backup

    Backing up/restoring systems in the partitions Functions of the System Management Console 4.6.2 Data backup This description assumes a system disk of a partition which is backed up using a tape device (DAT drive) which is connected to the system console (SMC). Backing up a file system A file system is backed up with the command ufsdump.
  • Page 109 Functions of the System Management Console Backing up/restoring systems in the partitions Procedure 1. In the partition which is to carry out the data backup the Solaris operating system is now started via the network from the system console: {0} ok boot <LAN controller> -s Here <LAN controller>...
  • Page 110 Backing up/restoring systems in the partitions Functions of the System Management Console Example using the Secure Shell Back up local file system /mnt on the tape device of the SMC: # ufsdump 0cf - /mnt | ssh root@<name of the SMC> "dd of=/dev/rmt/0 bs=64k"...
  • Page 111 Functions of the System Management Console Backing up/restoring systems in the partitions – Add the partition name and root to the file /.rhosts of the SMC. As an alternative, keys can be used in the framework of the Secure Shell. Example: <partition-name>...
  • Page 112 Backing up/restoring systems in the partitions Functions of the System Management Console Example Back up local files /dev/dsk/c0t0d0s1 on the tape device of the SMC. # dd if=/dev/rdsk/c0t0d0s1 bs=64k | rsh <name of the SMC> dd of=/dev/rmt/0 bs=64k 139072+1 records in 17801280+0 records out 16228173+3144616 records in 139072+1 records out...

  • Page 113: Recovery

    Functions of the System Management Console Backing up/restoring systems in the partitions 4.6.3 Recovery This description assumes a system disk which is restored from a tape device (DAT drive) which is connected to the system console (SMC). Restoring a file system A file system is restored with the command ufsrestore.
  • Page 114 Backing up/restoring systems in the partitions Functions of the System Management Console 6. Switch to the temporary mount point: Example: # cd /mnt 7. Secure the tape against write access and insert it in the tape device. 8. Restore the file system from the remote tape device with the command ufsrestore. Example Restore the file system from the tape device of the SMC: # ufsrestore rvf <name of the SMC>:/dev/rmt/0...
  • Page 115 Functions of the System Management Console Backing up/restoring systems in the partitions 4. Restart the system: # /usr/sbin/shutdown -y -g0 -i6 Restoring a disk A disk is restored with the command dd. The following describes how data can be restored with the commands dd and rsh (or ssh if the Secure Shell is used).
  • Page 116 Backing up/restoring systems in the partitions Functions of the System Management Console 6. Restore the files from the remote tape device with the commands dd and rsh (or ssh if the Secure Shell is used). Example Restore data from the tape device of the SMC on the local disk (/dev/dsk/c0t0d0s1): # rsh <name of the SMC>...

  • Page 117: Xscf

    Functions of the System Management Console XSCF 4.7 XSCF 4.7.1 Functionality of XSCF As of the SX150 model series the System Management Console (SMC) on the basis of a PRIMEPOWER250 system is equipped with the Extended System Control Facility (XSCF). XSCF is a system monitoring and control facility which runs on its own processors in the SMC and offers a user interface as long as it is connected to the power cables of the SMC.

  • Page 118: Table 2: Overview Of The Access Options To Xscf

    XSCF Functions of the System Management Console 4.7.2 Access options to XSCF The table below provides an overview of the various access options to XSCF. Function Description Serial port SCF-LAN Ethernet XSCF Shell – Monitors the server. The status of the server can be checked.

  • Page 119: Figure 40: Calling Xscf Administration Via The Machine Administration Menu

    Functions of the System Management Console XSCF 4.7.3 Configuration of XSCF XSCF is configured via the Machine Administration Menu of the SMC which is started with the command below: /opt/FJSVmadm/sbin/madmin Figure 40: Calling XSCF administration via the Machine Administration Menu of the SMC When you select 5 eXtended System Control Facility (XSCF) Administration the following window opens: Figure 41: XSCF Administration Menu...
  • Page 120 XSCF Functions of the System Management Console Configuration of XSCF comprises the following steps: Network Configuration (mandatory): Definition of the access from XSCF to the network (IP address, XSCF host name, subnet mask, name server, etc.) User Account Administration (mandatory): For access to the XSCF shell separate access IDs must be created in XSCF to which a different scope of commands can be made available depending on the group affili- ation.

  • Page 121: Figure 42: Xscf Shell

    Functions of the System Management Console XSCF 4.7.4 Accesses to XSCF Access to the XSCF shell The connection to the XSCF shell is, for example, set up using Exceed (see the section “Configuration and operation” on page 135) via Telnet port 8010 or SSH port 8810. In this case the last error message is output.

  • Page 122: Figure 43: Overview Of The Commands Of The Xscf Shell

    XSCF Functions of the System Management Console The help entry requests an overview of the commands of the XSCF shell: Figure 43: Overview of the commands of the XSCF shell Access to the console The remote connection to the XSCF console with write authorization is carried out using, for example, Exceed via Telnet port 23 or SSH port 22.

  • Page 123: Table 3: Xscf Functions Available Via A Web Browser

    Functions of the System Management Console XSCF Access via Web browser Access to XSCF is implemented in the Web browser at URL https://<xscf-hostname>. The XSCF host name was defined when XSCF was configured. XSCF is assigned a separate network connection with a separate network address and a separate host name. Network access to the SMC is not affected by this.
  • Page 124 XSCF Functions of the System Management Console U41272-J-Z385-3-76...

  • Page 125: Functions Of The Sx Server Entry-Level Models

    5 Functions of the SX server entry-level models 5.1 Switching on/off functions The SX server entry-level models are switched on and off via the power button on the control panel of the system unit: To switch on, press the power button once. The X2000 carrier system (in the normal Ê...

  • Page 126: Machine Administration Menu

    Machine Administration menu Functions of the SX server entry-level models 5.2 Machine Administration menu The machine administration menu is an application in the X2000 carrier system environment. This menu is used for server system operation and maintenance. To call the function in an SX server entry-level model, see also the section “Machine Admin- istration Menu (for entry-level models only)”...

  • Page 127: Figure 44: Machine Administration Menu Setting Monitoring

    Functions of the SX server entry-level models Machine Administration menu The following screen is displayed: Figure 44: Machine Administration Menu Setting Monitoring Notification Information You can now set the menu as follows: – Display error messages on the system console (activated as default) –...

  • Page 128: Timed Switching On/Off Of The Server

    Machine Administration menu Functions of the SX server entry-level models 5.2.2 Timed switching on/off of the server The automatic power control system (APCS) automatically switches the server on or off – based on a number of switching on/off schedule entries.These entries form the system schedule.

  • Page 129: Integrated Console

    Functions of the SX server entry-level models Integrated console 5.3 Integrated console To use the integrated console, open the rack door and pull out the drawer with the TFT monitor and keyboard. Fold the monitor into the upright position and switch on. When the monitor is in the upright position it is not possible to push in the drawer.

  • Page 130: Lan Console And Rca

    LAN console and RCA Functions of the SX server entry-level models 5.4 LAN console and RCA The operation of the SX server entry-level models via the LAN console and remote commu- nication adapter (RCA) is similar to that of SX servers with SMC. The main difference is in the software used to operate the physical consoles of the system units.

  • Page 131: Time Cluster With External Time Servers

    Functions of the SX server entry-level models Time cluster with external time servers 5.5 Time cluster with external time servers In principle, the use of an external time server in BS2000 is not necessary because BS2000 is automatically synchronized with the Solaris time of the X2000 carrier system. When requirements relating to accuracy of the time reference used are tightened, however, the use of an external timer for X2000 is recommended.
  • Page 132 Time cluster with external time servers Functions of the SX server entry-level models U41272-J-Z385-3-76...

  • Page 133: Remote Operation Via Pc

    Personal computers from the Scenic Professional series or workstations from the Celsius or Primergy series are recommended. If you have any queries concerning your hardware configuration, please contact a Fujitsu Siemens Computers sales represen- tative. U41272-J-Z385-3-76...
  • Page 134 Recommended hardware and software configuration Remote operation via PC Operating system ® A PC based on Microsoft Windows is recommended for operating the SX server. Windows 95, 98, ME, 2000, NT 4.0 and XP are supported as operating systems. No particular version is recommended at this point because the strategy of the customer cannot generally be considered here.

  • Page 135: Figure 45: Xconfig: Start Window

    Remote operation via PC Configuration and operation 6.2 Configuration and operation This section describes the configuration and operation of Exceed, PRIMEPOWER ServerView, SINIX-TE and the 9750 terminal emulation. Exceed The configuration of the Exceed X server is described below. The X server is used to access the CDE user interface of the current console.

  • Page 136: Figure 46: Xconfig: Network And Communication Window

    Configuration and operation Remote operation via PC You must make the following entries in the program window: 1. Select Network and Communication. The following window will open: Figure 46: Xconfig: Network and Communication window You make the following entries in this window: Mode = XDMCP-query Ê...

  • Page 137: Figure 48: Xconfig: Display And Video

    Remote operation via PC Configuration and operation Click the OK button or the Validate and Apply Changes button to confirm your entries. Click the OK button to return to the main menu. You have now completed the basic configuration for console access. 2.

  • Page 138: Figure 50: Xconfig: Editor

    Configuration and operation Remote operation via PC This possibility can be restricted to certain servers (only the SMC, the partitions of the SX server, the SKP-SR and the entry-level model). To do this, you must select File under Host Access Control List and edit the file xhosts.txt. In this file, you should enter the server names or IP addresses of servers which are to be authorized to display windows on the X server: Figure 50: Xconfig: Editor...

  • Page 139: Figure 52: Cde Login Screen

    Remote operation via PC Configuration and operation After the start screen has been displayed, you see the login screen for the System Management Console: Figure 52: CDE login screen After you have logged in, you can use the CDE desktop in exactly the same way as at the console: Figure 53: CDE desktop after login U41272-J-Z385-3-76...
  • Page 140 Configuration and operation Remote operation via PC PRIMEPOWER ServerView Suite When the PRIMEPOWER ServerView Suite is started, after the user interface is loaded first of all the name of the Management Server is queried on which the PRIMEPOWER ServerView Suite is to be started, and also the user ID with the associated password. You are informed if further applications for PRIMEPOWER ServerView Suite are available for downloading on the server.
  • Page 141 PRIMEPOWER ServerView Suite on the PC using the menu Start -> Programs -> PRIMEPOWER ServerView Suite -> Uninstall PRIMEPOWER ServerView Suite and delete the installation directory (with the standard installation this is the directory C:\Program Files/Fujitsu Siemens Computers/WebSysAdmin). U41272-J-Z385-3-76...

  • Page 142: Figure 54: Sinix-Te Window

    Configuration and operation Remote operation via PC SINIX-TE Optional it is possible to use an emulation keyboard to facilitate the operation of the BS2000 dialog functions. It is necessary to run an appropriate terminal emulation to support this keyboard. We recommend that you use SINIX-TE to emulate a 97801 terminal. However, SINIX-TE cannot be deployed in combination with the Secure Shell.
  • Page 143 Remote operation via PC Configuration and operation After you have clicked OK to confirm, the selected connection is opened. Once the connection has been tested to ensure that the server name/IP address has been entered correctly you can save the connection. To do this, open the File menu and select Save as….

  • Page 144: Access With Secure Shell

    Access with Secure Shell Remote operation via PC 6.3 Access with Secure Shell If you wish to use Secure Shell (SSH) to access SX servers you will first have to make some preparations on the server and client sides. These preparations include installing and configuring the openSSH software on the server side (on the SMC and the partitions).

  • Page 145: Figure 55: Installing Open Software

    Remote operation via PC Access with Secure Shell To install the patch 112438-01 first of all check whether it is already installed (using Ê patchadd -p | grep 112438-01). If it is not installed, switch over to the directory /cdrom/cdrom0/products and install the patch using patchadd 112438-01. When you have installed the patch, reboot the system with init 6.

  • Page 146: Configuring The Openssh Daemon

    Access with Secure Shell Remote operation via PC 6.3.2 Configuring the OpenSSH daemon Before you can use the software just installed you must configure the ssh daemon for X11 forwarding. To do this, on the BS2000 partitions and on the SMC of the model series up to and including SX140 edit the file /opt/SMAWPlus/etc/sshd_config or, on the SMC as of the SX150 model series, the file /etc/ssh/sshd_config as follows: Ê...

  • Page 147: Configuring The Pc Client Side

    Remote operation via PC Access with Secure Shell 6.3.3 Configuring the PC client side Once all the server side preparations for the use of Secure Shell have been completed, the next step is to prepare the administration PC so that the X server can be controlled by Exceed via the Secure Shell protocol.We recommend that you use the PuTTY terminal emulator software to build an X11 tunnel or a port forwarding.

  • Page 148: Figure 56: Putty Configuration: Session

    Access with Secure Shell Remote operation via PC PuTTY This section describes how to configure PuTTY in order to build an X tunnel to the server and to start the user interface from the server. In the first window which appears when you start PuTTY, enter the server name and the protocol to be used (in this case SSH).

  • Page 149: Figure 57: Putty Configuration: Connection

    Remote operation via PC Access with Secure Shell Under Category Connection, set the user ID and the terminal type to be used for the PuTTY terminal emulation. Figure 57: PuTTY Configuration: Connection In Category Connection -> SSH, enter the command to start the CDE user interface. The command is: /usr/dt/bin/Xsession Figure 58: PuTTY Configuration: SSH U41272-J-Z385-3-76...

  • Page 150: Figure 59: Putty Configuration: Tunnels

    Access with Secure Shell Remote operation via PC In Category Connection -> SSH -> Tunnels, configure the X tunnel and the local DISPLAY to be used. Figure 59: PuTTY Configuration: Tunnels If logon to the server is to be key-protected rather than password-protected, you should set Category Connection ->...

  • Page 151: Figure 60: Putty Configuration: Save

    Remote operation via PC Access with Secure Shell Once you have completed the connection settings, you can save them in Category Session with -> Save. Figure 60: PuTTY Configuration: Save 6.3.3.2 Using Exceed via Secure Shell 1. Call Exceed to start the X server. 2.

  • Page 152: Figure 61: Example Of User Interface Started From Putty

    Access with Secure Shell Remote operation via PC The user interface is similar to the one displayed during operation without Secure Shell (see chapter “Functions of the Solaris-CDE interface” on page 27). Figure 61: Example of user interface started from PuTTY U41272-J-Z385-3-76...

  • Page 153: Key Management For Secure Shell

    Remote operation via PC Key management for Secure Shell 6.4 Key management for Secure Shell 6.4.1 Generating the keys In SSH authentication and encryption are based on the asymmetrical system of public and private keys. Encryption and decryption are performed with different keys, and it is not possible to derive the key for decryption from that for encryption.
  • Page 154 Key management for Secure Shell Remote operation via PC Generating the keys Variaous algorithms are available for generating such key pairs. The most familiar are RSA and DSA. In Solaris they can be generated by calling the ssh-keygen command (see http://www.openssh.com).

  • Page 155: Use Of Ssh Agents

    Remote operation via PC Key management for Secure Shell There is no way you can recover a lost pass phrase. If you have lost one, a new key pair must be generated and its public key must be distributed to the communications partners. 6.4.2 Use of SSH agents Use of an SSH agent means that it is not necessary to type in the pass phrase (which is normally long and complex) each time you call the ssh program.
  • Page 156 Key management for Secure Shell Remote operation via PC These output commands of the ssh-agent program can be executed using the eval command. When doing so please take into account the reverse quotes (`): eval `ssh-agent ...` The eval command instructs the shell to let the ssh-agent command run and to execute the commands generated by it.

  • Page 157: Putty With Puttygen And

    Remote operation via PC Key management for Secure Shell 6.4.3 PuTTY with PuTTYgen and Pageant This section describes the generation of key pairs and the distribution of the public keys using PuTTY . PuTTY is a free implementation of Telnet and Secure Shell for Win32 and Unix System-based platforms and is useful in dialog mode.
  • Page 158 Key management for Secure Shell Remote operation via PC Authentication agent Pageant PuTTY's authentication agent Pageant contains the encrypted private keys in the memory and, as required, generates signatures or deals with the authentication procedure. At the beginning of a Windows session you start Pageant. If you then click on the Pageant icon with the right mouse button a menu opens.

  • Page 159: Operating Bs2000 Instances

    7 Operating BS2000 instances 7.1 Starting BS2000 To start BS2000, you will first need a BS2000 console screen (see the following section “Accessing BS2000 console mode”). When the status bar appears in the first line, use the [F2] key to branch into the Main KVP Function Menu (see page 164).

  • Page 160: Accessing Bs2000 Console Mode

    BS2000 console mode Operating BS2000 instances 7.2.1 Accessing BS2000 console mode For the console inputs/outputs you require a KVP. You will find an overview of its configu- ration in the section “Functions” on page 210. However, the KVP is only responsible for controlling the I/O traffic between X2000 and BS2000.

  • Page 161: Figure 62: Opening A Bs2000 Console Window Under The Cde Interface

    Operating BS2000 instances BS2000 console mode Click on the relevant icon on the front panel of the CDE interface to automatically open a window in which the functionality of the BS2000 console will be available after autho- rization (log in with the X2000 login cons0..7) (see also section “Calling terminal instances”...
  • Page 162 BS2000 console mode Operating BS2000 instances Working with terminal type bs2console If you intend working with a light background you must use a different color scheme. Emergency messages/queries: Messages/inputs: normal KVP messages: normal underlined You are recommended to activate this color scheme via terminal type bs2console. This type is a special dtterm and can be activated by: –...
  • Page 163 Operating BS2000 instances BS2000 console mode Protecting access to BS2000 console mode Access to BS2000 console mode is protected as follows: If you log on dynamically, the Solaris welcome screen automatically asks you to enter a valid password. – If the Solaris login has been locked, access to the console is canceled. The login must then first be released using the Solaris user administration (see section “User and group administration”...

  • Page 164: The Main Kvp Function Menu

    BS2000 console mode Operating BS2000 instances Assigning a KVP ID IPL mnemonic console name X2000 ensures that a BS2000 console always exists, even when no-one has opened a BS2000 console screen. The relevant background process always runs under the KVP ID CONS0.
  • Page 165 Operating BS2000 instances BS2000 console mode Use the functions Ë and Ê to select one of the following functions. When you have selected the function, start the function with [ENTER]: 1 – Permit Input You can permit input again. The valid password will be requested. If you supply an incorrect password, the system will wait for approximately 6 seconds.
  • Page 166 BS2000 console mode Operating BS2000 instances 5 – Programmable Function Keys You can use this function to call up a menu to edit P keys or F keys: Programmable Function Keys Show - View PFKey Files and Contents Auto - Start/Stop Automatic Loading of PFKeys Load - Load PFKeys from File Unload...
  • Page 167 Operating BS2000 instances BS2000 console mode There are two options: – the “start” option: Programmable Function Keys: Options Automatically Load PFKeys start The “start” option immediately loads and activates the selected PFKeys for this session. A restart automatically loads and activates them for all other consoles with the same user ID.
  • Page 168 BS2000 console mode Operating BS2000 instances A rudimentary FMLI editor is available. Another X2000 editor can also be used for longer or more complex processing. Programmable Function Keys Show - View PFKey Files and Contents Auto - Start/Stop Automatic Loading of PFKeys Load - Load PFKeys from File Unload - Unload PFKeys...
  • Page 169 Operating BS2000 instances BS2000 console mode 6 – SVP Commands Selecting this option opens a window in which you can call SVP commands: SVP Commands - start BS2000 dipl - start BS2000 dump IPL vipl - start VM2000 vmmr - VM monitor restart iohdump - dump IOH memory iosdump - dump IOS memory chinit...

  • Page 170: Table 4: Message Texts With Message Code Svr0002

    BS2000 console mode Operating BS2000 instances Clear BS2000 memory [y|n]: y Clear BS2000 memory n Do not clear BS2000 memory The form is sent by pressing [SAVE]. When the IPL has been started, the console screen is automatically activated. Messages may be output which provide information on the state of the computer or on errors which may have occurred.
  • Page 171 Operating BS2000 instances BS2000 console mode dipl – start BS2000 dump IPL A form is opened to start BS2000: start BS2000 dump IPL IPL load device: consol device: IORSF level: IPL parameter [d|u]: clear BS2000 memory [y|n]: IPL parameter [d|u]: d SLED startup (default) u UNLOCK For further information, see the command...
  • Page 172 BS2000 console mode Operating BS2000 instances iohdump – dump IOH memory This command creates an IOHDUMP in the directory /var/opt/SMAW/X2000/dump. Name of the file: RMA_R.<abend code>.<DateTime>.<X2000 version> If no abend code is available, SLD000 is used. The number of IOHDUMPs is limited to ten. When the maximum number has been reached, the oldest file in the directory /var/opt/SMAW/X2000/dump is deleted.
  • Page 173 Operating BS2000 instances BS2000 console mode 7 – KVP Administrative Functions A window with the following functions appears: 2 KVP Administrative functions - show / print logging files 2 - create a new logging file 3 - KVP control functions Select the required function.
  • Page 174 BS2000 console mode Operating BS2000 instances – Start time/end time By default, the times of the first and last entries of the logging file are shown. You can specify a shorter time period by entering other times within the specified time frame.
  • Page 175 Operating BS2000 instances BS2000 console mode – Printer [CHOICES] opens a window in which you can select a printer. If only a small number of printers are available, no new window is opened. In this case, the name of a printer is entered directly in the form. By repeatedly pressing [CHOICES], you can select the required printer.
  • Page 176 BS2000 console mode Operating BS2000 instances Create a new logging file This function creates a new logging file. The old file is then closed. KVP control functions The window “System choice” is opened: 3 System choice system HV0 system VM2 Select a system.
  • Page 177 Operating BS2000 instances BS2000 console mode – Show-log – Show logging options You can display the currently valid logging options and the archiving command with this function. When you have selected the function, the information window “Show logging options” appears: Show logging options LOGGING OPTIONS: Virtual machine:...

  • Page 178: Figure 63: Screen Areas For The Cons0 Partner

    BS2000 console mode Operating BS2000 instances 7.2.3 Structure of the KVP screen The screen is divided as follows in the BS2000 console mode: Line KVP status line Lines 2-24 Dialog area (for dtterm: 2 - n) Line Status line of the operator terminal (for dtterm, this bar is omitted) CONS0 daphneADM...
  • Page 179 Operating BS2000 instances BS2000 console mode KVP status line In line 1, the KVP outputs status information. The status line has the following structure: hh:mm Name User Host yyyy-mm-dd KVP message Meaning Partner SYS (BS2000/OSD) All inputs are sent to the system which is currently running. KVP name User ID Mnemonic console name of the operator terminal as seen by BS2000/OSD...

  • Page 180: Inputs

    BS2000 console mode Operating BS2000 instances 7.2.4 Inputs KVP supports 97801 and dtterm terminals. A BS2000 operator terminal normally operates in output mode. Press a character key to switch to input mode. The cursor is positioned in the input line (line 24 on the screen). If the input line is not large enough, additional input lines are made available.

  • Page 181: Outputs

    Operating BS2000 instances BS2000 console mode 7.2.5 Outputs Outputs are made in the roll-up area (lines 2 through 23 on the screen, for dtterm 2 through n) in the order in which they arrive. You can switch to input mode at any time. Any outputs will then be blocked and output later.

  • Page 182: Figure 64: Opening A Bs2000 Dialog Box Under The Cde Interface Of The Smc

    EM9750 mode Operating BS2000 instances 7.3 EM9750 mode EM9750 mode makes the local BS2000 system available to you. You can also connect to a BS2000 partner computer. In this case, the communication software of your computer must be configured and loaded. You can work with the BS2000 software which is available (utilities, application programs) in this operating mode.

  • Page 183: Establishing A Connection With The Em9750 Emulation

    If SINIX-TE is used on the administration PC to display 97801 windows (especially to support Fujitsu Siemens emulation keyboards for BS2000), a corresponding session must be set up to the X2000 of a BS2000 partition by specifying the login em9750. In addition to the connection name and the host address of X2000, the connection type RLOGIN and the login em9750 must be specified as connection parameters.
  • Page 184 EM9750 mode Operating BS2000 instances List This function outputs a numbered list of pre-defined connections. The required connection is selected by positioning the cursor and pressing the key [CONNECT] (F3). If more pre-defined connections are available than are displayed, a further list is output by pressing the key [n].
  • Page 185 Operating BS2000 instances EM9750 mode You only need to enter the partner in the field “(N5) Personal Name”. Complete the entry with <CR> and press the key [CONNECT](F3). The name of the partner must previously have been defined in TNSX (see the manual “CMX V5.1 (Solaris)”...

  • Page 186: Table 5: Function Keys For The Terminal Type Dtterm

    EM9750 mode Operating BS2000 instances Notes on operation when the emulation is running The complete range of functions of the EM9750 emulation is described in the manual “EMDS (SINIX)” [23]. The terminal emulation used here is the same as the “Terminal emulation for the alpha- numeric workstation”...

  • Page 187: Table 7: Mf-Ii-Special Key Assignments (Emds)

    The EMDS function HC generates a copy of the entire screen via the printing program assigned to the function LA1. – The EMDS function SC generates a screen copy from the write mark onwards. 2. The following applies to terminal type 98701 (Operation with SINIX-TE and Fujitsu- Siemens Emulation keyboard): Shift DÜ1...
  • Page 188 EM9750 mode Operating BS2000 instances Configuring the 9750 emulation Should additional administration of the terminal stations be necessary, the program emadmin can be used (call under root, see the manual “EMDS (SINIX)” [23]). You should note that the user name of the terminal is re-generated at each call. U41272-J-Z385-3-76...

  • Page 189: Bs2000 $Dialog Mode

    Operating BS2000 instances EM9750 mode 7.3.2 BS2000 $DIALOG mode If you wish to work in $DIALOG mode, you must establish a connection to the $DIALOG partner in the target computer. Select the relevant function from the menu to control the connection.

  • Page 190: Bs2000 Transaction Processing Mode

    EM9750 mode Operating BS2000 instances 7.3.3 BS2000 transaction processing mode If you wish to work in transaction processing mode, you must establish a connection to the required application in the target computer. To establish a connection (see page 183), select “Manual Connection” from the menu (see page 184): Ê...

  • Page 191: Event Mode

    Operating BS2000 instances EVENT mode 7.4 EVENT mode General Operating tasks can be carried out simply in EVENT mode. Special EVENT commands offer the option of calling up information and storing diagnostics information. Messages output in EVENT mode are listed in the section “EVENT error messages”...

  • Page 192: Possible Event Commands

    EVENT mode Operating BS2000 instances 7.4.1 Possible EVENT commands You can display the valid EVENT commands together with the available parameters on screen: ev.? Ú Ê 7.4.2 Querying the version numbers of the installed X2000/Solaris software You can output the version numbers of the installed X2000/Solaris software: Ê...

  • Page 193: Mtc Devices

    Operating BS2000 instances EVENT mode 7.4.4 MTC devices Setting an occupancy option for MTC devices You can specify that an MTC device is also to be occupied whenever the X2000 communi- cation on BS2000 systems which can also use the device is disrupted: Ê...

  • Page 194: Permitting/Inhibiting Input And Changing A Password

    EVENT mode Operating BS2000 instances 7.4.6 Permitting/inhibiting input and changing a password [F2] opens a menu with operating functions: Event Function Menu - Permit Input 2 - Inhibit Input 3 - Change Password 4 - Exit The current screen window of the EVENT mode is moved into the background. Any outputs are written to a buffer and output on screen after the menu window has been exited.

  • Page 195: The X2000 User Interface

    8 The X2000 user interface The section “Notes on configuring PRIMEPOWER ServerView domains“ applies to SX servers with SMC (and not to the SX server entry-level models). The other sections below apply to all SX servers. The installation and operation of the graphical user interface of PRIMEPOWER ServerView are described in the manual “PRIMEPOWER ServerView Suite V2.2 –...

  • Page 196: Starting Primepower Serverview Suite

    Starting PRIMEPOWER ServerView Suite The X2000 user interface 8.2 Starting PRIMEPOWER ServerView Suite You can call PRIMEPOWER ServerView Suite in write mode or read mode. You should note that an application (e.g. VConfig or Bs2Devices) can only be called in write mode by one user in the domain at any one time.

  • Page 197: Figure 65: Example: Calling Primepower Serverview

    The X2000 user interface Starting PRIMEPOWER ServerView Suite The following screen shows calling PRIMEPOWER ServerView on the CDE interface of the SMC: Figure 65: Example: Calling PRIMEPOWER ServerView U41272-J-Z385-3-76...

  • Page 198: Figure 66: Icon For Java Web Start

    Starting PRIMEPOWER ServerView Suite The X2000 user interface Starting on the administration PC Operation via a browser, Java Web Start or PC application is explained in detail in the manual “PRIMEPOWER ServerView Suite V2.2 – System Administration within Domain” [5]. Only brief instructions on calling are given at this point. Start using the browser Start your browser.

  • Page 199: Figure 68: Java Web Start Application Manager

    The X2000 user interface Starting PRIMEPOWER ServerView Suite Figure 68: Java Web Start Application Manager Ê Select the application and click on the “Start” button. Start as a PC application via the PC’s start menu Start the PRIMEPOWER ServerView Suite via Start -> Programs -> PRIMEPOWER Ê...

  • Page 200: Figure 70: Primepower Serverview Welcome Screen

    Starting PRIMEPOWER ServerView Suite The X2000 user interface After the PRIMEPOWER ServerView Suite has been loaded first the name of the computer on which PRIMEPOWER ServerView is to be loaded is queried, plus the user ID and the associated password. Enter the data for the SMC here. If a user ID is employed which was created for an administrator role (see the section “User groups and logins”...

  • Page 201: Privilege Concept With Role-Based Access Control

    The X2000 user interface Privilege concept with Role-Based Access Control 8.3 Privilege concept with Role-Based Access Control The PRIMEPOWER ServerView Suite can be used with a standard user ID of the SX servers such as root, sxadmin, bs2admin or soladmin. However, a special ID without particular SCS rights can also be set up for this purpose.
  • Page 202 Privilege concept with Role-Based Access Control The X2000 user interface If the RBAC feature is activated in the PRIMEPOWER ServerView Suite when the user ID is created the user ID is assigned neither access rights to the applications of the PRIMEPOWER ServerView Suite nor to the nodes of the administration domain.

  • Page 203: Figure 72: Displaying And Modifying Authorizations In Primepower Serverview

    The X2000 user interface Privilege concept with Role-Based Access Control Figure 72: Displaying and modifying authorizations in PRIMEPOWER ServerView U41272-J-Z385-3-76...

  • Page 204: Figure 73: Modifying Access To The Individual Applications In Primepower

    Privilege concept with Role-Based Access Control The X2000 user interface Modifying access to individual applications Ê In the Applications table mark the relevant line by clicking in the Access column. A drop-down menu with the possible access rights then appears and you can select the option you require.

  • Page 205: Figure 74: The Bs2Devices User Interface

    The X2000 user interface X2000 BS2Devices main window 8.4 X2000 BS2Devices main window When you click the X2000 - Bs2Devices button, you see the Bs2Devices user interface: Menu bar Toolbar Object table Hierarchical browser Figure 74: The Bs2Devices user interface U41272-J-Z385-3-76...

  • Page 206: Table 9: Functions On The Menu Bar And Toolbar

    X2000 BS2Devices main window The X2000 user interface Menu bar and toolbar You can choose a variety of actions via the menu bar and the toolbar. Some of the functions are context-dependent and are not always available: if an action cannot be executed in a particular context then it is grayed.

  • Page 207: Figure 75: Example Selection Configurator

    The X2000 user interface X2000 BS2Devices main window The toolbar also contains the selection configurator: Figure 75: Example selection configurator Here you can enter regular expressions to restrict the set of objects for output. Hierarchical browser The hierarchical browser helps you to navigate within an administration domain and allows you to select either the entire domain or individual computers within it.

  • Page 208: Figure 77: Example Pull-Down Menu

    X2000 BS2Devices main window The X2000 user interface The object list is located below the tab bar. The type and number of the attributes it contains depend on the selected tab or subtab as well as on the selections you have made in the hierarchical browser and the selection configurator in the toolbar.

  • Page 209: Available Functions

    The X2000 user interface X2000 BS2Devices main window 8.4.1.2 Available functions Whether or not a function is available depends on a number of factors: Pull-down or context menu The two menus can show different functions from each other. The functions are dependent on which devices are currently highlighted (see below) and, in some cases, on which subtab has been selected (see below).

  • Page 210: Figure 79: Example Pull-Down Menu: "Volumes+Pubsets

    X2000 BS2Devices main window The X2000 user interface X2000-specific functions These functions are only available in the pull-down menu in the X2000 user interface. Figure 79: Example pull-down menu: “Volumes+Pubsets” Device-specific functions These functions apply to specific devices. They can only be called if one or more devices have been highlighted in the object list.

  • Page 211: Figure 81: "Bs2 Disks" Subtab

    The X2000 user interface X2000 BS2Devices main window X2000 Display and modify of general system information From X2000 V2.5 onwards, the menu items Mirror, CSR and PSR are integrated in the PRIMEPOWER ServerView application Tools and can be activated from this. Modify (A) Assign processors and main memory to the BS2000 and X2000 systems.
  • Page 212 X2000 BS2Devices main window The X2000 user interface Create (Aab) Configures a BS2000 disk on a selected disk partition. A disk partition is only proposed if it is unused. This means that it is: – not configured as a BS2000 disk, –...

  • Page 213: Figure 82: "Volumes+Pubsets" Subtab

    The X2000 user interface X2000 BS2Devices main window Volumes+Pubsets Configuration and initialization of pubsets and private disks for use under BS2000 and BS2000 installation Different functions are available depending on the properties of the highlighted objects and the selected subtab: Figure 82: “Volumes+Pubsets”...

  • Page 214: Figure 83: "Bs2 Tapes" Subtab

    X2000 BS2Devices main window The X2000 user interface BS2 Tapes Configuration of BS2000 tapes The functions are offered depending on the selected subtab: – Configured Tapes – Not configured Tapes Figure 83: “BS2 Tapes” subtab The BS2000 tape devices supported are described in the online help “BS2 tapes - Creating“ (for MBKs, see also section “Magnetic tape cartridge devices”...
  • Page 215 The X2000 user interface X2000 BS2Devices main window BS2 KVP When the tab BS2-KVP is activated, all configured KVPs (console distribution program) are listed. The KVP is responsible for the BS2 console inputs and outputs. A KVP always consists of 2 devices (write and read path), and in the event of modifications the write path must always be clicked.

  • Page 216: Figure 84: "Bs2 Printers" Subtab

    X2000 BS2Devices main window The X2000 user interface Evaluation of shutdown (X) If Solaris is terminated for any reason, then automatically the first action performed is to terminate BS2000. You can define a command of your choice (default: /shutdown) and a maximum wait time (default: 30 minutes) in this menu. BS2 Printers Configuration of printers Different functions are available depending on the selected subtab:...
  • Page 217 The X2000 user interface X2000 BS2Devices main window BS2 LAN Ports List of all configured LAN ports Create You can configure a BS2000 LAN port. Modify The highlighted BS2000 LAN port is displayed and can be modified. Delete The highlighted LAN ports are deleted. Diagnostics Diagnostic information for selected LAN ports can be displayed.

  • Page 218: Figure 85: Tools Button

    X2000 BS2Devices main window The X2000 user interface 8.4.2 X2000 tools main window When you click on the X2000 - Tools button the Tools interface appears (see figure 122 on page 332): Clicking on the Tools button offers the following functional areas: Figure 85: Tools button Mirror (X) Prepare and configure system disk mirroring...

  • Page 219: Figure 86: Online Help

    The X2000 user interface X2000 BS2Devices main window 8.4.3 Online help Button bar Tab bar Hierarchy window Help text Figure 86: Online help You can call the online help system in two ways: by choosing Help -> Contents in the menu by clicking the Help button in a window Every function window contains a Help button at the bottom right.
  • Page 220 X2000 BS2Devices main window The X2000 user interface Tab bar The Content and Index tabs are located above the left-hand display window. Depending on the selected tab, different information is displayed in the two output windows: “Contents” tab The left-hand window lists all the PRIMEPOWER ServerView Suite sections and subsec- tions for which relevant information can be found in the online help system.

  • Page 221: Global X2000 Functions

    9 Global X2000 functions 9.1 BS2000 disks: Configuration and BS2000 installation 9.1.1 Internal SCSI disk This chapter explains all the steps required to operate a brand new or partitioned internal SCSI disk as a BS2000 disk. An internal SCSI disk is in principle created as a D3475-8F disk.
  • Page 222 BS2000 disks: Configuration and BS2000 installation Global X2000 functions b) The slices on the disk can be configured individually as a BS2000 disk in the tab BS2 disks with the action Create. The format can also be changed individually with this action.

  • Page 223: Fibre Channel Disks (Raid Systems)

    Global X2000 functions BS2000 disks: Configuration and BS2000 installation 9.1.2 Fibre Channel disks (RAID systems) Two different disk types can be created on the Fibre Channel disks (for the usage scenarios section “Rules of usage for disks D3435 and D3475-8F” on page 230).

  • Page 224: Figure 87: Mirror Disks In A System

    Mirroring of internal disks in X2000 Global X2000 functions 9.2 Mirroring of internal disks in X2000 As of X2000 V2.5 this function is offered in the Tools application of the PRIMEPOWER ServerView Suite. To increase high availability of system disks, the system disk of the SX server is mirrored. The internal disks are here mirrored with the functions provided by “Solstice Disk Suite”.

  • Page 225: Figure 88: Menu Field "Mirror Configuration

    Global X2000 functions Mirroring of internal disks in X2000 9.2.1 PRIMEPOWER ServerView Suite interface Ê Click on the tab Tools. Select the function Mirror in the pulldown menu Tools. Ê The menu field Mirror configuration is opened: Figure 88: Menu field “Mirror configuration”“ U41272-J-Z385-3-76...

  • Page 226: Window Of The Boot Mirror Disk

    Mirroring of internal disks in X2000 Global X2000 functions This menu field has the actions required to administer a mirror boot disk: – Set up a mirror disk – Add a disk to the mirror system (page 227) – Remove a disk from the mirror system (page 227) –...
  • Page 227 Global X2000 functions Mirroring of internal disks in X2000 Add a disk to the mirror system To add one or two disks, select one or two free disk and then activate them by clicking Execute change. With the Allow larger disk option disks with a larger capacity than the system disk are also offered.

  • Page 228: Error Situations

    Mirroring of internal disks in X2000 Global X2000 functions 9.2.2 Error situations 9.2.2.1 Replacing a defective disk After a defective disk is replaced by the service engineer the disk must be logically removed from the mirror configuration then added to it again (see page 227).

  • Page 229: Additional Information For Disks

    Global X2000 functions Additional information for disks 9.3 Additional information for disks 9.3.1 Default partitioning of the root disk There are default partitionings of the system disk already defined for Solaris installations for X2000. The table below shows the division of 36 GB and 72 GB disks: Type Slice size in MB Comment...

  • Page 230: Table 10: Sharing (Sh) And Switching (Sw) Between System Types

    Additional information for disks Global X2000 functions 9.3.2 Rules of usage for disks D3435 and D3475-8F D3475-8F An LUN is divided into 1-7 slices of the same size. Here the BS2000 format (KEY, NK2, NK4) may be selected and configured. The disk can be initialized via PRIMEPOWER ServerView for BS2000 operation.

  • Page 231: Change Of Format From Disk D3435 To Disk D3475-8F

    Global X2000 functions Additional information for disks 9.3.3 Change of format from disk D3435 to disk D3475-8F Change of format from D3475-8F to D3435 or from D3435 to D3475-8F: 1. The BS2000 disks in the BS2000 must first be detached. These disks must then be deconfigured (deleted) on all the X2000s by means of BS2 devices or BS2 disks (All).

  • Page 232: Magnetic Tape Cartridge Devices

    Magnetic tape cartridge devices Global X2000 functions 9.4 Magnetic tape cartridge devices Multiple systems can be granted access to the same magnetic tape cartridge device in a “Storage Area Network” (SAN). Such an environment requires the connected systems to be synchronized.

  • Page 233: Basic Conditions For Configuration

    Global X2000 functions Magnetic tape cartridge devices 9.4.1 Basic conditions for configuration 1. The X2000-based BS2000 systems which are able to access the MTC device in the SAN must be administered via a joint PRIMEPOWER ServerView management server (this means among other things: the DomainAdmin product of the PRIMEPOWER ServerView Suite must be installed on these systems).

  • Page 234: Figure 89: X2000 Window For Configuring A Bs2000 Tape Device

    Magnetic tape cartridge devices Global X2000 functions 9.4.2 Configuring an MTC device There are two steps involved in configuring an MTC device in the PRIMEPOWER ServerView application Bs2Devices : 1. The MTC device must be configured as a BS2000 device at each system (= Node in PRIMEPOWER ServerView node) from which it is accessible (BS2 Tapes ->...

  • Page 235: Figure 90: X2000 Window For Reconfiguring A Bs2000 Tape Device

    Global X2000 functions Magnetic tape cartridge devices 2. In the second step, the MTC device must be configured with one of the systems from the first step (BS2 Tapes -> Modify): Figure 90: X2000 window for reconfiguring a BS2000 tape device The Switch area of the window contains the following boxes: The Switched nodes box lists those BS2000 systems which see the MTC device as a shared device...
  • Page 236 Magnetic tape cartridge devices Global X2000 functions Notes – You are recommended to configure devices before the BS2000 involved are started. If a device is configured while a BS2000 system is in operation, an ATTACH-DEVICE takes place automatically in this syxstem after the first step. This must be undone with a manual DETACH-DEVICE as the second step cannot be performed while the device is in the ATTACHED state.

  • Page 237: Adding A Bs2000 System After Initial Configuration

    Global X2000 functions Magnetic tape cartridge devices 9.4.3 Adding a BS2000 system after initial configuration The MTC device may not be used between the physical connection of the new system and completion of configuration. If you subsequently want to connect an additional BS2000 system in the SAN to the MTC device then you must repeat the two steps described on page 234 in PRIMEPOWER...
  • Page 238 Magnetic tape cartridge devices Global X2000 functions Case B: X2000 not running In PRIMEPOWER ServerView, remove the BS2000 system from the Switched nodes box by using one of the remaining BS2000 systems. Under normal circumstances modifying the configuration in this way is only possible when the system is communicating with all the other BS2000 systems on the list in the Switched nodes box on the X2000 level.

  • Page 239: Occupying An Mtc Device When X2000 Communication Is Disrupted

    Global X2000 functions Magnetic tape cartridge devices 9.4.5 Occupying an MTC device when X2000 communication is disrupted In normal circumstances an MTC device can only be occupied by a BS2000 system for use when the BS2000 systems in the Switched nodes list can communicate with each other on the X2000 level.

  • Page 240: Displaying The Occupancy Status Of An Mtc Device

    Magnetic tape cartridge devices Global X2000 functions 9.4.6 Displaying the occupancy status of an MTC device The following EVENT command (see also section “MTC devices” on page 193) displays the occupancy status of an MTC device for the BS2000 systems on the Switched nodes list: sx.bs2mtcfetch -l tape-MN List option.
  • Page 241 Global X2000 functions Magnetic tape cartridge devices The following abnormal statuses are also reported: – disconnected or permission denied It is not possible to communicate with the BS200 system on the X2000 level. Possible causes: – X2000 is not able to respond within a set time period. –...

  • Page 242: Configuring Printers

    Configuring printers Global X2000 functions 9.5 Configuring printers 9.5.1 Configuring Xprint printers You configure Xprint printers in the Mercator graphical user interface. You can operate Mercator: – via the hardware console (SMC) of the SX server – via a PC with an X user interface For information on installing and operating the Mercator graphical user interface, see the manual “Xprint Management V6.0A GUI”...

  • Page 243: Figure 91: Mercator Welcome Screen

    Global X2000 functions Configuring printers You now see the welcome screen: Figure 91: Mercator welcome screen After a few seconds the first selection screen for configuration and administration is displayed. You can only perform administrative activities with Mercator if Xprint is running. If it is not, a message at the bottom of the first selection screen informs you that Xprint is not available.

  • Page 244: Figure 92: Mercator Configuration And Administration Window

    Configuring printers Global X2000 functions 9.5.1.2 Configuring a new printer Figure 92: Mercator configuration and administration window Left-click on the printer icon. Ê U41272-J-Z385-3-76...

  • Page 245: Figure 93: Mercator Printer Configuration Window (Basic)

    Global X2000 functions Configuring printers Choose Operations -> New. Ê A screen (Basic) in which you can configure a new printer is now displayed: Figure 93: Mercator printer configuration window (Basic) Enter the following: Ê – Printer name – IP address –...

  • Page 246: Figure 94: Mercator Printer Configuration Window (Connection)

    Configuring printers Global X2000 functions Click Connection. Choose LAN as the connection type Ê Figure 94: Mercator printer configuration window (Connection) U41272-J-Z385-3-76...

  • Page 247: Figure 95: Mercator Printer Configuration Window (Configuration)

    Global X2000 functions Configuring printers Click Configuration. You can define the required printer type via the PCL definition: Ê Figure 95: Mercator printer configuration window (Configuration) The table below indicates the printer type, emulation and PCL which can also be used as BS2000 spool printers or emulated TRANSDATA printers (see section “Configuring a BS2000 printer”...

  • Page 248: Figure 96: Mercator Window With Xprint Database (Printer Inactive)

    Configuring printers Global X2000 functions When you click the OK button, the settings are taken over into the Xprint database and the printer is displayed in graphical form in the first selection screen. In this screen, the printer icon is blurred and displayed with a broken connection since the printer is not yet active: Figure 96: Mercator window with Xprint database (printer inactive) The display of the new printer is delayed for approximately ½...

  • Page 249: Figure 97: Mercator Printer Configuration Window (State)

    Global X2000 functions Configuring printers Double-click the icon corresponding to the new printer. Ê This re-opens the configuration screen (State) in which you can set the printer to active. You can also make changes to the configuration. Figure 97: Mercator printer configuration window (State) U41272-J-Z385-3-76...

  • Page 250: Figure 98: Mercator Window With Xprint Database (Printer Active)

    Configuring printers Global X2000 functions After this, the printer icon is sharp and the line representing the connection is no longer broken: Figure 98: Mercator window with Xprint database (printer active) U41272-J-Z385-3-76...

  • Page 251: Configuring The Seh Printserver

    Global X2000 functions Configuring printers 9.5.2 Configuring the SEH Printserver In SX systems, printers are connected via an adapter produced by the company SEH, the so-called SEH Printserver. This print server may take the form of a separate adapter box (e.g.

  • Page 252: Figure 99: X2000 User Interface For Creating A Bs2000 Printer

    Configuring printers Global X2000 functions 9.5.3 Configuring a BS2000 printer You can create, modify or delete emulated BS2000 printers via the X2000 graphical user interface under PRIMEPOWER ServerView. You choose BS2 Printers -> Create to generate a new BS2000 printer (local spool printer) or an emulated TRANSDATA printer which can be used via RSO: Figure 99: X2000 user interface for creating a BS2000 printer U41272-J-Z385-3-76...

  • Page 253: Figure 100: X2000 Window For Creating A Bs2000 Printer

    Global X2000 functions Configuring printers When you select BS2000 printer, the Create a new BS2000 printer window opens: Figure 100: X2000 window for creating a BS2000 printer Node Computer node on which the BS2000 printer is to be set up. Name Here, you specify the name of a printer which is configured in the UNIX system and which is to be used for print output by the...

  • Page 254: Figure 101: X2000 Window For Creating A Transdata Printer

    Configuring printers Global X2000 functions active If you check this box then the emulation is activated immediately. If not, the device is simply declared to the BS2000 system. An entry is made in the SERSFILE (every minute) if the device is attached in the BS2000 system but not activated. Communication Only for serial device connections (not relevant for SX servers).
  • Page 255 Global X2000 functions Configuring printers Node Computer node on which the Transdata printer is to be set up. Name Here, you specify the name of a printer which is configured in the UNIX system and which is to be used for print output by the emulation.

  • Page 256: Figure 102: X2000 User Interface (Bs2000 Printer) Following Printer Configuration

    Configuring printers Global X2000 functions In the example below, a print station with the name E9017#00, operated in unbuffered mode without character conversion, is set up on the computer bari1. The UNIX printer p9017 is used as the physical device. -seh is specified in the Emulation options. This tells the printer emulation to communicate with the printer via the so-called RSO spool protocol and to use port number 2900 (print security!).

  • Page 257: Starting Up An Emulated Bs2000 Printer

    Global X2000 functions Configuring printers 9.5.4 Starting up an emulated BS2000 printer 1. Define the BS2000 printer using the SPSERVE administration program and specify the parameter values (ADD-SPOOL-DEVICE function) Example for printer type LP-EMUL DEVICE-NAME=P1 DEVICE-TYPE=lp-emulated-printer DEVICE-ACCESS=local-access( ACCESS-TYPE=bus-type-1 MNEMONIC-NAME=P1) Example for printer type xxx-REMOTE-PRINTER (user-definable name) DEVICE-NAME=DRV001 DEVICE-TYPE=*9014-REMOTE-PRINTER...

  • Page 258: Using Printer-Specific Functions With The Bs2000 Printer Type Lp-Emul

    Configuring printers Global X2000 functions 9.5.5 Using printer-specific functions with the BS2000 printer type LP-EMUL The BS2000 printer type LP-EMUL can be used to operate a number of different physical printer types (needle, ink jet, band and laser printers). In order to use the special characteristics of the connected printer, it is necessary to send not only the print data itself but also the control characters (or control character sequences) designed for precisely this printer type.

  • Page 259: Table 11: Operating Mode For Printers Equipped With Cutters

    Global X2000 functions Configuring printers The following commands are defined: DRAFT Sets draft mode Sets letter quality PORTRAIT Sets portrait format LANDSCAPE Sets landscape format CPI=nn Sets the character width: nn = 10, 12, 15 or 17 CPI = characters per inch LAN=cs Sets a country-specific character set in the printer.

  • Page 260: Emulation Options For Controlling The X2000 Printer Emulation

    Configuring printers Global X2000 functions 9.5.6 Emulation options for controlling the X2000 printer emulation You can use the emulation options to enable certain functions in the printer emulation. Some of these are required for diagnostic purposes whereas others may be useful or necessary for operation.
  • Page 261 Global X2000 functions Configuring printers A country-specific character set is selected in the printer. -lan=cs Possible values for cs are: Standard international Standard Ascii German English Danish French Italian Spanish Dutch Norwegian Swedish Finnish Cyrillic -spool The X2000 printer emulation makes it possible to gather the print data for a print job in a file instead of sending it to a physical printer.
  • Page 262 Configuring printers Global X2000 functions Example script #Print data from print file via Xprint to the printer # hpljlan # Print command xpadd with parameter -cp (Xprint creates # copy of file) xpadd -dr $1 -de hpljlan -cp # Delete print data file rm $1 If multiple emulated printers are configured and these are to output their data at different physical printers then the script can be extended as follows:...
  • Page 263 Global X2000 functions Configuring printers started and the printer is activated. Printer malfunctions are detected if Xprint itself detects a printer fault or if the number of queued print jobs exceeds a user-defined value. If a fault is present or is likely due to the excessive queue length then the RESERVE-CCW is acknowledged with an equipment check error.

  • Page 264: Local And Remote Communications

    Local and remote communications Global X2000 functions 9.6 Local and remote communications 9.6.1 ATNS The transport system permits both local communications between the BS2000 processor (general processor) and the Solaris processor and network-wide communication via the Solaris processor. The names of the locally communicating applications are automatically set up via the ATNS functions.
  • Page 265 Global X2000 functions Local and remote communications BS2000 standard applications The ATNS uses the file /etc/opt/SMAW/X2000/tnsrem_data to create the TNS entries for local BS2000 standard applications. The call is issued automatically after the successful configuration of a local BS2000 communication device (LAN port). If the file /etc/opt/SMAW/X2000/tnsrem_data is not present, it is generated automatically when ATNS is called and contains the following default values: $FJAM005...

  • Page 266: Example Of Setting Up A Connection

    Local and remote communications Global X2000 functions 9.6.1.2 Example of setting up a connection After system installation: Connections from the local X2000 system to all the BS2000 standard applications can be established via the preconfigured BS2000 communication devices. – LAN port (LOCLAN) LBS20$DIALOG must be entered as the connection partner in the EMDS.
  • Page 267 Global X2000 functions Local and remote communications All LOCLAN connections at the X2000 use the interface SMAWLnet0. The default IP address 192.168.138.12 is assigned to this interface. Any change to the IP address for the interface SMAWLnet0 consequently affects all LOCLAN connections.

  • Page 268: Loclan Between Guest Systems

    Local and remote communications Global X2000 functions 9.6.2.2 LOCLAN between guest systems Connections between the local X2000 and the local BS2000 via TCP/IP can be used by means of LOCLAN. This connection is emulated by X2000. If LOCLAN is used, the packet size may be up to 64 kbytes.

  • Page 269: Figure 103: Example Of Creating A New Bs2000 Lan Device

    Global X2000 functions Local and remote communications Example of VM2 guest system Figure 103: Example of creating a new BS2000 LAN device The same applies to all other guest systems. Configuration in VM2000 The communication devices must be assigned to the appropriate guest system.This is done, using the example above, by entering the following VM2000 administration commands: /ADD-VM-DEVICES (Y0,Y1),VM-ID=1...
  • Page 270 Local and remote communications Global X2000 functions The basic SOF file $TSOS.SOF.SX2000, which contains the entries for LOCLAN and LOCSIN, is shipped with the pre-installed standby system. For VM1: /DCOPT HOST=TESTVM1,... /BCOPTION BROADCAST=ON,ARP=ON /CREATE-NODE NODE-NAME=LOCLAN /CREATE-LINE LINE-NAME=LOCLAN,IP-ADDRESS=192.168.138.002,- L2-PROTOCOL=*CSMACD(NODE-NAME=LOCLAN,- MAX-LPDU-SIZE=*BY-DEVICE,- WRITE-DEVICE=Y0,READ-DEVICE=Y1) /BCACT NODE=LOCLAN /ACTIVATE-LINE LINE=LOCLAN /CREATE-PROC PROC-NAME=LOCSIN...

  • Page 271: Zaslan

    8232 bytes. All the configuration possibilities for the fjgi driver are contained in the “FUJITSU PCI GigabitEthernet User's Guide”. This Guide is present as an online manual in the FJSVged driver package on the Control CD. The predecessor was fjge with the corresponding fjge driver and analog configuration...
  • Page 272 Local and remote communications Global X2000 functions BS2000 /CREATE-NODE ../CREATE-LINE ..,L2-PROTOCOL=*CSMACD(...,MAX-LPDU-SIZE=*BY-DEVICE) /CREATE-PROCESSOR ... /CREATE-ROUTE ..,L3-PROTOCOL=*IP(...) /BCACT ... The following restrictions must be borne in mind when operating this configuration. All the network components (switches, routers etc.) and all terminals must be configured with this setting.

  • Page 273: Diagnostics For Lan Ports

    Global X2000 functions Local and remote communications You must ensure that the device pairs (G4, G5) and (J4, J5) are located on different system boards. Meadia monitoring must be activated in X2000 (in PRIMEPOWER ServerView Suite): BS2Devices application --> BS2 LAN Ports tab --> Configuration menu item --> Monitoring tab).

  • Page 274: Offline Psr

    Offline PSR Global X2000 functions 9.7 Offline PSR 9.7.1 Scope of function PSR is a tool for the physical backup and restoring of data. Disks or individual slices of these disks can be written onto a backup medium and later read again from it. PSR is operated on-line via PRIMEPOWER ServerView (see section “Functions”...

  • Page 275: Operation Of The Off-Line Psr

    Global X2000 functions Offline PSR 9.7.2 Operation of the off-line PSR In the off-line mode PSR is operated via its own Curses-based interface. The operation runs in the English language. 9.7.2.1 Starting the off-line PSR PSR in SX entry-level models Prerequisites: The CD0 of the Solaris installation record is required for off-line operation.
  • Page 276 Offline PSR Global X2000 functions e) Start PSR off-line with the following command: /tmp/psr The procedure first sets the TERM variable for the SUN console, then calls PSR. PSR logs on with the basic menu. PSR on SX servers with SMC Prerequisites: A correctly installed SMC, with built-in DAT disk drive, is required for the off-line mode.

  • Page 277: Figure 104: Basic Menu Of The Off-Line Psr

    Global X2000 functions Offline PSR 9.7.2.2 The basic menu PSR-X V3.0A Physical Save & Restore Oct 21 2004 Function Selection >Save Restore Copy Check Label Quit Use CURSOR to move, ENTER to select, CTRL c to abort Figure 104: Basic menu of the off-line PSR In the left field the header (1) contains the version and date of generation of the PSR.

  • Page 278: Figure 105: Slice Selection

    Offline PSR Global X2000 functions 9.7.2.3 Save PSR-X V3.0A Save Oct 21 2004 Disk c0t1d0s0 70086.972 MB Disks Slices c0t0d0s0 >ROOT SWAP BACKUP >c0t1d0s0 BS2000 BS2000 BS2000 BOOT Use CURSOR to move, SPACE to select, ENTER to confirm, CTRL c to abort Use TAB to skip between disk &...

  • Page 279: Figure 106: Selection Of The Tape Device

    Global X2000 functions Offline PSR After completion of the disk/slice selection, select the tape device (see figure 106). The backup can then be started. PSR-X V3.0A Save Oct 21 2004 Tape Selection: /dev/rmt/0cn Tapes IBM 3590 15GB >SEAGATE DAT Use CURSOR to move, ENTER to select, CTRL c to abort Figure 106: Selection of the tape device The backup is carried out by slices.The data is read, the CRC checksum is calculated and written onto tape.

  • Page 280: Restore

    Offline PSR Global X2000 functions 9.7.2.4 Restore Restoring a disk from the tape takes place in the same way as saving, only in the reverse order. The menu for selecting the tape device (see figure 106) is first called. After a device has been selected the tape archive is read and the menu for disk or slice selection displayed (see figure...

  • Page 281: Figure 108: Setting A Disk Copy Under Psr

    Global X2000 functions Offline PSR 9.7.2.5 Copy In the off-line mode PSR enables the disk copying; the full content of a hard disk can be copied to another hard disk. To do this, select the hard disk to be copied in the same way as you would if you were saving.

  • Page 282: Check

    Offline PSR Global X2000 functions 9.7.2.6 Check Unlike Restore, the Check function only checks the CRC checksum of the data read. However, there is no rewriting onto the disk. 9.7.2.7 Label The Label function is used to identify backup tapes. Every tape written by PSR is identified by a unique label consisting of the following sections: –...

  • Page 283: Supported Hardware

    SCSI connection 3591 (Magstar) EF Fibre Channel connection Supported disk drives: All disks which are released for the entry-level models of the SX series are supported in online and offline mode. 9.7.3.2 System type SX server with SMC Supported tape drives:...
  • Page 284 Offline PSR Global X2000 functions U41272-J-Z385-3-76...

  • Page 285: Dynamic Reconfiguration

    10 Dynamic Reconfiguration The “Dynamic Reconfiguration” (DR) functionality described in this section exists on BS2000 partitions of SX servers as of the SX150 model series, both native BS2000 and VM2000 being able to run in a BS2000 partition. Dynamic Reconfiguration of Solaris partitions is possible as already on servers of the SX130 and SX140 model series.
  • Page 286 Functional scope, concepts and applications Dynamic Reconfiguration The benefits of extended partitioning (XPAR) compared to physical partitioning (PPAR, based on the physical system board mode (PSB mode)) are as follows: Greater flexibility The smaller hardware granularity means that greater flexibility is achieved on the SX150 servers in the event of changing utilization of the hardware resources by the partitions.
  • Page 287 SX server configuration in such a way that the required DR scenarios are possible. Depending on the planned application scenario for DR, the configuration of the standard SX150 models may need to be expanded. To do this, please contact your sales representative at Fujitsu Siemens Computers GmbH. U41272-J-Z385-3-76...

  • Page 288: Applications For Dr And Recommendations

    Functional scope, concepts and applications Dynamic Reconfiguration 10.1.2 Applications for DR and recommendations Dynamic Reconfiguration can always be used during ongoing operation in the following cases: – Global resource management / dynamic workload distribution between partitions – CoD (Capacity on Demand) –...
  • Page 289 Dynamic Reconfiguration Functional scope, concepts and applications CoD (Capacity on Demand) Capacity on Demand (CoD) makes additional CPU power available when required in the context of purchased licenses. This is possible on the one hand when there are extra CoD-CPUs installed on the XSBs used by the partition in addition to the CPUs purchased.
  • Page 290 Functional scope, concepts and applications Dynamic Reconfiguration In both cases the same DR method (DR-connect) is used in order to reconnect the XSBs of the repaired or replaced system boards and thus restore the original status. It may be necessary to put the XSBs from the other partitions back into operation. Cross-partition DR concept The DR applications described the general recommendation applies that the DR concepts for the individual partitions of a system must be harmonized with each other:...

  • Page 291: The Dr Concept For Bs2000

    Dynamic Reconfiguration Functional scope, concepts and applications 10.1.3 The DR concept for BS2000 The DR processes in BS2000 partitions are performed at Solaris level, either from the graphical interface PRIMEPOWER ServerView or using the command interface. DR of XSBs in BS2000 partitions is supported in X2000 and BS2000/VM2000 by functions which relieve the user of many important tasks.
  • Page 292 Functional scope, concepts and applications Dynamic Reconfiguration 4. Releasing any “extra” CPUs which are used: – In the case of native BS2000 with /DETACH-DEVICE UNIT=*EXTRA-CPU(*ALL) – In the case of VM2000 with /DETACH-VM-RESOURCE UNIT=*EXTRA-CPU(*ALL) 5. Initiating the DR process (from PRIMEPOWER ServerView or using a command). With DR-disconnect the functions for DR support in X2000 and BS2000/VM2000 provide the configuration modifications which are necessary to withdraw the resources of the XSB affected from the system.

  • Page 293: Requirements For Dr

    Dynamic Reconfiguration Functional scope, concepts and applications 10.1.4 Requirements for DR With the requirements for DR a distinction is made below between the hardware and configuration requirements and the situation-dependent requirements. Hardware and configuration requirements Distribution of the XSBs of each partition to 2 physical system boards. The options are model-dependent (for details please also see table 17 on page 403).
  • Page 294 Functional scope, concepts and applications Dynamic Reconfiguration Redundant connection of the BS2000 devices on both system boards: The XSB may not contain the only or last path to a device – in particular the home pubset must be taken into account here – which cannot be placed in the DETACHED state.
  • Page 295 Dynamic Reconfiguration Functional scope, concepts and applications – In the case of DR-disconnect no “extra” CPU may be connected in BS2000/VM2000. No parallel actions Configuration measures which are performed in parallel to a DR process can prevent the DR process from running successfully. The same applies for Solaris applications which access the resources of an affected XSB in parallel to a DR process.

  • Page 296: An Example Of The Dr Scenarios

    Functional scope, concepts and applications Dynamic Reconfiguration 10.1.5 An example of the DR scenarios In this example an SX150 server with one BS2000 and one Solaris partition and a free XSB is used. The following is assumed here: The BS2000 partition (model variant SX150-40C) is configured as follows: XSB 00-0: 1 CPU, 8 GB memory;...

  • Page 297: Figure 109: Example Of An Sx Server With Dr Capability

    Dynamic Reconfiguration Functional scope, concepts and applications System Board 00 System Board 01 BS2 BS2 PCI Slots PCI Slots PCI Slots PCI Slots PCI Slots PCI Slots 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7...
  • Page 298 Functional scope, concepts and applications Dynamic Reconfiguration These CoD-XSBs can only be used as CPU-XSBs. To permit dynamic disconnection of the CoD-XSBs from the BS2000 partition later, no-obp-sb, no-mem-sb and no-io-sb must be set for them. For details see the section “Settings relevant to DR”...

  • Page 299: Figure 110: Online Maintenance: Temporary Operation (Until Online Maintenance)

    Dynamic Reconfiguration Functional scope, concepts and applications 1. Temporary operation (until online maintenance) with reduced resources The entire procedure is illustrated with the figure below (CPU and memory values relate to BS2000): Restricted Restricted Normal operation Normal operation operation 1 operation 2 3 CPUs, 6 GB 1 CPU, 6 GB...

  • Page 300: Figure 111: Online Maintenance: Temporary Operation (Until Online Maintenance)

    Functional scope, concepts and applications Dynamic Reconfiguration 2. Temporary operation (until online maintenance) of theCPUs of CoD-XSB The failure of hardware resources can be compensated for in part by puting the CPUs of XSB 01-1 into operation. The entire procedure is illustrated with the figure below: Restricted Restricted Normal operation...

  • Page 301: Figure 112: Online Maintenance: Permanent Use Of All Resources Of The Cod-Xsb

    Dynamic Reconfiguration Functional scope, concepts and applications 3. Permanent use of all resources of the CoD-XSB The failure of hardware resources can be compensated for fully by puting XSBs 01-3 into operation with all its resources. The entire procedure is illustrated with the figure below: Normal operation Normal operation Normal operation...
  • Page 302 Functional scope, concepts and applications Dynamic Reconfiguration Important notes – In this scenario the roles of XSBs 00-0 and 01-1 are swapped. – XSB 01-3, which was originally kept in reserve, initially remains in the partition. – The original boot-XSB 00-0 is initially not put into operation; it can take on the role of the CoD-XSB.

  • Page 303: Performing Dr

    Dynamic Reconfiguration Performing DR 10.2 Performing DR The sections below describe the DR interfaces of the administrative interface PRIMEPOWER ServerView and the DR command interface. These are then followed by a description of further details and constraints relating to DR. The XSB attributes “integrated”...

  • Page 304: Figure 113: Outputting An Overview Of Partitions And System Boards (Example)

    Performing DR Dynamic Reconfiguration 10.2.1 Administrative interface PRIMEPOWER ServerView In the administrative interface PRIMEPOWER ServerView the functions required for DR are offered within the VConfig application. Creating an overview of partitions and system boards The assignment of the system boards (XSBs) to the partitions is output by activating the subtab Systemboards DR in the Boards tab of the VConfig application.
  • Page 305 Dynamic Reconfiguration Performing DR Initiating the DR process The basic actions DR-connect and DR-disconnect are always performed in the partition for which they apply, and this independently of whether they are initiated in PRIMEPOWER ServerView within the partition or on the SMC. DR-connect and DR-disconnect are initiated by selecting the relevant XSB (designates the system board) and one of the actions Connect, Disconnect or Hot Swap in the Systemboards DR subtab of the Boards tab in the VConfig application.

  • Page 306: Figure 115: Removing An Xsb (Example)

    Performing DR Dynamic Reconfiguration In the example below XSB 01-1 (here named Systemboard_1-1) is removed immediately (Disconnect immediatly option) and not assigned to another partition but to the pool of free XSBs. Figure 115: Removing an XSB (example) Notes The Disconnect at next reboot option (alternative to the Disconnect immediatly option) is the equivalent of the -reset parameter in the drc command.

  • Page 307: Figure 116: Shifting An Xsb (Example)

    Dynamic Reconfiguration Performing DR DR-connect integrates the XSB in this receiving partition. The Move action is a cross-partition action comprising one of the simple actions DR-connect and DR-disconnect and is only possible on the SMC in PRIMEPOWER ServerView. The action is started for the partition which releases the XSB. Example Figure 116: Shifting an XSB (example) In the above example XSB 00-1 (here named Systemboard_0-2) is removed from the node...

  • Page 308: The Command Interface

    Performing DR Dynamic Reconfiguration 10.2.2 The command interface The commands described below can only be executed under the root ID and in the partition(s) concerned. Information functions – Partitions, system boards and associated resources 1. /opt/FJSVhwr/sbin/drcstat -board [all] -xpar command lists the system boards of the machine and their configuration drcstat statuses in the partitions (current partition, next partition after a Partition Solaris reboot).
  • Page 309 Dynamic Reconfiguration Performing DR 2. x2prtpci [-v] command lists, in compact form, the system boards, PCI bus processors x2prtpci (UPA bridges), PCI cards, ports on the PCI cards, and SCSI devices of the home partition. If the option is not specified, the list does not include ports and SCSI devices. The first line in the list has the following format: system1(01): 00-0 (80 81) 00-1 (a2) 01-3 (ee) Name of the partition...
  • Page 310 Please wait ..danteADM(00): 00-0 (80 81) 01-1 (aa) 01-2 (cc cd) 01-3 (ee) (PCIOB#0 at Cabinet#0,SCFA#0) 0 /pci@80,4000/network@1,1 (SCFA#0 at Cabinet#0) 0 /pci@80,4000/scsi@4 FUJITSU MAP3735NC FUJITSU MAP3735NC 1 /pci@80,4000/scsi@4,1 (PCI#01 at Cabinet#0,SCFA#0)
  • Page 311 Dynamic Reconfiguration Performing DR 3. bs2drstat [sb<SB-Name>] command lists the BS2000 resources which are lost in the partition due to bs2drstat DR-disconnect of the system board and specifies whether the DR-disconnect is possible from the X2000 viewpoint. If the command is called without an argument a menu for selecting the system board is offered.
  • Page 312 Performing DR Dynamic Reconfiguration Action functions – Initiating the DR process /opt/FJSVhwr/sbin/drc Depending on the parameters specified, the drc command initiates DR-connect or DR-disconnect for the specified XSB. The following parameters are supported: /opt/FJSVhwr/sbin/drc -connect sb<SB-Name> [-reset] /opt/FJSVhwr/sbin/drc -disconnect sb<SB-Name> [-reset] /opt/FJSVhwr/sbin/drc -disconnect sb<SB-Name>...

  • Page 313: Execution Of Dr, Diagnosis And Problem Handling

    Dynamic Reconfiguration Performing DR The -reset parameter controls immediate reconfiguration of reconfiguration via a reboot: – If the -reset parameter is not specified, the reconfiguration process is initiated immedi- ately. – If the -reset parameter is specified, the reconfiguration process is planned for the next time Solaris is rebooted.
  • Page 314 Performing DR Dynamic Reconfiguration Dialog with the user In a BS2000 partition a dialog with the user takes place when the -keep option is specified. The following question must be answered here: option is only used for system board hotswap operation. Continue ? [YES]/[NO] Trailer run and delays After the phases described above have been completed a trailer run takes place in the background in which the information about the DR process is distributed over the entire...
  • Page 315 Dynamic Reconfiguration Performing DR Canceling the DR lock In special situations (e.g. in the event of an abnormal shutdown procedure or SETS) BS2000/VM2000 sets a DR lock so that a SLED can be executed after shutdown. If the lock is set, DR aborts in the preadd/preremove phase with the following message: Current BS2000 state does not allow DR If for example a SLED is to be executed, the lock can be canceled with the following command:...

  • Page 316: Dr Runs In Bs2000

    Performing DR Dynamic Reconfiguration 10.2.4 DR runs in BS2000 DR processes are always initiated and executed at Solaris level. In BS2000/VM2000 no measures or actions are needed; the CPUs are automatically disconnected or connected in accordance with the licenses. The start and end and all BS2000 reconfiguration actions of a DR run are reported on the console in BS2000 or VM2000.
  • Page 317 Dynamic Reconfiguration Performing DR Further information on BS2000 During DR CPUs are attached and detached automatically and implicitly provided the existing licenses permit this. CPUs which are licensed in BS2000 but are located on XSBs which are not attached at a point in time are nevertheless reported by X2000 and displayed in BS2000 with the DET(EX)/OFF status.
  • Page 318 Performing DR Dynamic Reconfiguration If a DR action is rejected by BS2000/VM2000, all configuration changes made up to then are automatically undone. Exception: Owing to the length of time it takes separate mirror disks are not resynchronized. If during a DR-disconnect action im BS2000 a ZASLAN device is deactivated for which automatic reactivation has been enabled (SLOW-POLL=*ON), this results in constant attempts to reactivate the device.
  • Page 319 Dynamic Reconfiguration Performing DR Virtual CPUs are implicitly reconfigured by VM2000 when Dynamic Reconfiguration (attachment or detachment of real CPUs) takes place. If for a VM the number of active virtual CPUs has become greater than the number of attached real CPUs in the associated CPU pools, excess virtual CPUs are implicitly detached.
  • Page 320 Performing DR Dynamic Reconfiguration Further information on MSCF As of Version 15.0 (component part of OSD/XC V2.0) HIPLEX MSCF automatically supports Dynamic Reconfiguration. This excludes the possibility of inadvertent failure detection (caused by the absence of the sign-of-life signals during DR). In terms of MSCF DR runs as follows: Start of Dynamic Reconfiguration The system requests the “Cluster Recovery Lock”...

  • Page 321: Settings Relevant To Dr

    Dynamic Reconfiguration Performing DR 10.2.5 Settings relevant to DR The settings relevant to DR and hardware requirements which are described in the following are set ex works or automatically by the X2000 carrier system and need not be configured by the customer. This description is therefore only intended for information purposes and is restricted to the main aspects.

  • Page 322: Table 12: Settings In Primepower Serverview And Corresponding Obp Settings

    Performing DR Dynamic Reconfiguration Examples 1. Specifying a setting for 2 XSBs: eeprom no-mem-sb="01-1 01-2" 2. Resetting the setting for XSB 01-1: eeprom no-mem-sb="01-2" (The OBP parameter is supplied with a value from the Rest list.) 3. XSB 01-2 becomes the CPU-XSB by specifying all 3 settings: eeprom no-mem-sb="01-2"...

  • Page 323: Figure 117: Primepower Serverview: Modifying Obp Settings

    Dynamic Reconfiguration Performing DR In the following example After reboot is set to Off for XSB 01-1 (here named Systemboard_1-1) so that the XSB is not put into operation the next time Solaris is booted. Figure 117: PRIMEPOWER ServerView: Modifying OBP settings Further settings relevant to DR The system boards may not be operated in (Memory) Interleave Mode.
  • Page 324 Performing DR Dynamic Reconfiguration U41272-J-Z385-3-76...

  • Page 325: Solaris: System Administration

    11 Solaris: system administration 11.1 X2000 partition 11.1.1 System settings Ê After calling PRIMEPOWER-ServerView select the VConfig application. Ê Select the required computer in the object table. Select Modify. Ê U41272-J-Z385-3-76...

  • Page 326: Figure 118: Window For Defining The System Settings

    X2000 partition Solaris: system administration A window in which you can define the system settings is displayed. Example Figure 118: Window for defining the system settings You can make the following system settings: Date/time Time zone Directory for system memory dumps Minimum number of free blocks present in the DUMPDIR directory U41272-J-Z385-3-76...

  • Page 327: Figure 119: Window For Defining The Locale Parameters

    Solaris: system administration X2000 partition 11.1.2 Locale parameters Ê After calling PRIMEPOWER-ServerView select the VConfig application. Select the required computer in the object table. Ê Select Modify Locale Parameters. Ê A window in which you can define the locale parameters is displayed. Example Figure 119: Window for defining the locale parameters The parameters indicate:...
  • Page 328 X2000 partition Solaris: system administration – Currency notation – System language In X2000, only German (de_DE.ISO8859-15) and English (en_US.ISO8859-15) are permitted as languages. The only permitted values in LC_MESSAGES are de (for German) and C (for English) and the only permitted values in LANG are de (for German) and en_US (for English).

  • Page 329: Figure 120: Window For Defining Tasks

    Solaris: system administration X2000 partition 11.1.3 Recurrent tasks You are able to define tasks which have to be performed with root authorization regularly at a specified interval. A task can be a: – command – shell procedure – executable program Ê...

  • Page 330: User And Group Administration

    X2000 partition Solaris: system administration 11.1.4 User and group administration You can use this function to administer all the users and groups within the administrative domain. Call After calling PRIMEPOWER-ServerView select the Users application. Ê Tabs The users and groups are subdivided into three categories which are selected and displayed when you click on the corresponding tab or subtab: Users Subtab:...

  • Page 331: Solaris Partition

    Solaris partition. This is described in the manual “PRIMEPOWER ServerView Suite V2.2 System Administration within a Domain” [5]. In addition, Fujitsu Siemens Computers provides other functions together with the corre- sponding documentation for Solaris, for example: Dynamic Reconfiguration –...

  • Page 332: Figure 121: Start Buttons In Primepower Serverview

    PRIMEPOWER ServerView Suite application “Tools” Solaris: system administration 11.3 PRIMEPOWER ServerView Suite application “Tools” The functions “system disk mirror” (Mirror), “configuration data backup” (CSR) and “physical system disk backup” (PSR) have been removed from the PRIMEPOWER ServerView Suite application Bs2Devices for X2000 V2.5 and higher. They can now be found in the independent PRIMEPOWER ServerView Suite application Tools which can be accessed by selecting the “Tools”...

  • Page 333: Figure 123: Starting The Functions Mirror, Csr And Psr From The Drop-Down Menu

    Solaris: system administration PRIMEPOWER ServerView Suite application “Tools” The column “CSR last action” shows the date and type (save/restore) of the last CSR action executed. If nothing has been done there are no previous actions and the column therefore shows “-----”. The column “PSR status”...
  • Page 334 PRIMEPOWER ServerView Suite application “Tools” Solaris: system administration U41272-J-Z385-3-76...

  • Page 335: What If

    12 What if ... This chapter describes what to do if a fault occurs at the system unit. It helps you to detect faults, identify their causes and, in some cases, to eliminate such malfunctions immediately. In the case of faults that can only be rectified by service staff, you can perform a preliminary diagnosis and then contact the service staff for further information.

  • Page 336: Sx.diag Command

    sx.diag command What if ... 12.2 sx.diag command You can use this command to generate a Solaris system dump or to activate or deactivate devices. Command call This command is issued in the EVENT screen (see section “EVENT mode” on page 191): sx.diag <parameter>...

  • Page 337: Create X2000 Diagnostic Documents

    What if ... Create X2000 diagnostic documents sx.diag sinixatt An attempt is made to deactivate all the bus devices. CAUTION! Since all the devices have already been deactivated, there is a risk that BS2000 will crash. sx.diag sinixatt <chn> <unit> The device with this chn-no./unit-no.

  • Page 338: Create An Ioh/Ios Dump

    Create an IOH/IOS dump What if ... 12.4 Create an IOH/IOS dump If an error occurs at a BS2000 device then an IOH or IOS dump can be generated. This is described on page 172 (“iohdump – dump IOH memory” and “iosdump –...

  • Page 339: X2000 Messages

    13 X2000 messages 13.1 KVP messages The messages issued by the console distribution program (KVP) in UNIX mode begin with the message code KVP. KVP0000 7.500 KVP VERSION (&00) INITIALISED ON (&01) AT (&02) &00 = KVP version number, &01 = Date, &02 = Time KVP0001 KVP PARAMETER FILE ERROR Meaning...
  • Page 340 KVP messages X2000 messages KVP0002 NEW KVP PARAMETER FILE ACTIVATED KVP0005 CURRENT TRANSLATION TABLES: (&00) &00 = Designation of the line code or the conversion tables Meaning The BS2000 console messages are converted from EBCDIC and ASCII and vice versa on the basis of the specified standards.
  • Page 341 X2000 messages KVP messages KVP0014 STATION (&00) REJECTED BY SYSTEM: CONSOLE (&01) IS ALREADY ASSIGNED &00 = User ID, &01 = Mnemonic name of console Meaning Another station is already logged on at the BS2000 system with the specified mnemonic console name.
  • Page 342 KVP messages X2000 messages KVP0054 INPUT TO (&00) REJECTED UNTIL LOGGING IS POSSIBLE &00 = Partner (SYS, SVP) Response The original error must be eliminated (see the preceding messages). You can then repeat the input. If it is not possible to eliminate the original error, logging may also be deactivated. KVP0070 NO WORKING-STORAGE AVAILABLE FOR (&00) - ENTER INPUT AGAIN &00 = KVP name (HV0, VM1, VM2 etc.)
  • Page 343 X2000 messages KVP messages KVP0801 FILE-LOGGING FAILED Response The access rights to the file structure /var/opt/SMAW/X2000/log and the file /var/opt/SMAW/X2000/log/log_info should be checked and, if necessary, corrected. This message is also output if archiving is set to FORCED and none of the existing logging files could be archived.

  • Page 344: Svp Emulation Messages

    SVP emulation messages X2000 messages 13.2 SVP emulation messages The messages issued by the SVP emulation start with the message code SVR. SVR0000 xxxx started with device MM, console NN, iorsf P, BS2-Sys SS xxxx = IPL, DIPL or VIPL Meaning The IPL has been started.
  • Page 345 X2000 messages SVP emulation messages SVR0005 START-xxxx aborted (nnnnnn) xxxx = IPL, DIPL or VIPL Meaning IPL was aborted with errors (nnnnnn = cause of error). SVR0006 Incorrect command: xx xx = command entered Meaning An incorrect command has been entered. Response Enter command correctly.
  • Page 346 SVP emulation messages X2000 messages SVR0020 Channel initialization active, please wait Meaning Channel initialization is not yet complete. Response Wait until channel initialization is complete. SVR0021 IOD channel initialization started - please wait Meaning IOD channel initialization has been started. Response Wait until channel initialization is complete.
  • Page 347 X2000 messages SVP emulation messages SVR0030 START VIPL aborted - VM not active Meaning The VIPL was aborted because the VM mode was not activated. Response Activate VM-Mode via PRIMEPOWER ServerView Suite. SVR0031 Restart VM Monitor aborted (nnnnnnnn) Meaning The VMMR was aborted (nnnnnnnn = cause of the error). Response Correct the error.

  • Page 348: Iod Messages

    IOD messages X2000 messages 13.3 IOD messages 13.3.1 Messages referring to bus devices The messages issued by the I/O handler for bus devices begin with the message code IOD0xxx to IOD9xxx. IOD0000 IOD_Vxx RELEASE SL=mmm *** IOD-BUS IMPL READY *** IOD0000 IOD GENERATED ON YYYY/MM/DD AT HH:MM:SS Meaning...
  • Page 349 X2000 messages IOD messages IOD0879 IOD_Vxx SL=mmm. * Device configuration request from X2000 * IOD0879 RKF00 PCIB INVALID CHN=y UA=zz - REQUEST REJECTED Meaning A new device has been configured in X2000. The data passed from X2000 is incorrect. CHN: Host connector number ( equivalently to CHPID). Response Repeat configuration in X2000.
  • Page 350 IOD messages X2000 messages IOD0999 IOD_Vxx SL=mmm *** IOD ABNORMAL END *** IOD0999 *** ERROR CODE=modyyy *** START IMPL! Meaning IOD has detected an error and terminated the system run. On the next system start (IMPL), an IOHDUMP will be generated and saved in the directory /var/opt/SMAW/X2000/dump/. IOD0999 *** ERROR CODE=CPI015 *** START IMPL! Meaning...
  • Page 351 X2000 messages IOD messages IOD0999 *** ERROR CODE=IPL005 *** START IMPL! Meaning The RMAssist has not responded to an IOD message within 10 seconds. Response Identify the cause of the error and repeat the IMPL or execute bs2init 0 and bs2init 1. IOD3000 IO-CONFIGURATION ERROR: DEV#/MN xxxx/yyyy NOT UNIQUE Meaning...

  • Page 352: Messages Referring To Channel Devices

    IOD messages X2000 messages 13.3.2 Messages referring to channel devices The messages issued by the I/O handler for channel devices begin with the message codes IODAxxx to IODZxxx. IODC000 IOS0000 IOD CHANNEL STARTUP FINISHED Meaning This message indicates that IOD channel startup has run correctly. IODC002 IORSF TITLE: ...
  • Page 353 X2000 messages IOD messages IODE022 CHPID xx module error: module stopped Meaning Module stop error handling has been terminated with an error or due to the presence of a persistent error. The module has been stopped and identified as defective. A logout has been stored.
  • Page 354 IOD messages X2000 messages IODE053 CHPID xx vary offline rejected: hardware error Meaning The MSSF call CHPOFF - vary channel path offline was rejected because of the presence of a hardware error. Appropriate error handling is performed for the hardware error.
  • Page 355 X2000 messages IOD messages IODE062 CHPID xx was already online Meaning The module was already in the online state at the time of the MSSF call CHPOFF - vary channel path online. Response No maintenance response is required. IODE063 CHPID xx vary online rejected: hardware error Meaning The MSSF call CHPON - vary channel path online was rejected because of the presence of a hardware error.
  • Page 356 IOD messages X2000 messages IODE0E0 Error Code xx: Error detected by IOD-Firmware Meaning The IOD has detected an internal error and has reset the channel subsystem. All installed components of the channel subsystem are initialized and started. Response The error has been eliminated for the present by the error handling operation. There is generally no hardware error present when the IOD detects such an internal error.
  • Page 357 X2000 messages IOD messages IODF007 IORSF IDENTIFICATION INVALID Meaning Content error in IORSF. Response Regenerate IORSF. IODF008 IORSF ERROR: INVALID CHANNEL INTERFACE TYPE Meaning Content error in IORSF (possible cause: IORSF was generated for another system). Response Regenerate IORSF. IODF009 IORSF ERROR: Subchannel # less than 1000 Meaning Content error in IORSF.

  • Page 358: Hal Messages

    HAL messages X2000 messages 13.4 HAL messages HAL0001 MDEBUG ACTIVE Meaning The master debugger mdebug has been started HAL0002 MDEBUG INCATIVE Meaning The master debugger mdebug has been stopped HAL0140 HAL ABORT GPXX SSSSSSSSSSSSSSSS PPPPPPPPPPPPPPPP Meaning The HAL on this processor has detected an inconsistency and has terminated the processing of BS2000 instructions on all processors.
  • Page 359 X2000 messages HAL messages HAL0212 MDEBUG STOP GPXX SSSSSSSSSSSSSSSS PPPPPPPPPPPPPPPP BREAK-POINT Meaning A break point set by mdebug has been executed by the given processor. The processing of BS2000 instructions has been halted. Response The mdebug command ’bg’ will restart the processor. HAL0213 MDEBUG STOP GPXX SSSSSSSSSSSSSSSS PPPPPPPPPPPPPPPP DATA TRAP Meaning...
  • Page 360 HAL messages X2000 messages HAL0311 BS2000 STOP GPXX SSSSSSSSSSSSSSSS PPPPPPPPPPPPPPPP DISABLED-WAIT Meaning A new PSW has been loaded by the given processor in which the wait bit is set and no inter- rupts are enabled. As a result, the processing of BS2000 instructions has been halted. This may occur as part of a normal shutdown or may be due to a system crash - SETS.
  • Page 361 X2000 messages HAL messages HAL0350 BS2000 ACF GPXX PPPPPPPP EEEEEEEEEEEEEEEE ALIGNMENT ERROR CORRECTED PPPPPPPP = The 4 byte program counter. EEEEEEEEEEEEEEEE = The 8-byte extended address which caused the alignment error. Meaning The executing BS2000 program caused an alignment error when accessing data. The ACF facility then used a slower access method to access the data and enable the program to continue.

  • Page 362: X2000 Channel Connection Error Messages

    X2000 channel connection error messages X2000 messages 13.5 X2000 channel connection error messages 13.5.1 Structure of message numbers The messages issued by the X2000 channel connection service functions share the same structure and have the following format: 9...255 System signature The service function system signature for the X2000 channel connection is preset to “SV”.

  • Page 363: Metasyntax

    X2000 messages X2000 channel connection error messages 13.5.2 Metasyntax A metasyntax is used to avoid burdening the message text with unnecessary lists. Text variable Any text variable is enclosed in angle brackets (e.g. <variable>) and is explained in the associated message description or at the start of the section.

  • Page 364: Hwi Messages

    X2000 channel connection error messages X2000 messages 13.5.4 HWI messages The HWI messages are process-independent. HWI message code: Buffer start address for HWI opcode <addr> List of CHPIDs for the channels in question <chpid> ... Selected HWI opcode (four characters) <oc>...
  • Page 365 X2000 messages X2000 channel connection error messages ...I092 ioctl (<request>) failed, ..The system error message is appended to the message. Meaning Software error: The ioctl request <request> has been aborted..I093 sscanf() format error ’<Fname>’ Meaning File error: The file <Fname> has an invalid format and could not be processed with sscanf..I094 fwrite() failed ’<Fname>’...
  • Page 366 X2000 channel connection error messages X2000 messages ...I201 hw-configuration changed (channel) - CHPID(s): <chpid> ... Meaning Configuration message: The channels' hardware configuration has changed. This message is issued following a channel installation/de-installation operation or after a hardware failure..I202 conf-file is corrupted ’<Cname>’ Meaning Software error: The configuration file <Cname>...

  • Page 367: Main Messages

    X2000 messages X2000 channel connection error messages 13.5.5 MAIN messages The MAIN message numbers are process-dependent, i.e. the message is only unique if accompanied by a process signature. 13.5.5.1 ciodebug messages ciodebug message code: Channel Path Identification <chpid> ..AM001 illegal chpid <chpid> Meaning Software error: The storage area in CASA cannot be allocated because the CHPID <chpid>...

  • Page 368: Channel_Ipl Messages

    X2000 channel connection error messages X2000 messages 13.5.5.3 channel_ipl messages channel_ipl message code: <chpid> ... List of CHPIDs for the channels in question <oc> Selected HWI opcode (four characters) List of CHPID areas (x0...xF) of affected channels without further speci- <range>...
  • Page 369 X2000 messages X2000 channel connection error messages ..IM022 CASA init Meaning Runtime message: The CASA shadow memory is being initialized ..IM023 IOCF file iorsf<level> loaded Meaning Runtime message: The IOCF file with the IORSF level <level> has been loaded into the shadow memory.

  • Page 370: Logout System Messages

    X2000 channel connection error messages X2000 messages ..IM097 fopen() failed ’<Fname>’ Meaning File error/software error: The file <Fname> could not be opened. The path rights may have been set incorrectly, the file system may be defective or full or the file may have been deleted.
  • Page 371 X2000 messages X2000 channel connection error messages SVLB000 sequence number access error, logout dropped Meaning Error in creating the binary logout file lfxxxx (<xxxx> = logout sequence number). The logout data cannot be analyzed and cannot be backed up. SVLB001 error create lfxxxx Meaning Error in creating the binary logout file lfxxxx (<xxxx>...

  • Page 372: Channeld Messages

    X2000 channel connection error messages X2000 messages SVLB008 result compare error Meaning Error in comparing the analysis result with the previous result. No analysis result is backed up, but the basic binary logout is backed up and can be displayed via logging-V3-additional info.
  • Page 373 X2000 messages X2000 channel connection error messages ..MM004 ioctl (<request>) failed, ..The system error message is appended to the message. Meaning Software error: The IOCTL request <request> has been aborted. ..MM005 end of channeld by SIGTERM Meaning Runtime message: The daemon was terminated by the signal SIGTERM. ..MM006 <Dfunc>: sigaction() failed Meaning...

  • Page 374: Cinit Messages

    X2000 channel connection error messages X2000 messages ..MM299 fseek() failed ’<Fname>’ Meaning File error/software error: The positioning in the file <Fname> was invalid. The file was not opened or the position was beyond the end-of-file. ..MM401 illegal CHPID <chpid>; undefined channel group number Meaning Software error: The channel group selection of the channel path identification <chpid>...

  • Page 375: Set_Spd Messages

    X2000 messages X2000 channel connection error messages ..NM020 reconfiguration logout saved Meaning Runtime message: A reconfiguration logout was written. ..NM100 ioctl (<request>) failed, ..The system error message is appended to the message. Meaning Software error: The IOCTL request <request> has been aborted. 13.5.5.7 set_spd messages ..PM096...

  • Page 376: Ctest Messages

    X2000 channel connection error messages X2000 messages 13.5.5.8 ctest messages ctest message code: <B-type> Board type <D-no> D number (PCB number) Bus identification <busid> Cabinet identification <cabid> Channel path identification (CHPID) <chpid> <rep> Repetition count <slotid> Slot identification Test number <test>...
  • Page 377 X2000 messages X2000 channel connection error messages ..TM001 wrong channel selection <chpid> (CHPID) The message ..TM001 is also output. Meaning Warning: The formally incorrect CHPID <chpid> was specified (outside the number ranges 80...8E and 90...FF). ..TM001 no related channel for CHPID <chpid> The message ..TM001 is also output.
  • Page 378 X2000 channel connection error messages X2000 messages ..TM001 empty test number The message ..TM001 is also output. Meaning Warning: The -t option but no test number was specified. ..TM001 wrong test number <test> The message ..TM001 is also output. Meaning Warning: The test number is not 0 (all tests) or not in the number range 1...4.

  • Page 379: Initialization Script Messages

    X2000 messages X2000 channel connection error messages ..TM002 error in channel test <test> CHPID <chpid> CABINET ID: ? BUS ID: ? - <B-type>, SLOT ??, <D-no> Meaning A channel test program has detected an error: There is no valid cabinet ID for the current CHPID <chpid>; the IOCTL request PCHAN_CHAN_GET_LOC has been acknowledged incorrectly.
  • Page 380 X2000 channel connection error messages X2000 messages ..SS003 channel initialization timed out Meaning Software error: The cipl script was aborted because initialization of the channel system was not terminated within the predefined period (10 minutes). ..SS101 device <dev> occupied by ’<proc>’ PID: <pid> Meaning Reservation error: The called process is aborted because the device <dev>...

  • Page 381: X2000 Messages To The Bs2000 Console

    X2000 messages X2000 messages to the BS2000 console 13.6 X2000 messages to the BS2000 console If X2000 detects an error in a peripheral component that cannot be reported to BS2000 via an I/O then X2000 sends the following message to the BS2000 console: SNX2000 AN ERROR HAS OCCURRED IN A PERIPHERAL COMPONENT - FOR FURTHER INFORMATION PLEASE CONSULT THE PRIMEPOWER SERVERVIEW APPLICATION DIAGNOSTIC.

  • Page 382: Event Error Messages

    EVENT error messages X2000 messages 13.7 EVENT error messages If input errors occur in EVENT mode then the following messages are output in inverse video in line 24. wrong password or timeout Meaning The password was entered incorrectly during input. The previous input is ignored. Response Repeat the operation.
  • Page 383 X2000 messages EVENT error messages input rejected, destination invalid Meaning Messages in EVENT mode must be written in the form xx.text (xx=component in question and text=input text). The relevant component has been specified incorrectly. Response Repeat the input correctly. no command files present Meaning The command file from sx.command does not exist.
  • Page 384 EVENT error messages X2000 messages U41272-J-Z385-3-76...

  • Page 385: Appendix

    14 Appendix 14.1 Hardware features of the SX Series Business Servers Technical highlights of the business servers in the SX series are summarized in the following two sections. You will find further details of features specific to each model range in the section corresponding to the specific model range in the sections below.
  • Page 386 Hardware features of the SX Series Business Servers Appendix The basis for the division into physical partitions (PPARs) on SX130 servers is provided by the physical system boards (PSBs) and, as of the SX140 servers, the PSB mode of an SX server’s system boards.

  • Page 387: Figure 124: Example Of Creation Of Physical Partitions

    Appendix Hardware features of the SX Series Business Servers The figure below shows physical partitions based on physical system boards, using the SX130 as an example: Partition 1 Partition 2 Partition 3 (optional) BS2000 partition Solaris partition System board 0...
  • Page 388 As far as the BS2000 addressing modes in the program address space are concerned, the models in the SX series are fully compatible with the S servers. Data spaces are supported on SX servers as of BS2000/OSD V6.0 and X2000 V3.0A05.

  • Page 389: Sx Server System Peripherals

    On a model-specific basis, the SX server for BS2000/OSD also supports an optional channel interface. This means that existing BS2000 channel peripherals can be used in parallel to new Fibre Channel peripherals. The entry-level models in the SX series have no channel interface.
  • Page 390 Hardware features of the SX Series Business Servers Appendix Channel peripherals on BS2000 partitions Channel peripherals are only possible on SX servers which support the optional channel interface. Channel peripherals are connected to the SX server via the optional channel subsystem (Universal Hot Plug System, UHPS).

  • Page 391: Figure 126: Connection Of The Various Peripheral Devices, Example Using An

    Appendix Hardware features of the SX Series Business Servers Channel Type 2/Type S Channel Type 2/Type S Fibre Channel Peripherals Peripherals Peripherals ..FC Switch UHPS 1 (optional) UHPS 2 (optional) (PRIMEPOWER250)
  • Page 392 Hardware features of the SX Series Business Servers Appendix The connection possibilities are the same for the other models in the SX series, with the exception of the entry-level models. Operating peripherals in SX servers without SMC SX servers without SMC can be operated via the integrated console or via a LAN console.

  • Page 393: Table 13: Sx100 Series Model Range

    Optionally offers the connection of CentricStor and ITC/SBU via Fibre Channel Complete with integrated console (System Management Console (SMC) not available). Channel connections are not supported. The models in the SX100 Business Server model range are designated SX series entry- level models. This model range consists of the following:...

  • Page 394: Sx130

    Model ranges Appendix Peripherals of the SX100 system The basic version of the input/output system has two 73 GB hard disks configured as a mirrored system. Alongside the X2000 system partitions on these disks there are two BS2000 volumes, each 17 GB. Optionally it is possible to install an additional DISK subsystem with 4 x 73 GB, which can be extended to a maximum of 14 disks.

  • Page 395: Table 14: Sx130 Series Model Range

    Appendix Model ranges The SX130 Business Server model range (basic configurations) consists of the following: Model Capacity in RPF CPUs for BS2000/OSD CPUs for I/O (X2000) SX130-10A/B/C 35/42/55 SX130-20A/B/C 63/75/88 SX130-30C SX130-40C SX130-50C SX130-60C Table 14: SX130 series model range Servers in the SX130 series model range The basic version of all SX130 series models has two system boards.

  • Page 396: Figure 127: Examples Of Partitioning In Sx130 Servers

    Model ranges Appendix Basic version (2 system boards) Full version (4 system boards) BS2000 BS2000 BS2000 System board System board System board System board System board System board System board System board BS2000 BS2000 Solaris Solaris Solaris System board System board System board System board System board...
  • Page 397 Appendix Model ranges The maximum power supply protection can be achieved by using the optional dual power supply. SX130 system peripherals Channel peripherals (type 2 and type S) may be connected to the SX130 server via the optional channel subsystem. The channel subsystem is connected by an SCI controller and occupies a PCI slot of a system board in the BS2000 partition for up to 16 channel connections.

  • Page 398: Sx140

    Model ranges Appendix 14.2.3 SX140 Overview Maximum equipment: 16 CPUs and 64 GB memory. Supports a maximum of 2 system board, each with a maximum of 8 CPUs, 8 memory packages and 8 PCI slots. Also 1 PCI/disk box with 10 PCI slots exists for each physical system board for model SX140-40C and higher.

  • Page 399: Table 16: Sx140 Series Model Range

    Appendix Model ranges The SX140 Business Server model range consists of the following (basic configuration): Model Capacity CPUs for CPUs for I/O in RPF BS2000/OSD (X2000) SX140-10A/B/C 42/58/75 00-0 SX140-20A/B/C 94/113/133 00-0, 00-1 SX140-30C 00-0, 00-1 SX140-40C 00-0, 00-1, 00-2 SX140-50C 00-0, 00-1, 00-2 SX140-60C...

  • Page 400: Figure 128: Example Of The Sx140-10C Model Basic Versions

    Model ranges Appendix As default, the first BS2000/OSD instance is installed on XSB . If the number of processors requires this, XSB00-1, XSB00-2, XSB00-3 are added in the sequence indicated. XSB00-2 and XSB00-3 require a PCI/disk box which is integrated in models SX140-40C,...
  • Page 401 Appendix Model ranges The basic versions of the additional BS2000 partition have the same performance classifi- cation as that of the first BS2000 partition. They are equipped with a model-specific number of processors, a model-specific memory capacity, 2 boot disks, power supply and fans so that they can be installed in the system cabinet in addition to the first BS2000/OSD instance.

  • Page 402: Sx150

    Model ranges Appendix 14.2.4 SX150 Overview Maximum equipment: 16 CPUs and 64/128 GB memory. Supports a maximum of 2 system boards, each with a maximum of 8 CPUs, 8 memory packages and 8 PCI slots. Expansion by 10 PCI slots is possible using a PCI/disk box. The expansion is required if XSBs 00-2 and 00-3 of the first and/or XSBs 01-2 and 01-3 of the second system board are used.

  • Page 403: Table 17: Sx150 Series Model Range

    Appendix Model ranges The SX150 Business Server model range consists of the following (basic configurations): Model Capacity CPUs for Memory (GB) XSBs on in RPF slots Total X2000 SB 00 SB 01 SX150-10A/B/C 42/75/105 0, 1 SX150-20A/C 140/180 0, 1 SX150-30C 0, 1 SX150-40C...

  • Page 404: Table 18: Usage Of Additional Performance In The Sx150 Model Series

    Model ranges Appendix Capacity on Demand (CoD) Use of the Capacity on Demand (CoD) function provides the option of interrupt-free, tempo- rarily limited performance enhancement. This function can be used for different usage periods. Usage of additional CPU performance In addition to the CPUs which are activated by default one or more CoD processors can also be used if this is contractually agreed.
  • Page 405 Appendix Model ranges Using XSB mode the hardware resources of a system board listed above can each be divided into 4 independent extended system boards (XSBs). The interface for setting or modifying PSB or XSB mode and its configuration is described in the section “Administering the system board’s operating mode”...

  • Page 406: Figure 129: Example Of The Sx150-10C Model Basic Versions

    Model ranges Appendix The figure below shows the basic version of the SX150-10C model and some extension possibilities: System board 00 XSB00-0 XSB00-1 XSB00-2 XSB00-3 BS2000 BS2/Solaris BS2/Solaris BS2/Solaris 5 PCI slots 3 PCI slot 7 PCI slots 3 PCI slots 4 GB 4 GB PCI/disk box necessary...
  • Page 407 Appendix Model ranges FC, Ethernet and SCSI controllers can be replaced during ongoing operation, as can the redundant system components hard disks, power supplies and fans. The reconfiguration options of processors, memory and I/O system means that the SX150 system offers high availability.
  • Page 408 Model ranges Appendix Peripherals of the SX150 system Channel peripherals (of type 2 and/or type S) can be connected to the SX150 server by a maximum of 2 channel chassis in a BS2000 partition. A maximum of 32 channels in total are therefore available on an SX150 in a BS2000 partition.

  • Page 409: Skp-Sr For Bs2000 Operation

    Appendix SKP-SR for BS2000 operation 14.3 SKP-SR for BS2000 operation The use of an SKP-SR for the SX130 Business Server is optional. The SKP-SR can be used for the following applications: Operation of X2000 instances (e.g. BS2000 console) via LAN using preconfigurable virtual screens (not possible when using the Secure Shell) Operation of applications on an SX server with a graphical user interface (e.g.

  • Page 410: Automatic System Operation Via Atop

    SKP-SR for BS2000 operation Appendix 14.3.2 Automatic system operation via ATOP The ATOP is connected to the SKP-SR serial ports. One serial connection to the SKP-SR is required for each system to be monitored. The monitor script must first control the SKP-SR login before logging in via LAN to the system login which provides access to the console that is to be monitored (e.g.

  • Page 411: Abbreviations

    Abbreviations APCS Automatic Power Control System ATNS Advanced Transport Name Service Console Connection Unit Common Desktop Environment CHPID Channel Path Identification Capacity on Demand Central Processing Unit Digital Audio Tape DC DC Converter Domain-Name-Service Dynamische Rekonfiguration DSSM Dynamic Subsystem Management Enterprise System Architecture ESCoD Enhanced Server Capacity on Demand...
  • Page 412 Abbreviations Linear Tape Open Media Access Control Magnetic Tape Controller Network Time Protocol OpenBoot PROM Operating System OSD/XC OSD Extended Configuration Peripheral Component Interconnect PCI Hot Plug Partition ID POST Power On Self Test PPAR Physical Partition PuTTY Private Key File (file extension) Print Resource Management PROM Programmable Read Only Memory...
  • Page 413 Abbreviations TODR Time Of Day Register Unit-Adresse Virtual Channel Adapter Wide Area Network Crossbar XB-DDC Crossbar DC-DC Converter XPAR Extended Partition Extended System Board Web based System Administration, WebSysAdmin (earlier designation of PRIMEPOWER ServerView) WWPN World Wide Port Name XSCF eXtended System Control Facility U41272-J-Z385-3-76...
  • Page 414 Abbreviations U41272-J-Z385-3-76...

  • Page 415: Table Of Contents

    1: Example of an SX server: SX150 Business Server....2 Figure 2: Structure of the documentation for the SX Series Business Servers ..5 Figure 3: Example of an operating concept for an SX server .
  • Page 416 Figures Figure 22: Machine Administration Menu: “System-Specific Administration” ..60 Figure 23: Machine Administration Menu: “System/Partition Power Administration” . . 61 Figure 24: Machine Administration Menu: “APCS Setup Menu”....67 Figure 25: PRIMEPOWER ServerView- window: “Create task”...
  • Page 417 Figures Figure 45: Xconfig: Start window ........135 Figure 46: Xconfig: Network and Communication window .
  • Page 418 Figures Figure 71: Presentation of non-accessible nodes in the hierarchy browser of PRIMEPOWER ServerView........201 Figure 72: Displaying and modifying authorizations in PRIMEPOWER ServerView .
  • Page 419 Figures Figure 96: Mercator window with Xprint database (printer inactive) ....248 Figure 97: Mercator printer configuration window (State) ..... . 249 Figure 98: Mercator window with Xprint database (printer active) .
  • Page 420 Figures Figure 121: Start buttons in PRIMEPOWER ServerView ..... . . 332 Figure 122: “Tools” tab in PRIMEPOWER ServerView ......332 Figure 123: Starting the functions Mirror, CSR and PSR from the drop-down menu .

  • Page 421: Tables

    Tables Table 1: Functionality of the administrator user group in the SCS ....45 Table 2: Overview of the access options to XSCF ......118 Table 3: XSCF functions available via a Web browser .
  • Page 422 Tables U41272-J-Z385-3-76...

  • Page 423: Related Publications

    Target group This manual is designed for technical decision-makers who want to find out about the appli- cations of the SX Series Business Servers, and for users who want to familiarize themselves with the operation of the SX servers. Contents This manual describes the concepts and the architecture of SX Series Business Server.
  • Page 424 Related publications BS2000/OSD-BC V6.0 Migration Guide User Guide Target group Systems support and system services Contents The Migration Guide summarizes the individual work steps required for a changeover from BS2000/OSD-BC V4.0 or V5.0 to BS2000/OSD-BC V6.0 and offers hints for converting back to the old version.
  • Page 425 Related publications PRIMEPOWER ServerView Suite V2.2 Integration in Enterprise Server Management Systems Target group System administrators and customer service staff. Contents This manual describes two products, which allow integrating the PRIMEPOWER ServerView Suite in the two global IT management products CA Unicenter NSM and Tivoli. System Console Software User’s Guide (SCS) User Guide Target group...
  • Page 426 Related publications [11] BS2000/OSD-BC Commands, Volumes 1 - 5 User Guide Target group This manual is addressed to nonprivileged users and systems support staff. Contents Volumes 1 through 5 contain the BS2000/OSD commands ADD-... to WRITE-... (basic configuration and selected products) with the functionality for all privileges. The command and operand functions are described in detail, supported by examples to aid understanding.
  • Page 427 Related publications [13] BS2000/OSD-BC System Messages, Volumes 1 - 3 User Guide Target group This manual is addressed to systems support staff, operators and users. Contents Chapter 1 deals with message processing in BS2000/OSD. Chapter 2 contains the system messages of the message classes for the basic configuration of the BS2000/OSD operating system.
  • Page 428 Related publications [16] Assembler Instructions (BS2000/OSD) Reference Manual Target group BS2000/OSD assembly-language programmers Contents This manual describes in alphabetical order all (nonprivileged) assembler instructions of the CPUs supported by BS2000/OSD. For each instruction the following is described: – its function –...
  • Page 429 Related publications [18] openSM2 (BS2000/OSD) Software Monitor Volumes 1 and 2 User Guide Target group This manual is addressed to users and systems support staff. Contents The monitoring system SM2 supplies users with statistical data on the performance of their DP systems and on resource utilization.
  • Page 430 These Softbooks can also be found in the Internet on our manual server. You can browse in any of these manuals or download the entire manual. Order number U26175-J8-Z125-1-76 Internet address http://manuals.fujitsu-siemens.com [22] Xprint Management V6.0A GUI Target group Xprint administrators who use Xprint management functions.
  • Page 431 This document provides an introduction to this procedure. It describes the basics of the procedure and its approach and explains this using examples. Only available online: -> „UNIX based servers“ http://manuals.fujitsu-siemens.com [26] Dynamic Reconfiguration User’s Guide User Guide Target group...
  • Page 432 The manual describes the procedure for the dynamic reconfiguration of the PRIMEPOWER/GP7000F high-performance models (system unit) and the use of the system on the system unit. Only available online: http://manuals.fujitsu-siemens.com -> „UNIX based servers“ [28] Solaris System Diagnostics Target group...
  • Page 433 Related publications [31] Teleservice (Unix) User Guide Target group The manual is intended for customers and operators of Teleservice Centers. Contents The manual describes the basic technical functioning of the Teleservice software. It also provides guidelines for users and system administrators as well as information on tools and modem validation.
  • Page 434 Related publications U41272-J-Z385-3-76...

  • Page 435: Environmental Protection

    Environmental protection Take-back, recycling and disposal For details on take-back and reuse of devices and consumables within Europe, contact your Siemens branch office/subsidiary or our recycling center in Paderborn: Tel. +49 5251 8180-10 Fax. +49 5251 8180-15 Further information on environmental protection The Siemens AG representative for environmental protection will be pleased to answer any further questions you may have concerning environmental protection.
  • Page 436 Environmental protection U41272-J-Z385-3-76...

  • Page 437: Index

    Index BS2 KVP $DIALOG mode BS2 LAN ports /390 BS2 printers /390 firmware BS2 tapes BS2 users BS2000 $DIALOG mode 3919 BS2000 CONSOLE mode 3920 access 9750 emulation 134, exit configuring inputs notes on operation logging 97801 terminal menu function number of operator terminals outputs administrator...
  • Page 438 BS2000 disks DCE cluster displaying dipl dtterm window disk types fjge driver displaying EVENT commands NTP server documentation for the SX series Business parameter Servers partition partitioning aborting print server administrative interface printers 216, automatic recovery function private disks...
  • Page 439 Index DUMPDIR System Management Console Dynamic Reconfiguration IOH memory PRIMEPOWER ServerView iohdump iorsf iorsf list EM9750 mode IOS memory EMC Powerpath 108, iosdump emulation, printer entry model IP multipathing (IPMP) entry-level model environment variable ISO 8859-15 error messages escape sequence establishing connection Java machine euro currency symbol...
  • Page 440 Index model range SX140 model range SX150 param monitor script partition MSCF outputting information MSCF cluster possible distribution MTC device possible division configuring partition administrators displaying the occupancy status password 211, exclusive use of patch occupying when host communication PFKey file disrupted deleting setting an occupancy option...
