Operating BS2000 instances
Click on the relevant icon on the front panel of the CDE interface to automatically open
a window in which the functionality of the BS2000 console will be available after autho-
rization (log in with the X2000 login cons0..7) (see also
instances" on page
Figure 62: Opening a BS2000 console window under the CDE interface of the SMC
BS2000 console window using the optional SKP-SR (only SX130)
An SKP-SR outputs the windows preconfigured there locally on its console or remotely
on a PC with an X server (not possible when the Secure Shell is used). The functionality
of the BS2000 console is available after authorization has been granted (log in with the
X2000 login cons0..7).
BS2000 console window using SINIX-TE on an administration PC
If SINIX-TE is used on the administration PC to display 97801 windows, a corre-
sponding session must be set up to the X2000 of a BS2000 partition by specifying the
login cons0..7 (not possible when the Secure Shell is used). In addition to the X2000
connection name and host address, the connection type RLOGIN and the login
cons0..7 must be specified as the connection parameters (see also
ration and operation" on page
Working with terminal type dtterm
As the BS2000 messages are output from the KVP program in yellow and the dtterm
window by default has a light background, ensure that the dtterm window is opened with a
dark background (e.g. grey65). This is taken into account with the pre-installed console
windows in the sxadmin and bs2admin logins.
Examples of possible background colors
grey65...70, DarkGrey, tan2, burlywood3, DarkKhaki, CadetBlue, PeachPuff3,
NavajoWhite3, SteelBlue2
U41272-J-Z385-3-76
40).
135).
BS2000 console mode
section "Calling terminal
section "Configu-
161
