Configuring printers
active
Communication
settings
Device node
Emulation options
In the above example, the UNIX printer p9017 is assigned as a physical device to the local
BS2000 spool printer with the mnemonic name L0 at host connector/unit address 0/40 at
the computer bari1. -seh is specified in the Emulation options. This tells the printer
emulation to communicate with the printer via the so-called RSO spool protocol and to use
port number 2900 (print security!).
i
If you select Transdata printer, the Create a new Transdata printer window opens:

Figure 101: X2000 window for creating a Transdata printer

254
If you check this box then the emulation is activated immediately. If
not, the device is simply declared to the BS2000 system.
i
Only for serial device connections (not relevant for SX servers).
The system displays the IP address and the port number via which
the printer is accessed.
Here you can specify options, for example for diagnostic purposes.
If you specify multiple options then you must separate them using
spaces.
Further emulation options are described in
controlling the X2000 printer emulation" on page 260
online help system.
An entry is made in the SERSFILE (every minute) if the
device is attached in the BS2000 system but not activated.
Global X2000 functions
section "Emulation options for
of this manual and in the
U41272-J-Z385-3-76
