Page 1: Table Of Contents
PRIMERGY R450 System configurator and order-information guide November 2003 Contents Instructions Configuration diagram Configurator System software Basic unit Processor III Memory IV Graphics Accessible drives VI Hard disk drives VII SCSI controller VIII Disk array IX Communication/Network System Management Products... - Page 2 System configurator and order-information guide PRIMERGY R450 Status 2003-10-24 Instructions This document contains basic product and configuration information that will enable you to configure your system via PC-/ System-Architect. Only these tools will ensure a fast and proper configuration of your PRIMERGY server or your complete PRIMERGY Rack system.
- Page 3 System configurator and order-informtion guide PRIMERGY R450 Status 2003-10-24 Configuration diagram PRIMERGY R450 TOP VIEW FRONT VIEW System unit ( I ) Extension slots Peripheral Bay ( V ) Graphics ( IV ) 3.5"x0.5" 5.25"x0.5" SCSI controller ( VII )
- Page 4 System configurator and order-informtion guide PRIMERGY R450 Status 2003-10-24 Start "PRIMERGY R450" SW Configurator with OEM-Software without OEM-Software for PRIMERGY Server for PRIMERGY Server Later use of OEM operating system Microsoft does not allowe software is not allowed, Vmware-Software the use of OEM-software apart from OEM software by - ESX Server 1.5 (OEM)
-
Page 5: I Basic Unit
Status 2003-10-24 Section Basic unit Rack basic unit 4U including The PRIMERGY R450 basic unit comes with: 1 x Xeon MP CPU - 3 power supply module, hot-plug redundant 2 channel - 2 channel HD PBay with 3 HD bays each... -
Page 6: Processor
System configurator and order-information guide PRIMERGY R450 Status 2003-10-24 There are 3 bays for hot-plug power supplies, each with 500W Each basic unit contains 3 modules and provides redundancy for a fully equipped system Section Processor A mix of processors with different clock frequency and different On-Chip cache cannot be used... -
Page 7: Accessible Drives
System configurator and order-information guide PRIMERGY R450 Status 2003-10-24 Section Accessible drives SNP:SY-F2313E1-P SNP:SY-F2312E1-P A CD-ROM or DVD-ROM drive is required for CD-ROM 0,5" 24xATAPI DVD drive 0,5" installing the system with "Sever Start" Connector: LD50 8/24x or faster supplied with the system unit! Note: There is no incl. -
Page 8: Scsi Controller
System configurator and order-information guide PRIMERGY R450 Status 2003-10-24 Section SCSI-/Fibre-channel controller A. on-board SCSI Controller for internal hard disks 2-channel U160-SCSI controller on-board; included as standard The following cabling is standard, if no Disk Array Controller is used 1. Channel A of the U160 controller is connected to the 1st backplane for 3 HDs 2. -
Page 9: Disk Array
System configurator and order-information guide PRIMERGY R450 Status 2003-10-24 VIII Section Disk Array D. 0-channel Ultra RAID Controller The following cabling is standard, if any Disk Array Controller is used 1. Channel A of the RAID Controller is connected to the 1st backplane for 3 HDs 2. -
Page 10: Communication/Network
System configurator and order-information guide PRIMERGY R450 Status 2003-10-24 Section Communication / Network on-board LAN Controller Fast Ethernet Contr. on-board The Intel LAN controllers 10/100TX, 1000SX, 1000TX Intel Ethernet Express Pro100+ can be used with the on-board controller in Teaming Mode. -
Page 11: Miscellaneous
(1x with Standard PSU, 3x with hot plug upgrade) T26139-Y1742-L10 USA, Canada For shipments to USA&Canada, you have to order one power cord (1,8m, grey) per power supply. End PRIMERGY R450 Fujitsu Siemens Computers 11 of 12 Enterprise Products - PRIMERGY Server... -
Page 12: Change Report
System configurator and order-information guide PRIMERGY R450 Status 2003-10-24 Change report Date Order number Change 2003-08-13 S26361-F2764-E573 Hard disk 73GB 15.000rpm Ultra 320 SCSI - now available 2003-08-13 S26361-F2764-E536 Hard disk 36GB 15.000rpm Ultra 320 SCSI - now available 2003-08-13 S26361-F2764-E518 Hard disk 18GB 15.000rpm Ultra 320 SCSI - now available...
