Local and remote communications
The basic SOF file $TSOS.SOF.SX2000, which contains the entries for LOCLAN and
LOCSIN, is shipped with the pre-installed standby system.
For VM1:
/DCOPT HOST=TESTVM1,...
/BCOPTION BROADCAST=ON,ARP=ON
/CREATE-NODE NODE-NAME=LOCLAN
/CREATE-LINE LINE-NAME=LOCLAN,IP-ADDRESS=192.168.138.002,-
/ L2-PROTOCOL=*CSMACD(NODE-NAME=LOCLAN,-
/ MAX-LPDU-SIZE=*BY-DEVICE,-
/ WRITE-DEVICE=Y0,READ-DEVICE=Y1)
/BCACT NODE=LOCLAN
/ACTIVATE-LINE LINE=LOCLAN
/CREATE-PROC PROC-NAME=LOCSIN
/CREATE-ROUTE ROUTE-NAME=LOCSIN,PROCESSOR-NAME=LOCSIN,-
/ PATH=*NODE(NODE-NAME=LOCLAN,LINE-NAME=LOCLAN,-
/ L3-PROT=*IP(L4-PROTOCOL=*TCP,IP-ADDRESS=192.168.138.012))
/BCACT LOCSIN
/CREATE-PROC PROC-NAME=LOCVM2
/CREATE-ROUTE ROUTE-NAME=LOCVM2,PROCESSOR-NAME=LOCVM2,-
/ PATH=*NODE(NODE-NAME=LOCLAN,LINE-NAME=LOCLAN,-
/ L3-PROT=*IP(L4-PROTOCOL=*TCP,IP-ADDRESS=192.168.138.6))
/BCACT LOCVM2
/CREATE-...
For VM2:
/DCOPT HOST=TESTVM2,...
/BCOPTION BROADCAST=ON,ARP=ON
/CREATE-NODE NODE-NAME=LOCLAN
/CREATE-LINE LINE-NAME=LOCLAN,IP-ADDRESS=192.168.138.006,-
/ L2-PROTOCOL=*CSMACD(NODE-NAME=LOCLAN,-
/ MAX-LPDU-SIZE=*BY-DEVICE,-
/ WRITE-DEVICE=Y4,READ-DEVICE=Y5)
/BCACT NODE=LOCLAN
/ACTIVATE-LINE LINE=LOCLAN
/CREATE-PROC PROC-NAME=LOCSIN
/CREATE-ROUTE ROUTE-NAME=LOCSIN,PROCESSOR-NAME=LOCSIN,-
/ PATH=*NODE(NODE-NAME=LOCLAN,LINE-NAME=LOCLAN,-
/ L3-PROT=*IP(L4-PROTOCOL=*TCP,IP-ADDRESS=192.168.138.012))
/BCACT LOCSIN
/CREATE-PROC PROC-NAME=LOCVM1
/CREATE-ROUTE ROUTE-NAME=LOCVM1,PROCESSOR-NAME=LOCVM1,-
/ PATH=*NODE(NODE-NAME=LOCLAN,LINE-NAME=LOCLAN,-
/ L3-PROT=*IP(L4-PROTOCOL=*TCP,IP-ADDRESS=192.168.138.2))
/BCACT LOCVM1
/CREATE-...
