14.2.3 SX140

Overview
Maximum equipment: 16 CPUs and 64 GB memory.
Supports a maximum of 2 system board, each with a maximum of 8 CPUs, 8 memory
packages and 8 PCI slots. Also 1 PCI/disk box with 10 PCI slots exists for each physical
system board for model SX140-40C and higher.
Each system board can be operated in PSB or XSB mode.
Supports extended partitions (XPARs)
In XSB mode up to 4 extended system boards can be configured for each physical
system board (i.e. a maximum of 8 extended system boards can be used, see
Each partition consists of at least 1 physical or extended system board; i.e. the following
maximum numbers of partitions are possible:
–
–
–
It is not possible to mix PSBs and XSBs in one partition.
i
Minimum equipment per extended system board used: 1 CPU and 1 memory package.
Optional full Fibre Channel connectivity.
Max. memory per BS2000 partition for BS2000/OSD and X2000 combined: 12 GB
Optional, a maximum of 32 channel connections (type 2 and/or type S) are available for
each BS2000 partition.
398
2 physical partitions
oder 8 extended partitions
or 1 physical und 4 extended partitions
Each partition requires its own boot PROM. 2 boot PROMs are present on each
system board and 2 more can be configured in each PCI/disk box.
Appendix
table 16).
