Functional scope, concepts and applications

10.1.5 An example of the DR scenarios

In this example an SX150 server with one BS2000 and one Solaris partition and a free XSB
is used. The following is assumed here:
The BS2000 partition (model variant SX150-40C) is configured as follows:
XSB 00-0:
XSB 00-1:
XSB 01-0:
BS2000 works with 4 BS2000 CPUs (one of the 5 CPUs is for X2000) and, in line with
the SX150 model (see
memory (2 GB for X2000/Solaris, 4 GB are unused in the initial status).
All requirements (see
connection and configuration of the devices (console, LAN, etc.) on the primary boot-
XSB 00-0 and the secondary boot-XSB 01-0 are satisfied.
In the initial status XSBs 00-2 and 00-3 are integrated into a Solaris partition.
The two CoD-CPUs are implemented using XSB 01-1 with 2 CPUs (and 8 GB of
memory and 3 PCI slots).
This XSB can be operated in the periods when it is not used by the Bs2000 partition, in
the Solaris partition or in a separate Solaris partition.
XSBs 01-2 and 01-3 are not present.
The hardware ports of the peripherals are implemented with redundancy via the PCI
slots of XSBs 00-0 and 01-0.
296
1 CPU, 8 GB memory;
boot-XSB in the basic configuration / primary boot-XSB
2 CPUs, no usable memory and no usable I/O ports
(OBP parameters no-obp-sb, no-mem-sb, no-io-sb set; CPU-XSB)
2 CPUs, 8 GB memory; secondary boot-XSB
table 17 on page
page 293) for the DR capability of this partition, e.g. redundant
403), uses 10 GB of memory as its main
Dynamic Reconfiguration
