Preconfiguring terminals

3.3.4 BS2000 dialog

SX servers without entry-level models
To create BS2000 dialog access to a partition, the following command must be entered
when creating the action if the Secure Shell is not used:
dtterm -e rlogin <server name of the BS2000 partition> -l em9750
If the Secure Shell is used, the following command must be entered when creating the
action:
dtterm -e ssh <server name of the BS2000 partition> -l em9750
The call to the terminal emulation dtterm can be extended as described above to include
parameters for assigning a title text and selecting a character set.
Example without using the Secure Shell
dtterm -fn 9x15 -title "BS2000 dialog" -e rlogin sx-bs2 -l em9750
Example using the Secure Shell
dtterm -fn 9x15 -title "BS2000 dialog" -e ssh sx-bs2 -l em9750
Details of setting up console accesses to the guest systems of a VM2000 system are
provided in the section "Operating the guest systems using operator terminals" in the
"VM2000
SX server entry-level models with local console
To create BS2000 dialog access to a partition, the following command must be entered
when creating the action:
dtterm -e sh –c "exec login em9750"
Example
dtterm -fn 9x15 -title "BS2000 dialog – SX100" -e sh –c "exec login
em9750"
38
(BS2000/OSD)" [14] manual.
Functions of the Solaris-CDE interface
U41272-J-Z385-3-76
