Goodrive100-PV Series Solar Pump Inverter
P05 group Input terminals
Function
code
P05.00
HDI input type
S1 terminals
P05.01
function
selection
S2 terminals
P05.02
function
selection
S3 terminals
P05.03
function
selection
S4 terminals
P05.04
function
selection
S5 terminals
P05.05
function
selection
HDI terminals
P05.09
function
selection
Name
0: HDI is high-speed pulse input. See
P05.49–P05.54.
1: HDI is digital input
0: No function
1: Run forward
2: Run reversely
3: Three-wire running control
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and A
setting
15: Shift between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi-step speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Traverse pause (stop at the current
frequency)
27: Traverse reset (return to the center
frequency)
28: Counter reset
29: Disable torque control
Description
-31-
Function parameter list
Default Modify
◎
1
◎
42
◎
43
◎
44
◎
45
1
◎
46
