Low-frequency
P04.10
control factor of
High-frequency
P04.11
control factor of
P04.12
P04.36
closed-loop KP
P04.37
closed-loop KI

P05 group Input terminals

Function
code
P05.01 Function of S1
Name
In space voltage vector control mode, the
oscillation motor, especially the large-power motor,
may experience current oscillation at
motor 1 certain frequencies, which may cause
unstable motor running, or even inverter
overcurrent. You can adjust the two
oscillation
function codes properly to eliminate such
phenomenon.
motor 1
Setting range of P04.10 and P04.11: 0–
Oscillation
100
control
Setting range of P04.12: 0.00Hz–P00.03
threshold
(Max. output frequency)
Reactive
0–5000
Reactive
0–5000
Name
0: No function
1: Run forward
2: Run reversely
3: Reserved
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10–29: Reserved
30: Disable ACC/DEC
31–33: Reserved
34: DC braking
35: Reserved
36: Switch the running command channel
to keypad
Description
Description
-28-
Function parameter list
Default Modify
○
10
○
10
○
30.00Hz
○
50
○
50
Default Modify
◎
1
