Page 5 Preface This manual describes MICRO/I operator interfaces (HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P) and WindO/I-NV4 general configuration software. The information includes drawing tools, setup procedures, and how to configure all MICRO/I operator interfaces. This manual explains the operation and handling of the MICRO/I HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/ 1P.
Page 6 Symbols Used in this Manual This manual uses the following symbols to facilitate explanation. Symbols Information that requires special attention. Failure to operate the product in accordance …… with the information provided can lead to serious injury or damage. Information relating to requests or material to reference in the use of a function ……...
Page 7 Abbreviations, Generic Terms, and Terminology Used in this Manual Item Description HG5G-V The name is short for MICRO/I HG5G-VFXT22MF-B. HG4G-V The name is short for MICRO/I HG4G-VCXT22MF-B. HG4G The name is short for MICRO/I HG4G-CJT22*F-B. HG3G-V The name is short for MICRO/I HG3G-V*XT22MF-*. HG3G The name is short for MICRO/I HG3G-*JT22*F-*.
Page 8 Item Description A group of 32 texts maximum that is in order to dynamically switch the character Text Group displayed on the MICRO/I according to the value of the device address. Text fonts that can be displayed on the Windows OS on which the WindO/I-NV4 is Windows Font running.
Page 9: Table Of Contents
Contents SAFETY PRECAUTIONS ................Preface-1 Revision history ................... Preface-3 Caution ....................... Preface-3 Trademarks ....................Preface-3 Preface ....................... Preface-4 Symbols Used in this Manual ................ Preface-5 Abbreviations, Generic Terms, and Terminology Used in this Manual ....Preface-6 Chapter 1 System Composition System Composition....................
Page 10: Preface
Chapter 3 Communication Device Link Communication..................3-1 Overview ....................... 3-1 Device Link Communication Settings..............3-2 O/I Link Communication..................3-3 Overview ....................... 3-3 O/I Link Communication Settings..............3-3 DM Link Communication..................3-4 Overview ....................... 3-4 DM Link Communication Settings..............3-6 No External Devices ....................3-7 Overview .......................
Page 11 Project Settings Dialog Box.................. 4-25 System Tab....................4-25 Communication Interface Tab.................4-35 Communication Driver Tab ................4-45 Communication Driver Network Tab..............4-50 O/I Link Tab ....................4-53 User Communication Tab ................4-54 Sub Host Communication Tab.................4-58 Printer Tab....................4-60 External Memory Device Tab ................4-61 3.10 Autorun Tab....................4-62 3.11...
Page 12 Chapter 6 Drawings and Parts Overview ......................6-1 Drawing objects ....................6-2 Shapes ......................6-2 Picture......................6-2 Text ......................6-2 Part Types......................6-3 Buttons ......................6-3 Lamps ......................6-3 Data Displays ....................6-3 Charts ......................6-4 Commands ....................6-4 Drawings and Parts Overlapping ................6-5 Overview .......................
Page 13 Goto Screen Button..................... 8-39 How the Goto Screen Button is Used ..............8-39 Goto Screen Button Configuration Procedure ........... 8-40 Properties of Goto Screen Button Dialog Box ........... 8-41 Print Button......................8-56 How the Print Button is Used .................8-56 Print Button Configuration Procedure ..............8-57 Properties of Print Button Dialog Box ..............8-58 Key Button ......................
Page 14 Chapter 10 Data Displays Numerical Input ....................10-1 How the Numerical Input is Used ..............10-1 Numerical Input Configuration Procedure ............10-2 Properties of Numerical Input Dialog Box ............10-3 How to Enter Values ..................10-25 Advanced Usage..................10-26 Character Input ....................10-27 How the Character Input is Used ..............10-27 Character Input Configuration Procedure............
Page 15 Calendar ......................10-187 10.1 How the Calendar is Used ................10-187 10.2 Calendar Configuration Procedure .............. 10-188 10.3 Properties of Calendar Dialog Box............... 10-189 Chapter 11 Charts Bar Chart ......................11-1 How the Bar Chart is Used ................11-1 Bar Chart Configuration Procedure..............11-2 Properties of Bar Chart Dialog Box..............
Page 16 Multi-Command ....................12-38 How the Multi-Command is Used ..............12-38 Multi-Command Configuration Procedure............12-39 Properties of Multi-Command Dialog Box............12-40 Timer ....................... 12-59 How the Timer is Used ................12-59 Timer Configuration Procedure ..............12-60 Properties of Timer Dialog Box ..............12-61 Chapter 13 Alarm Log Function Overview ......................13-1...
Page 17 Chapter 15 Operation Log Function Overview......................15-1 How the Operation Log Function is Used............15-1 Recorded Events ...................15-3 Data Configuration ..................15-4 Saving and Deleting Data ................15-6 Using the Data....................15-7 Operation Log Function Configuration Procedure ........... 15-8 Configuring the Events and the Condition for Recording ........15-8 Operation Log Settings Dialog Box ..............15-10 Operation Log Settings Dialog Box..............
Page 18 Recipe Settings Dialog Box ...................18-8 Recipe Settings Dialog Box................18-8 Individual Settings Dialog Box ..............18-10 Creating and Deleting Data for Recipes ............... 18-14 Editing Recipe Data ..................18-14 Creating Recipe Files ................... 18-17 Editing Recipe Files..................18-21 Deleting Recipe Files ................... 18-22 Chapter 19 Text Group Overview ......................19-1...
Page 19 Chapter 21 Sound Function Function and Settings..................21-1 Overview - How the Sound Function is Used ........... 21-1 Supported Sound Files...................21-1 Sound Function Configuration Procedure .............. 21-2 Configuring Sound Files & Trigger Conditions ..........21-2 Sound Settings Dialog Box................... 21-6 Sound Settings Dialog Box ................
Page 20 Chapter 24 Online Function Communicating with the MICRO/I.................24-1 How the Online Function is Used ..............24-1 Connect MICRO/I to a Computer ..............24-4 Change Communication Settings ..............24-5 Downloading ..................... 24-12 Downloading Project Data to the MICRO/I ............ 24-12 Download Dialog Box................... 24-14 Downloading Files to an External Memory Device Inserted in the MICRO/I ..
Page 21 Simulator ......................26-7 Simulator...................... 26-7 Screen Monitor ................... 26-10 Custom Monitor ..................26-11 Batch Monitor ..................... 26-13 Script Debugger ..................26-15 Monitoring on the MICRO/I.................26-18 Chapter 27 Pass-Through Function Overview......................27-1 How the Pass-Through Function is Used............27-1 Supported External Devices ................27-2 How to Connect when Using the Pass-Through Function ........27-3 Use the Pass-Through Function ..............27-3 Pass-Through Function Settings Procedure............
Page 22 Operating E-mail function and checking sending status ........28-42 Restrictions of each E-mail ................28-43 E-mail Function Configuration Procedure ............28-44 E-mail Settings Dialog Box ................28-54 Chapter 29 Data Transfer Function Project Transfer Function..................29-1 What Can Be Done with the Project Transfer Function........29-1 Project Transfer Procedures................29-2 Converting Project for Transfer ...............29-3 Using Key Buttons, Multi-Buttons, or Multi-Commands to Transfer Project Data...
Page 23 Chapter 31 External Memory Devices External Memory Devices ..................31-1 Supported External Memory Devices............... 31-1 What Can Be Done Using an External Memory Device........31-1 Specifications of External Memory Devices ............31-2 File structure ....................31-3 Reading/Writing Data ..................31-4 Setting the External Memory Device Folder ........... 31-15 Deleting Files on the External Memory Device ..........
Page 24 Settings ......................34-7 Initial Setting (Initial Setting) .................34-7 Clock Setting....................34-11 Offline (Offline) ................... 34-11 Run ......................34-11 System Information (System Info.) ............... 34-12 File Manager ....................34-13 Ext.Mem.Device ..................34-13 Top Page ....................34-13 Self Diagnosis (Self Diag.) ................34-13 Chapter 35 MICRO/I Specifications HG5G/4G/3G/2G-V....................35-1...
Page 25 HG1P ........................35-57 Packing content ..................35-57 Part Numbers....................35-57 Part Names....................35-58 External Interfaces ..................35-59 Specifications....................35-60 Dimensions....................35-63 Installation ....................35-64 Wiring ......................35-67 Maintenance and Inspection ................ 35-69 Options ......................35-72 Optional items .................... 35-72 Replacement Parts ..................35-76 About the Warranty of the products ..............35-77 Warranty Period ..................
Page 26 WindO/I-NV4 User’s Manual Preface...
Page 27: Chapter 1 System Composition
System Composition Chapter 1 System Composition There are two types of system compositions used in operating the MICRO/I: One that is configured for the operation, and the other that is used for creating projects required for performing operations. In creating projects, use the WindO/I-NV4, the dedicated configuration software application for the MICRO/I.
Page 28: System Composition For Creating Screens
1 System Composition 1.2 System Composition for Creating Screens It is necessary to create and download a project to the MICRO/I for operating it. Use the WindO/I-NV4 to create a project. The project you have created can be downloaded to the MICRO/I by directly connecting it to the computer, or the project data can be downloaded to external memory device, and then it can be copied from external memory device to the MICRO/I equipped with the memory card interface or the USB interface.
Page 29: About The Windo/I-Nv4
2 About the WindO/I-NV4 About the WindO/I-NV4 WindO/I-NV4 is software that is exclusively designed for operation with the MICRO/I, for specifying settings and creating screens. The set of data made up of settings and created screens is called a project. Using WindO/I-NV4, you create a project and then download it to the MICRO/I, to build the interface necessary for operation.
Page 30: Operating Modes
3 Operating Modes Operating Modes The MICRO/I includes multiple modes, so you switch between modes as and when necessary. These modes are called operating modes. The functions and the operations and conditions for switching are as follows. Conditions required for Mode Functions switching to the mode...
Page 31: Flow From Screen Creation And To Run Operation
4 Flow from Screen Creation and to Run Operation Flow from Screen Creation and to Run Operation The following flowchart describes the sequence of step from the screen creation for the MICRO/I to the Run operation. Launch the WindO/I-NV4 ( refer to Chapter 2 “2.1 Starting WindO/I-NV4” on page 2-38) Creating a Project and Screen Creating a new project (...
Page 32 4 Flow from Screen Creation and to Run Operation Launch WindO/I-NV4 Launch WindO/I-NV4. Creating a Project and Screen Create a project and performing various settings. Create display screens. Saving the project Save the project data at any time after the configuration settings are done. Downloading the project Connect the computer to the MICRO/I using a USB cable or Ethernet cable and download the created project data to the internal memory of the MICRO/I.
Page 33: Chapter 2 Windo/I-Nv4 Features & Basic Operations
WindO/I-NV4 Features & Basic Operations Chapter 2 This chapter describes the minimum system requirements for WindO/I-NV4, how to start and exit it, and the configuration of its screens and menus. WindO/I-NV4 Specifications 1.1 Available Data Data types ● Data type is the format of the data related to the minimum and maximum values of data that can be processed by a part and handling of negative and real numbers.
Page 34 1 WindO/I-NV4 Specifications Data type Data handling Data is handled as an eight digit (32-bit) binary-coded decimal Upper word Lower word value. Each four bits from bit 0 to bit 27 is handled as the absolute value BCD8(EB) for the 1st to 7th digit. Sign Absolute value Bit 28 to bit 31 is handled as the minus sign (-) when its value is F...
Page 35 1 WindO/I-NV4 Specifications Example: Data handling Data type Storing 0FFF (Hex) in LDR0 Storing FFFF (Hex) in LDR0 LDR0 LDR0 UBIN16(W) 1111 111111111111 0000111111111111 0FFF (Hex) FFFF (Hex) 0FFF (Hex) is handled as 4095 (Dec). FFFF (Hex) is handled as 65535 (Dec). LDR0 LDR0 0000...
Page 36 1 WindO/I-NV4 Specifications Data type Storing "MICRO/I" in LDR50 Select from Upper byte in Storage Method of String Data LDR50 LDR51 LDR52 LDR53 Stored value (No change) (4d) (49) (43) (52) (4f) (49) Upper byte Lower byte Upper byte Lower byte Upper byte Lower byte Upper byteLower byte...
Page 37 1 WindO/I-NV4 Specifications Indirect Read and Indirect Write Settings ● The indirect specification of a device address means to add a value (indirect value) to the address number of the set device address and use that address number as the actual read source or write destination. You can change the read source or write destination address number just by changing this indirect value.
Page 38: Available Text
1 WindO/I-NV4 Specifications 1.2 Available Text Font ● Supported Languages The MICRO/I can display multiple fonts by installing them. In addition to the fonts installed on the MICRO/I, all Windows fonts displayed on your computer can be used on the display. Font Description Fonts to be pre-loaded on the MICRO/I.
Page 39 1 WindO/I-NV4 Specifications Installed Fonts in the MICRO/I Font Name Code System Language JIS 8-bit code Japanese JIS level-1 and Japanese level-2 kanji sets Icelandic, Irish, Italian, English, Dutch, Swedish, Spanish, Danish, English ISO 8859-1 (Latin1) Standard German, Norwegian, Portuguese, Finnish, Faeroese, French Fonts Icelandic, Irish, Italian, English, Dutch, Swedish, Spanish, Danish, Stroke...
Page 40 1 WindO/I-NV4 Specifications Available Fonts for Parts Parts Description Windows Font MICRO/I-installed Font Bit Button Word Button Goto Screen Button Print Button Buttons Key Button Keypad Selector Switch Pilot Lamp Lamps Multi-State Lamp Numerical Input Character Input *2*3 Message Display Message Switching Display Data Displays Alarm List Display...
Page 41 1 WindO/I-NV4 Specifications Font Size Font Name Code System Size Japanese large font (first standard) JIS level-1 kanji set 476KB Japanese large font (second standard) JIS level-2 kanji set 423KB Chinese GB2312 237KB Korean KSC5601 108KB Optional Fonts Taiwanese BIG5 421KB European large font ISO 8859-1 (Latin1)
Page 42 1 WindO/I-NV4 Specifications High-quality Fonts ● The high-quality fonts are the Japanese large fonts (first standard/second standard), and European fonts. If you download high-quality fonts and select Use large font on the System tab in the Project Setting dialog box, the MICRO/I can replace some of the optional fonts with the high-quality fonts.
Page 43 1 WindO/I-NV4 Specifications High-quality Japanese Font Display (Size 8x16) WindO/I-NV4 User’s Manual 2-11...
Page 44 1 WindO/I-NV4 Specifications High-quality Japanese Font Display (Size 16x16) • When the high-quality fonts have not been downloaded into the operator interface, the Standard fonts are used even if “Use large font” is selected. • When the Character Input part display font size is 8x16, high-quality fonts are not displayed even if “Use large font”...
Page 45 1 WindO/I-NV4 Specifications Windows Font ● Selecting Windows Font for the Font property gives you access to all of the fonts installed on your computer for use on Drawing Objects and Parts. This allows you to display fonts and languages that are not installed on the MICRO/I. Windows Font Settings Windows Font settings are made in the Font Settings dialog box.
Page 46 1 WindO/I-NV4 Specifications Using Windows Fonts This section describes how to use Windows Fonts. Selecting Windows Font for the Font property for Draw Objects and Parts automatically disables these properties: • Style: The style set under Windows Font will be used. •...
Page 47 1 WindO/I-NV4 Specifications To select a font in the Properties dialog box Applicable Text draw object Buttons Bit Button, Word Button, Goto Screen Button, Print Button, Key Button, Keypad Applicable parts Lamps Pilot Lamp, Multi-State Lamp Select Windows for Font on the Properties dialog box for a Draw Object or Part. The Font property may appear in different locations depending on the part.
Page 48 1 WindO/I-NV4 Specifications Character Code Table ● Using the Character Code Table Example: Finding the character code for the character “a” in the table. Upper 4 bits of the code (hexadecimal) Lower 4 bits of the code (hexadecimal) The upper four bits of the code are hexadecimal 6. The lower four bits of the code are hexadecimal 1.
Page 49 1 WindO/I-NV4 Specifications European Font (ISO 8859-1) Central European Font (ANSI 1250) WindO/I-NV4 User’s Manual 2-17...
Page 50 1 WindO/I-NV4 Specifications Baltic Font (ANSI 1257) Cyrillic Font (ANSI 1251) WindO/I-NV4 User’s Manual 2-18...
Page 51 1 WindO/I-NV4 Specifications Japanese Font (JIS X0201) Control Codes Refer to the following table when using control codes in User Communications. WindO/I-NV4 User’s Manual 2-19...
Page 52: Available Number Of Colors
Calendar, and Meter cannot correctly display pictures that use a transparent color. • IDEC recommends using bitmap image files when display speed is a priority. JPEG image files take more time to display on the MICRO/I than bitmap image files.
Page 53 1 WindO/I-NV4 Specifications Saving pictures in Picture Manager ● This section describes how to save drawing objects in Picture Manager. Saved pictures can be used for part diagrams and drawings. Saving image files Click Import in Picture Manager. The Open dialog box is displayed. When managing pictures by category, create a new category, and select it.
Page 54 1 WindO/I-NV4 Specifications The picture is saved in Picture Manager. The name of the image file becomes the picture name. (Picture name) • Even when the image is saved to a different category, if a picture of the same name is already saved in that category, a confirmation message to overwrite the file is displayed.
Page 55 1 WindO/I-NV4 Specifications Selecting pictures from Symbol Factory Click Symbol Factory in Picture Manager. Symbol Factory is displayed. When managing pictures by category, create a new category, and select it. To create a category, click Configure, and then click (New Category) on the Category dialog box. For details, refer to “Category Dialog Box”...
Page 56 1 WindO/I-NV4 Specifications Select a picture from (Categories tab) to display it in Preview. The size of the picture displayed in Preview is equal the size of the registered picture. The size of the picture displayed in Preview can be changed. Right-click the picture displayed in Preview, then click Set Preview Size.
Page 57 1 WindO/I-NV4 Specifications Click OK. The picture is saved in Picture Manager. If a picture contains transparency or Transparent Color is selected as to for the imported picture, the transparency range is displayed in magenta (R: 255, G: 4, B: 255). Saving drawing objects drawn on the editing screen Drawing objects drawn on the editing screen are saved as pictures, in NMF (NV Metafile) format in Picture Manager.
Page 58 1 WindO/I-NV4 Specifications Enter the name of the drawing object in Picture Name. The maximum number is 256 characters. You cannot use the following characters in the picture name. \ / : , ; * ? " < > | (Options) Configures the image processing in Options.
Page 59 1 WindO/I-NV4 Specifications Saving pictures as image files ● To use a picture saved in Picture Manager on another computer, save the picture as an image file. Select a picture to export, and then click Export. The Browse For Folder dialog box is displayed. •...
Page 60 1 WindO/I-NV4 Specifications Picture Manager ● Pictures used in pictures of part diagrams and drawings are managed using Picture Manager. (Picture List) (Image) (Picture Name) (Check box) (Rename picture) ■ Renames the picture selected in the picture list. The maximum number is 256 characters. You cannot use the following characters in the picture name.
Page 61 1 WindO/I-NV4 Specifications (Picture list) ■ The saved pictures are displayed as a list of images. (Image): An image of the picture is displayed. If a picture contains transparency or a picture is imported with the option of enabling the transparency, the transparency range is displayed in magenta (R: 255, G: 4, B: 255).
Page 62 1 WindO/I-NV4 Specifications Open Dialog Box By clicking Options, you have the option to set the Apply Dithering and Color Exchange for the image to be registered in the Picture Manager. Apply Dithering ■ Selects this check box to perform dithering (error diffusion method) on images. This function enables some images with tonal gradations and photo-like pictures to be rendered more beautifully when they are saved.
Page 63 1 WindO/I-NV4 Specifications Category Dialog Box Manage the categories where pictures are registered. (Category List) (New Category) ■ Creates a new category in the Category List. The default category name is "NewBook " ( : Number). (Delete Category) ■ Deletes a category from the Category List. (Rename Category) ■...
Page 64 1 WindO/I-NV4 Specifications Symbol Factory Symbol Factory is an English-version library tool that offers 5,000 images. (Categories tab) (Symbol Options) For details, see online help for Symbol Factory. Categories ■ The images supplied by Symbol Factory are divided into categories. Selects categories of pictures saved in Picture Manager.
Page 65 1 WindO/I-NV4 Specifications Symbol Options Modify the fill color and background color, and to flip or rotate a picture selected in (Categories tab). (Symbol Options) Fill Color ■ Fill Color Mode: Select from the following picture color conversion methods. Original: The color of the image is not changed.
Page 66 1 WindO/I-NV4 Specifications Rotation: Select from the following rotation methods. The image is not rotated. The image is rotated 90° counterclockwise. 180: The image is rotated 180° counterclockwise. 270: The image is rotated 270° counterclockwise. None Export Options ■ Background Color: Selects the background color of the image when saving an image in Picture Manager or exporting an image using Export from the right-click menu.
Page 67 1 WindO/I-NV4 Specifications Set Preview Size Dialog Box Configures the size of picture selected from (Categories tab). (Width) (Height) (Setting Method) (Width) ■ Enters the width of the picture in pixels. (Height) ■ Enters the height of the picture in pixels. (Setting Method) ■...
Page 68 1 WindO/I-NV4 Specifications Picture Name Setting Dialog Box Specifies a name for images saved in Picture Manager. (Image) (Image) ■ An image of the picture is displayed. Picture Name ■ Enter a name for the picture. The maximum number is 256 characters. You cannot use the following characters in the picture name.
Page 69: Available Sound Files
1 WindO/I-NV4 Specifications 1.5 Available Sound Files HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The sound file formats that can be played on the MICRO/I are as follows. Item Description File format Wave files (.wav) Data format Sampling rate 8000, 11025, 12000, 16000, 24000, 22050, 32000, 44100 Hz Quantization...
Page 70: Starting And Exiting Windo/I-Nv4
2 Starting and Exiting WindO/I-NV4 Starting and Exiting WindO/I-NV4 2.1 Starting WindO/I-NV4 Windows 10 ■ Click Start, click All Apps, click Automation Organizer V2, and then click WindOI-NV4. Windows 8 ■ On the Start screen tiles, click WindOI-NV4. Windows 7, Windows Vista ■...
Page 71 Date Shows the date the software was released. Information Shows the software's title and version. Click on this link to connect to IDEC's download site. The software can be updated by downloading and running the latest version. Description ■ This area shows the details of the latest changes in the software.
Page 72: Exiting Windo/I-Nv4
2 Starting and Exiting WindO/I-NV4 Project Recovery Dialog Box ● The Project Recovery dialog box is a feature to restore edited project data if your computer crashes while you were editing. With this feature, you can return crashed the project to its last-saved state and restore project data that was being edited.
Page 73: Configuration & Functions
3 Configuration & Functions Configuration & Functions This section describes the names and functions that make up WindO/I-NV4. Quick access toolbar Title bar Application menu Ribbon Workspace Editing window Information Window Status bar Right click menu Title bar ■ The title bar shows the name of the project being edited and the name of this software, “WindO/I-NV4”. Application menu ■...
Page 74: Application Menu Command List
3 Configuration & Functions 3.1 Application Menu Command List Commands that can be executed from the application button are listed below. Command Description Creates project data by configuring settings displayed in dialog boxes step by step. Open Opens project data that has already been created. Save Saves the project data being edited.
Page 75: Quick Access Toolbar
3 Configuration & Functions 3.2 Quick Access Toolbar Quick access toolbar buttons and menus ● Click on a quick access toolbar button or click on ▼ to the right of a button and then click on the displayed command to execute that command. Quick access toolbar Customizing the quick access toolbar ●...
Page 76 3 Configuration & Functions Add or delete commands. To add a command Select the command to add in Choose commands from. Click on the command to add from the list and then click the Add>> button. The command is added. To delete a command Click the command to delete and then click the Remove button.
Page 77 3 Configuration & Functions The quick access toolbar moves below the ribbon. You can also change the quick access toolbar display position to be below the ribbon with the following methods. • Right click the quick access toolbar or the ribbon and then click Show below the Ribbon. •...
Page 78 3 Configuration & Functions 3.3 Ribbon Command List Home ● Home is where basic operations are performed such as creating a new screen, editing, and downloading project data. Clipboard ■ Command Description Paste Pastes the contents of the clipboard. Cuts the selected object from the editing window and copies it to the clipboard. Copy Copies the selected object to the clipboard.
Page 79 3 Configuration & Functions Parts ■ Command Description Bit Button Inserts a Bit Button. Word Button Inserts a Word Button. Goto Screen Button Inserts a Goto Screen Button. Print Button Inserts a Print Button. Buttons Key Button Inserts a Key Button. Multi-Button Inserts a Multi-Button.
Page 80 3 Configuration & Functions Editing ■ Command Description Bring to Front Moves the selected object to the front. Send to Back Moves the selected object to the back. Group Groups multiple objects. Ungroup Cancels the group. Align Left Aligns selected objects to the left. Align Center Aligns selected objects to the center.
Page 81 3 Configuration & Functions Configuration ● Configuration is where you configure the system settings for the MICRO/I that will use the project data being edited. System Setup ■ Command Description Project Configures MICRO/I operations and functions. Alarm Log Configures the alarm log. Data Log Configures the data log.
Page 82 3 Configuration & Functions Online ● Online is where you download created project data and files to the MICRO/I, where you upload data from the MICRO/I, and where you perform monitoring. Transfer ■ Command Description Project Data Downloads project data to the MICRO/I. Files to External Memory Stops the MICRO/I and then downloads files to the external memory device inserted Download...
Page 83 3 Configuration & Functions Communication ■ Command Description Configures the communication target and communication conditions between the Setup target and the MICRO/I or between the computer and the MICRO/I. View ● View is where you can switch the workspace display and display the Tag Editor, Screen Diagram, and various managers.
Page 84 3 Configuration & Functions Screens ■ Command Description Focus Order Changes the order to move the focus with Numerical Input and Character Input. Reset Returns the displayed images to the default images. ON/OFF State Switches between the ON image and the OFF image for buttons and lamps. Previous State Changes the image for the displayed part to the previous state.
Page 85 3 Configuration & Functions Arrange ■ Command Description X-coordinate Changes the X-coordinate of the selected object. Y-coordinate Changes the Y-coordinate of the selected object. Bring to Front Moves selected object to the front. Send to Back Moves selected object to the back. Group Groups selected objects so they can be handled as a single object.
Page 86: Windows Displayed In The Workspace
3 Configuration & Functions 3.4 Windows Displayed in the Workspace Changing the position of windows ● Disabling docking You can change the display position of the window by dragging and dropping the title bar of the window or its tab to disable docking.
Page 87 3 Configuration & Functions When the mouse cursor gets close to a (Docking) icon while dragging the title bar or tab, the location to dock the window is displayed. Window docking location Drop the title bar or tab on the (Docking) icon to dock that window to WindO/I-NV4’s left, right, top, or bottom frame or a separate window.
Page 88 3 Configuration & Functions • If you put the mouse cursor on another window while dragging a floating windows title bar, the (Docking) icon is displayed. Drop the title bar on the (Docking) icon to dock the floating window to that window. Change the displayed window with the tabs.
Page 89: Status Bar
3 Configuration & Functions 3.5 Status Bar Mode Data Size Text Group Type Number Communication Driver Position Active User Preview Zoom Slider Snap to Grid Zoom In button Grid Settings Zoom Zoom Out button Status bar items ● Mode ■ This section of the status bar shows WindO/I-NV4’s current mode.
Page 90 3 Configuration & Functions Snap to Grid ■ Click to align objects to the grid. Grid Settings ■ You can change the style and spacing of the grid displayed in the editing window. Click to display the Grid Settings dialog box. Configure the items and click the OK button. Type: Selects the type of grid.
Page 91 3 Configuration & Functions Preview ■ You can preview an edited screen. Click to open the preview window. Click the button to switch between the OFF image and ON image for buttons and lamps. You can save the image displayed in the preview window as a bitmap image file by clicking the Copy button. The preview display and the actual screen displayed on the MICRO/I may differ.
Page 92: Customizing Windo/I-Nv4
4 Customizing WindO/I-NV4 Customizing WindO/I-NV4 4.1 Configuring the Work Environment You can configure WindO/I-NV4 settings such as mode and options when editing screens, the path when selecting files, and the path for automatic backups. The settings configured here are saved even when you exit WindO/I-NV4. The procedure for configuring the work environment is shown below.
Page 93 4 Customizing WindO/I-NV4 General tab ● Properties ■ Select whether or not to display the Properties dialog box for parts in the Advanced mode. Basic: Displays the Properties dialog box in Basic mode to use only basic functions. Advanced: Displays the Properties dialog box in Advanced mode so that all functions can be used. You can also change the mode by clicking on the Advanced button and the Basic button in the Properties dialog box for parts.
Page 94 4 Customizing WindO/I-NV4 Workspace ■ Workspace Setup: Displays the Workspace Setup dialog box. You can configure items displayed in the workspace window. For details, refer to “4.2 Customizing the Workspace” on page 2-66 Compatibility ■ Use Compatible functions from previous version: Select this box to enable functions from previous versions. For details, refer to Chapter 4 “3.17 Compatible Tab”...
Page 95 4 Customizing WindO/I-NV4 AutoSave ■ Save the following information every: Specify the interval (5 to 60 minutes) for creating an AutoRecover file or Backup from a project being edited. This option can only be set when AutoRecover file or Backup is selected. AutoRecover file: A project being edited is automatically saved as often as you want.
Page 96 4 Customizing WindO/I-NV4 Customize tab ● Choose commands from ■ Select the category of command to add. A list of commands for selected category is displayed. Show Quick Access Toolbar below the Ribbon ■ To change the position of the quick access toolbar to be located below the ribbon, select this check box. Add>>...
Page 97 For details, refer to “Automation Organizer Updater Dialog Box” on page 2-39. Go to IDEC ■ Go online: Shows the IDEC web page for free updates, manuals, and online services. About WindO/I-NV4 ■ About: Shows the About WindO/I-NV4 dialog box and displays the version of WindO/I-NV4.
Page 98: Customizing The Workspace
4 Customizing WindO/I-NV4 4.2 Customizing the Workspace You can change the windows that are displayed in the workspace with the Workspace Setup dialog box. Screen List tab ● This tab changes the Screen List window display. Zoom ■ Select the zoom magnification for the thumbnails displayed in the Screen List window from the following. 100, 125, 150, 175, 200, 250, 300, 350, 400 Object List tab ●...
Page 99 4 Customizing WindO/I-NV4 Parts List tab ● This tab changes the items displayed in the Part List window. Show Image Name ■ Select this box to display the image name for parts in the Part List window. WindO/I-NV4 User’s Manual 2-67...
Page 100: Windo/I-Nv4 Common Operations And Settings
5 WindO/I-NV4 Common Operations and Settings WindO/I-NV4 Common Operations and Settings This section describes common settings when creating project data. 5.1 Device Address Settings Device addresses are memory on the MICRO/I and external devices that can store values in bit or word units. By setting device addresses to parts and functions, you can control the screen display and operation of parts.
Page 101 5 WindO/I-NV4 Common Operations and Settings Bit Number ■ Specifies the bit number in a word device (0 to 15). This option can only be configured when a word device is selected for Device Type. Show ■ Select from the following and display the device addresses on the (Address list). All: Displays all of the device addresses that can be used with the device selected in Target.
Page 102 5 WindO/I-NV4 Common Operations and Settings Cross Reference Dialog Box On the Tag Editor, select the device address, and then click (Cross Reference) to show the screen type, screen number, and part number where that device address is used. Enter the device address in Device Address and click (Reflesh) to see the updated data.
Page 103: Setting Conditional Expressions
5 WindO/I-NV4 Common Operations and Settings 5.2 Setting Conditional Expressions Specify conditional expressions with Condition on the Trigger Condition tab. Conditional expressions are specified by combining data and operators using the following basic format. Data Operator Data Directly enter the conditional expression or specify it with the Trigger Conditions Settings dialog box. Direct entry ●...
Page 104 5 WindO/I-NV4 Common Operations and Settings Data and operations that can be configured ● Data You can specify these types and values of data for conditional expressions. Item Description Set a constant number as data. Value The range that can be set differs according to the selected data type. For details, refer to “Data types”...
Page 105 5 WindO/I-NV4 Common Operations and Settings Setting and operation examples ● Settings Action Trigger Condition Settings Direct entry dialog box The condition is satisfied if the values of Data Data [M 0] == [M 1] M0 and M1 are equal. The condition is satisfied if the result of Data Data...
Page 106 5 WindO/I-NV4 Common Operations and Settings WindO/I-NV4 User’s Manual 2-74...
Page 107: Chapter 3 Communication
Communication Chapter 3 This chapter describes the communication between the MICRO/I and the external device. Device Link Communication HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 Overview Device Link Communication refers to the communication protocol used for communication with the MICRO/I, via the CPU Unit or PLC Link Unit Programming Port of the external device connected to the MICRO/I.
Page 108: Device Link Communication Settings
1 Device Link Communication Connection Types ● There are two basic types of connections. 1:1 Communication, where an external device is connected to a MICRO/I; and 1:N Communication, where multiple external devices are connected to a MICRO/I. 1:1 Communication ■ The MICRO/I is connected to a single external device.
Page 109: I Link Communication
2 O/I Link Communication O/I Link Communication HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 2.1 Overview O/I Link Communication is a protocol for communication between Master and Slave, where a MICRO/I connected to the external device is configured as a Master and multiple MICRO/I (Slaves) communicate with the external device via the Master.
Page 110: Dm Link Communication
DM Link Communication reads and writes value to external devices using the MICRO/I's dedicated DM Link memory. The device type of dedicated DM Link memory is DM. This method uses a dedicated IDEC protocol, so a communication program is required in the external device. DM Link Communication...
Page 111 3 DM Link Communication DM Link 1:N Communication ■ HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The external device is connected to multiple MICRO/I by using a serial interface. DM Link 1:N Communication MICRO/I External device Read Write Dedicated DM Link memory...
Page 112: Dm Link Communication Settings
• Click Communication Driver on the status bar to display the Communication Driver tab on the Project Settings dialog box. For details, refer to Chapter 4 “Changing Communication Drivers” on page 4-21. Select IDEC System in Manufacturer, and then select DM Link (1:1), DM Link (1:N) or DM Link Ethernet (UDP) in Communication Driver.
Page 113: No External Devices
4 No External Devices No External Devices HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 4.1 Overview In this case, there is no communication with an external device, so the MICRO/I operates as a standalone unit. It is only possible to operate the MICRO/I with relays and registers. MICRO/I No external device Internal device...
Page 114: User Communication
5 User Communication User Communication HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 5.1 Overview User Communication allows you to develop a communication protocol to transmit and receive data from an external device, such as a barcode reader. User Communication is supported up to three interfaces of the MICRO/I, either serial, Ethernet, or USB interfaces.
Page 115: User Communication Settings Procedure
5 User Communication 5.2 User Communication Settings Procedure This section describes the procedure for setting user communication. Create a new user communication protocol, and then configure it to a communication interface ● Using Transmission Command and Receive Command HG5G-V HG4G-V HG4G HG3G-V HG3G...
Page 116 5 User Communication Specify the items for Interface Settings. The settings vary based on the interface. Serial Interface ■ • HG5G/4G/3G/2G-V, HG4G/3G, HG2G-F  For details, refer to Chapter 4 “When COM1, COM2, COM2(RS232C), or COM2(RS422/485) is selected under Interface Configuration” on page 4-38. •...
Page 117 5 User Communication Enter the name of the user communication protocol that will be set in Protocol Name. The maximum number for protocol name is 40 characters. You cannot use the following characters in the protocol name. \ / : , ; * ? " < > | Set the time out (0 to 255) in Receiving Character Time Out (x100 msec).
Page 118 5 User Communication Set Transmission (TXD) command. Click Add under Command List. The Command Settings dialog box is displayed. Select TXD in Type. Specify the transmitted data to the external device connected to the MICRO/I and the conditions for transmitting data.
Page 119 5 User Communication Select the condition to transmit data in Trigger Type under Trigger Condition from the following. Rising-edge ■ Data is transmitted when the value of device address changes from 0 to 1. Specify the bit device or the bit number of the word device as the condition. Click to display the Tag Editor.
Page 120 5 User Communication Set data for transmission command. Click Add under Data List. The Data Settings dialog box is displayed. Select data type in Type. Data setting items are displayed. For details on transmission command, refer to “Transmission (TXD) Command” on page 3-49. Set the data, and then click OK.
Page 121 5 User Communication Repeat steps through to set all the data for the transmission command. • The data is displayed in Data List in the order they were set. To change the order of data, select data, and then click Up or Down to shift it. •...
Page 122 5 User Communication Specify Receive (RXD) command. Click Add under Command List. The Command Settings dialog box is displayed. Select RXD in Type. Define the data configuration for received data from the external device. WindO/I-NV4 User’s Manual 3-16...
Page 123 5 User Communication Select the condition for being ready to receive data in Trigger Type under Trigger Condition from the following. Always Enabled ■ The device is always ready to receive data. While ON ■ Ready to receive data when the value of device address is 1. Specify the bit device or the bit number of the word device as the condition.
Page 124 5 User Communication Set data for receive command. Click Add under Data List. The Data Settings dialog box is displayed. Select data type in Type. Data setting items are displayed. For details on receive command, refer to “Receive (RXD) Command” on page 3-62. Specify the data, and then click OK.
Page 125 5 User Communication Repeat steps through to specify all the data for the receive command. • The data are displayed in Data List in the order they were set. To change the order of data, select data, and then click Up or Down to shift it. •...
Page 126 5 User Communication Configure all commands, click OK. This concludes configuring user communication to use Transmission (TXD) and Receive (RXD) commands. To set the created user communication protocol to another user communication or to use it in another project, click Copy to Protocol Manager to register it in Protocol Manager. For details on the Protocol Manager, refer to “5.3 Protocol Manager”...
Page 127 5 User Communication Using Inching Function HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P On the Configuration tab, in the System Setup group, click Project. The Project Settings dialog box is displayed. Click the Communication Interface Tab in the Project Settings dialog box. Select the interface for user communication under Interface Configuration, and then select the User Communication 1 in Function under Interface Settings.
Page 128 5 User Communication Specify the items for Interface Settings. The settings vary based on the interface. Serial Interface ■  For details, refer to Chapter 4 “When SERIAL1(RS232C), SERIAL1(RS422/485), COM(RS232C), or COM(RS422/485) is selected under Interface Configuration” on page 4-39. Ethernet Interface ■...
Page 129 5 User Communication Double click the cell under Inching Function and select Enable. Specifies the Execution Interval (x10 msec) as 40 to 1000 (20 ms increments). Select the Inching check box. The items displayed in Command List can be changed with the TXD, RXD and Inching check boxes. Commands in Command List are displayed in the order they were created, but commands for inching function are always displayed above the transmission and receive commands in the list.
Page 130 5 User Communication Select Inching in Type. Specify the transmitted data for the inching function to the external device connected to the MICRO/I and the conditions for transmitting data. With Function Key under Trigger Condition, select the function key (F1 to F12) to which the command will be assigned.
Page 131 5 User Communication Enter a comment of the command for the inching function in Comment under Detail. The maximum number is 40 characters. Set the command data for the inching function. Click Add under Data List. The Data Settings dialog box is displayed. Select data type in Type.
Page 132 5 User Communication Set the data, and then click OK. The data configured in Data List on the Command Settings dialog box is displayed. Repeat steps through to set all the command data for the inching function. • The data are displayed in Data List in the order they were set. To change the order of data, select data, and then click Up or Down to shift it.
Page 133 5 User Communication Configure all commands, click OK. This concludes configuring user communication. To set the created user communication protocol to another user communication or to use it in another project, click Copy to Protocol Manager to register it in Protocol Manager. For details on the Protocol Manager, refer to “5.3 Protocol Manager”...
Page 134 5 User Communication Configuring registered user communication protocol to another user communication ● Configure an user communication protocol registered in Protocol Manager to another user communication. On the Configuration tab, in the System Setup group, click Project. The Project Settings dialog box is displayed. In the User Communication tab on the Project Settings dialog box, select the user communication to set from the protocol list, and then click Open Protocol Manager.
Page 135 5 User Communication The user communication protocol selected in Protocol Manager is configured to the user communication specified on the Project Settings dialog box. WindO/I-NV4 User’s Manual 3-29...
Page 136 5 User Communication Using registered user communication protocol on another project ● To use the user communication protocol registered in Protocol Manager on another project, save it as a file, and then import it to a project. Saving registered user communication protocol as a file On the Configuration tab, in the Manager group, click Protocol Manager.
Page 137 5 User Communication Importing user communication protocol On the Configuration tab, in the Manager group, click Protocol Manager. Protocol Manager is displayed. On Protocol Manager, click Import. The Open dialog box is displayed. Specify the user communication protocol file, and then click Open. The user communication protocol is registered in Protocol Manager.
Page 138: Protocol Manager
5 User Communication 5.3 Protocol Manager User communication protocols to use in user communication can be created and registered protocols can be edited. (Protocol List) (Type) (Protocol List) ■ Displays the registered user communication protocol. No.: Displays the number for managing the user communication protocol. Protocol Name: Enter the name of the user communication protocol.
Page 139 5 User Communication • The value of the Receiving Character Time Out (address number+0, bit 15) of the Status Device Address LDR110 remains 0. Receiving Character Time Out duration First byte of receive data Second byte of receive data Receive command Value of Device Address LM100 when Trigger Condition is While ON Value of Completed Device Address...
Page 140 5 User Communication Add Protocol: Adds a user communication protocol to the (Protocol List). Copy Protocol: Copies the selected user communication protocol in the (Protocol List). Click this button to add a copy of the selected user communication protocol to the end of the (Protocol List).
Page 141 5 User Communication Add: Adds a command to the Command List. A maximum of 255 commands may be added. Click this button, displays the Command Settings dialog box. For details, refer to “Command Settings Dialog Box” on page 3-36. Edit: Edits the command selected in the Command List.
Page 142 5 User Communication Command Settings Dialog Box ● Specify the command details for user communication protocol. WindO/I-NV4 User’s Manual 3-36...
Page 143 5 User Communication Type ■ Select the type of communication command from the following items. TXD: A command for data transmission from the MICRO/I to an external device. External device MICRO/I Transmission Transmission data (31h) (32h) (33h) (34h) Processing of transmission command is as follows. Example: When Trigger Type in Trigger Condition is Rising-edge, Device Address is LM100 and Completed Device Address is LM101 When the value of the Trigger Condition device address LM100 changes to 1, data is...
Page 144 5 User Communication Inching: Commands that send data from the MICRO/I to the external device and execute inching operations of the driving part. This option can only be set when Enable is selected in Inching Function on the Project Settings dialog box.
Page 145 5 User Communication Trigger Condition ■ Set the trigger conditions for transmission or receiving of data. TXD is selected as Type: Trigger Type: A condition for data transmission is selected from the following. Rising-edge: Data is transmitted when the value of device address changes from 0 to 1. Value of Device Address Action Execution...
Page 146 5 User Communication While OFF: Ready to receive data when the value of device address is 0. Value of Device Address Action Enabled Enabled Enabled While satisfying the condition: Ready to receive data while the condition is satisfied. Satisfied Condition Not satisfied Action Enabled...
Page 147 5 User Communication Detail ■ Completed Device Address: Specify the bit device or the bit number of the word device for reporting that data transmission or receiving was successfully completed. You can only specify an internal device. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings”...
Page 148 5 User Communication Status Device Address: Specify the destination word device for the transmitted or received data size and error information. Error information and command data size is stored at the beginning of the configured device address. When data transmission or receiving has not successfully completed, the value of each bit changes to 1. The bits of the Status Device Address changes to 0 when the trigger condition is satisfied and they are not changed to 0 automatically.
Page 149 5 User Communication Address Function Description number Transmission Data Size (bytes) Stores the size of transmission data. When the Error Information bit changes to 1, data is not transmitted, and the Transmission Completed Device Address does not change to 1. RXD is selected as Type: Address Function...
Page 150 5 User Communication Address Function Cause Solution number 1 frame of data is not received even when the preset Receiving Time Check the transmission data Receiving Time Out duration has passed after the from the external device. Trigger Condition is satisfied. While 1 frame of data is being received, even after the time out period—the specified time interval between Receiving...
Page 151 5 User Communication Example: When Trigger Type in Trigger Condition is While ON, Device Address is LM100, Status Device Address is LDR110, Completed Device Address is LM101 and the Not Clear Completed Device Address automatically check box is not selected When Status Device Address is LDR110, error information and time out information is stored in each bit of LDR110.
Page 152 5 User Communication Data List ■ Shows a list of command data. Double clicking the line displays the Data Settings dialog box. For details, refer to “Data Settings Dialog Box” on page 3-48. The maximum data size that can be configured is 1500 bytes per command.
Page 153 5 User Communication BCC: Displays the specified data enclosed in BCC ( ). BCC(Calculation Start Position Calculation End Position Calculation Type Conversion Type Number of bytes) Calculation Start Position: Displays the data position where the BCC calculation starts. Calculation End Position: Displays the data position where the BCC calculation ends.
Page 154 5 User Communication Data Settings Dialog Box ● Specify the transmitted or received data by a command. Type ■ Selects data types from the following items. Constant (Character), Constant (Hexadecimal), Device Address, Registering Constant (Character), Registering Constant (Hexadecimal), BCC, Skip Skip can only be configured when RXD is selected as Type on the Command Settings dialog box.
Page 155 5 User Communication Transmission (TXD) Command ● Constant (Character) The character data is sent without being converted. This can be configured only when TXD or Inching is selected as Type on the Command Settings dialog box, and Constant (Character) is selected under Type on the Data Settings dialog box. Data ■...
Page 156 5 User Communication Constant (Hexadecimal) The hexadecimal data is sent without being converted. Use this setting to send a control code of ASCII data (00h to 1Fh). This can be configured only when TXD or Inching is selected as Type on the Command Settings dialog box, and Constant (Hexadecimal) is selected under Type on the Data Settings dialog box.
Page 157 5 User Communication Device Address The value of device address is either not converted or converted to ASCII and then sent as data with the specified size. This can be configured only when TXD or Inching is selected as Type on the Command Settings dialog box, and Device Address is selected under Type on the Data Settings dialog box.
Page 158 5 User Communication Words ■ Specify the number of word devices (1 to 99) of transmitted data. Variable ■ Select this check box to change the transmitted data size according to conditions. This can be configured only when No conversion is selected under Conversion Type. When the check box is not selected, the amount of data (bytes) transmitted is data (bytes) for Number of bytes x Words.
Page 159 5 User Communication Example 3 Item Setting Conversion Type Hexadecimal to ASCII Device Address LDR100 Use Reference Device Address Number of bytes Words Variable When the trigger condition is satisfied, the value of device address is read, and data is converted to ASCII and transmitted in the following order.
Page 160 5 User Communication Example 6 Item Setting Conversion Type No conversion Device Address LDR100 Use Reference Device Address Storage Method of data from Lower byte Number of bytes Words Variable ON, Device Address: LDR200 When the trigger condition is satisfied, the value of device address is read and data is transmitted in the following order.
Page 161 5 User Communication Registering Constant (Character) From the registered character data, character data according to the value of device address is read and transmitted. This can be configured only when TXD or Inching is selected as Type on the Command Settings dialog box, and Registering Constant (Character) is selected under Type on the Data Settings dialog box.
Page 162 5 User Communication Example: Transmission command for Registering Constant (Character) data Item Setting Number of Registering Constants Index No. 1: 123 Registering Constants Index No. 2: 456 Index No. 3: 789 Index Device Address LDR100 When the trigger condition is satisfied, the data of the Index No. according to the value of device address is transmitted.
Page 163 5 User Communication Registering Constant (Hexadecimal) From the registered hexadecimal data, the hexadecimal data according to the value of device address is read and transmitted. This can be configured only when TXD or Inching is selected as Type on the Command Settings dialog box, and Registering Constant (Hexadecimal) is selected under Type on the Data Settings dialog box.
Page 164 5 User Communication Example: Transmission command for Registering Constant (Hexadecimal) data Item Setting Number of Registering Constants Index No. 1: 1234 Registering Constants Index No. 2: 5678 Index No. 3: 2537 Index Device Address LDR100 When the trigger condition is satisfied, the data of the Index No. according to the value of device address is transmitted.
Page 165 5 User Communication BCC (Block Check Code) A BCC for the transmission data is automatically calculated and appended to the transmission data at an arbitrary position and transmitted. This can be configured only when TXD or Inching is selected as Type on the Command Settings dialog box, and BCC is selected under Type on the Data Settings dialog box.
Page 166 5 User Communication Modbus RTU (CRC): CRC-16 (Generating polynomial:x +1) is calculated according to the following procedure. Conversion Type: No conversion, Number of bytes: 2 1. Obtain an exclusive OR (XOR) of 1 byte data at Calculation Start Position and FFFFh. 2.
Page 167 5 User Communication • Bytes and BCC data When the converted data is 3034h, the data appended to the transmission data is as follows. Converted data BCC data (Second byte) (First byte) (30h) (34h) (34h) 1 byte Converted data BCC data (Second byte) (First byte) (30h) (34h)
Page 168 5 User Communication Receive (RXD) Command ● Constant (Character) The received data is considered as character data and compared with the data specified without being converted. This can be configured only when RXD is selected as Type on the Command Settings dialog box, and Constant (Character) is selected under Type on the Data Settings dialog box.
Page 169 5 User Communication Constant (Hexadecimal) The received data is considered as hexadecimal data and compared with the data specified without being converted. Use this setting to receive a control code of ASCII data (00h to 1Fh). This can be configured only when RXD is selected as Type on the Command Settings dialog box, and Constant (Hexadecimal) is selected under Type on the Data Settings dialog box.
Page 170 5 User Communication Device Address From the received data, data of the specified size is unconverted, or converted to binary format, and stored in the device. This can be configured only when RXD is selected as Type on the Command Settings dialog box, and Device Address is selected under Type on the Data Settings dialog box.
Page 171 5 User Communication Variable ■ Select this check box to store data up to either Constant (Character) data, or Constant (Hexadecimal) data from the beginning of the received data in a device. Stores data of the size specified under Words. When the stored data is smaller than the size specified under Words, the values of all remaining devices will stored 0.
Page 172 5 User Communication Example 3 Item Setting Conversion Type ASCII to Hexadecimal Device Address LDR100 Use Reference Device Address Number of bytes Words Variable When the trigger condition is satisfied, the received data is stored in device addresses in the following order. Received data Value of Device Address LDR100:...
Page 173 5 User Communication Example 6 Item Setting Conversion Type No conversion Device Address LDR100 Use Reference Device Address Storage Method of data from Lower byte Number of bytes Words Variable When the trigger condition is satisfied, the received data is stored in device addresses in the following order. Data from the beginning of the received data to Constant (Hexadecimal) data is stored in the device address.
Page 174 5 User Communication Example 8 Item Setting Conversion Type ASCII to Decimal Device Address LDR100 Use Reference Device Address Number of bytes Words Variable When the trigger condition is satisfied, the received data is stored in device addresses in the following order. Data from the beginning of the received data to Constant (Hexadecimal) data is stored in the device address.
Page 175 5 User Communication Registering Constant (Character) The received data is compared with the registered character data and the number of the matching character data is stored in the device address. This can be configured only when RXD is selected as Type on the Command Settings dialog box, and Registering Constant (Character) is selected under Type on the Data Settings dialog box.
Page 176 5 User Communication Example: Registering Constant (Character) for receive command data Item Setting Number of Registering Constants Index No. 1: 123 Registering Constants Index No. 2: 456 Index No. 3: 789 Index Device Address LDR100 When the trigger condition is satisfied, the received data is compared with the registered data, and the value of the Index No.
Page 177 5 User Communication Registering Constant (Hexadecimal) The received data is compared with the registered hexadecimal data and the number of the matching hexadecimal data is stored in the device address. This can be configured only when RXD is selected as Type on the Command Settings dialog box, and Registering Constant (Hexadecimal) is selected under Type on the Data Settings dialog box.
Page 178 5 User Communication Example: Registering Constant (Hexadecimal) for receive command data Item Setting Number of Registering Constants Index No. 1: 1234 Registering Constants Index No. 2: 5678 Index No. 3: 2537 Index Device Address LDR100 When the trigger condition is satisfied, the received data is compared with the registered hexadecimal data, and the value of the Index No.
Page 179 5 User Communication • Since the Indirect Device Address LDR100 of Device Address of the receive command data is 2 (Dec), the data is stored in the device address LDR202, which is offset by +2. Value of Device Address LDR200: 0000h LDR100=2 LDR201:...
Page 180 5 User Communication BCC (Block Check Code) The BCC comparison data is automatically calculated from the receive data and compared with the BCC part of the receive data. This can be configured only when RXD is selected as Type on the Command Settings dialog box, and BCC is selected under Type on the Data Settings dialog box.
Page 181 5 User Communication Modbus RTU (CRC): CRC-16 (Generating polynomial:x +1) is calculated according to the following procedure. Conversion Type: No conversion, Number of bytes: 2 1. Obtain an exclusive OR (XOR) of 1 byte data at Calculation Start Position and FFFFh. 2.
Page 182 5 User Communication • Number of bytes and comparison data When the converted data is 3034h, the data used for comparison with the BCC part of the receive data is as follows. Converted data Comparison data (Second byte) (First byte) (30h) (34h) (34h)
Page 183 5 User Communication Skip The data with the specified number of bytes in the receive data will be ignored. This can be configured only when RXD is selected as Type on the Command Settings dialog box, and Skip is selected under Type on the Data Settings dialog box. Number of bytes ■...
Page 184 5 User Communication Start Code and Terminal Code ● A start code starts data reception and a terminal code judges the terminal of data reception. A start code and a terminal code can be configured for either Constant (Character) or Constant (Hexadecimal) settings for receive command.
Page 185 5 User Communication Terminal Start code Variable Description of the procedure for terminal of data reception code Reception is started from the beginning and terminated with the terminal code. Registering Constant Command settings: Constant (Hexadecimal) Device Address (Hexadecimal) Not set <<1:”AB”...
Page 186: Example Of User Communication Settings
5 User Communication 5.4 Example of User Communication Settings This section describes examples of user communication settings and command operations. Example 1 ● This section describes an example of user communication protocol settings for creating the following commands and command operations. •...
Page 187 5 User Communication Receive command: Command Settings dialog box settings Item Setting Type Trigger Condition While ON, Device Address: LM101 Completed Device Address LM102 Not Clear Completed Device Address automatically Status Device Address LDR130 Receiving Time Out 0 (No Receive Time Out) Comment RXD command Constant...
Page 188 5 User Communication Example 2 ● This section describes an example of user communication protocol settings for creating the following commands and command operations. • Transmission command for transmitting data using Constant (Hexadecimal), Registering Constant (Character), Device Address, BCC, Constant (Hexadecimal) command settings when the trigger condition device address changes to 1 •...
Page 189 5 User Communication Receive command: Command Settings dialog box settings Item Setting Type Trigger Condition While ON, Device Address: LM202 Completed Device Address LM203 Not Clear Completed Device Address automatically Status Device Address LDR260 Receiving Time Out 0 (No Receive Time Out) Comment RXD command Constant...
Page 190 5 User Communication - The BCC calculation type is XOR. 02h^41h^42h^43h^44h^31h^32h^33h^34h^=02h - When the BCC calculation result is 0002h, the converted data will be 3032h. Data 0002h (30h) (32h) Hexadecimal to ASCII - When the converted data is 3032h, the data for comparison with the BCC part of the receive data will be 3032h.
Page 191 5 User Communication Example 3 ● This section describes an example of user communication protocol settings for creating the following commands and command operations. Transmission command for transmitting data using Constant (Hexadecimal), Constant (Character), Constant (Hexadecimal), BCC, Constant (Hexadecimal) command settings when the value of the trigger condition device address is 1 Settings in the User Communication tab on the Project Settings dialog box ■...
Page 192: Connection Diagram For User Communication
5 User Communication 5.5 Connection Diagram for User Communication When connecting an external device to the MICRO/I via user communication, refer to the following connection diagram. Serial interface 1 (RS232C) ■ HG5G/4G/3G/2G-V, External Device (RS232C) HG4G/3G, HG2G-5F (Connector) Name Pin No. Pin No.
Page 193: Sub Host Communication
External device 6.2 Supported Protocols and Communication Driver The Sub Host communication can be used with the following protocols and communication drivers: Protocol Communication Driver Manufacturer: IDEC MICROSmart Communication driver: OpenNet,MICROSmart,SmartAXIS Pro/Lite(RS232C/485) Manufacturer: Modbus Modbus RTU Master Communication driver: Modbus RTU Master For the device addresses that can be used by each protocol, communication cable connection, and usable device addresses, refer to “5.5 Connection Diagram for User Communication”...
Page 194: Hmi Link Register (Llr) Assignment
6 Sub Host Communication 6.3 HMI Link Register (LLR) Assignment This section describes how to allocate and the operation of HMI Link Registers (LLR) in Sub Host Communication. Example of HMI Link Register (LLR) Settings ● Use the Device Link Communication between the external device and the MICRO/I's serial interface (COM1), and use the Sub Host communication between the external device and the MICRO/I's serial interface (COM2).
Page 195: Sub Host Communication Configuration Procedure
6 Sub Host Communication 6.4 Sub Host Communication Configuration Procedure This section describes the configuration procedure for Sub Host Communication. Setting Sub Host Communication for a communication interface ● On the Configuration tab, in the System Setup group, click Project. The Project Settings dialog box appears.
Page 196 6 Sub Host Communication Configure the Interface Settings. HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F ■ For details, refer to Chapter 4 “When COM1, COM2, COM2(RS232C), or COM2(RS422/485) is selected under Interface Configuration” on page 4-38. HG2G-5T, HG1G/1P ■ For details, refer to Chapter 4 “When SERIAL1(RS232C), SERIAL1(RS422/485), COM(RS232C), or COM(RS422/485) is selected under Interface Configuration”...
Page 197 6 Sub Host Communication Allocate the external device addresses to the HMI Link Registers (LLR) used with Address Number in Settings. For details, refer to Chapter 4 “3.7 Sub Host Communication Tab” on page 4-58. Click OK. This concludes configuring Sub Host Communication for communication interfaces. WindO/I-NV4 User’s Manual 3-91...
Page 198: Error Information
6 Sub Host Communication 6.5 Error Information This setting is for monitoring all error information and for controlling Sub Host Communication. Monitor the error information of all Slave Numbers ● The error information of all external devices communicated with using Sub Host Communication can be monitored. This option is configured on the Sub Host Communication tab in the Project Settings dialog box.
Page 199 6 Sub Host Communication Monitor the error information of each Slave Number ● The error information of external devices communicated with using Sub Host Communication can be monitored per external device. This option is configured on the Sub Host Communication tab in the Project Settings dialog box. Select the Monitor the error information of each Slave Number check box, and then specifies a word device to write the error information.
Page 200: Bacnet Communication
7 BACnet Communication BACnet Communication HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 7.1 Overview BACnet communication stands for "Building Automation and Control Networking Protocol". In building equipment, it is an open protocol that has been standardized for interoperability between systems built by different manufacturers, and a communication standard for building networks.
Page 201: Bacnet Specifications
7 BACnet Communication 7.2 BACnet Specifications Item Details Interface Ethernet Interface Applicable Standards ANSI/ASHRAE135-2012 Protocol BACnet/IP Profile B-ASC Device Object, Analog Input Object, Analog Output Object, Analog Object Type Value Object, Binary Input Object, Binary Output Object, Binary Value Object Standard Number of Objects 256 maximum...
Page 202: About Bacnet
7 BACnet Communication 7.3 About BACnet Applicable Standards ■ • ANSI/ASHRAE135-2012 Profile ■ BACnet/IP in the MICRO/I supports the following profile. • B-ASC Objects ■ Information, such as input and output values handled by BACnet devices that support BACnet/IP, are managed in units called objects.
Page 203 7 BACnet Communication BIBB ■ BACnet interoperability building blocks (BIBB) are groupings of multiple services for each function that will be implemented. BIBBs are classified into the client side that uses the function and the server side that provides the function.
Page 204: Function
7 BACnet Communication 7.4 Function The MICRO/I provides the following functions as a single BACnet device. • Object and Device Address Binding function • Read Property function • Write Property function • Subscribed COV function • Unsubscribed COV function • Foreign Device function Object and Device Address Binding Function ●...
Page 205 7 BACnet Communication Read Property Function ● In the Read Property function, the MICRO/I returns the value of a property when there is a read property request from a BACnet device. This function is implemented using DS-RP-B (Data Sharing Read Property B) and DS-RPM-B (Data Sharing Read Property Multiple B).
Page 206 7 BACnet Communication Subscribed COV (COV) function ● In the COV (Change Of Value) function, the MICRO/I monitors an object for which a report request has been received from a BACnet device. Then when Present_Value or Status_Flags has changed, the MICRO/I notifies the BACnet device of the change.
Page 207 7 BACnet Communication The MICRO/I implements the COV function by sending the Confirmed COV Notification service/Unconfirmed COV Notification service to the report requesting BACnet device according to the parameters contained in the report request when that report request (Subscribe COV service) was transmitted from the BACnet device. The key parameters contained in the report request are as follows.
Page 208 7 BACnet Communication Unsubscribed COV (COVU) function ● In the COVU (Change Of Value Unsubscribed) function, the MICRO/I spontaneously provides notification that Present_Value or Status_Flags of a specific object has changed to all BACnet devices connected to the same network. The properties of objects that correspond to the COVU function and the timing of when to provide notification of changes are given as follows.
Page 209 7 BACnet Communication Foreign device function ● When the BACnet/IP network is built with multiple IP subnets, install one BBMD (BACnet Broadcast Management Device) on each IP subnet. A BBMD is a device that transfers broadcast communications of BACnet devices to different IP subnets.
Page 210: Bacnet/Ip Operation
7 BACnet Communication 7.5 BACnet/IP Operation BACnet/IP is enabled and disabled according to the value of HMI Special Internal Relay LSM70 (BACnet Communication Bit). Properties with allocated device addresses work by referencing those device addresses. When BACnet/IP is enabled and properties or the values of device addresses that are associated with properties are changed, they operate with the values after the change.
Page 211: Bacnet/Ip Settings Procedure
7 BACnet Communication 7.6 BACnet/IP Settings Procedure This section describes the procedure for setting BACnet/IP. On the Configuration tab, in the System Setup group, click Project. The Project Settings dialog box is displayed. Click the BACnet/IP Settings tab, select the Use BACnet/IP check box and click Settings. The BACnet Settings dialog box is displayed.
Page 212 7 BACnet Communication Adds a new object. Click New. The New Object dialog box is displayed. Select the object type of the object to register, and assign it an instance number. Click OK. The new object is added to the object list. WindO/I-NV4 User’s Manual 3-106...
Page 213 7 BACnet Communication Click the registered object ID in the object list. The properties are displayed. Configure the properties. For details, refer to “Object List” on page 3-110. The maximum number of objects that can be registered is 256. Repeat steps through to set all the objects.
Page 214: Bacnet Settings Dialog Box
7 BACnet Communication 7.7 BACnet Settings Dialog Box This section describes items on the BACnet Settings dialog box. BACnet/IP Settings ● Basic Settings ■ Device ID: The assigned ID used to identify BACnet devices on the BACnet/IP network. Configures the device ID in the range from 1 to 4,194,302.
Page 215 7 BACnet Communication Device Communication Control Password: Configures the password to request when the Device Communication Control service is received from a BACnet device. The maximum number is 20 characters. When the Device Communication Control service is received, the MICRO/I does not initiate a service or provide a response for the specified period of time.
Page 216 7 BACnet Communication Object List ● Select an object node to display the list of registered objects. For example, select Analog Input to display the list of Analog Input objects, and select the object list node to display the list of all objects. The properties can also be changed when the list is displayed. (Property settings) (Property settings) ■...
Page 217 7 BACnet Communication ■ Adds a new object. Click New to display the New Object dialog box. Configures the object type and instance number (0 to 4,194,302). Ensures that objects of the same object type do not have the same instance number. Delete ■...
Page 218 7 BACnet Communication Present_Value Settings ● This section describes how to configure Present_Value. Present_Value is a Float32(F) numeric value. Analog Input Object Use these settings to configure fixed values and device addresses for Present_Value of the Analog Input object. Device Control ■...
Page 219 7 BACnet Communication Allocate device addresses to Present_Value Select Enable in the Device Control of Present_Value, and then click a button displayed in Device to display the Present_Value Settings dialog box. Configure the parameters in the Present_Value Settings dialog box. Device for Present_Value ■...
Page 220 7 BACnet Communication Analog Output Object Use these settings to configure devices for Present_Value of the Analog Output object. Device Control ■ Device Control of Present_Value is Enable. A constant value cannot be configured for Present_Value of the Analog Output object. WindO/I-NV4 User’s Manual 3-114...
Page 221 7 BACnet Communication Allocate device addresses to Present_Value Configure the parameters in the Present_Value Settings dialog box. Device for Present_Value ■ Configures the device address to store Present_Value. According to Conversion type, 1 or 2 continuous words of address number are used starting from the specified address number of Device Address.
Page 222 7 BACnet Communication Analog Value Object Use these settings to configure device addresses for Present_Value of the Analog Value object. Device Control ■ Device Control of Present_Value is Enable. A constant value cannot be configured for Present_Value of the Analog Value object. WindO/I-NV4 User’s Manual 3-116...
Page 223 7 BACnet Communication Allocate device addresses to Present_Value Configure the parameters in the Present_Value Settings dialog box. Device for Present_Value ■ Configures the device address for reading Present_Value and the device address for writing Present_Value. The device address for reading Present_Value and writing Present_Value are automatically assigned according to the configured device address and Conversion type.
Page 224 7 BACnet Communication Conversion type ■ Configures the data type of the device address to which Present_Value is allocated. For details, refer to Present_Value in “Analog Value Object” on page 3-138. Coefficient ■ The product of Present_Value multiplied by 1/coefficient is stored in the device addresses allocated as Present_Value for reading.
Page 225 7 BACnet Communication Binary Input Object Use these settings to configure fixed values and device addresses for Present_Value of the Binary Input object. Device Control ■ Selects whether to set a fixed value for Present_Value or to allocate device addresses. Enable: Specifies the Present_Value as a constant.
Page 226 7 BACnet Communication Allocate device addresses to Present_Value Select Enable in the Device Control of Present_Value, and then click a button displayed in Device to display the Present_Value Settings dialog box. Configure the parameters in the Present_Value Settings dialog box. Device for Present_Value ■...
Page 227 7 BACnet Communication Binary Output Object Use these settings to configure device addresses for Present_Value of the Binary Output object. Device Control ■ Device Control of Present_Value is Enable. A constant value cannot be configured for Present_Value of the Binary Output object. Allocate device addresses to Present_Value Configure the parameters in the Present_Value Settings dialog box.
Page 228 7 BACnet Communication Binary Value Object Use these settings to configure device addresses for Present_Value of the Binary Value object. Device Control ■ Device Control of Present_Value is Enable. A constant value cannot be configured for Present_Value of the Binary Value object. WindO/I-NV4 User’s Manual 3-122...
Page 229 7 BACnet Communication Allocate device addresses to Present_Value Configure the parameters in the Present_Value Settings dialog box. Device for Present_Value ■ Configures the device address for reading Present_Value and the device for writing Present_Value. The devices for reading Present_Value and writing Present_Value are automatically assigned according to the set device address.
Page 230: Objects
7 BACnet Communication 7.8 Objects The MICRO/I holds objects registered with WindO/I-NV4 in internal memory. Part of the properties of the object can be allocated to the device address, and the value of the device address can be written and read. BACnet devices can read and write the properties of objects on the MICRO/I using services.
Page 231 7 BACnet Communication Analog Input Object ● This object manages a Float32(F) numeric value. The MICRO/I can make arbitrary numeric values available to BACnet devices. For example, use this object when handling analog values input with the analog input module, the measured room temperature, and other analog values.
Page 232 7 BACnet Communication Analog Output Object ● This object manages a Float32(F) numeric value. The MICRO/I can receive arbitrary numeric values from BACnet devices. For example, this object is used when receiving analog values such as those values that are output with the analog output module and temperature set points used as operating parameters from BACnet devices.
Page 233 7 BACnet Communication Analog Value Object ● This object can be used in the same manner as the Analog Input object and Analog Output object. Properties List (1): Read and write from BACnet devices (2): Read and write from device addresses when properties are allocated to device addresses R: Read-only, W: Write-only, R/W: Read and write, -: Not Read and write Property Identifier Data Type of Property...
Page 234 7 BACnet Communication Binary Input Object ● This object manages a binary value (on/off). Use this object when the MICRO/I makes binary values available to BACnet devices. Properties List (1): Read and write from BACnet devices (2): Read and write from device addresses when properties are allocated to device addresses R: Read-only, W: Write-only, R/W: Read and write, -: Not Read and write Property Identifier Data Type of Property...
Page 235 7 BACnet Communication Binary Output Object ● This object manages a binary value (on/off). Use this object when the MICRO/I receives binary values from BACnet devices. Properties List (1): Read and write from BACnet devices (2): Read and write from device addresses when properties are allocated to device addresses R: Read-only, W: Write-only, R/W: Read and write, -: Not Read and write Property Identifier Data Type of Property...
Page 236 7 BACnet Communication Binary Value Object ● This object can be used in the same manner as the Binary Input object and Binary Output object. Properties List (1): Read and write from BACnet devices (2): Read and write from device addresses when properties are allocated to device addresses R: Read-only, W: Write-only, R/W: Read and write, -: Not Read and write Property Identifier Data Type of Property...
Page 237 7 BACnet Communication Device Object ● Use this object when the MICRO/I makes basic information available to BACnet devices. Properties List (1): Read and write from BACnet devices (2): Read and write from device addresses when properties are allocated to device addresses R: Read-only, W: Write-only, R/W: Read and write, -: Not Read and write Property Identifier Data Type of Property...
Page 238: Key Properties
7 BACnet Communication 7.9 Key Properties Present_Value ● This property represents the current value. This property handles input and output values associated with objects. Priority Mechanism Objects with Present_Value that can be written from BACnet devices use a priority mechanism with Priority_Array in which write instructions are ranked and the value of Present_Value is determined.
Page 239 7 BACnet Communication Writing the Value of a Device Address as Present_Value or Writing Present_Value from a BACnet Device BACnet device MICRO/I BACnet objects Device addresses Read value Present_Value Present_Value for reading Present_Value for writing Priority_Array (3), (5) Device for priority Write value Device for write trigger...
Page 240 7 BACnet Communication Writing from the BACnet Device (4) The BACnet device writes the value of Present_Value to Priority_Array at the index number indicated by the specified priority. (5) The value stored in the Priority_Array property with the smallest index number out of all non-NULL(00h) values is used as the value of Present_Value.
Page 241 7 BACnet Communication Writing a Value to Present_Value from the BACnet Device Example: When #D0000 is allocated to the Present_Value device, #D0010 is allocated to the top device for priority and trigger, and Float32(F) is allocated to the conversion type, the device addresses are allocated as follows: #D0000 is the Present_Value for reading, #D0002 is the Present_Value for writing, #D0010 is the Device for priority, and #D0011 is the Device for write trigger.
Page 242 7 BACnet Communication Analog Input Object Present_Value of the Analog Input object can be set to a fixed value or allocated device addresses and set to the value of those device address. Present_Value is a Float32(F) numeric value. When device addresses are allocated to Present_Value, Present_Value is set to the product of those device addresses multiplied by the coefficient.
Page 243 7 BACnet Communication Analog Output Object Present_Value of the Analog Output object can be allocated device addresses and set to the value of those device addresses. Present_Value is a Float32(F) numeric value. When device addresses are allocated to Present_Value, the product of Present_Value multiplied by 1/coefficient is stored in the device addresses.
Page 244 7 BACnet Communication Analog Value Object Present_Value of the Analog Value object can be used as Present_Value of both the Analog Input and Analog Output objects. Present_Value is a Float32(F) numeric value. The following diagram illustrates the concept when device addresses are allocated to Present_Value of the Analog Value object and the temperature of an office air conditioner is temporarily lowered from the base temperature (27.0°C) to 26.5°C.
Page 245 7 BACnet Communication Writing a Value to Present_Value from the BACnet Device MICRO/I BACnet device BACnet objects Device addresses Analog Value object #D0000: 26.5 Present_Value Present_Value: for reading 26.5 #D0002: XXXX Present_Value Reflected for writing Priority_Array 26.5 #D0010: XXXX Device for priority Write value: NULL(00h) 26.5...
Page 246 7 BACnet Communication Depending on the data type of the allocated device addresses, Present_Value is stored in the device addresses as follows. Set the data type according to the value of Present_Value. The data type of Present_Value is set in “Conversion type”...
Page 247 7 BACnet Communication Binary Input Object Present_Value of the Binary Input object can be set to a fixed value or allocated to a bit device address and set to the value of that bit device. The following diagram illustrates the concept when an external input is allocated to Present_Value of the Binary Input object and the BACnet device reads out the state of the external input.
Page 248 7 BACnet Communication Binary Output Object Present_Value of the Binary Output object can be allocated to a bit device and set to the value of that bit device. The following diagram illustrates the concept when a device address is allocated to Present_Value of the Binary Output object and the BACnet device writes the state of the external output.
Page 249 7 BACnet Communication Binary Value Object Present_Value of the Binary Value object can be used as Present_Value of both the Binary Input and Binary Output objects. The following diagram illustrates the concept when an internal relay is allocated to Present_Value of the Binary Value object and the office lights are temporarily turned on from off.
Page 250 7 BACnet Communication Writing a Value to Present_Value from the BACnet Device MICRO/I BACnet device BACnet objects Device addresses Binary Value object #M0000: 1 Present_Value Present_Value: for reading #M0001: XXXX Present_Value Reflected for writing Priority_Array #D0010: XXXX Device for priority Write value: NULL(00h) #D0011: XXXX...
Page 251 7 BACnet Communication Status_Flags This property represents the current status of the object (in alarm, fault, out of service, etc.). Status_Flags Value Logical Value Condition FALSE When obtaining a value where Event State is Normal. IN_ALARM TRUE Other than above FALSE Other than below FAULT...
Page 252 7 BACnet Communication Out_Of_Service Out_Of_Service is the property that represents whether or not Present_Value and the physical input/output have been unbound. Properties Value Logical Value Condition FALSE In service (Present_Value and the physical input/output are bound.) Out_Of_Service TRUE Out of service (Present_Value and the physical input/output are unbound.) Out_Of_Service can be read out to an internal relay, and the status of an internal relay can be written as Out_Of_Service.
Page 253 7 BACnet Communication System_Status Indicates the physical status and logical status of the MICRO/I. Parameter Value OPERATIONAL OPERATIONAL_READ_ONLY DOWNLOAD_REQUIRED DOWNLOAD_IN_PROGRESS NON_OPERATIONAL BACKUP_IN_PROGRESS System_Status of the MICRO/I is fixed as OPERATIONAL. Firmware_Revision This property is set with the System Software Version of the MICRO/I. Application_Software_Version Set information about the application, such as the modification date of the created project data, as a fixed string with WindO/I-NV4.
Page 254 7 BACnet Communication WindO/I-NV4 User’s Manual 3-148...
Page 255: Project Settings
Project Settings Chapter 4 The settings and screen data required to run the MICRO/I are contained in a data structure called a Project. You must create a project using WindO/I-NV4 before creating the screens and configuring the settings for the MICRO/I. This chapter describes the various settings required to create a project.
Page 256 1 Creating and Manipulating WindO/I-NV4 Project Data Select Product Series, Type Number, and Installation, and then click Next. The Select Communication Driver dialog box is displayed. Product Series ■ Select the MICRO/I type. Type Number ■ A list of model numbers associated with the selected MICRO/I is displayed. Select the model number to use. Installation ■...
Page 257 1 Creating and Manipulating WindO/I-NV4 Project Data Select Manufacturer and Communication Driver and then click OK. Manufacturer ■ Select the manufacturer name of the external device used. Communication Driver ■ Shows the communication driver list for the select manufacturer. Select the communication driver to use. Expression of Device Address Format ■...
Page 258: Opening Project Data
1 Creating and Manipulating WindO/I-NV4 Project Data 1.2 Opening Project Data Opening project data ● You can open project data that has already been created. Click , then click Open. The Open dialog box is displayed. Select the file and click Open. If a password has been configured for the project data, the Enter Password screen will be displayed.
Page 259: Saving Project Data
1 Creating and Manipulating WindO/I-NV4 Project Data 1.3 Saving Project Data Saving project data ● You can save the project data being edited. Click and then click Save. When new project data is created and you have never save it, the Save As dialog box is displayed. Enter the project name and then click Save.
Page 260 1 Creating and Manipulating WindO/I-NV4 Project Data Saving project data with a different name ● You can save the project data being edited with a different name. Click , then click Save As. The Save As dialog box is displayed. Enter the project name and click Save.
Page 261: Printing Project Data
1 Creating and Manipulating WindO/I-NV4 Project Data 1.4 Printing Project Data You can print the settings for the project data being edited and its screen images. Click and then click Print and Print Settings. The Print Settings dialog box is displayed. If the print settings have been completed, click , and then press Print and Print to immediately start printing.
Page 262 1 Creating and Manipulating WindO/I-NV4 Project Data Print Settings Dialog Box ● The items to print and details for those items are configured in the Print Settings dialog box. (Print Items) (Detailed Settings) (Print Items) ■ Select the check boxes of the items to print. Cover Page: Select the cover page items, enter the information to print, and those items will be printed.
Page 263 1 Creating and Manipulating WindO/I-NV4 Project Data Global Script: Settings in Global Script will be printed. Script Manager: Select the print target for the Script Manager and those settings will be printed. For details, refer to “Script Manager” on page 4-13. Text Manager: Select the (Text Messages List) for the Text Group and those settings will be printed.
Page 264 1 Creating and Manipulating WindO/I-NV4 Project Data Cover Page Screen Info ■ Select the check boxes of the items to print about the project data information. Title: Enter the title of the project data. The maximum length is 90 characters on 3 lines. Created on: Select the creation date of the project data.
Page 265 1 Creating and Manipulating WindO/I-NV4 Project Data Project Settings Print Content ■ Select the check boxes of the project settings to print. System: The settings on the System tab will be printed. Communication Interface: Interface and Function that have been configured and the corresponding Interface Settings will be printed.
Page 266 1 Creating and Manipulating WindO/I-NV4 Project Data Alarm Log Settings Print Content ■ Select the print target to print from Basic or Advanced. Basic: Settings on the Channel tab will be printed. The settings of numbers that do not use the alarm function will not be printed. Advanced: Prints the Basic print content, the Storage Method and the Monitoring Period on the General tab, and the contents of the External Memory Device tab, the Printing tab and the Options tab.
Page 267 1 Creating and Manipulating WindO/I-NV4 Project Data E-mail Settings Print Content ■ Select the print target to print from Basic or Advanced. Basic: Settings will be printed. Numbers for which E-mail Function is Disable will not be printed. Advanced: Only content that differs from the default content will be printed for the Basic print content and E- mail Function, Trigger Condition, and E-mail content for each number.
Page 268 1 Creating and Manipulating WindO/I-NV4 Project Data Text Manager Print Content ■ Please select the group numbers to print: Select the check boxes of the Text Group to print the Text Message List. Up to 6 groups can be printed at once. Group No.: Displays the number of the Text Group.
Page 269 1 Creating and Manipulating WindO/I-NV4 Project Data Screen Print Range ■ Screen Type: Select the screens to print from the following items. All, Base Screen, Popup Screen Screen List: This list shows screens that have already been created. Select the check boxes of the screens to print.
Page 270 1 Creating and Manipulating WindO/I-NV4 Project Data Print Preview Dialog Box ● Displays the Print Preview dialog box. An image of the layout to print on paper will be displayed in the preview. The layout can be configured while checking the preview. This is a Windows dialog box. (Print Preview) (Current Page) (Print Document)
Page 271 1 Creating and Manipulating WindO/I-NV4 Project Data (Print Preview) ■ Displays a preview of the content that will be printed. (Current Page) ■ Indicates the current page number in (Current Page)/(Total Pages) format. You can also enter a page number to display it.
Page 272: Comparing Project Data
1 Creating and Manipulating WindO/I-NV4 Project Data 1.5 Comparing Project Data Compares project data during editing with the screens and scripts of saved projects. On the Home tab, in the Project group, click Compare. The Open dialog box is displayed. Select a file to compare with, then click Open.
Page 273: Changing Project Settings
1 Creating and Manipulating WindO/I-NV4 Project Data 1.6 Changing Project Settings Changing Product Series ● This section describes how to change the product series set in the project data being edited. Click Change Product Series on the status bar. The Change Product Series dialog box is displayed. Select Product Series, Model, and Installation, and then click OK.
Page 274 1 Creating and Manipulating WindO/I-NV4 Project Data When the data is finished being converted, click Close. • Color settings (color data) are not converted. • If the Popup Screen size is larger than the Base Screen size after the Product Series is changed, the Popup Screen size is changed to the same size as the Base Screen.
Page 275 1 Creating and Manipulating WindO/I-NV4 Project Data Changing Communication Drivers ● This section describes how to change the communication driver set in the project data being edited. With Communication Driver on the status bar, click one of External Device Communication 1 to External Device Communication 4.
Page 276 1 Creating and Manipulating WindO/I-NV4 Project Data Check the message and click Yes. If there are no device addresses that correspond to the external device addresses used in the current project data after changing the communication driver, the items set with those device addresses are blank. WindO/I-NV4 User’s Manual 4-22...
Page 277: Closing Project Data
1 Creating and Manipulating WindO/I-NV4 Project Data 1.7 Closing Project Data You can close the project data being edited. Click and then click Close. If the project data being edited has not been saved, a confirmation message for saving the project data is displayed.
Page 278: Project Settings Configuration Procedure
2 Project Settings Configuration Procedure Project Settings Configuration Procedure HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Project Settings dialog box is used to configure MICRO/I operations and functions for the project overall. This section describes the configuration procedure for project settings. On the Configuration tab, in the System Setup group, click Project.
Page 279: Project Settings Dialog Box
3 Project Settings Dialog Box Project Settings Dialog Box HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes items and buttons on the Project Settings dialog box. 3.1 System Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P...
Page 280 3 Project Settings Dialog Box Backlight ■ These options configure the backlight control function. Auto OFF: Select this check box to turn off the backlight when the MICRO/I is unused for an extended period of time. To turn on the backlight, touch the screen or write 1 to System Area 1 Backlight auto off bit (address number+1, bit 5) or System Area 1 Backlight bit (address number+1, bit 0).
Page 281 3 Project Settings Dialog Box Use Large Font ■ Select this check box to display text on the MICRO/I in high-quality fonts. The Japanese or European font is replaced with the high-quality fonts depending on the magnification. To use high-quality fonts, the fonts must be downloaded to the MICRO/I at the same time as the project. To download fonts, specify the high-quality fonts under Optional Fonts to be downloaded in the Font Settings tab.
Page 282 3 Project Settings Dialog Box Watch Dog ■ Select this check box to monitor on the external device side whether or not the MICRO/I and the external device are communicating by writing a set value (00FF (Hex)) at a fixed interval. Device Address: Specifies the word device to write the value.
Page 283 3 Project Settings Dialog Box Storage Method of 32-bit Numerical Data for Internal Devices ■ Selects the handling method for values of internal devices when UBIN32(D), BIN32(L), BCD8(EB), or Float32(F) is selected for Data Type from the following. The initial value is set according to the communication driver that was selected when the project was created.
Page 284 3 Project Settings Dialog Box System Area ● Overview The area of predetermined device addresses to control the screen and communicate error information and time information between the MICRO/I and the external device is called the System Area. The System Area on the MICRO/I is as follows. System Area Number of word addresses User Access...
Page 285 3 Project Settings Dialog Box Address Function Description number This bit stores the screen flash state (0.5 sec. cycle). Write a value to this bit to change the state. This bit is 0 immediately after the power is turned Do not flash Flash display Stop flashing the screen and turn it on.
Page 286 3 Project Settings Dialog Box Address Function Description number This bit changes to 1 when executing the following arithmetic operations. To clear this bit, write 1 to the Clear error bit (System Area 1 address number+1, bit 9). • There is data which cannot be handled with the specified data type; BCD4(B), BCD8(EB), or Float32(E).
Page 287 3 Project Settings Dialog Box Address Function Description number The value of this bit changes to 1 when Auto OFF is configured and the backlight was turned off by this function. To configure Auto OFF, select Backlight auto off running the Auto OFF check box under Backlight in the Project Settings dialog box.
Page 288 3 Project Settings Dialog Box System Area 4 This area reads the MICRO/I internal clock data in one minute intervals. Address Function Description number 0 to 7 Clock data Month These bits store the current Month (01 to 12) value as a 2 digit BCD. 8 to 15 Clock data Year These bits store the current Year (00 to 99) value as a 2 digit BCD.
Page 289: Communication Interface Tab
3 Project Settings Dialog Box 3.2 Communication Interface Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Communication Interface tab is used to configure the functions used by the MICRO/I communication interfaces. Interface Configuration ■ Interface Configuration lists the communication interfaces and functions to use. Select the appropriate Interface (COM1, COM2, etc.) to switch Interface Settings to the items that can be configured for that communication interface.
Page 290 3 Project Settings Dialog Box HG4G/3G, HG2G-5F Function External Device User Name Interface O/I Link O/I Link Sub Host Maintenance Communication Communication Printer Master Slave Communication Communication 1 to 4 1 to 3 Serial Interface COM1 (RS232C or RS422/485) Serial Interface COM2 (RS232C or RS422/485)
Page 291 3 Project Settings Dialog Box Functions Available with the Serial Interface The following functions can be used with MICRO/I models equipped with the serial interface. • Online  Refer to Chapter 24 “Online Function” on page 24-1. • Debug  Refer to Chapter 25 “Monitor Function” on page 25-1. •...
Page 292 3 Project Settings Dialog Box Interface Settings ■ The items that can be configured vary based on the communication interface selected under Interface Configuration. With multiple communication interfaces, External Device Communication 1 to External Device Communication 4 or User Communication 1 to User Communication 3 on the Function cannot be configured in multiple settings.
Page 293 3 Project Settings Dialog Box When SERIAL1(RS232C), SERIAL1(RS422/485), COM(RS232C), or COM(RS422/485) is selected under Interface Configuration The items displayed in the Interface vary based on the model. HG2G-5T: SERIAL1(RS232C), SERIAL1(RS422/485) HG1G/1P: COM(RS232C) , COM(RS422/485) Function: Selects the function used by Serial Interface from the following. N/A, External Device Communication 1, External Device Communication 2, External Device Communication 3, External Device Communication 4, O/I Link Master, O/I Link Slave, User Communication 1, User Communication 2, User Communication 3, Sub Host...
Page 294 3 Project Settings Dialog Box When Ethernet is selected under Interface Configuration Example: To communicate with two MICRO/Is and a computer via Ethernet Set MICRO/I A, MICRO/I B, and the computer all to the same values: subnet mask 255.255.255.0, default gateway 192.168.1.254.
Page 295 3 Project Settings Dialog Box Regarding TCP port number of MICRO/I, note the following points. The numbers that cannot be used: • 2538 (for pass-through) • 2101 (for FC4A Series MicroSmart direct connection pass-through) Duplicate numbers cannot be configured in the following functions: •...
Page 296 3 Project Settings Dialog Box When Protocol1 to Protocol7 is selected for Ethernet under Interface Configuration Function: Selects the user communication to configure for the selected function from the following. External Device Communication 1, External Device Communication 2, External Device Communication 3, External Device Communication 4 User Communication 1, User Communication 2, User Communication 3 Operation Mode:...
Page 297 • Duplicate UDP port numbers of MICRO/I cannot be configured in the following functions. - UDP is selected for the User Communication ( refer to “Port No.” on page 4-42) - IDEC System as Manufacture and DM LINK Ethernet(UDP) as Communication Driver are selected on the Communication Driver tab (...
Page 298 3 Project Settings Dialog Box When USB2(USB-A) is selected under Interface Configuration Function: Selects the function used by the USB interface (Type A) from the following. N/A, User Communication 1, User Communication 2, User Communication 3 This communication interface is not used when N/A is selected. When USB1(USB-B) or USB(USB-B) is selected under Interface Configuration The items displayed in the Interface vary based on the model.
Page 299: Communication Driver Tab
3 Project Settings Dialog Box 3.3 Communication Driver Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Communication Driver tab is used to configure the communication driver for the external device configured in the current project data. (Function) (Function) ■...
Page 300 The Pass-Through function can only use one of External Device Communication 1 to External Device Communication 4. The Pass-Through Tool is required to use the Pass-Through function when using a version of WindLDR before Ver. 6.01, another company's PLC programming software, or an external device other than IDEC's external device. Communication Driver Extension Settings: This button is displayed when the communication driver extension settings are required.
Page 301 3 Project Settings Dialog Box Ignore communication errors and continue operation ■ Select this check box to continue MICRO/I operation even when a communication error occurs. Display error message: Select this check box to display an error message (communication error) when a communication error occurs and operation continues.
Page 302 Communication drivers that cannot be simultaneously used (3) ■ Manufacturer Communication Driver DM Link (1:1) DM Link (1:N) IDEC System DM Link Ethernet(UDP) Modbus RTU Slave Modbus Modbus TCP Server Example: Communication Driver for External Device Communication 1 is set to Modbus RTU Slave...
Page 303 3 Project Settings Dialog Box Communication Driver Extension Settings Dialog Box ● The Communication Driver Extension Settings dialog box is used to configure the communication driver extension settings. These settings vary based on the external device. For details, refer to the WindO/I-NV4 External Device Setup Manual.
Page 304: Communication Driver Network Tab
3 Project Settings Dialog Box 3.4 Communication Driver Network Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Communication Driver Network tab is used to configure the information for external devices. Settings ■ Edits the settings for the external devices. External Device ID: Shows the number (0 to 31) that the MICRO/I uses to manage the external devices are displayed.
Page 305 3 Project Settings Dialog Box Communication Driver: Shows the communication driver for use with the External Device Communication. Slave Number: Displays the slave number of the external device. Clicking the cell allows you to change the slave number of the external device. This option can only be configured when Serial Interface is selected for Interface Configuration on Communication Interface tab.
Page 306 3 Project Settings Dialog Box Number of external device limitations • The number of external devices that can be connected to External Device Communication 1 to External Device Communication 4 is a total of 32 external devices. • The number of external devices that can be set varies based on the communication interface. Communication Interface Number of External Devices Serial Interface (Connection: 1:1 communication)
Page 307: O/I Link Tab
3 Project Settings Dialog Box 3.5 O/I Link Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The O/I Link tab configures the slave stations to connect to when the MICRO/I is used as the O/I Link communication master. It configures the O/I link station when the MICRO/I is used as a slave. For details, refer to Chapter 3 “2 O/I Link Communication”...
Page 308: User Communication Tab
3 Project Settings Dialog Box 3.6 User Communication Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The User Communication tab is used to configure communication with external devices such as barcode readers. For details, refer to Chapter 3 “5 User Communication” on page 3-8. This option can only be configured when User Communication 1, User Communication 2, or User Communication 3 is selected for Function under Interface Settings on the Communication Interface tab.
Page 309 3 Project Settings Dialog Box • The value of the Receiving Character Time Out (address number+0, bit 15) of the Status Device Address LDR110 remains 0. Receiving Character Time Out duration First byte of receive data Second byte of receive data Receive command Value of Device Address LM100 when Trigger Condition is While ON...
Page 310 3 Project Settings Dialog Box Open Protocol Manager: Configures the user communication protocol registered in the Protocol Manager to the user communication protocol selected in the (Protocol List). Click this button to display Protocol Manager. For details, refer to Chapter 3 “Configuring registered user communication protocol to another user communication”...
Page 311 3 Project Settings Dialog Box Add: Adds a command to the Command List. A maximum of 255 commands may be added. Click this button, displays the Command Settings dialog box. For details, refer to Chapter 3 “Command Settings Dialog Box” on page 3-36. Edit: Edits the command selected in the Command List.
Page 312: Sub Host Communication Tab
3 Project Settings Dialog Box 3.7 Sub Host Communication Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Sub Host Communication tab is used to configure the sub host communication protocol and HMI Link Register (LLR) addresses to use. For details, refer to Chapter 3 “6 Sub Host Communication” on page 3-87. This option can only be configured when Sub Host Communication is selected for Function under Interface Settings on the Communication Interface tab.
Page 313 3 Project Settings Dialog Box Set: Allocates the device address to the HMI Link Register (LLR). When a device address is already allocated to an LLR address number, the allocated device address can be changed. Select an LLR address number and click Set to allocate the settings configured by Device Type, Address Number, Bit Number, and Slave Number to the HMI Link Register (LLR).
Page 314: Printer Tab
3 Project Settings Dialog Box 3.8 Printer Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Printer tab is used to configure the printer that is connected to the MICRO/I. Form ■ Selects the paper size to output as A4 or Letter. If the printer does not support the selected paper size, printing is performed with the paper size specified in the printer's settings.
Page 315: External Memory Device Tab
3 Project Settings Dialog Box 3.9 External Memory Device Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The External Memory Device tab is used to configure the destination folder on the external memory device inserted in the MICRO/I. External Memory Device Folder ■...
Page 316: Autorun Tab
3 Project Settings Dialog Box 3.10 Autorun Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Autorun tab is used to configure the functions for a USB flash drive inserted in the MICRO/I. For details, refer to Chapter 31 “2 USB Autorun Function”...
Page 317: Expansion Module Tab
3 Project Settings Dialog Box 3.11 Expansion Module Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Expansion Module tab is used to configure input and output expansion modules attached to the MICRO/I. For details on expansion modules, refer to Chapter 30 “Expansion Modules” on page 30-1. Use Cyclic Script ■...
Page 318: Web Server Tab
3 Project Settings Dialog Box 3.12 Web Server Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Web Server tab configures the MICRO/I's Web Server function. For details, refer to Chapter 28 “1 Web Server Function” on page 28-1. (Data Type) Use System Web Page ■...
Page 319 3 Project Settings Dialog Box If Device Address is selected for (Data Type), note the following points: • If the value of device address is set to 61 or higher, it will be treated as 60 minutes. • Once a network connection is established between the web browser and the MICRO/I, the timeout period cannot be changed.
Page 320: Ftp Server Tab
3 Project Settings Dialog Box 3.13 FTP Server Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The FTP Server tab configures the MICRO/I's FTP Server function. For details, refer to Chapter 28 “2 FTP Server Function” on page 28-18. (Data Type) Enable FTP Server function ■...
Page 321 3 Project Settings Dialog Box Inactivity Timeout ■ Set the timeout period between the MICRO/I and the FTP Client. After log in to the MICRO/I, if there is no communication between the MICRO/I and the FTP client for a specified set time, the MICRO/I will automatically disconnect the communication.
Page 322: E-Mail Tab
3 Project Settings Dialog Box 3.14 E-mail Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P You can set the outgoing mail server (SMTP) to be used for sending an e-mail from MICRO/I. For details, refer to Chapter 28 “4 E-mail Function” on page 28-40. General Setting ■...
Page 323 3 Project Settings Dialog Box Outgoing mail server (SMTP) port number: Specifies the port number for the outgoing mail server (SMTP) (0 to 65535). The outgoing mail server (SMTP) port number to use varies based on the server. For details, contact the administrator of the network which the MICRO/I is connected to.
Page 324 3 Project Settings Dialog Box Device Addresses for General Setting and Authentication Setting When the Specify General setting and Authentication setting by Value of Device Address check box is selected, it allocates the settings of the General Setting and the Authentication Setting starting at the device address set in the Top Device Address.
Page 325 3 Project Settings Dialog Box Example: The Authentication Setting and the General Setting are set as follows: Settings Preset Value Outgoing mail server (SMTP), IP Address is selected. 192.168.0.44 Outgoing mail server (SMTP) port number Sender E-mail Address test@example.com Sender Name Test Require authentication (LOGIN) to send E-mail Selected...
Page 326 3 Project Settings Dialog Box Settings Preset Value Device Address LKR 186 LKR 187 LKR 188 LKR 189 LKR 190 LKR 191 LKR 192 LKR 193 to LKR 206 String (ASCII) ‘t’‘e’ ‘s’‘t’ ‘_’‘p’ ‘a’‘s’ ‘s’‘w’ ‘o’‘r’ ‘d’‘\0’ ‘\0’‘\0’ Password Value 7465h 7374h...
Page 327: Project Details Tab
3 Project Settings Dialog Box 3.15 Project Details Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Project Details tab displays and configures project data information. Project Name ■ Shows the current project name. Project Folder Size ■...
Page 328 3 Project Settings Dialog Box Language ■ Select the language used for outputting alarm log data to the printer , and when saving alarm log, data log, and operation log data as CSV files: European, Japanese, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic The display type for dates and times varies based on the selected language.
Page 329: Font/Kanji Dictionary Data Tab
3 Project Settings Dialog Box 3.16 Font/Kanji Dictionary Data Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Font/Kanji Dictionary Data tab is used to configure the optional fonts and the Kanji dictionary data when downloading to the MICRO/I. Optional Fonts to be downloaded ■...
Page 330: Compatible Tab
3 Project Settings Dialog Box 3.17 Compatible Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Compatible tab is used to enable the functions in previous versions of WindO/I-NV4 and older MICRO/I series (HG1B). This tab is only displayed when the Use Compatible functions for previous version check box or the Use HG1B Compatible functions check box is selected in the WindO/I-NV4 Options dialog box, on the General tab, under Compatibility.
Page 331 3 Project Settings Dialog Box Parts: Expand display area of text for parts placed on the Top Layer: Select this check box to draw text even when a part of the text is located outside of the part. However, if the text too far outside the outline of the part, it may not be drawn. Align the text area (Character Input/Message Display/Numerical Input/Numerical Display): For characters displayed in Numerical Input, Character Input, Message Display, and Numerical Display, select this check box to align characters based on the area of maximum displayable...
Page 332: Bacnet/Ip Settings Tab
3 Project Settings Dialog Box 3.18 BACnet/IP Settings Tab HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P Enables the functions of the BACnet communication. For details on the BACnet communication, refer to Chapter 3 “7 BACnet Communication” on page 3-94. Use BACnet/IP ■...
Page 333: Project Restrictions
4 Project Restrictions Project Restrictions HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 4.1 Download Restrictions Project Data Size ■ The size of the project data that can be downloaded to the MICRO/I is as follows. MICRO/I Project data size HG5G/4G/3G/2G-V Approx.
Page 334 4 Project Restrictions E-mail Settings ■ A maximum of 255 external device addresses can be used in the E-mail settings. File Transfer Settings (FTP client function) ■ A maximum of 240 external device addresses can be used in the File Transfer settings. WindO/I-NV4 User’s Manual 4-80...
Page 335: Chapter 5 Screen
Screen Chapter 5 This chapter gives an overview of the MICRO/I screen and describes how to create setup and operate the screen. Screen Overview HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 Screen Types The types of screens offered by the MICRO/I and screens that can be created with the WindO/I-NV4 are given below. MICRO/I Maintenance Maintenance Screen...
Page 336: Creating And Manipulating Windo/I-Nv4 Screens
2 Creating and Manipulating WindO/I-NV4 Screens Creating and Manipulating WindO/I-NV4 Screens HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 2.1 Creating Screens This section describes how to create Base Screens and Popup Screens. Creating a screen ● On the Home tab, in the Screens group, click ▼ under New. Click Base Screen or Popup Screen.
Page 337: Opening Screens
2 Creating and Manipulating WindO/I-NV4 Screens 2.2 Opening Screens Opening a screen ● You can open a single screen that has already been created. Double click the screen to open in the Project window. If you right click a screen in the Project window, and then click Open Screens, the selected screen opens. Opening specific screens ●...
Page 338 2 Creating and Manipulating WindO/I-NV4 Screens Opening the previous or next screen ● You can open the screen with the previous screen number or the next screen number of the screen displayed in the active editing window. To open the screen with the previous screen number, click the (Open Previous Screen) button in the Screens group on the Home tab.
Page 339: Closing Screens
2 Creating and Manipulating WindO/I-NV4 Screens 2.3 Closing Screens Closing the displayed screen ● You can close the active editing window. Click in the upper-right of the editing window. Closing all screens ● You can close all the editing windows. On the View tab, in the Window group, click Close All.
Page 340 2 Creating and Manipulating WindO/I-NV4 Screens Click the screens to close in Screen List and click the OK button. To select multiple screens, press and hold SHIFT or CTRL while you click the specific items. Screen Type ■ Select the type of screen to close from the following items. The selected screen type is displayed in Screen List. All, Base Screen, Popup Screen Screen List ■...
Page 341: Duplicating Screens
2 Creating and Manipulating WindO/I-NV4 Screens 2.4 Duplicating Screens You can copy a screen that has already been created to create a new screen. Right click a screen folder or screen in the Project window and click Duplicate Screens. The Duplicate Screens dialog box is displayed. Select the screens to copy in Screen List.
Page 342 2 Creating and Manipulating WindO/I-NV4 Screens • If multiple screens are selected in Screen List or if the Number of copies is 2 or more, consecutive screen numbers are added to the screens starting with the number specified in Screen Number. Example: When a screen with screen number of 1 is selected in Screen List, the Number of copies is 3, and Screen Number is 100 is selected, then the screen numbers after duplication are “100”, “101”, “102”.
Page 343: Deleting Screens
2 Creating and Manipulating WindO/I-NV4 Screens 2.5 Deleting Screens Deleting a screen ● You can delete a single screen. Right click the screen to delete in the Project window and click Delete Screens. A delete confirmation message is displayed. Click the Yes button. The screen is deleted.
Page 344 2 Creating and Manipulating WindO/I-NV4 Screens Click the screens to delete in Screen List and click the OK button. A delete confirmation message is displayed. To select multiple screens, press and hold SHIFT or CTRL while you click the specific items. Screen Type ■...
Page 345: Reusing Screens
2 Creating and Manipulating WindO/I-NV4 Screens 2.6 Reusing Screens You can copy screens from other project data. On the Home tab, in the Screens group, click Reuse. If you right click a screen folder or screen in the Project window and click Reuse Screens, the Open dialog box is displayed.
Page 346 2 Creating and Manipulating WindO/I-NV4 Screens Click the screens to copy in Screen List and click the OK button. To select multiple screens, press and hold SHIFT or CTRL while you click the specific items. Screen Type ■ Select the type of screen to copy from the following items. The selected screen type is displayed in Screen List. All, Base Screen, Popup Screen Screen List ■...
Page 347: Batch Editing Of Multiple Screen Settings
2 Creating and Manipulating WindO/I-NV4 Screens 2.7 Batch Editing of Multiple Screen Settings You can modify the settings for multiple base screens or popup screens collectively. Selects multiple screens of the same type on the Project window or in the Screen List window, right-click to open a popup menu, and then click Properties.
Page 348: Base Screen
3 Base Screen Base Screen HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The screen that is displayed when the MICRO/I is in Run Mode. This screen places drawing objects and parts on the base and creates a screen that is displayed on the MICRO/I. 3.1 Properties of Base Screen Dialog Box General Tab ●...
Page 349 3 Base Screen Options Tab ● Background Color ■ Select the screen’s background color (color: 256 colors, monochrome: 16 shades). Click this button to open the color palette. Select color with the color palette. When Overlay with Base Screen is configured, the background color for the Base Screen specified as the background is displayed.
Page 350 3 Base Screen Display the Order of Overlapping Screens ■ You can select the display order of the Base Screen and the overlay screens. Example: To display the Base Screen being edited as the background Overlay screen (5 screens max) Base screen being edited Example: To display the Base Screen being edited above overlay screen: 3 Base screen being edited...
Page 351 3 Base Screen Security Tab ● This tab is used to restrict displaying the screen by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box. (Settings) ■...
Page 352: Displaying Layered Base Screens
3 Base Screen 3.2 Displaying Layered Base Screens It is possible to layer and display multiple Base Screens. The coordinates and display order for layered screens can be set on the screen that will serve as the base. A maximum of 5 layered screens can be displayed. Coordinates ■...
Page 353 3 Base Screen • Layered screens that have been set as layered screens will not be displayed on the screen that is displayed as the base. Example: Layering and displaying Base Screen: 100 on Base Screen: 1 Layering and displaying Base Screen: 101 on Base Screen: 100 Base Screen: 101 Layered Screen Layered Screen...
Page 354: Popup Screen
4 Popup Screen Popup Screen HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Popup Screen that is displayed on the Base Screen when the MICRO/I is in Run Mode. The size and coordinates of the screen can be specified and this screen can also be moved on the Base Screen. 4.1 Properties of Popup Screen Dialog Box General Tab ●...
Page 355 4 Popup Screen Title ■ Enter the Popup Screen’s title. Maximum number is 40 characters. This title is displayed in the Popup Screen’s title bar. This option can only be entered when Use Text Manager is cleared. Size ■ Width, Height: Specify the width (40 dots to Base Screen width) and the height (40 dots to Base Screen height) of the Popup Screen.
Page 356 4 Popup Screen Open with Fade In ■ When opening a Popup Screen, select this to gradually fade in the popup screen from nothing to the transparency specified in Transparency. Close while changing Base Screen ■ Select this to close the displayed popup screen when changing the Base Screen. Focus Order ■...
Page 357 4 Popup Screen Security Tab ● This tab is used to restrict displaying the screen by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box. (Settings) ■...
Page 358: Popup Screen Configuration
4 Popup Screen 4.2 Popup Screen Configuration Title Bar Move Button Close Button Screen Display Area Title Bar ■ Displays buttons and the title of the Popup Screen. Pressing the title bar of the screen allows you to move the screen to the front. MICRO/I MICRO/I MICRO/I...
Page 359: Standard Keypad Popup Screen
4 Popup Screen (Close) Button ■ Closes the Popup Screen. Screen Display Area ■ The area where drawing objects and parts are placed. 4.3 Standard Keypad Popup Screen A Popup Screen that places a regular Keypad used for Numerical Input, Character Input, inputting for E-mail and clock settings on screen numbers 3001 to 3015 with the WindO/I-NV4.
Page 360: Screen Restrictions
5 Screen Restrictions Screen Restrictions HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 5.1 Screen Number The number of screens and layered screens that can be created in a single project and the number of Popup Screens that can be displayed on the Base Screen are as follows: Base Screen ■...
Page 361: Maximum Number Of External Device Addresses
5 Screen Restrictions 5.3 Maximum Number of External Device Addresses The maximum number of Read/Write device addresses of external devices is 512 for base screens (including overlay screens) and popup screens. If the same device address is used in multiple device address settings, the used number of device addresses will be counted as 1 device address.
Page 362 5 Screen Restrictions WindO/I-NV4 User’s Manual 5-28...
Page 363: Overview
Drawings and Parts Chapter 6 This chapter contains an overview of drawings and parts that are used when creating a screen and a description of the types of drawings and parts. Overview HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P Drawings and parts are used by placing them on base screens and popup screens.
Page 364: Drawing Objects
2 Drawing objects Drawing objects HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes the drawing objects that can be drawn in WindO/I-NV4. 2.1 Shapes Shapes Function Line Draws a line. Polyline Draws a polyline. Polygon Draws an object that connects two or more vertices with straight lines.
Page 365: Part Types
3 Part Types Part Types HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes the parts that can be used on the MICRO/I. 3.1 Buttons Part Description Bit Button Writes a 0 or 1 to a bit device. Writes a value to a word device.
Page 366: Charts
3 Part Types 3.4 Charts Part Description Bar Chart Displays values of word devices in a Bar Chart. Line Chart Displays data logs and values of word devices in a Line Chart. Pie Chart Displays values of word devices in a Pie Chart. Meter Displays a value of a word device using a needle gauge.
Page 367: Drawings And Parts Overlapping
4 Drawings and Parts Overlapping Drawings and Parts Overlapping HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes when drawing and parts overlap. 4.1 Overview Place the drawings and parts on the top layer to have precedence when these objects overlap on base screens and popup screens.
Page 368: Displaying Overlapping Drawings And Parts
4 Drawings and Parts Overlapping 4.2 Displaying Overlapping Drawings and Parts The display when drawings and parts overlap on base screens and popup screens varies based on the location where they are placed. Display order of overlapping parts ● •If two parts overlap on a base screen or popup screen, the part last modified is displayed in the front. Example: A Numerical Display is placed on the base screen and a Bit Button is placed in front of it.
Page 369 4 Drawings and Parts Overlapping Display order of drawing and parts overlapping ● •If a drawing and part are overlapping with each other on a base screen or popup screen, the drawing or part configured in the Properties dialog box as a top layer, then it will be displayed in the front over the other. Example: An equilateral hexagon is placed on the base screen and a Numerical Display is placed in front of it.
Page 370 4 Drawings and Parts Overlapping Drawing and Parts are hidden ● In the following situations, the drawing and the part image type are hidden. •When the drawing or part is flashing •When the hidden condition is satisfied in a part configured with display conditions •When a lamp is off that has its Not Display Image check box selected on the View tab •When an unregistered state or number is selected for the image type in a Multi-State Lamp or Picture Display •When moving a Picture Display...
Page 371 4 Drawings and Parts Overlapping Display order of overlapping parts that have None selected for Image Type ● •When a drawing and a part that has None selected for Image Type placed on a base screen or popup screen overlap, if the value for the part changes or if the picture for the part changes, the portion of the background drawing that was overlapped remains missing.
Page 372: Restrictions
4 Drawings and Parts Overlapping 4.3 Restrictions •To place overlapping drawings and parts on a screen, we recommend they be placed on the top layer. When the amount of data for parts placed on the top layer exceeds the upper limit, the display is the same as when they are placed on a base screen or popup screen.
Page 373: Chapter 7 Drawings
Drawings Chapter 7 This chapter describes the procedures for drawing with shapes and the procedures for configuring pictures and text. Shapes HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 Line Line Drawing Procedure ● This section describes the procedure for drawing lines. On the Home tab, in the Drawings group, click Shapes, and then click (Line) under Basic Shapes.
Page 374 1 Shapes Properties of Line Dialog Box ● This section describes items and buttons in the Properties dialog box. Line Width ■ Selects the line width for the line from the following. 1 dot, 2 dots, 3 dots, 5 dots 3 dots and 5 dots can only be configured when Solid is selected for Line Type.
Page 375: Polyline
1 Shapes 1.2 Polyline Polyline Drawing Procedure ● This section describes the procedure for drawing polylines. On the Home tab, in the Drawings group, click Shapes, and then click (Polyline) under Basic Shapes. The mouse cursor changes to (pencil). Click at the location (start point) to start drawing the polyline on the edit screen. Click the end point locations in order.
Page 376 1 Shapes Properties of Polyline Dialog Box ● This section describes items and buttons in the Properties dialog box. Line Width ■ Selects the line width for the polyline from the following. 1 dot, 2 dots, 3 dots, 5 dots 3 dots and 5 dots can only be configured when Solid is selected for Line Type.
Page 377: Polygon
1 Shapes 1.3 Polygon Polygon Drawing Procedure ● This section describes the procedure for drawing polygons. On the Home tab, in the Drawings group, click Shapes, and then click (Polygon) under Basic Shapes. The mouse cursor changes to (pencil). Click at the location (start point) to start drawing the polygon on the edit screen. Click the end point locations in order.
Page 378 1 Shapes Properties of Polygon Dialog Box ● This section describes items and buttons in the Properties dialog box. Line Width ■ Selects the line width for the polygon from the following. 1 dot, 2 dots, 3 dots, 5 dots 3 dots and 5 dots can only be configured when Solid is selected for Line Type.
Page 379 1 Shapes Size ■ W, H: Specifies the size of the polygon in width and height. 1 to (base screen horizontal size) 1 to (base screen vertical size) Width Screen Height Polygon Place on the Top Layer ■ Select this check box to display the polygon on the top layer. The polygon will have precedence when other drawings and parts are overlapping with it.
Page 380: Rectangle
1 Shapes 1.4 Rectangle Rectangle Drawing Procedure ● This section describes the procedure for drawing rectangles. On the Home tab, in the Drawings group, click Shapes, and then click (Rectangle) under Basic Shapes. The mouse cursor changes to (pencil). Click and hold the mouse button at the location (start point) to start drawing the rectangle on the edit screen. Drag the mouse to the stop point location so that location becomes the opposite angle of the rectangle.
Page 381 1 Shapes Properties of Rectangle Dialog Box ● This section describes items and buttons in the Properties dialog box. Line Width ■ Selects the line width for the rectangle from the following. 1 dot, 3 dots, 5 dots 3 dots and 5 dots can only be configured when Solid is selected for Line Type. Line Type ■...
Page 382 1 Shapes Round Radius ■ Specifies the rounding radius (1 to 200). However, the range that can be configured is where round radius x 2 is a value smaller than Size W and Size H. This option can only be configured when Curve or Straight is selected for Round Type. For Curve For Straight Round Radius...
Page 383: Circle/Ellipse
1 Shapes 1.5 Circle/Ellipse Circle/Ellipse Drawing Procedure ● This section describes the procedure for drawing circles and ellipses. On the Home tab, in the Drawings group, click Shapes, and then click (Circle/Ellipse) under Basic Shapes. The mouse cursor changes to (pencil).
Page 384 1 Shapes Properties of Circle/Ellipse Dialog Box ● This section describes items and buttons in the Properties dialog box. Line Width ■ Selects the line width for the circle or ellipse from the following. 1 dot, 3 dots, 5 dots 3 dots and 5 dots can only be configured when Solid is selected for Line Type.
Page 385 1 Shapes Coordinates ■ X, Y: Specifies the display position of the circle or ellipse in coordinates. With the upper-left corner of the screen as the origin, the upper-left corner of the rectangle that circumscribes the circle or ellipse is the X and Y coordinates. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0)
Page 386: Arc
1 Shapes 1.6 Arc Arc Drawing Procedure ● This section describes the procedure for drawing arcs. On the Home tab, in the Drawings group, click Shapes, and then click (Arc) under Basic Shapes. The mouse cursor changes to (pencil). Click and hold the mouse button at the location (start point) to start drawing the arc on the edit screen. Drag the mouse to the stop point location so that location becomes the opposite angle of the rectangle.
Page 387 1 Shapes Properties of Arc Dialog Box ● This section describes items and buttons in the Properties dialog box. Line Width ■ Selects the line width for the arc from the following. 1 dot, 3 dots, 5 dots 3 dots and 5 dots can only be configured when Solid is selected for Line Type. Line Type ■...
Page 388: Pie
1 Shapes 1.7 Pie Pie Drawing Procedure ● This section describes the procedure for drawing pies. On the Home tab, in the Drawings group, click Shapes, and then click (Pie) under Basic Shapes. The mouse cursor changes to (pencil). Click and hold the mouse button at the location (start point) to start drawing the pie on the edit screen. Drag the mouse to the stop point location so that location becomes the opposite angle of the rectangle.
Page 389 1 Shapes Properties of Pie Dialog Box ● This section describes items and buttons in the Properties dialog box. Line Width ■ Selects the line width for the pie from the following. 1 dot, 3 dots, 5 dots 3 dots and 5 dots can only be configured when Solid is selected for Line Type. Line Type ■...
Page 390 1 Shapes Size ■ W, H: Specifies the size of the pie in width and height. 1 to (base screen horizontal size) 1 to (base screen vertical size) Width Screen Height Place on the Top Layer ■ Select this check box to display the pie on the top layer. The pie will have precedence when other drawings and parts are overlapping with it.
Page 391: Equilateral Polygons
1 Shapes 1.8 Equilateral Polygons Equilateral Polygons Drawing Procedure ● This section describes the procedure to draw equilateral polygons (equilateral triangle, equilateral diamond, equilateral pentagon, equilateral hexagon, equilateral octagon). On the Home tab, in the Drawings group, click Shapes, and then click (Equilateral Triangle), (Equilateral Diamond),...
Page 392 1 Shapes Properties of Equilateral Polygon Dialog Box ● This section describes items and buttons in the Properties dialog box. Line Width ■ Selects the line width for the equilateral polygon from the following. 1 dot, 2 dots, 3 dots, 5 dots 3 dots and 5 dots can only be configured when Solid is selected for Line Type.
Page 393 1 Shapes Size ■ Sets width to define the size of the equilateral polygon. The maxium size varies based on the item selected for Installation. Horizontal: 1 to (base screen vertical size) Vertical: 1 to (base screen horizontal size) Displays the same as the width. Width Screen Height...
Page 394: Fill
1 Shapes 1.9 Fill Fill Configuration Procedure ● This section describes the fill configuration procedure. On the Home tab, in the Drawings group, click Shapes, and then click (Fill) under Fill. The mouse cursor changes to (pencil). Click on a section where multiple shapes overlap on the edit screen. The section where multiple shapes overlap is filled with the Foreground Color, Background Color, and Pattern of the shape last drawn or the shape that last had its style changed.
Page 395 1 Shapes Properties of Fill Dialog Box ● This section describes items and buttons in the Properties dialog box. Foreground Color, Background Color ■ Selects the foreground color and the background color to fill with (color: 256 colors, monochrome: 16 shades). Click either button to display the Color Palette.
Page 396: Picture
2 Picture Picture HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 2.1 Picture Configuration Procedure This section describes the picture configuration procedure. On the Home tab, in the Drawings group, click Picture. The mouse cursor changes to (picture). Click the location on the edit screen to place the picture.
Page 397: Properties Of Picture Dialog Box
2 Picture 2.2 Properties of Picture Dialog Box This section describes items and buttons in the Properties dialog box. Browse ■ Changes the picture placed on the screen. Click this button to display Picture Manager. Flash ■ Select this check box to make the picture flash. The flash interval is specified with Flashing Cycle on the System tab in the Project Settings dialog box.
Page 398: Text
3 Text Text HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 3.1 Text Configuration Procedure This section describes the configuration procedure for text. On the Home tab, in the Drawings group, click Text. The mouse cursor changes to (text).
Page 399: Properties Of Text Dialog Box
3 Text 3.2 Properties of Text Dialog Box This section describes items and buttons in the Properties dialog box. Font ■ Selects the font to use to display text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke This option can only be configured if the Use Text Manager check box is cleared.
Page 400 3 Text Vertical Writing ■ Select this check box to display text vertically. This option can only be configured when Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic or Windows is selected for Font. When the Vertical Writing check box is selected, take care about the following points. This is applicable for installations of Windows that support East Asian characters.
Page 401 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) When Use Text Area is cleared When Use Text Area is selected (0, 0) (0, 0) IDEC IDEC Text Text area Screen Screen Use Text Area ■...
Page 402 3 Text WindO/I-NV4 User’s Manual 7-30...
Page 403: Chapter 8 Buttons
Buttons Chapter 8 This chapter describes the setup for the button parts and related MICRO/I operations. Bit Button HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 How the Bit Button is Used Writes a 0 or 1 to a bit device. MICRO/I External device ■...
Page 404 1 Bit Button Momentary ■ Pressing the button writes a 1 to the Press Release Press Release bit device. Releasing the button writes a 0 to the Operation and bit device. view Initial image Action Write Write Write Write Data written Pressing and holding the button until the screen changes causes a 0 to be written to the bit device.
Page 405: Bit Button Configuration Procedure
1 Bit Button 1.2 Bit Button Configuration Procedure This section describes the configuration procedure for Bit Buttons. On the Home tab, in the Parts group, click Buttons, and then click Bit Button. Click a point on the edit screen where you wish to place the Bit Button. Double-click the dropped Bit Button and a Properties dialog box will be displayed.
Page 406: Properties Of Bit Button Dialog Box
1 Bit Button 1.3 Properties of Bit Button Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. >>OFF Text, >>ON Text ■...
Page 407 1 Bit Button Momentary: Pressing the button writes a 1 to the bit device. Releasing the button writes a 0 to the bit device. Press Release Press Release Operation and view Initial image Action Write Write Write Write Data written Pressing and holding the button until the screen changes causes a 0 to be written to the bit device.
Page 408 1 Bit Button Write ■ Specify the number of bit devices (1 to 64) at the destination. This setting is enabled only if Action Mode is set to Set or Reset. Example: This fills a contiguous block of bit devices with the same value. Action Mode: Set Destination Device Address: M0 Write: 5...
Page 409 1 Bit Button View Switching Method ■ Select how to display the ON/OFF status of the button. Button: Pressing the button changes the drawing object displayed. Device Address: The drawing objects assigned to the OFF and ON states are displayed when the value of the device address is 0 and 1, respectively.
Page 410 1 Bit Button View Tab ● Only Coordinates and Size can be configured when No Image is selected for View Switching Method on the General tab. Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphics contained within WindO/I-NV4.
Page 411 1 Bit Button Flash ■ Select this check box if flashing is desired (alternating ON and OFF) when a part is ON. Flash ON image OFF image Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0)
Page 412 1 Bit Button Registration Text Tab ● These options can only be configured when Button or Device Address is selected for View Switching Method on the General tab. Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke Can only be set when the Use Text Manager check box is cleared.
Page 413 1 Bit Button OFF, ON ■ Text: Inputs characters to be displayed on parts. The maximum number is 3,750 characters. The characters that can be entered depend on the font selected using Font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Text ID: Specifies the Text Manager ID No.
Page 414 1 Bit Button Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Button is enabled and operational while the condition is satisfied. The Button is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Button is not operational.
Page 415 1 Bit Button While OFF: Enables the Button when the value of device address is 0. Value of device address Button state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Button when the condition is satisfied. Satisfied Condition Not satisfied...
Page 416 1 Bit Button Trigger Type: Selects the condition to display the Button from the following. Always visible: The Button is always displayed. Button state Always show While ON: Displays the Button when the value of device address is 1. Value of device address Button state Hide...
Page 417 1 Bit Button Options Tab ● The Options tab is displayed in Advanced mode. ON delay ■ Select this check box to use the ON delay function. Time (x100 msec): Specify the length of time that the button must be held down before activation by selecting a value from 0 to 600 (units of 10 ms).
Page 418 1 Bit Button Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 419 1 Bit Button Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 420 1 Bit Button Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 421: Word Button
2 Word Button Word Button HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 2.1 How the Word Button is Used Writes a value to a word device. Can be used to indirectly specify the destination address or to perform operations on the written value.
Page 422 2 Word Button ■ Pressing the button writes a fixed value to a word device. Press Release Press Release Operation and view Initial image Action Write Write Data written Value Value Move ■ Pressing the button writes the value of source device address to the Press Release...
Page 423 2 Word Button Add, Sub, Multi, Div, Mod, OR, AND, XOR ■ Pressing the button performs arithmetic on the value of source Press Release Press Release device address and a fixed value, or a Operation and value of device address and writes the view result to a word device.
Page 424: Word Button Configuration Procedure
2 Word Button 2.2 Word Button Configuration Procedure This section describes the configuration procedure for Word Buttons. On the Home tab, in the Parts group, click Buttons, and then click Word Button. Click a point on the edit screen where you wish to place the Word Button. Double-click the dropped Word Button and a Properties dialog box will be displayed.
Page 425: Properties Of Word Button Dialog Box
2 Word Button 2.3 Properties of Word Button Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. >>OFF Text, >>ON Text ■...
Page 426 2 Word Button Momentary: Pressing the button writes the constant value of ON data to a word device. Releasing the button writes the constant value of OFF data to a word device. Press Release Press Release Operation and view Initial image Action Write Write...
Page 427 2 Word Button Data Type ■ Select the data type to be handled by the operation selected for Action Mode. For details, refer to Chapter 2 “1.1 Available Data” on page 2-1. UBIN16(W) and UBIN32(D) can only be set if Action Mode is set to OR, AND, or XOR. UBIN16(W) and UBIN32(D) can only be set if Action Mode is set to Move.
Page 428 2 Word Button Destination Device Address ■ Destination Device Address: Specify the destination word device. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. Use Reference Device Address : Select this check box and specify a device address to change the destination word device according to the value of the specified device address.
Page 429 2 Word Button View Switching Method ■ Select how to display the ON/OFF status of the button. Button: Pressing the button changes the drawing object displayed. Device Address: The drawing objects assigned to the OFF and ON states are displayed when the value of the device address is 0 and 1, respectively.
Page 430 2 Word Button View Tab ● Only Coordinates and Size can be configured when No Image is selected for View Switching Method on the General tab. Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphics contained within WindO/I-NV4.
Page 431 2 Word Button Flash ■ Select this check box if flashing is desired (alternating ON and OFF) when a part is ON. Flash ON image OFF image Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0)
Page 432 2 Word Button Registration Text Tab ● These options can only be configured when Button or Device Address is selected for View Switching Method on the General tab. Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke Can only be set when the Use Text Manager check box is cleared.
Page 433 2 Word Button OFF, ON ■ Text: Inputs characters to be displayed on parts. The maximum number is 3,750 characters. The characters that can be entered depend on the font selected using Font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Text ID: Specifies the Text Manager ID No.
Page 434 2 Word Button Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Button is enabled and operational while the condition is satisfied. The Button is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Button is not operational.
Page 435 2 Word Button While OFF: Enables the Button when the value of device address is 0. Value of device address Button state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Button when the condition is satisfied. Satisfied Condition Not satisfied...
Page 436 2 Word Button Trigger Type: Selects the condition to display the Button from the following. Always visible: The Button is always displayed. Button state Always show While ON: Displays the Button when the value of device address is 1. Value of device address Button state Hide...
Page 437 2 Word Button Options Tab ● The Options tab is displayed in Advanced mode. ON delay ■ Select this check box to use the ON delay function. Time (x100 msec): Specify the length of time that the button must be held down before activation by selecting a value from 0 to 600 (units of 10 ms).
Page 438 2 Word Button Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 439 2 Word Button Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 440 2 Word Button Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 441 3 Goto Screen Button Goto Screen Button HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 3.1 How the Goto Screen Button is Used Switches to another screen or displays a window. • Pressing the button switches between Base Screens. MICRO/I MICRO/I •...
Page 442: Goto Screen Button
3 Goto Screen Button 3.2 Goto Screen Button Configuration Procedure This section describes the configuration procedure for Goto Screen Buttons. On the Home tab, in the Parts group, click Buttons, and then click Goto Screen Button. Click a point on the edit screen where you wish to place the Goto Screen Button. Double-click the dropped Goto Screen Button and a Properties dialog box will be displayed.
Page 443: Properties Of Goto Screen Button Dialog Box
3 Goto Screen Button 3.3 Properties of Goto Screen Button Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. >>OFF Text, >>ON Text ■...
Page 444 3 Goto Screen Button Action Mode ■ Select the behavior of the button from the following: Back to previous Screen: Switches to the previous screen. Returns to up to 16 earlier screens. Switch to Base Screen: Switches between Base Screen. For details, refer to Chapter 5 “3 Base Screen” on page 5-14.
Page 445 3 Goto Screen Button Goto Screen ■ Screen Number: If Action Mode is set to Switch to Base Screen, specify the Base Screen number to switch to (from 1 to 3000). If Action Mode is set to Open Popup Screen or Close Popup Screen, specify the number of the Popup Screen to open or close (from 1 to 3015).
Page 446 3 Goto Screen Button *2 Advanced mode only Configure Processing Area of User Account Setting Screen Dialog Box Top Device Address ■ Specifies a word device to use Processing Area of User Account Setting Screen. 152 words are used from the starting device address.
Page 447 3 Goto Screen Button View Tab ● Only Coordinates and Size can be configured when No Image is selected for View Switching Method on the General tab. Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphics contained within WindO/I-NV4.
Page 448 3 Goto Screen Button Flash ■ Select this check box if flashing is desired (alternating ON and OFF) when a part is ON. Flash ON image OFF image Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen.
Page 449 3 Goto Screen Button Registration Text Tab ● These options can only be configured when Button or Device Address is selected for View Switching Method on the General tab. Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke Can only be set when the Use Text Manager check box is cleared.
Page 450 3 Goto Screen Button OFF, ON ■ Text: Inputs characters to be displayed on parts. The maximum number is 3,750 characters. The characters that can be entered depend on the font selected using Font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Text ID: Specifies the Text Manager ID No.
Page 451 3 Goto Screen Button Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Button is enabled and operational while the condition is satisfied. The Button is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Button is not operational.
Page 452 3 Goto Screen Button While OFF: Enables the Button when the value of device address is 0. Value of device address Button state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Button when the condition is satisfied. Satisfied Condition Not satisfied...
Page 453 3 Goto Screen Button Trigger Type: Selects the condition to display the Button from the following. Always visible: The Button is always displayed. Button state Always show While ON: Displays the Button when the value of device address is 1. Value of device address Button state...
Page 454 3 Goto Screen Button Options Tab ● The Options tab is displayed in Advanced mode. ON delay ■ Select this check box to use the ON delay function. Time (x100 msec): Specify the length of time that the button must be held down before activation by selecting a value from 0 to 600 (units of 10 ms).
Page 455 3 Goto Screen Button Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 456 3 Goto Screen Button Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button...
Page 457 3 Goto Screen Button Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 458: Print Button
4 Print Button Print Button HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 4.1 How the Print Button is Used Outputs a screenshot to a printer or an external memory device • Pressing the Print Button outputs a screenshot of the current screen to the printer. Printer MICRO/I HG5G-V HG4G-V HG3G-V HG2G-V...
Page 459: Print Button Configuration Procedure
4 Print Button 4.2 Print Button Configuration Procedure This section describes the configuration procedure for Print Buttons. On the Home tab, in the Parts group, click Buttons, and then click Print Button. Click a point on the edit screen where you wish to place the Print Button. Double-click the dropped Print Button and a Properties dialog box will be displayed.
Page 460: Properties Of Print Button Dialog Box
4 Print Button 4.3 Properties of Print Button Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. >>OFF Text, >>ON Text ■...
Page 461 4 Print Button • For details about printers, refer to Chapter 32 “Printer” on page 32-1. • For details about external memory devices, refer to Chapter 31 “External Memory Devices” on page 31-1. Action Mode ■ Select the behavior of the button from the following. This option is only displayed when Printer is selected in Output to. Print Screen: Outputs a screenshot of the current screen to the printer or the external memory device Cancel Printing...
Page 462 4 Print Button The methods to erase screenshot files saved on the external memory device are as follows. • To erase files during operation using parts, on the External Memory Device tab on the Project Settings dialog box, select the Remove Files check box and the All Screenshot data check box, and then configure the trigger device address.
Page 463 4 Print Button View Tab ● Only Coordinates and Size can be configured when No Image is selected for View Switching Method on the General tab. Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphics contained within WindO/I-NV4.
Page 464 4 Print Button Flash ■ Select this check box if flashing is desired (alternating ON and OFF) when a part is ON. Flash ON image OFF image Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0)
Page 465 4 Print Button Registration Text Tab ● These options can only be configured when Button or Device Address is selected for View Switching Method on the General tab. Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke Can only be set when the Use Text Manager check box is cleared.
Page 466 4 Print Button OFF, ON ■ Text: Inputs characters to be displayed on parts. The maximum number is 3,750 characters. The characters that can be entered depend on the font selected using Font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Text ID: Specifies the Text Manager ID No.
Page 467 4 Print Button Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Button is enabled and operational while the condition is satisfied. The Button is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Button is not operational.
Page 468 4 Print Button While OFF: Enables the Button when the value of device address is 0. Value of device address Button state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Button when the condition is satisfied. Satisfied Condition Not satisfied...
Page 469 4 Print Button Trigger Type: Selects the condition to display the Button from the following. Always visible: The Button is always displayed. Button state Always show While ON: Displays the Button when the value of device address is 1. Value of device address Button state Hide...
Page 470 4 Print Button Options Tab ● The Options tab is displayed in Advanced mode. ON delay ■ Select this check box to use the ON delay function. Time (x100 msec): Specify the length of time that the button must be held down before activation by selecting a value from 0 to 600 (units of 10 ms).
Page 471 4 Print Button Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 472 4 Print Button Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 473 4 Print Button Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 474: Key Button
5 Key Button Key Button HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 5.1 How the Key Button is Used Performs a variety of functions including uploading and downloading, copying files, and operating other parts. • Entering numbers in the Numerical Input MICRO/I 1230 •...
Page 475 5 Key Button • Copying and recovering data archived on the SD memory card, inserted in the MICRO/I, to the USB flash drive. SD memory card MICRO/I Copy files USB flash drive HG5G-V HG4G-V HG3G-V HG2G-V HG4G HG3G HG2G-5F • Operating the Video Display MICRO/I SD memory card Play...
Page 476: Key Button Configuration Procedure
5 Key Button 5.2 Key Button Configuration Procedure This section describes the configuration procedure for Key Buttons. On the Home tab, in the Parts group, click Buttons, and then click Key Button. Click a point on the edit screen where you wish to place the Key Button. Double-click the dropped Key Button and a Properties dialog box will be displayed.
Page 477: Properties Of Key Button Dialog Box
5 Key Button 5.3 Properties of Key Button Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● (Key) Displays settings applicable to the selected key. Part Name ■ Enter a name for the part. The maximum number is 20 characters. >>OFF Text, >>ON Text ■...
Page 478 5 Key Button Popup Screen Number ■ The Alt key switches the current Popup Screen used as a Keypad when this button is pressed. Specify the Popup Screen number to open a Keypad for. This setting is enabled only if Alt was selected using the Key Browser. Scroll Size ■...
Page 479 5 Key Button If Upload Project is selected. Destination: Specify where to save the project uploaded from MICRO/I. Select the location: SD Memory Card or USB Flash Drive. Location: Specify the location where the uploaded project will be saved. The maximum number is 247 characters.
Page 480 5 Key Button If Download PLC Program is selected. Source: Select the the external memory where the PLC program (ZLD Project File) to be transferred is stored: SD Memory Card or USB Flash Drive. Location: Specify the location of the ZLD Project File(.zld). The maximum number is 247 characters.
Page 481 5 Key Button If Upload PLC Program is selected. Source: Specify the source PLC connected to the MICRO/I. The PLC type is configured in the Project Settings dialog box, on the Communication Driver Network tab. For details, refer to Chapter 4 “3.4 Communication Driver Network Tab”...
Page 482 5 Key Button Recording Channel ■ The recording of images starts. Selects Channel 1 or Channel 2 to record a video only (no audio) out of the signals input from the device. This setting is enabled only if Rec. was selected using the Key Browser. •...
Page 483 5 Key Button View Switching Method ■ Select how to display the ON/OFF status of the button. Button: Pressing the button changes the drawing object displayed. Device Address: The drawing objects assigned to the OFF and ON states are displayed when the value of the device address is 0 and 1, respectively.
Page 484 5 Key Button View Tab ● Only Coordinates and Size can be configured when No Image is selected for View Switching Method on the General tab. Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4.
Page 485 5 Key Button Flash ■ Select this check box if flashing is desired (alternating ON and OFF) when a part is ON. Flash ON image OFF image Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0)
Page 486 5 Key Button Registration Text Tab ● These options can only be configured when Button or Device Address is selected for View Switching Method on the General tab. Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke Can only be set when the Use Text Manager check box is cleared.
Page 487 5 Key Button OFF, ON ■ Text: Inputs characters to be displayed on parts. The maximum number is 3,750 characters. The characters that can be entered depend on the font selected using Font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Text ID: Specifies the Text Manager ID No.
Page 488 5 Key Button Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Button is enabled and operational while the condition is satisfied. The Button is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Button is not operational.
Page 489 5 Key Button While OFF: Enables the Button when the value of device address is 0. Value of device address Button state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Button when the condition is satisfied. Satisfied Condition Not satisfied...
Page 490 5 Key Button Trigger Type: Selects the condition to display the Button from the following. Always visible: The Button is always displayed. Button state Always show While ON: Displays the Button when the value of device address is 1. Value of device address Button state Hide...
Page 491 5 Key Button Options Tab ● The Options tab is displayed in Advanced mode. ON delay ■ Select this check box to use the ON delay function. Time (x100 msec): Specify the length of time that the button must be held down before activation by selecting a value from 0 to 600 (units of 10 ms).
Page 492 5 Key Button Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 493 5 Key Button Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 494 5 Key Button Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 495: Key Buttons
5 Key Button 5.4 Key Buttons For Keypad(Half-Width Character) ● These keys can be used for Numerical Input and Character Input: Numerical Input Keypad ■ Operation Inputs a decimal point. 0 to 9 Inputs a number from 0 to 9. A to F Inputs a character from A to F.
Page 496 5 Key Button Operation > Inputs a >. Inputs a ?. Inputs a @. A to Z Inputs a character from A to Z. Inputs a [. Inputs a Inputs a ]. Inputs a ^. Inputs a _. Inputs a '. a to z Inputs a character from a to z.
Page 497 5 Key Button For Keypad(Hiragana) ● These keys to enter Hiragana and Kanji which can be used for Character Input are as follows. Character Input Keypad ■ Operation Inputs a character from あんあん Inputs a 、、 Inputs a 。...
Page 498 5 Key Button For Data Transfer Keys ● These keys can be used to execute Data Transfer functions. For details about Data Transfer functions, refer to Chapter 29 “Data Transfer Function” on page 29-1. Operation Download Project Downloads a project (ZNV Project File) saved on an external memory device to the MICRO/I.
Page 499 5 Key Button For the Multimedia Function ● Recording ■ Operation Stop Stops recording images and sound Rec. Records images and sound Video Display ■ The keys that can be used with the Video Display are given below. Operation Play Play movie file and display images from the video input.
Page 500: Key Browser
5 Key Button 5.5 Key Browser Select the key using the Key Browser. The Key Browser closes when a key is selected. The name of the key is shown in Key Type. Settings that apply to the selected key are displayed. When you select a key, the label for that key is assigned as the Registration Text.
Page 501 5 Key Button Data Transfer ■ These buttons are used to execute Data Transfer functions. Alarm Display ■ These buttons are used to manipulate the Alarm List Display and Alarm Log Display parts. WindO/I-NV4 User’s Manual 8-99...
Page 502 5 Key Button Multimedia Function ■ These buttons are used to start and stop recording and to operate the Video Display. *2 This is applicable for models with a video interface only. WindO/I-NV4 User’s Manual 8-100...
Page 503: Key Button Usage Examples
5 Key Button 5.6 Key Button Usage Examples Recording Images and Sound ● HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes how to record using the Rec. and Stop key buttons. Configuration Procedure On the Home tab, in the Parts group, click Buttons, and then click Key Button. Click a point on the edit screen where you wish to place the Key Button.
Page 504 5 Key Button Select Multimedia Function and click Rec. You are returned to the Properties of Key Button dialog box. Select a recording channel or a recording target Recording Channel ■ Selects Channel 1 or Channel 2 to record a video only (no audio) out of the signals input from the device. This setting is enabled only if Rec.
Page 505 5 Key Button Select Multimedia Function and click Stop. You are returned to the Properties of Key Button dialog box. Click OK. Close the Properties of Key Button dialog box. This concludes configuring the record function and key buttons. Operating Procedure The MICRO/I must be connected to a video camera and microphone Press the Rec.
Page 506 5 Key Button Playing Recorded Images and Sound ● HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes how to select a movie file to play with the Movie File Screen and play it on a Video Display. Configuration Procedure On the Home tab, in the Parts group, click Data Displays, and then click Video Display.
Page 507 5 Key Button Click OK. The Properties of Video Display dialog box closes. Create a button to open the screen to select a recorded images. On the Home tab, in the Parts group, click Buttons, and then click Goto Screen Button. Click a point on the edit screen where you wish to place the Goto Screen Button.
Page 508 5 Key Button Specify the display location in coordinates for the movie file screen to open above the base screen with Coordinates X, Y. With the upper-left corner of the screen as the origin, the upper-left corner of the window is the X and Y coordinates. X: 0 to (base screen horizontal size - 1) Y: 0 to (base screen vertical size - 1) Click OK.
Page 509 5 Key Button Select a movie file. Press  to select “123000.avi” and then press Select. The movie file will be selected and the File Screen will close. File Screen DRIVE: SD Card Page No.: 1 Folder Up \HGDATA01\RECORD\20110313 File name Size 120000.avi 512,000,000...
Page 510: Multi-Button
6 Multi-Button Multi-Button HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 6.1 How the Multi-Button is Used Executes multiple commands at once. These commands can be assigned to a Multi-Button. Command Description Bit Write Writes a 0 or 1 to the specified bit device when pressed. Writes a value to a word device when pressed.
Page 511 6 Multi-Button Momentary ■ The button turns ON when pressed, and OFF when released. Press Release Press Release Operation and view Initial image Action Alternate ■ The button switches between ON and OFF each time it is pressed. Press Release Press Release Operation and...
Page 512: Multi-Button Configuration Procedure
6 Multi-Button 6.2 Multi-Button Configuration Procedure This section describes the configuration procedure for Multi-Buttons. On the Home tab, in the Parts group, click Buttons, and then click Multi-Button. Click a point on the edit screen where you wish to place the Multi-Button. Double-click the dropped Multi-Button and a Properties dialog box will be displayed.
Page 513: Properties Of Multi-Button Dialog Box
6 Multi-Button 6.3 Properties of Multi-Button Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. >>OFF Text, >>ON Text ■...
Page 514 6 Multi-Button Multi-Functions ■ Use this grid to add or edit commands to execute when the Multi-Button is pressed. Function List: Lists the commands to be executed. Command Type: Shows the command type. Command Name: Shows the command name. Device Address: Shows the setting when one of the following Command Type is selected.
Page 515 6 Multi-Button View Switching Method ■ Select how to display the ON/OFF status of the button. Button: Pressing the button changes the drawing object displayed. Device Address: The drawing objects assigned to the OFF and ON states are displayed when the value of the device address is 0 and 1, respectively.
Page 516 6 Multi-Button Properties of Bit Write for Multi-Functions Dialog Box Sets the Bit Write command for the Multi-Button. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Action Mode ■ Select the behavior of the Multi-Button from the following: Set: Pressing the Multi-Button writes a 1 to the bit device.
Page 517 6 Multi-Button Properties of Word Write for Multi-Functions Dialog Box Sets the Word Write command for the Multi-Button. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Action Mode ■ Select the behavior of the Multi-Button from the following: Set: Pressing the button writes a fixed value to a word device.
Page 518 6 Multi-Button Source Data ■ Select the data handled by the operation selected for Action Mode. Value: Use a constant value. Only a Value can be handled if Action Mode is set to Set or Set ON & OFF Data. If Action Mode is set to Set ON &...
Page 519 6 Multi-Button Properties of Goto Screen for Multi-Functions Dialog Box Sets the Goto Screen command for the Multi-Button. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Action Mode ■ Select the behavior of the Multi-Button from the following: Back to previous Screen: Switches to the previous screen.
Page 520 6 Multi-Button Goto Screen ■ Screen Number: If Action Mode is set to Switch to Base Screen, specify the Base Screen number to switch to (from 1 to 3000). If Action Mode is set to Open Popup Screen or Close Popup Screen, specify the number of the Popup Screen to open or close (from 1 to 3015).
Page 521 6 Multi-Button Properties of Print for Multi-Functions Dialog Box Sets the Print command for the Multi-Button. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Output to ■ Select where to direct the screenshot to. Printer Outputs the screenshot to the printer connected to the MICRO/I.
Page 522 6 Multi-Button • These operations cannot be performed simultaneously. - Outputting to the external memory device by pressing the Multi-Button. - Outputting to the printer by pressing the Multi-Button - Printing alarm logs • It may take some time to output screenshots when copying files using the USB Autorun function or a Key Button.
Page 523 6 Multi-Button Properties of Key for Multi-Functions Dialog Box Sets the Key command for the Multi-Button. (Key) Displays settings applicable to the selected key. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Key Type ■...
Page 524 6 Multi-Button Scroll Size ■ Key Buttons Page Up and Page Down scroll the list up and down, respectively. Key Buttons Up and Down move the focus up and down, respectively. This settings specifies the number of pages or lines (1 to 1023 lines) to scroll or move the focus per each press of the button.
Page 525 6 Multi-Button If Upload Project is selected. Destination: Specify where to save the project uploaded from MICRO/I. Select the location: SD Memory Card or USB Flash Drive. Location: Specify the location of the folder where the uploaded project will be saved. The maximum number is 247 characters.
Page 526 6 Multi-Button If Download PLC Program is selected. Source: Select the the external memory where the PLC program (ZLD Project File) to be transferred is stored: SD Memory Card or USB Flash Drive. Location: Specify the location of the ZLD Project File(.zld). The maximum number is 247 characters. Example: “LDR_PROGRAM.ZLD”...
Page 527 6 Multi-Button If Upload PLC Program is selected. Source: Specify the source PLC connected to the MICRO/I. The PLC type is configured in the Project Settings dialog box, on the Communication Driver Network tab. For details, refer to Chapter 4 “3.4 Communication Driver Network Tab”...
Page 528 6 Multi-Button Recording Channel ■ The recording of images starts. Selects Channel 1 or Channel 2 to record a video only (no audio) out of the signals input from the device. This setting is enabled only if Rec. was selected using the Key Browser. •...
Page 529 6 Multi-Button Properties of Script for Multi-Functions Dialog Box Sets the script for the Multi-Button. (Script) Command Name ■ Enter a name for the command. The maximum number is 20 characters. Script ID ■ Specify the script ID (1 to 32000) of the script to operate. Script Manager will open when is clicked.
Page 530 6 Multi-Button View Tab ● Only Coordinates and Size can be configured when No Image is selected for View Switching Method on the General tab. Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphics contained within WindO/I-NV4.
Page 531 6 Multi-Button Flash ■ Select this check box if flashing is desired (alternating ON and OFF) when a part is ON. Flash ON image OFF image Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0)
Page 532 6 Multi-Button Registration Text Tab ● These options can only be configured when Button or Device Address is selected for View Switching Method on the General tab. Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke Can only be set when the Use Text Manager check box is cleared.
Page 533 6 Multi-Button OFF, ON ■ Text: Inputs characters to be displayed on parts. The maximum number is 3,750 characters. The characters that can be entered depend on the font selected using Font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Text ID: Specifies the Text Manager ID No.
Page 534 6 Multi-Button Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Button is enabled and operational while the condition is satisfied. The Button is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Button is not operational.
Page 535 6 Multi-Button While OFF: Enables the Button when the value of device address is 0. Value of device address Button state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Button when the condition is satisfied. Satisfied Condition Not satisfied Button...
Page 536 6 Multi-Button Trigger Type: Selects the condition to display the Button from the following. Always visible: The Button is always displayed. Button state Always show While ON: Displays the Button when the value of device address is 1. Value of device address Button state Hide...
Page 537 6 Multi-Button Options Tab ● The Options tab is displayed in Advanced mode. ON delay ■ Select this check box to use the ON delay function. Time (x100 msec): Specify the length of time that the button must be held down before activation by selecting a value from 0 to 600 (units of 10 ms).
Page 538 6 Multi-Button Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box. (Settings) (Settings) ■...
Page 539 6 Multi-Button Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 540 6 Multi-Button Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 541: Keypad
7 Keypad Keypad HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 7.1 How the Keypad is Used A part comprised of Key Buttons. Enters numbers and characters into Numerical or Character Input parts. • Entering numbers in the Numerical Input MICRO/I 1230 Numerical Input...
Page 542: Keypad Configuration Procedure
7 Keypad 7.2 Keypad Configuration Procedure This section describes the configuration procedure for Keypads. On the Home tab, in the Parts group, click Buttons, and then click Keypad. Click a point on the edit screen where you wish to place the Keypad. Double-click the dropped Keypad and a Properties dialog box will be displayed.
Page 543: Properties Of Keypad Dialog Box
7 Keypad 7.3 Properties of Keypad Dialog Box This section describes items and buttons in the Properties dialog box. Browse ■ Select a prebuilt Keypad within WindO/I-NV4. Displays the Standard Browser when clicked. Select numeric keys or character keys registered in the Standard Browser.
Page 544 7 Keypad Coordinates ■ X, Y: Specify the display coordinates of the Keypad. X and Y specify the upper left corner of the Keypad using the upper left corner of the screen as the origin. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 545: Selector Switch
8 Selector Switch Selector Switch HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 8.1 How the Selector Switch is Used Writes a 0 or 1 to a bit device. This is an exclusive control that only writes a single value as 1 and all other values as 0. •...
Page 546: Selector Switch Configuration Procedure
8 Selector Switch 8.2 Selector Switch Configuration Procedure This section describes the configuration procedure for Selector Switch buttons. On the Home tab, in the Parts group, click Buttons, and then click Selector Switch. Click a point on the edit screen where you wish to place the Selector Switch. Double-click the dropped Selector Switch and a Properties dialog box will be displayed.
Page 547: Properties Of Selector Switch Dialog Box
8 Selector Switch 8.3 Properties of Selector Switch Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Switch Type ■...
Page 548 8 Selector Switch 2-Notch R-return: After the knob switches from Ch1 to Ch2, it returns to Ch1 when the R-button is released. Press Release Operation and view Default state Action Write Write Data written 2-Notch L-return: After the knob switches from Ch2 to Ch1, it returns to Ch2 when the L-button is released. Press Release Operation...
Page 549 8 Selector Switch 3-Notch L-return: • If the knob is switched to Ch1, it returns to Ch2 when the button is released. • If the knob is switched to Ch2, or from Ch3 to Ch2, it stays where it is even if the button is released.
Page 550 8 Selector Switch Text ID: Shows the Text ID. Double clicking the cell displays the Text Manager where you can change the Text ID. Can only be set when the Use Text Manager check box is selected. Color: Shows the color of the Registration Text for the channel. Double clicking the cell displays Color Palette where you can change the Text Color Set:...
Page 551 8 Selector Switch Notch Settings Dialog Box This dialog configures a notch for a channel. If the channel has already been set with a notch, the setting is overwritten. Destination Device Address ■ Specify the destination bit device or the bit number in the destination word device. Click to display the Tag Editor.
Page 552 8 Selector Switch View Tab ● Browse ■ Select the type of graphic to be used to represent the part from the list of graphics. Click this button to display the View Browser. Knob Color ■ Selects the knob color of the Selector Switch (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette.
Page 553 8 Selector Switch Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 554 8 Selector Switch Format Tab ● Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Stroke Can only be set when the Use Text Manager check box is cleared. The characters that can be displayed depend on the font.
Page 555 8 Selector Switch Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Selector Switch is enabled and operational while the condition is satisfied. The Selector Switch is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Selector Switch is not operational.
Page 556 8 Selector Switch While OFF: Enables the Selector Switch when the value of device address is 0. Value of device address Selector Switch state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Selector Switch when the condition is satisfied. Satisfied Condition Not satisfied...
Page 557 8 Selector Switch Trigger Type: Selects the condition to display the Selector Switch from the following. Always visible: The Selector Switch is always displayed. Selector Switch state Always show While ON: Displays the Selector Switch when the value of device address is 1. Value of device address Selector...
Page 558 8 Selector Switch Options Tab ● The Options tab is displayed in Advanced mode. No Touch Sound ■ This function is to disable touch sounds only for specified parts when the MICRO/I makes touch sounds. Select this check box to display disable touch sounds for this part. To enable touch sounds on the MICRO/I, select the Enable Touch Sound check box under the System tab of the Project Settings dialog box.
Page 559 8 Selector Switch Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 560 8 Selector Switch Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 561 8 Selector Switch Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 562: Potentiometer
9 Potentiometer Potentiometer HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 9.1 How the Potentiometer is Used Writes a value to a word device by pressing a slider button. • The slider display position increases and decreases while the button is depressed. The value of the slider at the displayed position is written to the device address when the button is released.
Page 563: Potentiometer Configuration Procedure
9 Potentiometer 9.2 Potentiometer Configuration Procedure This section describes the configuration procedure for Potentiometer parts. On the Home tab, in the Parts group, click Buttons, and then click Potentiometer. Click a point on the edit screen where you wish to place the Potentiometer. Double-click the dropped Potentiometer and a Properties dialog box will be displayed.
Page 564: Properties Of Potentiometer Dialog Box
9 Potentiometer 9.3 Properties of Potentiometer Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Data Type ■ Select the data type to be handled by the Potentiometer.
Page 565 9 Potentiometer View Tab ● Browse ■ Select the type of graphic to be used to represent the part from the list of graphics. Click this button to display the View Browser. Slider Color ■ Selects the slider color of the Potentiometer (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette.
Page 566 9 Potentiometer Switch ■ Foreground Color, Background Color: Selects the foreground and background colors of the buttons (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette. Select a color from the Color Palette. Pattern: Selects a pattern or tonal gradation for the button. Click Pattern to display the Pattern Palette.
Page 567 9 Potentiometer Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Potentiometer is enabled and operational while the condition is satisfied. The Potentiometer is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Potentiometer is not operational.
Page 568 9 Potentiometer While OFF: Enables the Potentiometer when the value of device address is 0. Value of device address Potentiometer state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Potentiometer when the condition is satisfied. Satisfied Condition Not satisfied Potentiometer...
Page 569 9 Potentiometer Trigger Type: Selects the condition to display the Potentiometer from the following. Always visible: The Potentiometer is always displayed. Potentiometer state Always show While ON: Displays the Potentiometer when the value of device address is 1. Value of device address Potentiometer state...
Page 570 9 Potentiometer Options Tab ● The Options tab is displayed in Advanced mode. No Touch Sound ■ This function is to disable touch sounds only for specified parts when the MICRO/I makes touch sounds. Select this check box to display disable touch sounds for this part. To enable touch sounds on the MICRO/I, select the Enable Touch Sound check box under the System tab of the Project Settings dialog box.
Page 571 9 Potentiometer Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box. (Settings) (Settings) ■...
Page 572 9 Potentiometer Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 573 9 Potentiometer Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 574 9 Potentiometer WindO/I-NV4 User’s Manual 8-172...
Page 575: Chapter 9 Lamps
Lamps Chapter 9 This chapter describes the setup for the lamp parts and related MICRO/I operations. Pilot Lamp HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 How the Pilot Lamp is Used Pilot Lamp parts display drawing objects. The value of a bit device is used to switch the drawing object displayed. •...
Page 576: Pilot Lamp Configuration Procedure
1 Pilot Lamp 1.2 Pilot Lamp Configuration Procedure This section describes the configuration procedure for Pilot Lamps. On the Home tab, in the Parts group, click Lamps, and then click Pilot Lamp. Click a point on the Edit screen where you wish to place the Pilot Lamp. Double-click the dropped Pilot Lamp and a Properties dialog box will be displayed.
Page 577: Properties Of Pilot Lamp Dialog Box
1 Pilot Lamp 1.3 Properties of Pilot Lamp Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. >>OFF Text, >>ON Text ■...
Page 578 1 Pilot Lamp Example: When Action Mode is Flash (ON + Flash), Flash Trigger Device Address is M0, and on the Trigger Condition tab, Trigger Type is While ON, Device Address is LM0 Trigger Condition: Device Address LM0 value Action Mode: Value of Flash Trigger Device Address M0 Displayed drawing object Displays OFF Displays ON...
Page 579 1 Pilot Lamp View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. Browse ■...
Page 580 1 Pilot Lamp Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts is defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 581 1 Pilot Lamp Registration Text Tab ● Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke Can only be set when the Use Text Manager check box is cleared. The characters that can be displayed depend on the font.
Page 582 1 Pilot Lamp OFF, ON ■ Text: Inputs characters to be displayed on parts. The maximum number is 3,750 characters. The characters that can be entered depend on the font selected using Font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Text ID: Specifies the Text Manager ID No.
Page 583 1 Pilot Lamp Trigger Condition Tab ● Lightning ■ The Pilot Lamp is on while the condition is satisfied, and it is off while the condition is not satisfied. The Pilot Lamp displays the ON graphic when on and it displays the OFF graphic when off. Example: When Trigger Type is While ON and Device Address is LM0 When LM0 is 0, condition is not satisfied, so Lamp displays OFF graphic.
Page 584 1 Pilot Lamp While OFF: Turns on the Pilot Lamp when the value of device address is 0. Value of device address Pilot Lamp status While satisfying the condition: Turns on the Pilot Lamp when the condition is satisfied. Satisfied Condition Not satisfied Pilot Lamp status...
Page 585 1 Pilot Lamp Trigger Type: Selects the condition to display the Pilot Lamp from the following. Always visible: The Pilot Lamp is always displayed. Pilot Lamp state Always show While ON: Displays the Pilot Lamp when the value of device address is 1. Value of device address Pilot Lamp state...
Page 586 1 Pilot Lamp Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 587 1 Pilot Lamp Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 588 1 Pilot Lamp Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 589 1 Pilot Lamp Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 590: Multi-State Lamp
2 Multi-State Lamp Multi-State Lamp HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 2.1 How the Multi-State Lamp is Used Multi-state lamp parts display drawing objects. The value of a specified word device is used to switch the drawing object to be displayed.
Page 591 2 Multi-State Lamp • Display a picture when in the OFF state. MICRO/I bit15 bit3 bit0 External device bit3 bit0 0100 State: State: State: bit3 bit0 0001 bit3 bit0 0010 bit3 bit0 0000 The conditions to display the picture set by the OFF state on the screen are as follows. •...
Page 592: Multi-State Lamp Configuration Procedure
2 Multi-State Lamp 2.2 Multi-State Lamp Configuration Procedure This section describes the configuration procedure for Multi-State Lamps. On the Home tab, in the Parts group, click Lamps, and then click Multi-State Lamp. Click a point on the edit screen where you wish to place the Multi-State Lamp. Double-click the dropped Multi-State Lamp and a Properties dialog box will be displayed.
Page 593: Properties Of Multi-State Lamp Dialog Box
2 Multi-State Lamp 2.3 Properties of Multi-State Lamp Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Switching Method ■...
Page 594 2 Multi-State Lamp Example 2: Bit Number is selected. The bits of trigger device address D0 and the OFF state are allocated to the following pictures. bit15 bit3 bit0 Value of Trigger Device Address D0 Picture State: State: State: Switches the picture to display according to the status of the bits. I f m u l t i p l e b i t s a r e 1 , display the picture for the lowest order bit.
Page 595 2 Multi-State Lamp Trigger Device Address ■ Specifies the word device to use as the condition for switching the drawing object. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. WindO/I-NV4 User’s Manual 9-21...
Page 596 2 Multi-State Lamp View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. Coordinates ■...
Page 597 2 Multi-State Lamp Registration Text Tab ● Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Windows, Stroke Can only be set when the Use Text Manager check box is cleared. The characters that can be displayed depend on the font.
Page 598 2 Multi-State Lamp State Tab ● Number of States ■ Specify the number of drawing objects (1 to 16) to display by switching. Settings ■ Lists the state settings. The list shows various settings such as the state number and file name for the drawing object. State: Shows the OFF state and state number.
Page 599 2 Multi-State Lamp Pattern: Shows the pattern or tonal gradation for standard images. Double clicking the cell opens the Pattern Palette where you can change the pattern or tonal gradation of the image. This setting can only be changed if Image Type is set to Standard on the View tab.
Page 600 2 Multi-State Lamp State Settings Dialog Box This dialog box sets the drawing object and registration text to display. Image ■ Browse: Select the drawing object to use for the lamp part. Clicking this button opens the View Browser if Standard is selected under Image Type on the View tab, or Picture Manager if Picture is selected.
Page 601 2 Multi-State Lamp Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Visible Condition ■ The Multi-State Lamp is displayed while the condition is satisfied. The Multi-State Lamp is hidden while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Multi-State Lamp is hidden.
Page 602 2 Multi-State Lamp While OFF: Displays the Multi-State Lamp when the value of device address is 0. Value of device address Multi-State Lamp state Show Hide Show Hide Hide Show While satisfying the condition: Displays the Multi-State Lamp when the condition is satisfied. Satisfied Condition Not satisfied...
Page 603 2 Multi-State Lamp Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 604 2 Multi-State Lamp Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 605 2 Multi-State Lamp Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 606 2 Multi-State Lamp Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 607: Data Displays
Data Displays Chapter 10 This chapter describes how to configure the Data Display parts and their operation on the MICRO/I. Numerical Input HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 How the Numerical Input is Used The Numerical Input features a display mode that displays the current value of a device address and an entry mode that enters a value using the keypad or key buttons and writes that value to a device address.
Page 608: Numerical Input Configuration Procedure
1 Numerical Input 1.2 Numerical Input Configuration Procedure This section describes the configuration procedure for Numerical Inputs. On the Home tab, in the Parts group, click Data Displays, and then click Numerical Input. Click a point on the edit screen where you wish to place the Numerical Input. Double-click the dropped Numerical Input and a Properties dialog box will be displayed.
Page 609: Properties Of Numerical Input Dialog Box
1 Numerical Input 1.3 Properties of Numerical Input Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Methods of using the Numerical Input ■...
Page 610 1 Numerical Input Keypad ■ Configures the keypad for entering values in the Numerical Input. Type: According to the location where the keypad is configured, selects the type from the following. Standard: Uses the standard keypad. The standard keypad is the keypad configured as the popup screen for the standard keypad (screen number 3000 to 3015).
Page 611 1 Numerical Input Floating Digits: Specifies the number of digits for the fractional part of the decimal value out of the number of digits specified by Digits. This option can only be configured when the Display Floating Point check box is selected. The range of digits that can be set for the fractional part varies based on the display type and data type.
Page 612 1 Numerical Input When input value is out of range, display value near maximum or minimum: Select this check box to display the nearest value of the minimum or maximum when a value out of range is entered. Example: The When input value is out of range, display value near maximum or minimum check box is selected, the Value under the Range on the Data Over tab is selected and the Minimum is 0 and the Maximum is 10000.
Page 613 1 Numerical Input Input Method ■ These options specify the destination for entered values. Destination Device Address: Specifies the word device to write the entered value to. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. Use Reference Device Address : Select this check box and specify a device address to change the destination word device by the value of this device address.
Page 614 1 Numerical Input Focus is moved by ENT button ■ When multiple Numerical Inputs are configured on the screen, select this check box to continue entering values on each of the Numerical Inputs. Each time ENT is pressed, the focus moves between the Numerical Inputs according to Focus Order. On the View tab, in the Screens group, click Focus Order, and then click the Numerical Inputs in the order to move the focus.
Page 615 1 Numerical Input View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. None: The plate and the flange of the part are not displayed.
Page 616 1 Numerical Input Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts is defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 617 1 Numerical Input Format Tab ● Font ■ Selects the font used for displaying text from the following. Standard, Windows, Stroke, 7-Segment The characters that can be displayed depend on the font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Size ■...
Page 618 1 Numerical Input Display Numerical Value with “*” ■ Select this check box to display the entered value as * (asterisks). Nothing is displayed if the value of device address is 0 when this check box is selected and the Suppress Zeros check box is selected on the General tab.
Page 619 1 Numerical Input Flash ■ Select this check box to make the text and plate colors flash. The flashing will occur as follows: • The Change Display Colors check box is cleared, then the colors specified by Text Color and Plate Color on the View tab and the colors specified by Text Color and Plate Color under Flash are alternately displayed.
Page 620 1 Numerical Input Trigger Device Address: Specifies the bit device or the bit number of the word device that will be used to trigger flash. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. Flash intervals are set in the Flashing Cycle on the System tab in the Project Settings dialog box.
Page 621 1 Numerical Input Data Over Tab ● The Data Over tab is displayed in Advanced mode. Range ■ Select data type. Value: Specifies the minimum and/or the maximum as a constant. Device Address: Specifies the minimum and/or the maximum as a value of word device. Specifies the allowable range of values to enter or display.
Page 622 1 Numerical Input When Data Over ■ These options configure the operation of the part when the value entered with the keypad exceeds the allowable range. These options can only be configured when the Minimum or Maximum check boxes are selected under Range. Report: Select this check box to write 1 in the Report Device Address when the entered value or the value of the device address to display exceeds the allowable range.
Page 623 1 Numerical Input Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Input Condition ■ The Numerical Input is enabled and operational while the condition is satisfied. The Numerical Input is disabled and not operational while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Numerical Input is not operational.
Page 624 1 Numerical Input While OFF: Enables the Numerical Input when the value of device address is 0. Value of Device Address Numerical Input state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Numerical Input when the condition is satisfied. Satisfied Condition Not satisfied...
Page 625 1 Numerical Input Trigger Type: Selects the condition to display the Numerical Input from the following. Always visible: The Numerical Input is always displayed. Numerical Input state Always show While ON: Displays the Numerical Input when the value of device address is 1. Value of Device Address Numerical...
Page 626 1 Numerical Input Options Tab ● The Options tab is displayed in Advanced mode. Input with Arithmetic Operation ■ To apply arithmetic operations to values entered using a keypad and writing the results, select this check box and input the arithmetic formula. Example: To divide the value of device address when entered by 60 External device MICRO/I...
Page 627 1 Numerical Input Data Item Description The device address on which the arithmetic operation is performed is specified in the arithmetic formula. Only one device address can be set for an arithmetic operation. The device address is as specified for Destination Device Address under the General tab. Sets the constant values for the arithmetic formula.
Page 628 1 Numerical Input Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 629 1 Numerical Input Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Numerical Input No.
Page 630 1 Numerical Input Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 631: How To Enter Values
1 Numerical Input 1.4 How to Enter Values Use the keypad or key buttons to write a value to a device address with the Numerical Input. The input methods are as follows. Pressing the Numerical Input and Entering Values from the Standard Keypad ■...
Page 632: Advanced Usage
1 Numerical Input Without Pressing the Numerical Input, Directly Entering Values from a Keypad on the Same Screen ■ Arrange a Numerical Input and a keypad on the same screen. In the properties dialog box for the Numerical Input, on the General tab, under Keypad, select Current Screen for Type and select the Always Entry Mode check box.
Page 633: Character Input
2 Character Input Character Input HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 2.1 How the Character Input is Used The Character Input features a display mode that displays the character codes in current values of device addresses as text and an entry mode that enters text using the keypad or key buttons and writes the character codes for the entered text to device addresses.
Page 634: Character Input Configuration Procedure
2 Character Input 2.2 Character Input Configuration Procedure This section describes the configuration procedure for Character Inputs. On the Home tab, in the Parts group, click Data Displays, and then click Character Input. Click a point on the edit screen where you wish to place the Character Input. Double-click the dropped Character Input and a Properties dialog box will be displayed.
Page 635: Properties Of Character Input Dialog Box
2 Character Input 2.3 Properties of Character Input Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Keypad ■...
Page 636 2 Character Input Coordinates X, Y: Specifies the display location of the popup screen configured as the keypad. With the upper-left corner of the screen as the origin, the X and Y coordinates are the upper-left corner of the popup screen. This option can only be configured when Standard(Half-Width Character), Standard(Hiragana) or Popup is selected for Type and the Adjust location automatically check box is cleared.
Page 637 2 Character Input Example: If Input Digits is 10 and a string with a length of 6 was input Check box: Selected Check box: Cleared Character Input HG SERIES HG SERIES display ‘H’ ‘G’ ‘H’ ‘G’ 4847 4847 (Hex) (Hex) ‘...
Page 638 Example: When the Always Entry mode check box is selected Press CLR Enter text Press ENT IDEC_ IDEC_ Operations and display Deletes text Enter IDEC Display values of Write character codes to Display only focus Display text being Action device addresses as text device addresses (Entry mode)
Page 639 2 Character Input Focus is moved by ENT button ■ When multiple Character Inputs are configured on the screen, select this check box to continue entering text on each of the Character Inputs. Each time ENT is pressed, the focus moves between the Character Inputs according to Focus Order. On the View tab, in the Screens group, click Focus Order, and then click the Character Inputs in the order to move the focus.
Page 640 2 Character Input View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. None: The plate and the flange of the part are not displayed.
Page 641 2 Character Input Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts is defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 642 2 Character Input Format Tab ● Font ■ Selects the font used for displaying text from the following. Japanese, European, Central European, Baltic, Cyrillic, Stroke The characters that can be displayed depend on the font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Size ■...
Page 643 2 Character Input Display Character with “*” ■ Select this check box to display the entered characters as * (asterisks). If this check box is selected, nothing is displayed until a value is entered from the key buttons or keypad when the Character Input is in entry mode.
Page 644 2 Character Input Flash ■ Select this check box to make the text and plate colors flash. The flashing will occur as follows: • The Change Display Colors check box is cleared, then the colors specified by Text Color and Plate Color on the View tab and the colors specified by Text Color and Plate Color under Flash are alternately displayed.
Page 645 2 Character Input Trigger Device Address: Specifies the bit device or the bit number of the word device that will be used to trigger flash. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. Flash intervals are set in the Flashing Cycle on the System tab in the Project Settings dialog box.
Page 646 While LM0 is 0, the condition is not satisfied and the Character Input is not operational. While LM0 is 1, the condition is satisfied and the Character Input is operational. MICRO/I LM0 : Condition operational IDEC satisfied Operational LM0 : 1 Condition IDEC...
Page 647 2 Character Input While OFF: Enables the Character Input when the value of device address is 0. Value of Device Address IDEC IDEC IDEC IDEC IDEC IDEC Character Input state Enabled Disabled Enabled Disabled Disabled Enabled While satisfying the condition: Enables the Character Input when the condition is satisfied.
Page 648 2 Character Input Trigger Type: Selects the condition to display the Character Input from the following. Always visible: The Character Input is always displayed. IDEC Character Input state Always show While ON: Displays the Character Input when the value of device address is 1.
Page 649 2 Character Input Options Tab ● The Options tab is displayed in Advanced mode. No Touch Sound ■ This function is to disable touch sounds only for specified parts when the MICRO/I makes touch sounds. Select this check box to display disable touch sounds for this part. To enable touch sounds on the MICRO/I, select the Enable Touch Sound check box under the System tab of the Project Settings dialog box.
Page 650 2 Character Input Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 651 2 Character Input Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted HG SERIES Reader Permitted Line Chart and Bar Chart...
Page 652 2 Character Input Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 653: How To Enter Text
2 Character Input 2.4 How to Enter Text Use the keypad or key buttons to write character codes to device addresses with the Character Input. The input methods are as follows. Pressing the Character Input and Entering Text from the Standard Keypad ■...
Page 654 2 Character Input Without Pressing the Character Input, Directly Entering Text from a Keypad on the Same Screen ■ Arrange a Character Input and a keypad on the same screen. In the properties dialog box for the Character Input, on the General tab, under Keypad, select Current Screen for Type and select the Always Entry Mode check box.
Page 655: Character Input Usage Examples
2 Character Input 2.5 Character Input Usage Examples Enter Kanji characters ● HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P Using the Standard Keypad Popup Screen (Screen number: 3008) for inputting Kanji characters, enter Kanji characters in the Character Input. Configuration Procedure On the Home tab, in the Parts group, click Data Displays, and then click Character Input.
Page 656 2 Character Input Click the Format tab, select the Japanese as the Font, and then select the 16x16 as the Size. Click OK. The Properties of Character Input dialog box closes. On the Configuration tab, in the System Setup group, click Project. The Project Settings dialog box is displayed.
Page 657 2 Character Input On the Home tab, in the Project group, click the Download icon. The Download dialog box is displayed. If the project data was changed, a confirmation message to save the project data is displayed. Click OK to save the project data and display the Download dialog box. Click Cancel to return to the editing screen without saving the project data.
Page 658 2 Character Input Operating Procedure This section describes an example of entering the Kanji characters " 山田太郎 " to the Character Input. Press the Character Input for entering the Kanji characters. The popup screen for the standard keypad (screen number 3008) will be displayed. MICRO/I External device Press the Kanji to switch it to Kanji input mode.
Page 659 2 Character Input Press SP to display conversion candidates. やまだ ← → 山田あかさたなはまやらわヤマダゆりをいきしちにひみ山だ耶麻だうくすつぬ...
Page 660 2 Character Input Repeat steps through to enter all the characters. 山田たろう ← → 太郎なはまやらわあかさた田老ゆりをいきしちにひみ足ろうたろううく...
Page 661: String Data Storage Method
2 Character Input 2.6 String Data Storage Method The entered text is stored in the upper byte and lower byte according to the Storage Method of String Data setting. Storage Method of String Data is configured on the System tab in the Project Settings dialog box. For details, refer to Chapter 4 “3.1 System Tab”...
Page 662: Picture Display
3 Picture Display Picture Display HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 3.1 How the Picture Display is Used The Picture Display displays pictures. It can change, move, or scale the displayed picture according to value of device address.
Page 663 3 Picture Display • Switch and display pictures at a regular interval MICRO/I Picture List Pic0 Pic1 5 x 100 ms Pic2 5 x 100 ms 5 x 100 ms • Move the picture position by values of device addresses MICRO/I External device X-coordinate D100=...
Page 664 3 Picture Display • Scale the size of the picture by values of device addresses and display it MICRO/I External device Width D100= Scale picture to Height D101= W 360, H 240 Width D100= Height D101= Scale picture to W 720, H 480 Shrink picture to Width D100= W 180, H 120...
Page 665: Picture Display Configuration Procedure
3 Picture Display 3.2 Picture Display Configuration Procedure This section describes the configuration procedure for Picture Displays. On the Home tab, in the Parts group, click Data Displays, and then click Picture Display. Click a point on the edit screen where you wish to place the Picture Display. Double-click the dropped Picture Display and a Properties dialog box will be displayed.
Page 666: Properties Of Picture Display Dialog Box
3 Picture Display 3.3 Properties of Picture Display Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Switching Method ■...
Page 667 3 Picture Display Value: Switches the picture to display according to the value of the device address. Example: When Value is selected and the trigger device addresses D0 are allocated to the following pictures. Trigger device address D0 value Picture Pic0 Pic1 Pic2...
Page 668 3 Picture Display Flash ■ Select this check box to flash the displayed pictures. The picture is repeatedly shown and hidden. Dynamic Position ■ Select this check box to move and display the picture by specifying the coordinates of the picture as values of device addresses.
Page 669 3 Picture Display Dynamic Rotation ■ Select this check box to rotate and display a picture. Edit: Configures details for rotating and displaying a picture. Click this button to display the Dynamic Rotation dialog box. For details, refer to “Dynamic Rotation Dialog Box”...
Page 670 3 Picture Display Dynamic Rotation Dialog Box Configures details for rotating and displaying a picture. The center of picture Maximum Minimum Rotation angle End angle of rotation Start angle of rotation Center Point (X Point, Y Point) Pivot point of rotation Source Device Address ■...
Page 671 3 Picture Display Range of Value ■ Configures the range of values to read from the Source Device Address with a fixed value or a value of device address. Converts the read value to the specified angle range, and then rotate the picture. This option can only be configured when the Use Custom Settings check box is selected.
Page 672 3 Picture Display Center Point ■ Configures the coordinate point of the center point that will serve as the pivot point for rotation with a fixed value or a value of device address. This option can only be configured when the Use Custom Settings check box is selected. Value: Specifies as constants.
Page 673 3 Picture Display Specify from Picture dialog box Center Point Point To specify the center point that will serve as the pivot point for rotation, perform one of the following operations. For the coordinates, the X-coordinate and Y-coordinate of the center point are displayed with the center of the picture as the origin.
Page 674 3 Picture Display View Tab ● (Pic number - File name) Settings ■ Registers the pictures to display on the Picture Display. (Pic number - File name): Registers the pictures to display. Double clicking the cell displays the Picture Manager where you can specify the picture. The picture number (Pic number) and the file name of the registered picture are displayed.
Page 675 3 Picture Display Size ■ W, H: Sets width and height to define the size of parts. 2 to (base screen horizontal size) 2 to (base screen vertical size) Width Screen Parts Height WindO/I-NV4 User’s Manual 10-69...
Page 676 3 Picture Display Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. The Picture Display is enabled while the condition is satisfied, and it is disabled while the condition is not satisfied. Select the operation when the condition is not satisfied as Not update Picture data or Not show Picture Display under While not satisfying the condition.
Page 677 3 Picture Display While ON: Enables the Picture Display when the value of device address is 1. Example: When While not satisfying the condition is Not update Picture data Data Pic0 Pic1 Pic2 Pic0 Pic1 Pic2 Pic0 Value of Device Address Display Do not update Update...
Page 678 3 Picture Display Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 679 3 Picture Display Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 680 3 Picture Display Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 681 3 Picture Display Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 682: Picture Display Usage Examples
3 Picture Display 3.4 Picture Display Usage Examples Rotating and Displaying a Picture ● This example shows rotating and displaying a picture by the values of device addresses. On the Home tab, in the Parts group, click Data Displays, and then click Picture Display. Click a point on the edit screen where you wish to place the Picture Display.
Page 683 3 Picture Display Registers the pictures to display on the Picture List. Double click "pic0-Unregistered". Picture Manager is displayed. Click Import. Open dialog box is displayed. Specify the image file, and then click Open. The picture is saved in Picture Manager. WindO/I-NV4 User’s Manual 10-77...
Page 684 3 Picture Display Specify the image file, and then click Select. The picture is saved in Settings. Repeat steps through and register all pictures for switching. WindO/I-NV4 User’s Manual 10-78...
Page 685 3 Picture Display Click the General tab. Select the Dynamic Rotation check box, and then click Edit. WindO/I-NV4 User’s Manual 10-79...
Page 686 3 Picture Display In Source Device Address, specify the word device to be read that holds the value to rotate and display the picture. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings”...
Page 687: Video Display
4 Video Display Video Display This function is only supported by models that are equipped with a video interface. HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 4.1 How the Video Display is Used • Play movie files MICRO/I SD memory card Play...
Page 688 4 Video Display • Using multiple Video Displays is as follows. - HG5G/4G/3G-V The maximum number of the Video Display that can be arranged on a single screen is two, you cannot arrange three or more Video Displays on a single screen including overlay. Two Video Displays can display image from video input at the same time, but can not display movie file at the same time.
Page 689: Video Display Configuration Procedure
4 Video Display 4.2 Video Display Configuration Procedure This section describes the configuration procedure for the Video Display. On the Home tab, in the Parts group, click Data Displays, and then click Video Display. Click a point on the edit screen where you wish to place the Video Display. Double-click the dropped Video Display and a Properties dialog box will be displayed.
Page 690: Properties Of Video Display Dialog Box
4 Video Display 4.3 Properties of Video Display Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. Maximum number is 20 characters. Action ■ Select the content to execute on the Video Display from the following.
Page 691 4 Video Display Play the specified movie: Plays movie files by the order of the ID number. Selects files to be played from the movie file list and then creates a list of files to be played. This can be set only when Play the specified movie is selected. Displays the movie file list ID.
Page 692 4 Video Display View Tab ● Browse ■ Select the type of graphic to be used to represent the part from the list of graphics. Click this button to display the View Browser. Plate Color ■ Selects the plate (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette.
Page 693 4 Video Display Buttons ■ Foreground Color, Background Color: Selects the foreground and background colors of the buttons (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette. Select a color from the Color Palette. Pattern: Selects a pattern or tonal gradation for the button. Click Pattern to display the Pattern Palette.
Page 694 4 Video Display Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 695 4 Video Display Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 696 4 Video Display Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 697 4 Video Display Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 698: File Screen
4 Video Display 4.4 File Screen With the File Screen, movie files can be selected from an SD memory card and then played on a Video Display. When Play a movie or recorded file from the File Screen has been selected in Action for the Video Display, movie files can be selected with the File Screen and then played.
Page 699 4 Video Display (File List) ■ File Name: Displays a list of the files and folders in the currently selected folder. Size: For files, this displays the file size (bytes). For folders, this is displayed as Folder. File names should be alphanumeric characters only. Movie files that meet the following specifications can be played with the MICRO/I: HG5G/4G/3G-V: AVI file (.avi)
Page 700 4 Video Display Select a Movie File ● Display the File Screen on the Base Screen and select a movie file from a Memory Card. Press the Goto Screen Button or Multi-Button that has been set to Open File Screen or execute the Goto Screen Command or Multi-Command.
Page 701 4 Video Display Press  to select “20110313” and then press Select. The contents of the “20110313” folder will be displayed. File Screen DRIVE: SD Card Page No.: 1 Folder Up \HGDATA01\RECORD File name Size 20110312 Folder 20110313 Folder 20110314 Folder 20110315 Folder...
Page 702: Message Display
5 Message Display Message Display HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 5.1 How the Message Display is Used The Message Display is used to constantly display messages registered in advance and to display text read from values of word devices as character codes.
Page 703 5 Message Display • Scroll messages MICRO/I Message details Line A : 1234K pcs. Line B : 5678K pcs. Line A A : 1234K pcs. pcs. Line B 8K pcs. • Change the message and plate color according to a value of device address MICRO/I External device Upper byte...
Page 704: Message Display Configuration Procedure
5 Message Display 5.2 Message Display Configuration Procedure This section describes the configuration procedure for Message Displays. On the Home tab, in the Parts group, click Data Displays, and then click Message Display. Click a point on the edit screen where you wish to place the Message Display. Double-click the dropped Message Display and a Properties dialog box will be displayed.
Page 705: Properties Of Message Display Dialog Box
5 Message Display 5.3 Properties of Message Display Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Use Text Manager ■...
Page 706 5 Message Display Message ■ Enter the text to display. The maximum number is 610 characters. You can enter multi-line messages by inserting a newline. To configure text to display according to values of device addresses, enter “\@” (1 to 8) at the location to read the values of word devices as character codes and display them as text.
Page 707 5 Message Display View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. None: The plate and the flange of the part are not displayed.
Page 708 5 Message Display Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts is defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 709 5 Message Display Format Tab ● Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Stroke The characters that can be displayed depend on the font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6.
Page 710 5 Message Display Vertical Writing ■ Select this check box when displaying text vertically. Can only be set when Font is set to Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, or Cyrillic. When the Vertical Writing check box is selected, take care about the following points. This is applicable for Windows supports East Asian characters.
Page 711 5 Message Display Scroll ■ Select this check box to enable scrolling display displaying of messages. This option can only be configured when the Flash check box is cleared and Standard is selected for Image Type on the View tab. Speed (1: Fastest): Sets the scrolling speed (1 to 10).
Page 712 5 Message Display Change Display Colors ■ To switch the text and plate colors, select this check box and select the method to the display colors from the following. Specify Color: Switches the text and plate to the specified colors. MICRO/I External device Trigger Device Address...
Page 713 5 Message Display Specify Color by Device Address: Specifies the text and plate colors by the value of the device address. External device MICRO/I Device Address Upper byte Lower byte Upper byte Lower byte 0 x F 7 0 x 0 0 HG SERIES 0 x F 7 0 x 0 0...
Page 714 5 Message Display Flash ■ Select this check box to make the text and plate colors flash. The flashing will occur as follows: • The Change Display Colors check box is cleared, then the colors specified by Text Color and Plate Color on the View tab and the colors specified by Text Color and Plate Color under Flash are alternately displayed.
Page 715 5 Message Display • The Change Display Colors check box is selected, Specify Color by Device Address is selected, then the colors that correspond to the values stored in the device addresses for Specify Color by Device Address and this device address number+1 are alternately displayed. Upper byte Lower byte Device Address for...
Page 716 5 Message Display Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. The Message Display is enabled while the condition is satisfied, and it is disabled while the condition is not satisfied. Select the operation when disabled as Not display message or Not show Message Display under While not satisfying the condition.
Page 717 5 Message Display While ON: Enables the Message Display when the value of device address is 1. Example: When While not satisfying the condition is Not display message. Value of Device Address HG SERIES HG SERIES HG SERIES HG SERIES Message Display state Hide...
Page 718 5 Message Display Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 719 5 Message Display Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 720 5 Message Display Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 721 5 Message Display Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 722: String Data Storage Method
5 Message Display 5.4 String Data Storage Method The values of device addresses read as character codes are stored in the upper byte and lower byte of words according to the Storage Method of String Data setting. Storage Method of String Data is configured on the System tab in the Project Settings dialog box.
Page 723: Message Switching Display
6 Message Switching Display Message Switching Display HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 6.1 How the Message Switching Display is Used The Message Switching Display is used to switch the displayed message according to the value of a word device. bit15 bit3 bit0...
Page 724: Message Switching Display Configuration Procedure
6 Message Switching Display 6.2 Message Switching Display Configuration Procedure This section describes the configuration procedure for Message Switching Displays. On the Home tab, in the Parts group, click Data Displays, and then click Message Switching Display. Click a point on the edit screen where you wish to place the Message Switching Display. Double-click the dropped Message Switching Display and a Properties dialog box will be displayed.
Page 725: Properties Of Message Switching Display Dialog Box
6 Message Switching Display 6.3 Properties of Message Switching Display Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Switching Method ■...
Page 726 6 Message Switching Display Value: Switches the message to display according to the value of a device address. Example: When Value is selected and the trigger device addresses D0 are allocated to the following messages. Message details Drying Value of Trigger Device Address D0 Msg0 Heating Msg1...
Page 727 6 Message Switching Display Message Tab ● Use Text Manager ■ Select this check box to use text registered in Text Manager. Settings ■ Edits the message settings. No.: Shows the message number (Msg number). The number of messages that can be registered varies based on Switching Method on the General tab.
Page 728 6 Message Switching Display Remove ■ Deletes the registered settings from the list. ■ Shifts the selected settings upward in the list. Down ■ Shifts the selected settings downward in the list. WindO/I-NV4 User’s Manual 10-122...
Page 729 6 Message Switching Display View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. None: The plate and the flange of the part are not displayed.
Page 730 6 Message Switching Display Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts is defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 731 6 Message Switching Display Format Tab ● Font ■ Selects the font used for displaying text from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic, Stroke The characters that can be displayed depend on the font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6.
Page 732 6 Message Switching Display Vertical Writing ■ Select this check box when displaying text vertically. Can only be set when Font is set to Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, or Cyrillic. When the Vertical Writing check box is selected, take care about the following points. This is applicable for Windows supports East Asian characters.
Page 733 6 Message Switching Display Change Display Colors ■ Select this check box to switch the text and plate colors. MICRO/I External device Trigger Device Address Text Color Plate Color on the View tab HG SERIES Trigger Device Address Text Color under Change Display Colors Plate Color under Change Display Colors HG SERIES Trigger Device Address: Specifies the bit device or the bit number of the word device to use as the trigger to switch...
Page 734 6 Message Switching Display Flash ■ Select this check box to make the text and plate colors flash. The flashing will occur as follows: • The Change Display Colors check box is cleared, then the colors specified by Text Color and Plate Color on the View tab and the colors specified by Text Color and Plate Color under Flash are alternately displayed.
Page 735 6 Message Switching Display Trigger Device Address: Specifies the bit device or the bit number of the word device that will be used to trigger flash. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings”...
Page 736 6 Message Switching Display Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. Visible Condition ■ The Message Switching Display is displayed while the condition is satisfied. The Message Switching Display is hidden while the condition is not satisfied. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the Message Switching Display is hidden.
Page 737 6 Message Switching Display Trigger Type: Selects the condition to display the Message Switching Display from the following. Always visible: The Message Switching Display is always displayed. HG SERIES Message Switching Display state Always show While ON: Displays the Message Switching Display when the value of device address is 1. Value of Device Address HG SERIES...
Page 738 6 Message Switching Display Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 739 6 Message Switching Display Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 740 6 Message Switching Display Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 741 6 Message Switching Display Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 742: Alarm List Display
7 Alarm List Display Alarm List Display HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 7.1 How the Alarm List Display is Used The Alarm List Display works with the Alarm Log function to display messages for active alarms and to display multiple messages according to values of device addresses in a list.
Page 743: Alarm List Display Configuration Procedure
7 Alarm List Display 7.2 Alarm List Display Configuration Procedure This section describes the configuration procedure for Alarm List Displays. On the Home tab, in the Parts group, click Data Displays, and then click Alarm List Display. Click a point on the edit screen where you wish to place the Alarm List Display. Double-click the dropped Alarm List Display and a Properties dialog box will be displayed.
Page 744: Properties Of Alarm List Display Dialog Box
7 Alarm List Display 7.3 Properties of Alarm List Display Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Message Settings ■...
Page 745 7 Alarm List Display Example: When New Message List is selected and the bits of trigger device address D0 are allocated to the following messages. bit15 bit3 bit0 Trigger device address D0 Message Setting 1 : 100 Setting 2 : 200 Setting 3 : 300 The messages are displayed according to the state of the bits.
Page 746 7 Alarm List Display List Tab ● The List tab is only displayed when New Message List is selected for Message Settings on the General tab. (Block settings) Number of Blocks ■ Configures the device addresses that trigger messages to display and message switching as blocks (1 to 64). 1 block is composed of 16 channels.
Page 747 7 Alarm List Display Insert: Inserts the block settings in the position selected on the list. Select the block number at the position to insert the settings in the list and click this button to display the Individual Settings dialog box. For details, refer to “Individual Settings Dialog Box”...
Page 748 7 Alarm List Display View Tab ● Browse ■ Select the type of graphic to be used to represent the part from the list of graphics. Click this button to display the View Browser. Plate Color ■ Selects the plate (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette.
Page 749 7 Alarm List Display Buttons ■ Foreground Color, Background Color: Selects the foreground and background colors of the buttons (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette. Select a color from the Color Palette. Pattern: Selects a pattern or tonal gradation for the button.
Page 750 7 Alarm List Display Format Tab ● Font ■ Configures the format of the messages to display. Style: Selects Regular or Bold for text style. Magnification: W, H: Selects text magnification (0.5, 1 to 8). Display with Same Text Color ■...
Page 751 7 Alarm List Display Line Spacing ■ Selects the specification method for line spacing in the list and configures the line spacing. Set with Number of Lines: Specifies the number of lines for the message to display for one alarm line. Number of Lines: Enter the number of lines .
Page 752 7 Alarm List Display Scroll ■ Select this check box to enable scrolling display displaying of messages. Can only be set when One Line is selected for Display Type under the General tab. For Alarm List Display, this can only be set if One Line is selected for Display Type under the General tab. Speed (1: Fastest): Sets the scrolling speed (1 to 10).
Page 753 7 Alarm List Display Options Tab ● The Options tab is displayed in Advanced mode. (Reference screen list) Reference Screen ■ The Options tab is used to configure the reference screen. The reference screen is a base screen or popup screen associated with each individual message.
Page 754 7 Alarm List Display Screen Number Setting Method ■ Selects the setting method for the screen numbers on the reference screen list. Serial: Continuously and automatically specifies screen numbers (1 to 3000) that are at or below the selected message number. Example 1: When screen number “100”...
Page 755 7 Alarm List Display Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 756 7 Alarm List Display Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button...
Page 757 7 Alarm List Display Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 758: Alarm Log Display
8 Alarm Log Display Alarm Log Display HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 8.1 How the Alarm Log Display is Used The Alarm Log Display displays Alarm Log data saved in the data storage area. • List the message, the occurrence time, recovery time, and confirmation time for the alarms that have occurred MICRO/I 12 : 00 External device...
Page 759: Alarm Log Display Configuration Procedure
8 Alarm Log Display 8.2 Alarm Log Display Configuration Procedure This section describes the configuration procedure for Alarm Log Displays. On the Home tab, in the Parts group, click Data Displays, and then click Alarm Log Display. Click a point on the edit screen where you wish to place the Alarm Log Display. Double-click the dropped Alarm Log Display and a Properties dialog box will be displayed.
Page 760: Properties Of Alarm Log Display Dialog Box
8 Alarm Log Display 8.3 Properties of Alarm Log Display Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Alarm Log Settings ■...
Page 761 8 Alarm Log Display First Alarm ■ An alarm that occurs in a state where no alarms have occurred is called the first alarm. Select the check boxes for the operations to execute when the first alarm occurs. Display First Alarm to 1st line on List: Always displays the first alarm on the first line of the list.
Page 762 8 Alarm Log Display Log Tab ● (Show items detailed settings) Show Items ■ Select these check boxes for the items to display on the Alarm Log Display. Title: Shows the titles on the first line of the list. Occurrence Time: Shows the time the alarm occurred.
Page 763 8 Alarm Log Display (Show items detailed settings) ■ Each of the show items selected by the check boxes under Show Items can be configured in detail here. Title: Double click the cell, and then enter the titles for the items to display. The maximum number is 100 characters.
Page 764 8 Alarm Log Display View Tab ● Browse ■ Select the type of graphic to be used to represent the part from the list of graphics. Click this button to display the View Browser. Plate Color ■ Selects the plate (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette.
Page 765 8 Alarm Log Display Buttons ■ Foreground Color, Background Color: Selects the foreground and background colors of the buttons (color: 256 colors, monochrome: 16 shades). Click Color to display the Color Palette. Select a color from the Color Palette. Pattern: Selects a pattern or tonal gradation for the button.
Page 766 8 Alarm Log Display Format Tab ● Style ■ Selects Regular or Bold for text style. Magnification ■ W, H: Selects text magnification (0.5, 1 to 8). Title Font ■ Select the font that will be used for the title from the following options. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic The characters that can be displayed depend on the font.
Page 767 8 Alarm Log Display Line Spacing ■ Selects the specification method for line spacing in the list and configures the line spacing. Set with Number of Lines: Specifies the number of lines for the message to display for one alarm line. Number of Lines: Enter the number of lines .
Page 768 8 Alarm Log Display Options Tab ● The Options tab is displayed in Advanced mode. Reference Screen Settings ■ The Options tab is used to configure the reference screen. The reference screen is a base screen or popup screen associated with each individual message. The reference screen is displayed when the key button Ref. is pressed. 1.
Page 769 8 Alarm Log Display Display Block Number ■ Specifies the range of block numbers that will display the collected alarm log data. All: Displays the data for all blocks. Block Number: Displays only the data for the specified blocks in the Alarm Log Display. Alarms in unspecified blocks are not displayed, even if active.
Page 770 8 Alarm Log Display Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 771 8 Alarm Log Display Example: If the user and security group for a part are set as follows: User Name User1 User2 User3 Security Group Reader Operator Administrator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button...
Page 772 8 Alarm Log Display Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 773: Numerical Display
9 Numerical Display Numerical Display HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 9.1 How the Numerical Display is Used The Numerical Display is used to display the value of a word device in the specified format. • Display the current value of a device address MICRO/I Display Device Address : D100 External device...
Page 774: Numerical Display Configuration Procedure
9 Numerical Display 9.2 Numerical Display Configuration Procedure This section describes the configuration procedure for Numerical Displays. On the Home tab, in the Parts group, click Data Displays, and then click Numerical Display. Click a point on the edit screen where you wish to place the Numerical Display. Double-click the dropped Numerical Display and a Properties dialog box will be displayed.
Page 775: Properties Of Numerical Display Dialog Box
9 Numerical Display 9.3 Properties of Numerical Display Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Display Type ■...
Page 776 9 Numerical Display Floating Digits: Specifies the number of digits for the fractional part of the decimal value out of the number of digits specified by Digits. This option can only be configured when the Display Floating Point check box is selected. The range of digits that can be set for the fractional part varies based on the display type and data type.
Page 777 9 Numerical Display Display Method ■ Specifies the source of the value to display. Display Device Address: Specifies the word device that stores the value to display. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. : Select this check box and specify a device address to change the source device Use Reference Device Address address by the value of this device address.
Page 778 9 Numerical Display View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. None: The plate and the flange of the part are not displayed.
Page 779 9 Numerical Display Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts is defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 780 9 Numerical Display Format Tab ● Font ■ Selects the font used for displaying text from the following. Standard, Windows, Stroke, 7-Segment The characters that can be displayed depend on the font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6. Size ■...
Page 781 9 Numerical Display With Unit ■ Select this check box to display units or other characters at the end of a number. Displayed characters must be registered in Text Manager. The displayed text color will be as set for Text Color under the Format tab. Text ID: Specifies the Text Manager ID No.
Page 782 9 Numerical Display Flash ■ Select this check box to make the text and plate colors flash. The flashing will occur as follows: • The Change Display Colors check box is cleared, then the colors specified by Text Color and Plate Color on the View tab and the colors specified by Text Color and Plate Color under Flash are alternately displayed.
Page 783 9 Numerical Display Trigger Device Address: Specifies the bit device or the bit number of the word device that will be used to trigger flash. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. Flash intervals are set in the Flashing Cycle on the System tab in the Project Settings dialog box.
Page 784 9 Numerical Display Data Over Tab ● The Data Over tab is displayed in Advanced mode. Range ■ Select data type. Value: Specifies the minimum and/or the maximum as a constant. Device Address: Specifies the minimum and/or the maximum as a value of word device. Specifies the allowable range of values to display.
Page 785 9 Numerical Display When Data Over ■ These options configure the operation of the part when the allowable range is exceeded. These options can only be configured when the Minimum or Maximum check boxes are selected under Range. Flash: Select this check box to make the value flash when the displayed data exceeds the allowable range. Report: Select this check box to write 1 in the Report Device Address when the displayed data exceeds the allowable range.
Page 786 9 Numerical Display Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. The Numerical Display is enabled while the condition is satisfied, and it is disabled while the condition is not satisfied. Select the operation when the condition is not satisfied as Not display Numerical data, Not update Numerical data, or Not show Numerical Display under While not satisfying the condition.
Page 787 9 Numerical Display While ON: Enables the Numerical Display when the value of device address is 1. Example: When While not satisfying the condition is Not update Numerical data Data Value of Device Address Display Do not update Update Do not update Update Update Do not update...
Page 788 9 Numerical Display Options Tab ● The Options tab is displayed in Advanced mode. Display with Arithmetic Operation ■ To apply arithmetic operations to values of device addresses and writing the results, select this check box and input the arithmetic formula. Example: To multiple the value of device address when displayed by 60 External device MICRO/I...
Page 789 9 Numerical Display Operators Specify the type of arithmetic operation to be performed on the data. The operator priority is the same as for scripts. For details, refer to Chapter 20 “6.3 About the Priority of the Operator” on page 20-59. Item Description Sets the arithmetic operators.
Page 790 9 Numerical Display Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 791 9 Numerical Display Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 792 9 Numerical Display Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 793: Calendar
10 Calendar 10 Calendar HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 10.1 How the Calendar is Used The Calendar can be used to display the date and time using the MICRO/I's clock data. • Display the date and time MICRO/I 12/07 13:45 •...
Page 794: Calendar Configuration Procedure
10 Calendar 10.2 Calendar Configuration Procedure This section describes the configuration procedure for Calendars. On the Home tab, in the Parts group, click Data Displays, and then click Calendar. Click a point on the edit screen where you wish to place the Calendar. Double-click the dropped Calendar and a Properties dialog box will be displayed.
Page 795: Properties Of Calendar Dialog Box
10 Calendar 10.3 Properties of Calendar Dialog Box This section describes items and buttons on the properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Calendar Type ■ Selects the type of Calendar from the following.
Page 796 10 Calendar Alarm Tab ● These options can only be configured when Alarm or Clock & Alarm is selected for Calendar Type on the General tab. (Alarm conditions) Alarm Time ■ Selects the type of data for the alarm time. Value: Specifies the alarm time as values and the day of the week.
Page 797 10 Calendar ON Time ■ Configures the time to write 1 to the Report Device Address according to the type of data. • After 1 is written to the Report Device Address with ON Time, that value is retained. Value of device address retained after ON Time elapses Report Device Address M0 value Time...
Page 798 10 Calendar View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. None: The plate and the flange of the part are not displayed.
Page 799 10 Calendar Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts is defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 800 10 Calendar Format Tab ● Font ■ Selects the font used for displaying text from the following. Standard, Stroke, 7-Segment The characters that can be displayed depend on the font. For details, refer to Chapter 2 “1.2 Available Text” on page 2-6.
Page 801 10 Calendar Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. The Calendar is enabled while the condition is satisfied, and it is disabled while the condition is not satisfied. When disabled, the plate and flange are displayed, but the time is not displayed. However, if the Not show Calendar check box under While not satisfying the condition is selected, the plate and flange are also hidden and the part image is not displayed.
Page 802 10 Calendar While ON: Enables the Calendar when the value of device address is 1. Example: When the Not show Calendar check box is cleared under While not satisfying the condition Value of Device Address 12/07 13:45 12/07 13:45 12/07 13:45 12/07 13:45 Calendar state Hide time...
Page 803 10 Calendar Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to place the parts on the top layer. When drawings and parts overlap, those place on the top layer are displayed in preference.
Page 804 10 Calendar Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box. (Settings) (Settings) ■...
Page 805 10 Calendar Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 806 10 Calendar Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 807: Chapter 11 Charts
Charts Chapter 11 This chapter describes how to configure charts and meters and their operation on the MICRO/I. Bar Chart HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 How the Bar Chart is Used Bar charts and peak charts can be used to display word device values. •...
Page 808: Bar Chart Configuration Procedure
1 Bar Chart 1.2 Bar Chart Configuration Procedure This section describes the configuration procedure for bar charts. On the Home tab, in the Parts group, click Charts, and then click Bar Chart. Click a point on the edit screen where you wish to place the Bar Chart. Double-click the dropped Bar Chart and a Properties dialog box will be displayed.
Page 809: Properties Of Bar Chart Dialog Box
1 Bar Chart 1.3 Properties of Bar Chart Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Chart Type ■...
Page 810 1 Bar Chart Data Format ■ Data Type: Selects the data type handled by the chart from the following. UBIN16(W), BIN16(I), UBIN32(D), BIN32(L), BCD4(B), BCD8(EB), Float32(F) For details, refer to Chapter 2 “1.1 Available Data” on page 2-1. Origin, Minimum, Maximum: Specifies the origin, minimum, and maximum for the chart.
Page 811 1 Bar Chart Data Tab ● Number of Data ■ Specifies the number of data to be displayed in the chart(1 to 10). Settings ■ Lists the chart settings. The list shows the numbers, source device addresses, and colors for the chart. No.: Shows the numbers for the chart (Ch1 to Ch10).
Page 812 1 Bar Chart Bg. Normal: Selects the background color of the chart when normal. (color: 256 colors, monochrome: 16 shades) Double clicking the cell displays the Color Palette where you can change the background color of the chart when normal. Selects the background color of the chart when data over.
Page 813 1 Bar Chart View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. None: The plate and the flange of the part are not displayed. Browse ■...
Page 814 1 Bar Chart Space between Bars ■ Specifies the spacing for the bar chart (0 to 100 dots). Scale not shown Show scale Chart spacing Chart spacing Chart spacing Chart spacing Chart spacing Chart spacing Example: If Space between Bars is 10 If Space between Bars is 0 10 dots 10 dots...
Page 815 1 Bar Chart Data Over Tab ● The Data Over tab is displayed in Advanced mode. Range ■ Select data type. Value: Specifies the minimum and/or the maximum as a constant. Device Address: Specifies the minimum and/or the maximum as a word device value. Specifies the allowable range of values to display.
Page 816 1 Bar Chart When Data Over ■ These options configure the operation of the part when the allowable range is exceeded. These options can only be configured when the Minimum or Maximum check boxes are selected under Range. Flash: Select this check box to make the chart flash when the displayed data exceeds the allowable range. Report: Select this check box to write 1 in the Report Device Address when the displayed data exceeds the allowable range.
Page 817 1 Bar Chart Scale Tab ● The Scale tab is displayed in Advanced mode. The options on the Scale tab vary based on the type selected with Chart Type on the General tab. Horizontal Bar, Horizontal Peak: X-Axis Vertical Bar, Vertical Peak: Y-Axis Show Ticks ■...
Page 818 1 Bar Chart Show Gridline ■ Select this check box to display grid lines on the chart. Grid lines are displayed above the chart. Can only be set when the Show Ticks check box is selected. Display Position: Select from Scale and Data Over to specify the grid line display position. Scale: Grid lines are displayed according to the number of major scale divisions.
Page 819 1 Bar Chart Label Tab ● The Label tab is only displayed in Advanced mode. Show Label for X-Axis, Show Label for Y-Axis ■ Select this check box to display a label on X-axis and Y-axis scales. The options on the Label tab vary based on the type selected with Chart Type on the General tab. Horizontal Bar, Horizontal Peak: Show Label for X-Axis Vertical Bar, Vertical Peak: Show Label for Y-Axis...
Page 820 1 Bar Chart Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. The bar chart is enabled while the condition is satisfied, and it is disabled while the condition is not satisfied. Select the operation when the condition is not satisfied as Not display Chart data or Not update Chart data under While not satisfying the condition.
Page 821 1 Bar Chart While ON: Enables the bar chart when the value of device address is 1. Example: When While not satisfying the condition is Not update Chart data Ch1 data Ch2 data Value of device address Display Do not update Update Do not update Update...
Page 822 1 Bar Chart Comment ■ Used for entering comments about trigger conditions. Maximum number is 80 characters. While not satisfying the condition ■ Selects operation of the Bar Chart when condition is not satisfied. Not display Chart data: The plate and flange are displayed, but Bar Chart is not displayed. Not update Chart data: The last updated Bar Chart is displayed.
Page 823 1 Bar Chart Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 824 1 Bar Chart Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 825 1 Bar Chart Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 826 1 Bar Chart Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 827: Line Chart
2 Line Chart Line Chart HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 2.1 How the Line Chart is Used The line chart can be used to display values of device addresses sampled with the Data Log function and the values of multiple word devices.
Page 828: Line Chart Configuration Procedure
2 Line Chart 2.2 Line Chart Configuration Procedure This section describes the configuration procedure for Line Charts. On the Home tab, in the Parts group, click Charts, and then click Line Chart. Click a point on the edit screen where you wish to place the Line Chart. Double-click the dropped Line Chart and a Properties dialog box will be displayed.
Page 829: Properties Of Line Chart Dialog Box
2 Line Chart 2.3 Properties of Line Chart Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Chart Type ■...
Page 830 2 Line Chart Log Trend (Pen Recorder): Shows values of device addresses sampled with the Data Log function in a trend chart. The displayed chart is updated each time the latest data is sampled and the latest data is always displayed at the right edge. The entire chart shifts to the left point by point and the display is updated.
Page 831 2 Line Chart Restart Chart ■ Select this check box to display the chart from the beginning when switching screens. This option can only be configured when Log Trend (Normal) or Log Trend (Pen Recorder) is selected for Chart Type. MICRO/I MICRO/I MICRO/I...
Page 832 2 Line Chart View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. None: The plate and the flange of the part are not displayed. Browse ■...
Page 833 2 Line Chart Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen. X: 0 to (base screen horizontal size - 1) Y: 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 834 2 Line Chart X-Axis Tab ● Display Points ■ Specifies the maximum number of points of data to display on the chart (2 to 65535). This option can only be configured when Log Trend (Normal) or Log Trend (Pen Recorder) is selected for Chart Type.
Page 835 2 Line Chart Number of automatic scrolls when updating display ■ Specifies the number of points of data to scroll when updating the chart display (1 to Screen size (Horizontal)). This option can only be configured when Log Trend (Normal) is selected for Chart Type. (Data Type): Selects the data type to use with the scroll size.
Page 836 2 Line Chart Display of the saved data ■ This option can only be configured when Log Trend (Normal) or Log Trend (Pen Recorder) is selected from Chart Type on the General tab. Stop updating the display and display the saved data: To scroll the chart to display past data and to display the cursor, the chart display updating must be stopped.
Page 837 2 Line Chart Number of Scroll: Specifies the number of points of data to scroll the chart left or right (1 to the Screen size (Horizontal)) when stopping the chart display. This option can only be configured when the Stop updating the display and display the saved data check box is selected.
Page 838 2 Line Chart Display cursor: Select this check box and specify the bit device or the bit number of the word device to display the cursor. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings”...
Page 839 2 Line Chart Specifying Date and Time with Values of device addresses Using this option requires the sequential address number of 6 words starting from the specified device address. The data is handled as BCD values in the order of year, month, day, hour, minute, and second. Example: Top Device Address is LDR100, and the date and time is October 1 2018 12:01:30.
Page 840 2 Line Chart Font: Selects the font for text used in labels from the following. Japanese, European, Chinese, Taiwanese, Korean, Central European, Baltic, Cyrillic Can only be set when the Use Text Manager check box is cleared. The characters that can be displayed depend on the font. For details, refer to Chapter 2 “1.2 Available Text”...
Page 841 2 Line Chart Y-Axis Tab ● Number of Axes ■ Specifies the number of Y-axis (1 to 4 Example: Display sample when Number of Axes is configured to 4 Y-axis Y-axis Y-axis Y-axis (No. 3) (No. 1) (No. 2) (No. 4) 50000 40000 30000...
Page 842 2 Line Chart Data Format ■ Data Type: Selects the data type handled by the chart from the following. UBIN16(W), BIN16(I), UBIN32(D), BIN32(L), BCD4(B), BCD8(EB), Float32(F) For details, refer to Chapter 2 “1.1 Available Data” on page 2-1. Minimum, Maximum: Specifies the minimum and maximum for the chart. (Data Type): Selects the data type to use for the minimum and the maximum.
Page 843 2 Line Chart Data No.: Out of the data contained in the selected Data Log channel number, specifies the data number to display on the chart (1 to 128). Double clicking the cell allows you to edit the data number. Line Type: Selects the type of line from the following.
Page 844 2 Line Chart Data ■ Reference Device Address: Specifies the start address number of the data to display on the chart. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. The data size for the device addresses is 16 bits.
Page 845 2 Line Chart Line Size: Specifies the line size. You can also specify it using the value of device address. Value: Selects the line size from the following. 1 dot, 2 dots, 3 dots, 5 dots Device Address: Specifies the line size using the value of device address. Click to display the Tag Editor.
Page 846 2 Line Chart Scale Tab ■ Show Ticks: Select this check box to display a scale on a chart. Major Divisions: Enter the number of major scale divisions (1 to 20). Minor Divisions: Enter the number of minor scale divisions (1 to 20). Color: Selects the color of scales (color: 256 colors, monochrome: 16 shades).
Page 847 2 Line Chart Show Gridline: Select this check box to display grid lines on the chart. The grid lines are displayed on the chart. Can only be set when the Show Ticks check box is selected. Display Position: Select from Scale and Data Over to specify the grid line display position. Scale: Grid lines are displayed according to the number of major scale divisions.
Page 848 2 Line Chart Label Tab ■ Show Label: Select this check box to display a label on Y-axis scales. Use Text Manager: Select this check box if using the text registered in Text Manager for labels. Can only be set when the Show Label check box is selected. If a carriage return (CR) is included in the character displayed on the label, the characters after the CR are not displayed.
Page 849 2 Line Chart Date and Time (Cursor) Tab ● The Date and Time (Cursor) tab is only displayed when Log Trend (Normal) or Log Trend (Pen Recorder) is selected for Chart Type on the General tab and the Display cursor check box on the X-Axis tab is selected. Cursor Display Position ■...
Page 850 2 Line Chart Cursor Position data ■ Store numerical data: To store the numerical data at the position indicated by the cursor in internal devices, select this check box and specify the destination word device. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings”...
Page 851 2 Line Chart Show date and time data at the cursor position ■ To show the date and time data at the position indicated by the cursor, select this check box and specify the font and display type. Font: Configures the format to display the date and time data. Font: Selects the font for displayed characters from the following.
Page 852 2 Line Chart Trigger Condition Tab ● The Trigger Condition tab is displayed in Advanced mode. The line chart is enabled while the condition is satisfied, and it is disabled while the condition is not satisfied. When disabled, the plate and flange are displayed, but the chart is not displayed. Example: When Trigger Type is While ON and Device Address is LM0 While LM0 is 0, the condition is not satisfied and the line chart is not displayed.
Page 853 2 Line Chart While ON: Enables the line chart when the value of device address is 1. Value of device address Chart state Hide chart Show chart Hide chart Show chart Show chart Show chart Hide chart While OFF: Enables the line chart when the value of device address is 0. Value of device address Chart state...
Page 854 2 Line Chart Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 855 2 Line Chart Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 856 2 Line Chart Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 857 2 Line Chart Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 858: Pie Chart
3 Pie Chart Pie Chart HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 3.1 How the Pie Chart is Used The stacked bar chart and pie chart are used to show the proportion of individual data to the sum of the data. They can be used to check the relative change in multiple values of device addresses in real-time.
Page 859: Pie Chart Configuration Procedure
3 Pie Chart 3.2 Pie Chart Configuration Procedure This section describes the configuration procedure for pie charts. On the Home tab, in the Parts group, click Charts, and then click Pie Chart. Click a point on the edit screen where you wish to place the Pie Chart. Double-click the dropped Pie Chart and a Properties dialog box will be displayed.
Page 860: Properties Of Pie Chart Dialog Box
3 Pie Chart 3.3 Properties of Pie Chart Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Chart Type ■...
Page 861 3 Pie Chart Pie: Shows the proportion of the sum of the data as a pie chart. Example: When displaying the values for three device addresses Ch1 data Ch2 data Ch3 data Pie chart display Propor on 1 : 1 : 1 2 : 2 : 1 4 : 2 : 1 30 : 5 : 1...
Page 862 3 Pie Chart Remove ■ Deletes the registered settings from the list. ■ Shifts the selected settings upward in the list. Down ■ Shifts the selected settings downward in the list. WindO/I-NV4 User’s Manual 11-56...
Page 863 3 Pie Chart View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. None: The plate and the flange of the part are not displayed. Browse ■...
Page 864 3 Pie Chart Size ■ W, H: Sets width and height to define the size of parts. W: 5 to (base screen horizontal size) H: 5 to (base screen vertical size) Width Screen Height Parts WindO/I-NV4 User’s Manual 11-58...
Page 865 3 Pie Chart Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 866 3 Pie Chart Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box.
Page 867 3 Pie Chart Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 868 3 Pie Chart Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 869: Meter
4 Meter Meter HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 4.1 How the Meter is Used The meter displays the value of a word device as the movement of a needle. • Display the value of a word device in a meter MICRO/I External device D100 :...
Page 870: Meter Configuration Procedure
4 Meter 4.2 Meter Configuration Procedure This section describes the configuration procedure for meters. On the Home tab, in the Parts group, click Charts, and then click Meter. Click a point on the edit screen where you wish to place the Meter. Double-click the dropped Meter and a Properties dialog box will be displayed.
Page 871: Properties Of Meter Dialog Box
4 Meter 4.3 Properties of Meter Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Meter Type ■ Select the type of meter from the following items.
Page 872 4 Meter Data Format ■ Data Type: Selects the data type handled by the meter from the following. UBIN16(W), BIN16(I), UBIN32(D), BIN32(L), BCD4(B), BCD8(EB), Float32(F) For details, refer to Chapter 2 “1.1 Available Data” on page 2-1. Minimum, Maximum: Specifies the minimum and maximum for the data. (Data Type): Selects the data type to use for the minimum and the maximum.
Page 873 4 Meter View Tab ● Image Type ■ Select the type of graphic to be used to represent the part. Standard: Uses the default graphic for WindO/I-NV4. Picture: Uses an image file saved using Picture Manager. For details about image file restrictions, refer to Chapter 2 “1.4 Available Image Files” on page 2-20. None: The plate and the flange of the part are not displayed.
Page 874 4 Meter Coordinates ■ X, Y: Sets the display position of parts using coordinates. The X and Y coordinates of parts are defined relative to an origin at the top-left corner of the screen. 0 to (base screen horizontal size - 1) 0 to (base screen vertical size - 1) (0, 0) Screen...
Page 875 4 Meter Range Tab ● The Range tab is only displayed in Advanced mode. Show Range ■ Select this check box to show ranges on the meter and configure the number of ranges, range colors, and limits. Ranges can only be configured when Standard or None is selected under Image Type on the View tab. Number of Ranges: Specifies the number of ranges (1 to 5).
Page 876 4 Meter Scale Tab ● The Scale tab is displayed in Advanced mode. Show Ticks ■ Select this check box to display a scale on a or meter. Scales can only be configured when Standard or None is selected under Image Type on the View tab. Major Divisions: Enter the number of major scale divisions (1 to 20).
Page 877 4 Meter Options Tab ● The Options tab is displayed in Advanced mode. Place on the Top Layer ■ Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and parts are overlapping with it.
Page 878 4 Meter Security Tab ● This tab is used to restrict displaying and using the part by security groups. This option can only be set when Use Security functions is selected. The Use Security functions check box is set on General tab in the Security dialog box. (Settings) (Settings) ■...
Page 879 4 Meter Example: If the user and security group for a part are set as follows: User Name User1 User2 Security Group Reader Operator MICRO/I Numerical Display No. Group Name Display Administrator Permitted Operator Permitted Reader Permitted Line Chart and Bar Chart Button No.
Page 880 4 Meter Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 881: Chapter 12 Commands
Commands Chapter 12 This chapter describes how to setup commands and their operation on the MICRO/I. Bit Write Command HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 How the Bit Write Command is Used Writes a 0 or 1 to a bit device. MICRO/I External device Not satisfied...
Page 882 1 Bit Write Command Toggle ■ Toggles the value of the specified bit device when the trigger condition is Not satisfied Not satisfied Not satisfied Satisfied Satisfied Satisfied Not satisfied Not satisfied Not satisfied Satisfied Satisfied Satisfied satisfied. State of condition If the value of the bit device is 0 it Condition Condition...
Page 883: Bit Write Command Configuration Procedure
1 Bit Write Command 1.2 Bit Write Command Configuration Procedure This section describes the configuration procedure for the Bit Write Command. On the Home tab, in the Parts group, click Commands, and then click Bit Write Command. Click a point on the edit screen where you wish to place the Bit Write Command. Double-click the dropped Bit Write Command and a Properties dialog box will be displayed.
Page 884: Properties Of Bit Write Command Dialog Box
1 Bit Write Command 1.3 Properties of Bit Write Command Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Action Mode ■...
Page 885 1 Bit Write Command Toggle: Toggles the value of the specified bit device when the trigger condition is satisfied. If the value of the bit device is 0 it changes to 1, and vice versa. Not satisfied Not satisfied Not satisfied Satisfied Satisfied Satisfied...
Page 886 1 Bit Write Command Trigger Condition Tab ● When the condition has been or is satisfied, the command is executed; when not satisfied, the command is not executed. Example: When Trigger Type is Rising-edge and Device Address is LM0 The command is executed when LM0 changes from 0 to 1. MICRO/I LM0 : Condition...
Page 887 1 Bit Write Command Satisfy the condition: Command is executed when condition changes from not satisfied to satisfied. Satisfied Condition Not satisfied Action Execution Execution Execution While satisfying the condition: The command continues being executed while the condition is satisfied. Satisfied Condition Not satisfied...
Page 888 1 Bit Write Command Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 889: Word Write Command
2 Word Write Command Word Write Command HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 2.1 How the Word Write Command is Used Writes a value to a word device. Can be used to indirectly specify the destination address number or to perform operations on the written value.
Page 890 2 Word Write Command ■ Writes a fixed value to a word device when the trigger condition is satisfied. Not satisfied Not satisfied Not satisfied Satisfied Satisfied Satisfied Not satisfied Not satisfied Not satisfied Satisfied Satisfied Satisfied State of condition Condition Condition Condition...
Page 891: Word Write Command Configuration Procedure
2 Word Write Command 2.2 Word Write Command Configuration Procedure This section describes the configuration procedure for the Word Write Command. On the Home tab, in the Parts group, click Commands, and then click Word Write Command. Click a point on the edit screen where you wish to place the Word Write Command. Double-click the dropped Word Write Command and a Properties dialog box will be displayed.
Page 892: Properties Of Word Write Command Dialog Box
2 Word Write Command 2.3 Properties of Word Write Command Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Action Mode ■...
Page 893 2 Word Write Command Add, Sub, Multi, Div, Mod, OR, AND, XOR: Performs arithmetic on the value in a reference device address and a fixed value, or the value at a device address and writes the result to a word device when the trigger condition is satisfied. Not satisfied Not satisfied Not satisfied...
Page 894 2 Word Write Command Device Address: Use a value of device address. Specify the device address. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. Use Reference Device Address : Select this check box and specify a device address to change the source word device according to the value of the specified device address.
Page 895 2 Word Write Command Trigger Condition Tab ● When the condition has been or is satisfied, the command is executed; when not satisfied, the command is not executed. Example: When Trigger Type is Rising-edge and Device Address is LM0 The command is executed when LM0 changes from 0 to 1. MICRO/I LM0 : Condition...
Page 896 2 Word Write Command Satisfy the condition: Command is executed when condition changes from not satisfied to satisfied. Satisfied Condition Not satisfied Action Execution Execution Execution While satisfying the condition: The command continues being executed while the condition is satisfied. Satisfied Condition Not satisfied...
Page 897 2 Word Write Command Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 898: Goto Screen Command
3 Goto Screen Command Goto Screen Command HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 3.1 How the Goto Screen Command is Used Switches to another screen or displays a window. • Switches between Base Screens when the trigger condition is satisfied. MICRO/I Satisfied Satisfied...
Page 899: Goto Screen Command Configuration Procedure
3 Goto Screen Command 3.2 Goto Screen Command Configuration Procedure This section describes the configuration procedure for the Goto Screen Command. On the Home tab, in the Parts group, click Commands, and then click Goto Screen Command. Click a point on the edit screen where you wish to place the Goto Screen Command. Double-click the dropped Goto Screen Command and a Properties dialog box will be displayed.
Page 900: Properties Of Goto Screen Command Dialog Box
3 Goto Screen Command 3.3 Properties of Goto Screen Command Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Action Mode ■...
Page 901 3 Goto Screen Command Open File Screen for movie files Opens the File Screen. For details, refer to Chapter 10 “4.4 File Screen” on page 10-92. Close File Screen for movie files Closes the File Screen. For details, refer to Chapter 10 “4.4 File Screen” on page 10- Switch to System Mode: Switches to the Top Page in the System Mode.
Page 902 3 Goto Screen Command Trigger Condition Tab ● When the condition has been or is satisfied, the command is executed; when not satisfied, the command is not executed. Example: When Trigger Type is Rising-edge and Device Address is LM0 The command is executed when LM0 changes from 0 to 1. MICRO/I LM0 : Condition...
Page 903 3 Goto Screen Command Satisfy the condition: Command is executed when condition changes from not satisfied to satisfied. Satisfied Condition Not satisfied Action Execution Execution Execution While satisfying the condition: The command continues being executed while the condition is satisfied. Satisfied Condition Not satisfied...
Page 904 3 Goto Screen Command Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 905: Print Command
4 Print Command Print Command HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 4.1 How the Print Command is Used Outputs a screenshot to a printer or an external memory device • Outputs a screenshot of the current screen to the printer when the trigger condition is satisfied. MICRO/I Printer Satisfied...
Page 906: Print Command Configuration Procedure
4 Print Command 4.2 Print Command Configuration Procedure This section describes the configuration procedure for the Print Command. On the Home tab, in the Parts group, click Commands, and then click Print Command. Click a point on the edit screen where you wish to place the Print Command. Double-click the dropped Print Command and a Properties dialog box will be displayed.
Page 907: Properties Of Print Command Dialog Box
4 Print Command 4.3 Properties of Print Command Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Output to ■...
Page 908 4 Print Command • These operations cannot be performed simultaneously. - Outputting to the external memory device using the Print Command - Outputting to the printer using the Print Command - Printing alarm logs • It may take some time to output screenshots when copying files using the USB Autorun function or a Key Button.
Page 909 4 Print Command Trigger Condition Tab ● When the condition has been or is satisfied, the command is executed; when not satisfied, the command is not executed. Example: When Trigger Type is Rising-edge and Device Address is LM0 The command is executed when LM0 changes from 0 to 1. MICRO/I LM0 : Condition...
Page 910 4 Print Command Satisfy the condition: Command is executed when condition changes from not satisfied to satisfied. Satisfied Condition Not satisfied Action Execution Execution Execution While satisfying the condition: The command continues being executed while the condition is satisfied. Satisfied Condition Not satisfied Action...
Page 911 4 Print Command Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 912: Script Command
5 Script Command Script Command HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 5.1 How the Script Command is Used Executes a script when certain conditions are satisfied. Executes Script Satisfied Satisfied Satisfied // Script A Start Condition [D 100] = [D 100] + 1;...
Page 913: Script Command Configuration Procedure
5 Script Command 5.2 Script Command Configuration Procedure This section describes the configuration procedure for Script Commands. On the Home tab, in the Parts group, click Commands, and then click Script Command. Click a point on the edit screen where you wish to place the Script Command. Double-click the dropped Script Command and a Properties dialog box will be displayed.
Page 914: Properties Of Script Command Dialog Box
5 Script Command 5.3 Properties of Script Command Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● (Script) Part Name ■ Enter a name for the part. The maximum number is 20 characters. Script ID ■...
Page 915 5 Script Command Trigger Condition Tab ● When the condition has been or is satisfied, the command is executed; when not satisfied, the command is not executed. Example: When Trigger Type is Rising-edge and Device Address is LM0 The command is executed when LM0 changes from 0 to 1. MICRO/I LM0 : Condition...
Page 916 5 Script Command While satisfying the condition: The command continues being executed while the condition is satisfied. Satisfied Condition Not satisfied Action Execution Execution Execution Execution Execution Fixed Period: Command executes within a fixed time interval. Fixed time interval Fixed time interval Fixed time interval Action Execution...
Page 917 5 Script Command Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 918: Multi-Command
6 Multi-Command Multi-Command HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 6.1 How the Multi-Command is Used Executes multiple commands at once. These commands can be assigned to a Multi-Command. Command Description Bit Write Writes a 0 or 1 to the specified bit device. Writes a value to a word device.
Page 919: Multi-Command Configuration Procedure
6 Multi-Command 6.2 Multi-Command Configuration Procedure This section describes the configuration procedure for Multi-Commands. On the Home tab, in the Parts group, click Commands, and then click Multi-Command. Click a point on the edit screen where you wish to place the Multi-Command. Double-click the dropped Multi-Command and a Properties dialog box will be displayed.
Page 920: Properties Of Multi-Command Dialog Box
6 Multi-Command 6.3 Properties of Multi-Command Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Multi-Functions ■ Add and edit commands to be executed when the trigger condition is satisfied. Function List: Lists the commands to be executed.
Page 921 6 Multi-Command Goto Screen: Switches to another screen or displays a window. For details, refer to “Properties of Goto Screen for Multi-Functions Dialog Box” on page 12-45. Print: Outputs a screenshot to a printer or an external memory device. For details, refer to “Properties of Print for Multi-Functions Dialog Box”...
Page 922 6 Multi-Command Properties of Bit Write for Multi-Functions Dialog Box Sets the Bit Write command for the Multi-Command. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Action Mode ■ Select the action to perform when the trigger condition is satisfied from the following: Set: Writes a 1 to the specified bit device when the trigger condition is satisfied.
Page 923 6 Multi-Command Properties of Word Write for Multi-Functions Dialog Box Sets the Word Write command for the Multi-Command. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Action Mode ■ Select the action to perform when the trigger condition is satisfied from the following: Set: Writes a fixed value to the specified word device when the trigger condition is satisfied.
Page 924 6 Multi-Command Source Data ■ Select the data handled by the operation selected for Action Mode. Value: Use a constant value. Only a Value can be handled if Action Mode is set to Set or Set ON & OFF Data. If Action Mode is set to Set ON &...
Page 925 6 Multi-Command Properties of Goto Screen for Multi-Functions Dialog Box Sets the Goto Screen command for the Multi-Command. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Action Mode ■ Select the action to perform when the trigger condition is met from the following: Back to previous Screen: Switches to the previous screen.
Page 926 6 Multi-Command Goto Screen ■ Screen Number: If Action Mode is set to Switch to Base Screen, specify the Base Screen number to switch to (from 1 to 3000). If Action Mode is set to Open Popup Screen or Close Popup Screen, specify the number of the Popup Screen to open or close (from 1 to 3015).
Page 927 6 Multi-Command Properties of Print for Multi-Functions Dialog Box Sets the Print command for the Multi-Command. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Output to ■ Select where to direct the screenshot to. Printer Outputs the screenshot to the printer connected to the MICRO/I.
Page 928 6 Multi-Command • These operations cannot be performed simultaneously. - Outputting to the external memory device by pressing the Multi-Command. - Outputting to the printer by pressing the Multi-Command. - Printing alarm logs • It may take some time to output screenshots when copying files using the USB Autorun function or a Key Button.
Page 929 6 Multi-Command Properties of Key for Multi-Functions Dialog Box Sets the Key command for the Multi-Command. (Key) Displays settings applicable to the selected key. Command Name ■ Enter a name for the command. The maximum number is 20 characters. Key Type ■...
Page 930 6 Multi-Command Scroll Size ■ Key Buttons Page Up and Page Down scroll the list up and down, respectively. Key Buttons Up and Down move the focus up and down, respectively. This settings specifies the number of pages or lines (1 to 1023 lines) to scroll or move the focus per each press of the button.
Page 931 6 Multi-Command If Upload Project is selected. Destination: Specify where to save the project uploaded from MICRO/I. Select the location: SD Memory Card or USB Flash Drive. Location: Specify the location of the folder where the uploaded project will be saved. The maximum number is 247 characters.
Page 932 6 Multi-Command If Download PLC Program is selected. Source: Select the the external memory device where the PLC program (ZLD Project File) to be transferred is stored: SD Memory Card or USB Flash Drive. Location: Specify the location of the ZLD Project File(.zld). The maximum number is 247 characters. Example: Where “LDR_PROGRAM.ZLD”...
Page 933 6 Multi-Command If Upload PLC Program is selected. Source: Specify the source PLC connected to the MICRO/I. The PLC type is configured in the Project Settings dialog box, on the Communication Driver Network tab. For details, refer to Chapter 4 “3.4 Communication Driver Network Tab”...
Page 934 6 Multi-Command Recording Channel ■ The recording of images starts. Selects Channel 1 or Channel 2 to record a video only (no audio) out of the signals input from the device. This setting is enabled only if Rec. was selected using the Key Browser. •...
Page 935 6 Multi-Command Properties of Script for Multi-Functions Dialog Box Sets the script for the Multi-Command. (Script) Command Name ■ Enter a name for the command. The maximum number is 20 characters. Script ID ■ Specify the script ID (1 to 32000) of the script to operate. Script Manager will open when is clicked.
Page 936 6 Multi-Command Trigger Condition Tab ● When the condition has been or is satisfied, the command is executed; when not satisfied, the command is not executed. Example: When Trigger Type is Rising-edge and Device Address is LM0 The command is executed when LM0 changes from 0 to 1. MICRO/I LM0 : Condition...
Page 937 6 Multi-Command Satisfy the condition: Command is executed when condition changes from not satisfied to satisfied. Satisfied Condition Not satisfied Action Execution Execution Execution While satisfying the condition: The command continues being executed while the condition is satisfied. Satisfied Condition Not satisfied Action Execution...
Page 938 6 Multi-Command Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 939: Timer
7 Timer Timer HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 7.1 How the Timer is Used Starts a countdown when the trigger condition is satisfied, and writes 1 to an internal device (HMI Timer Relay LTC) once the set time has elapsed. MICRO/I Satisfied Satisfied...
Page 940: Timer Configuration Procedure
7 Timer 7.2 Timer Configuration Procedure This section describes the configuration procedure for Timers. On the Home tab, in the Parts group, click Commands, and then click Timer. Click a point on the edit screen where you wish to place the Timer. Double-click the dropped Timer and a Properties dialog box will be displayed.
Page 941: Properties Of Timer Dialog Box
7 Timer 7.3 Properties of Timer Dialog Box This section describes items and buttons in the Properties dialog box. General Tab ● Part Name ■ Enter a name for the part. The maximum number is 20 characters. Timer Address Number ■...
Page 942 7 Timer Trigger Condition Tab ● When the condition has been or is satisfied, the command is executed; when not satisfied, the command is not executed. Example: When Trigger Type is Rising-edge and Device Address is LM0 The command is executed when LM0 changes from 0 to 1. MICRO/I LM0 : Condition...
Page 943 7 Timer Data Type ■ Selects the data type to be handled by the condition formula. Can only be set if While satisfying the condition is selected as Trigger Type. For details, refer to Chapter 2 “1.1 Available Data” on page 2-1. Device Address ■...
Page 944 7 Timer Comment Tab ● The Comment tab is used to specify the parts arranged on the editing screen, and the popup text displayed when the mouse pointer is placed close to No., Name, or Type in the object list. When there are multiple parts of the same shape on the screen, this features makes it possible to distinguish between the parts without displaying the Properties dialog box for each part, by just mousing over the part.
Page 945: Chapter 13 Alarm Log Function
Alarm Log Function Chapter 13 This chapter describes how to configure the Alarm Log function and its operation on the MICRO/I. Overview HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 How the Alarm Log Function is Used The Alarm Log function samples the occurrence of alarms and recovery information by monitoring and evaluating the state of device addresses.
Page 946 1 Overview • Output Alarm Log data to the external memory device External Memory Device MICRO/I SD memory card Output to External memory device USB flash drive Alarm Log data (CSV) • Output Alarm Log data to the printer MICRO/I Printer Output to printer HG5G-V HG4G-V HG3G-V HG2G-V...
Page 947: Alarm States
1 Overview 1.2 Alarm States Alarms have three states: occurred, recovered, and confirmed. Alarm state Details Indicates that an alarm has occurred. There are two types of alarms that occur. Occurred First Alarm: The first alarm that occurs in a state where no alarms have occurred. Second and later: An alarm that has occurred while another alarm is active.
Page 948: Sampling Data
1 Overview 1.3 Sampling Data Data is sampled each time the alarm occurs, is recovered from, or confirmed. Example: When the message for channel number 1-1 is “Voltage drop” and the message for channel number 1-2 is “Temperature abnormal” Channel No. 1-1: Alarm occurred Message Occurrence Time Recovery Time Confirmation Time...
Page 949: Data Configuration
1 Overview 1.4 Data Configuration The sampled data is composed of the channel number, message, alarm state, time, and label. The relationship between the Alarm Log function settings and the sampled data is as follows. Alarm Log settings 2. Channel No. 3.
Page 950 1 Overview For sampled data, the format for displayed items varies based on the output method. Batch ■ Batch output shows the recovery and confirmation time for an alarm that has occurred on a single line. The labels displayed in the label row are “Ch.No.”, “Message”, “Occurrence Time”, “Recovery Time”, and “Confirmation Time”.
Page 951: Saving And Deleting Data
1 Overview 1.5 Saving and Deleting Data Saving Data ● You can select whether or not to save the sampled data in the data storage area. The method to save data is configured on the Channel tab in the Alarm Log Settings dialog box. When Saving Data to the Data Storage Area Select Store under Data in the Auto-Setup dialog box or in the Individual Settings dialog box.
Page 952 1 Overview Data Storage Amount The maximum amount of data that can be saved in the data storage area is as follows. Model Maximum amount of data that can be saved in the data storage area HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F 11,660 HG2G-5T, HG1G/1P 5,520 When Not Saving Data to the Data Storage Area...
Page 953: Using Data And Detected Alarms
1 Overview 1.6 Using Data and Detected Alarms The saved data and detected alarms can be used in the following ways. Using Saved Data ● The saved data can be used in the following ways. Alarm Log data Ch.No. Message Occurrence Time Recovery Time Conﬁrma on Time...
Page 954: Alarm Log Function Configuration Procedure
2 Alarm Log Function Configuration Procedure Alarm Log Function Configuration Procedure HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes the configuration procedure for the Alarm Log function. 2.1 Configuring the Device Addresses to Monitor and the Alarm Detection Condition On the Configuration tab, in the System Setup group, click Alarm Log.
Page 955 2 Alarm Log Function Configuration Procedure Specify the device address to monitor in Source. Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68. For the Auto-Setup dialog box, the device addresses are sequentially set starting with the specified device address from the highlighted row in Settings.
Page 956 2 Alarm Log Function Configuration Procedure Click OK. The device addresses to monitor and the messages are batch configured and displayed in Settings. Click OK. The Alarm Log Settings dialog box closes. This concludes configuring the device addresses to monitor and the alarm detection condition. Next, configure the functions to execute using saved data and detected alarms.
Page 957: Alarm Log Settings Dialog Box
3 Alarm Log Settings Dialog Box Alarm Log Settings Dialog Box HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes items and buttons on the Alarm Log Settings dialog box. 3.1 Alarm Log Settings Dialog Box General Tab ●...
Page 958 3 Alarm Log Settings Dialog Box Monitoring Period (x 100 msec) ■ Specifies the period to write the state of the monitored device address to the MICRO/I (6 to 500 (100 ms units)). Monitor Number of Active Alarms ■ Select this check box to count the number of active alarms. (Destination Device Address): Specifies a word device to write the number of active alarms.
Page 959 3 Alarm Log Settings Dialog Box Monitor the State of Each Alarm ■ Select this check box to check the alarm state per channel. (Top Device Address): Specifies a word device to write the alarm state. Number of blocks x 16 (number of channels) address numbers are used starting from the set device address.
Page 960 3 Alarm Log Settings Dialog Box Channel Tab ● The Channel tab is used to configure the device addresses to monitor and the alarm detection condition. Source Device Address Type ■ Selects the type of device address to monitor. Word: Uses a word device. Device Addresses are configured per block. Bit: Uses a bit device.
Page 961 3 Alarm Log Settings Dialog Box Settings ■ The Alarm Log settings for each channel are edited here. No.: Displayed as (Block No.)-(Channel No.). Double clicking the cell opens the Individual Settings dialog box. Source: Shows the bit device or the bit number of the word device to monitor. Double clicking the cell opens the Tag Editor.
Page 962 3 Alarm Log Settings Dialog Box Auto-Setup Dialog Box and Individual Settings Dialog Box With the Auto-Setup dialog box, the Alarm Log settings for all channels are batch registered or changed. With the Individual Settings dialog box, the Alarm Log settings for the selected channel are registered or changed. Channel ■...
Page 963 3 Alarm Log Settings Dialog Box Channel Settings ■ The trigger condition for the channel is configured here. Alarm function: Selects whether or not to use the alarm function. Enable: Monitors the state of the device address configured for the channel and samples the alarm information.
Page 964 3 Alarm Log Settings Dialog Box External Memory Device Tab ● The External Memory Device tab is used to configure whether or not to output saved data to the external memory device The output data is stored in the following folder on the external memory device \External Memory Device folder\ALARMLOG The default External Memory Device folder name is “HGDATA01”.
Page 965 ‘ I ’ ‘D’ 4844(Hex) LDR101 ‘E’ ‘C’ 4543(Hex) LDR102 0000(Hex) (NULL) The file name at this time becomes "IDEC.CSV". *1 SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F, USB flash drive for HG2G-5T and HG1G/1P WindO/I-NV4 User’s Manual 13-21...
Page 966 3 Alarm Log Settings Dialog Box Select this check box to add the bottom three digits of Add Device Address data to File Name: the value of the device address configured by (File Name Device Address) to the end of the file name for the output data.
Page 967 3 Alarm Log Settings Dialog Box Real Time ■ Select this check box to output data to the external memory device in real time. External Memory Device SD memory card MICRO/I Alarm Log data Output to Time State Ch.No. Message External memory device USB flash drive 12/01/2011 12:00:05...
Page 968 (NULL) 0000 (Hex) The file name at this time becomes "IDEC.CSV". Add Device Address data to File Name: Select this check box to add the bottom three digits of the value of the device address configured by (File Name Device Address) to the end of the file name for the output data.
Page 969 3 Alarm Log Settings Dialog Box When the Set limit on files check box is selected, note the following points. • If the number of data files saved on the external memory device increases, it may take some time for the data output processing, or the output of the next data may not be processed normally.
Page 970 LDR100 value: 4944 (Hex) Specify File Name by Value of Device LDR100 LDR101 value: 4543 (Hex) Address Text to set is "IDEC" LDR102 value: 0000 (Hex) Add value of Device Address to File (File Name Device Address) is LDR200 value: 123...
Page 971 3 Alarm Log Settings Dialog Box Printing Tab ● HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P The Printing tab is used to configure whether or not to output saved data to the printer. Batch ■ Select this check box to batch output all the sampled data to the printer. MICRO/I Printer Output to printer...
Page 972 3 Alarm Log Settings Dialog Box Print with Second: Select this check box to print the time including seconds. Paper Feed Direction: Selects the paper feed direction as either Vertical or Horizontal. Vertical: Horizontal: • For A4 size paper, up to 40 items of Alarm Log data are printed on a single sheet. •...
Page 973 3 Alarm Log Settings Dialog Box Options Tab ● The Options tab is used to configure whether or not the MICRO/I’s internal buzzer operates and the screen flashing. Trigger Buzzer when Alarm occurs ■ Select this check box to sound a beep when an alarm has occurred. Screen flashing when Alarm occurs ■...
Page 974 3 Alarm Log Settings Dialog Box • While the beep is sounding, System Area 1 (address number+1, bit 6) is 1. • While the screen is flashing, System Area 1 (address number+1, bit 2) is 1. • To stop the sound of the buzzer and the screen flashing when an alarm has occurred, use the following methods.
Page 975: Using Data And Detected Alarms
4 Using Data and Detected Alarms Using Data and Detected Alarms HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 4.1 Displaying Saved Data with the Alarm Log Display On the Configuration tab, in the System Setup group, click Alarm Log. The Alarm Log Settings dialog box is displayed.
Page 976 4 Using Data and Detected Alarms Select Enable under Alarm function, configure NO/NC and Lock/Unlock, and click OK. You are returned to the Alarm Log Settings dialog box. Repeat steps through to register all the channels. Click OK. The Alarm Log Settings dialog box closes. On the Home tab, in the Parts group, click Data Displays, and then click Alarm Log Display.
Page 977: Displaying Registered Messages With The Alarm List Display According To The Active Alarm
4 Using Data and Detected Alarms Displaying Registered Messages with the Alarm List Display According to the Active Alarm On the Configuration tab, in the System Setup group, click Alarm Log. The Alarm Log Settings dialog box is displayed. Select the type of device address to monitor under Source Device Address Type on the Channel tab and specify Number of Blocks.
Page 978 4 Using Data and Detected Alarms Specify the device address to monitor in Source and select No Store under Data. Select Enable under Alarm function and configure NO/NC and Lock/Unlock. Select the Text ID check box and click Text Manager opens. Double click the (Text) and enter the message.
Page 979 4 Using Data and Detected Alarms Click OK. The registered message is displayed in Settings. Repeat steps through to register messages for all the channels. The messages to use can be registered in advance in Text Manager. Click OK. The Alarm Log Settings dialog box closes. On the Home tab, in the Parts group, click Data Displays, and then click Alarm List Display.
Page 980 4 Using Data and Detected Alarms On the General tab, under Message Settings, select Use Alarm Log Settings. Configure the other settings and the settings on each tab as necessary. For details, refer to Chapter 10 “7.3 Properties of Alarm List Display Dialog Box” on page 10-138. Click OK.
Page 981: Make A Sound Of The Buzzer And Flash The Screen When An Alarm Has Occurred
4 Using Data and Detected Alarms 4.3 Make a Sound of the Buzzer and Flash the Screen when an Alarm has Occurred On the Configuration tab, in the System Setup group, click Alarm Log. The Alarm Log Settings dialog box is displayed. Select the type of device address to monitor under Source Device Address Type on the Channel tab and specify Number of Blocks.
Page 982 4 Using Data and Detected Alarms Click the Options tab in the Alarm Log Settings dialog box. Select the Trigger Buzzer when Alarm occurs check box to make a sound of the buzzer when an alarm has occurred. Select the Screen flashing when Alarm occurs check box to have the screen flashing when an alarm has occurred.
Page 983: Saving The Data As A Csv File
4 Using Data and Detected Alarms 4.4 Saving the Data as a CSV File Saving the Data as a CSV File ● The Alarm Log data can be saved to the external memory device as a CSV file or uploaded to a computer. The procedure to save the data is as follows.
Page 984 4 Using Data and Detected Alarms Real Time ■ Real time output displays the alarm state and the time the alarm became that state on a single line each time an alarm occurs, is recovered from, or is confirmed. The data structure of files output with real time output is as follows. Bold items are replaced by the Alarm Log settings, the sampled data, the running project name, and WindO/I-NV4 version number.
Page 985: Chapter 14 Data Log Function
Data Log Function Chapter 14 This chapter describes how to configure the Data Log function and its operation on the MICRO/I. Overview HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P 1.1 How the Data Log Function is Used The Data Log function samples values of device addresses with the MICRO/I using the configured sampling condition and Condition of Writing to Data Storage Area.
Page 986 1 Overview • Copy Data Log data to internal devices Data Log data Sampling Time Data001 01/01/2011 12:00:30 01/01/2011 12:01:30 01/01/2011 12:02:30 MICRO/I 01/01/2011 12:03:30 External device 01/01/2011 12:04:30 01/01/2011 12:05:30 01/01/2011 12:06:30 Copy LDR10 : 126 LDR11 : 125 LDR12 : 124 (Internal device) WindO/I-NV4 User’s Manual...
Page 987: Sampling Values Of Device Addresses
1 Overview 1.2 Sampling Values of Device Addresses The MICRO/I samples values of target device addresses at a regular interval or when a value of device address changes. Sampling Value of Device Addresses at a Regular Interval ● When sampling values of device addresses (D100 to D102) at a 5 minute interval (Time: 300 seconds) with the data storage amount in the data storage area is set to 3, the MICRO/I samples Data Log data as follows.
Page 988 1 Overview Sampling Values of Device Addresses when a Value of Device Address Changes ● If sample values of device addresses (D100 to D102), when the bit device or the bit number of the word device configured as the Condition of Writing to Data Storage Area switches from 0 to 1 and the data storage amount in the data storage area is set to 3, the MICRO/I samples Data Log data as follows.
Page 989: Data Configuration
1 Overview 1.3 Data Configuration The sampled data is composed of the sampling time, values of device addresses, and labels. The relationship between the Data Log function settings and the sampled data is as follows. Data log settings Data No. 1 settings Data No.
Page 990: Saving And Deleting Data
1 Overview 1.4 Saving and Deleting Data Saving Data ● The sampled values of device addresses along with the sampling time are all saved in the data storage area. Data Log data Sampling Time Data001 Data002 Data003 01/01/2011 12:00:00 01/01/2011 12:10:00 MICRO/I 01/01/2011 12:20:00 External device...
Page 991: Using The Data
1 Overview 1.5 Using the Data The saved data can be used in the following ways. Data Log data Sampling Time Data001 Data002 Data003 01/01/2011 12:00:00 01/01/2011 12:10:00 01/01/2011 12:20:00 01/01/2011 12:30:00 01/01/2011 12:40:00 To use with the MICRO/I To use with devices other than the MICRO/I •...
Page 992: Data Log Function Configuration Procedure
2 Data Log Function Configuration Procedure Data Log Function Configuration Procedure HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes the configuration procedure for the Data Log function. 2.1 Configuring the Data Log Function On the Configuration tab, in the System Setup group, click Data Log. The Data Log Settings dialog box is displayed.
Page 993 2 Data Log Function Configuration Procedure On the General tab, under Log function, select Enable. The channel number selected on the Data Log Settings dialog box is displayed in Channel No. Enter the name of the channel in Channel Name. Under Condition of Writing to Data Storage Area, select the condition that will be used to write the values of the sampled device addresses to the data storage area.
Page 994 2 Data Log Function Configuration Procedure Click the Data tab. Under Output Items, select the items that will be output when data is output as CSV. Select the check boxes of the items to output. If the Label check box is selected, enter the label to display in the sampling time column when the data is output as CSV.
Page 995 2 Data Log Function Configuration Procedure In Label, enter the text to display for the label of the data. The label is used for the label row of the data number columns when the data is output as CSV. • When Number of Data is 2 or higher, "Data+Number" is automatically entered. Example: Data001, Data002, Data003 •...
Page 996 2 Data Log Function Configuration Procedure Click OK to close the Individual Settings dialog box. You are returned to the Data Log Settings dialog box. Repeat steps through to register Data Log settings for all of the channel numbers to use. Click OK.
Page 997: Data Log Settings Dialog Box
3 Data Log Settings Dialog Box Data Log Settings Dialog Box HG5G-V HG4G-V HG4G HG3G-V HG3G HG2G-V HG2G-5F HG2G-5T HG1G HG1P This section describes the items and buttons on the Data Log Settings dialog box and the Individual Settings dialog box. 3.1 Data Log Settings Dialog Box All the device addresses to sample values from and their sampling conditions and Condition of Writing to Data Storage Area are collectively managed in the Data Log Settings dialog box.
Page 998 3 Data Log Settings Dialog Box Range: Shows the time in seconds (1 to 9999) to sample data in a fixed interval when Fixed Period is selected in Condition of Writing to Data Storage Area. Double clicking the cell displays the Individual Settings dialog box where you can edit the settings.
Page 999 3 Data Log Settings Dialog Box Sampling Method ■ Sets the method that will be used by the MICRO/I to read the values of device addresses. Always: The values of the device addresses set for the data of each channel are always read. When the condition of writing to the data storage area is satisfied, the values that were read at that point in time are written to the data storage area.
Page 1000: Individual Settings Dialog Box
3 Data Log Settings Dialog Box 3.2 Individual Settings Dialog Box Use the Individual Settings dialog box to register or edit the Data Log settings for the selected channel. Channel Number ■ Shows the channel number selected in Settings in the Data Log Settings dialog box. General Tab ●...

This manual is also suitable for:

Micro/i hg3g-v xt22mf series Micro/i hg3g jt22 f series Micro/i hg2g-v5ft22tf series Micro/i hg2g-5ft22tf series Micro/i hg2g-5t 22tf series Micro/i hg1g-4vt22tf series ... Show all

IDEC MICRO/I HG4G-CJT22 F-B Series User Manual

Chapter 1 System Composition

Chapter 2 Windo/I-NV4 Features & Basic Operations

Chapter 3 Communication

Chapter 4 Project Settings

Chapter 5 Screen

Chapter 6 Drawings and Parts

Chapter 7 Drawings

Chapter 8 Buttons

Chapter 9 Lamps

Chapter 10 Data Displays

Chapter 11 Charts

Chapter 12 Commands

Quick Links

Related Manuals for IDEC MICRO/I HG4G-CJT22 F-B Series

Summary of Contents for IDEC MICRO/I HG4G-CJT22 F-B Series
