Warnings and Alarms

8 Warnings and Alarms

8.1 System Monitoring

The adjustable frequency drive monitors the condition of
its input power, output, and motor factors as well as other
system performance indicators. A warning or alarm may
not necessarily indicate a problem internal to the
adjustable frequency drive itself. In many cases, it indicates
failure conditions from input voltage, motor load or
temperature, external signals, or other areas monitored by
the adjustable frequency drive's internal logic. Be sure to
investigate those areas exterior to the adjustable frequency
drive as indicated in the alarm or warning.

8.2 Warning and Alarm Types

8.2.1 Warnings

A warning is issued when an alarm condition is impending
or when an abnormal operating condition is present and
may result in the adjustable frequency drive issuing an
alarm. A warning clears by itself when the abnormal
condition is removed.

8.2.2 Alarm Trip

An alarm is issued when the adjustable frequency drive is
tripped, that is, the adjustable frequency drive suspends
operation to prevent adjustable frequency drive or system
damage. The motor will coast to a stop. The adjustable
frequency drive logic will continue to operate and monitor
the adjustable frequency drive status. After the fault
condition is remedied, the adjustable frequency drive can
be reset. It will then be ready to start operation again.
A trip can be reset in any of four ways:
•
Press [Reset]
•
Digital reset input command
•
Serial communication reset input command
•
Auto reset
®
VLT Refrigeration Drive Instruction Manual

8.2.3 Alarm Trip Lock

An alarm that causes the adjustable frequency drive to
trip-lock requires that input power be cycled. The motor
will coast to a stop. The adjustable frequency drive logic
will continue to operate and monitor the adjustable
frequency drive status. Remove input power to the
adjustable frequency drive and correct the cause of the
fault, then restore power. This action puts the adjustable
frequency drive into a trip condition as described above
and may be reset in any of those four ways.

8.3 Warning and Alarm Displays

Figure 8.1
An alarm or trip-lock alarm will flash on the display along
with the alarm number.
Figure 8.2
®
