P17 Group Status Viewing - INVT Goodrive10 Series Operation Manual

Goodrive10 Series Mini VFD

P17 group Status viewing

Function
Name
code
Set
P17.00
frequency
Output
P17.01
frequency
Ramp
P17.02 reference
frequency
Output
P17.03
voltage
Output
P17.04
current
Motor
P17.05
speed
Motor
P17.08
power
Output
P17.09
torque
DC bus
P17.11
voltage
Digital
input
P17.12
terminal
state
Digital
output
P17.13
terminal
state
Digital
P17.14
adjustment
Display current set frequency of the VFD.
Range: 0.00Hz–P00.03
Display current output frequency of the VFD.
Range: 0.00Hz–P00.03
Display current ramp reference frequency of the
VFD.
Range: 0.00Hz–P00.03
Display current output voltage of the VFD.
Range: 0–1200V
Display current output current of the VFD.
Range: 0.0–5000.0A
Displays current motor speed.
Range: 0–65535RPM
Displays current motor power; 100% relative to
rated motor power, positive value is motoring
state, negative value is generating state.
Setting range: -300.0%–300.0% (relative to
rated motor power)
Displays current output torque of the VFD; 100%
relative to rated motor torque, positive value is
motoring state, negative value is generating
state.
Range: -250.0–250.0%
Display current DC bus voltage of the VFD
Range: 0.0–2000.0V
Display current digital input terminals state of the
VFD
Range: 0000–00FF
Display current digital output terminals state of
the VFD
Range: 0000–000F
Display the adjustment through the keypad of
the VFD.
Range : 0.00Hz–P00.03
Description
-74-
Function parameters
Default Modify
●
0.00Hz
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0 RPM
●
0.0%
●
0.0%
●
0V
●
0
●
0
●
0.00V
