APPENDIX I Instruction Lists
■ 32-Bit Delayed Branch Macro Instructions
Table I.2-17 32-Bit Delayed Branch Macro Instructions
Mnemonic
*CALL32:D label32,Ri
*BRA32:D label32,Ri
*BEQ32:D label32,Ri
*BNE32:D label32,Ri
*BC32:D label32,Ri
*BNC32:D label32,Ri
*BN32:D label32,Ri
*BP32:D label32,Ri
*BV32:D label32,Ri
*BNV32:D label32,Ri
*BLT32:D label32,Ri
*BGE32:D label32,Ri
*BLE32:D label32,Ri
*BGT32:D label32,Ri
*BLS32:D label32,Ri
*BHI32:D label32,Ri
[Reference 1] CALL32:D
1) If label32-PC-2 is between -0x800 and +0x7fe, create an instruction as shown below:
CALL:D label12
2) If label32-PC-2 is outside the range in 1) or contains an external reference symbol, create an instruction as
shown below:
LDI:32 #label32,Ri
CALL:D @Ri
[Reference 2] BRA32:D
1) If label32-PC-2 is between -0x100 and +0xfe, create an instruction as shown below:
BRA:D label9
2) If label32-PC-2 is outside the range in 1) or contains an external reference symbol, create an instruction as
shown below:
LDI:32 #label32,Ri
JMP:D @Ri
[Reference 3] Bcc32:D
1) If label32-PC-2 is between -0x100 and +0xfe, create an instruction as shown below:
Bcc:D label9
2) If label32-PC-2 is outside the range in 1) or contains an external reference symbol, create an instruction as
shown below:
Bxcc false
LDI:32 #label32,Ri
JMP:D @Ri32
false:
718
Operation
Address of the next instruction
→
label20 PC
→
label32 PC
if(Z==1) then label20
s/Z==0
s/C==1
s/C==0
s/N==1
s/N==0
s/V==1
s/V==0
s/V xor N==1
s/V xor N==0
s/(V xor N) or Z==1
s/(V xor N) or Z==0
s/C or Z==1
s/C or Z==0
xcc is the opposite condition of cc.
→
RP, Ri: Temporary register (See Reference 1)
Ri: Temporary register (See Reference 2)
→
PC Ri: Temporary register (See Reference 3)
Remarks
